Bonnet #
ITW # Description
144937 00-977002
1 way solenoid valve, 1 x 10 L/min
145587 00-977003
Drive shaft gasket + wear ring
147792 00-977004
3 way solenoid valve, 2 x 10 L/min + 1 x 5 L/min
166754 00-977005
Heating element after sales kit
300676 00-977006
Reed switch
300698 00-977007
Three-pole 25A 230V 50/60 Hz contactor
300769 00-977008
Anti-interference relay filter
300787 00-977009
Ultra fast fuse 0.2A 250V 5 x 20
300788 00-977010
Fuse 5 x 20 10 Amps
300789 00-977011
1A Temporized fuse
300790 00-977012
Fuse 2 Amps
300791 00-977013
Fuse 0.25 Amps temporized
300793 00-977014
Fuse 10A 10.3x38.1 class cc
301066 00-977015
Safety thermostat
301485 00-977016
1 point regulation probe, PT 100
304295 00-977017
Motor
304296 00-977018
Capacitor 12.5μf
304297 00-977019
Axial fan
305110 00-977020
Reducing gear with centre return spring, 85 degrees
308350 00-977021
Lighting transformer BT 230V 50HZ 12V
308491 00-977022
Transformer
308492 00-977023
Transformer 230V/24V
309407 00-977024
Fuse 3.15 Amps
309634 00-977025
FASTPAD screen card
309638 00-977026
LED strip
309644 00-977027
Coder
309663 00-977028
Output control card
314374 00-977029
Flow meter FHKC56
314379 00-977030
Pump kit
314380 00-977031
Inlet/outlet 1 way solenoid valve, 10 L/min
366461 00-977032
Heating element gasket
366572 00-977033
Door stop
384183 00-977034
Door closure mechanism
384677 00-977035
Door catch sub assembly
VulcanMINIJETSparePartsList
F37518 04/2017
384677
4
309644
309634
366572
309638
4
384183
4
309698
300769
301066
300788
309663
4
300789
309407
309407
300787
300789
300790
300791
304296
304297
301485
300676
308491
308492
308350
300793
314379
314374
147792
144937
314380
145587
304295
366461
166754
305110
