Technical Specification__Audience 42 C
Technical Specification__Audience 42 C
Sensitivity (2.83 V/1 m): 85 dB
Recommended Amp. Power: Small size rooms: >30 watts
Medium size rooms: >80 watts
Large size rooms: -- watts
IEC Long Term Power Handling: 150 watts
Impedance, Nominal: 4 ohms
Impedance, (20-200 Hz): 3.7 - 9.6 ohms
Impedance, (200-20 kHz): 3.7 - 19 ohms
Impedance, Phase Shift (20-200 Hz): -27° - +26°
Impedance, Phase Shift (200-20 kHz): -16° - +46°
Impedance, HF (200 kHz): 15 ohms
Frequency Response (+/- 3 dB): 55 Hz - 27 kHz
Resonance Frequency: 56 Hz
Internal Cabinet Volume: 6.1 litres
Bass Principle: Bass reflex
Weight: 5.5 kg
Dimensions (W x H x L): 370 x 165 x 200 mm
Crossover: 2 way.
The crossover is impedance corrected
Crossover Frequencies: 1800 Hz
Crossover Slope: Woofer 6 dB/oct; Tweeter 6 dB/oct
Connection: CE compliant insulated gold binding posts
Recommended Placing: Above/below TV-set, or on a stand
Remarks: Tweeter: 28 mm soft dome.
Magnetic fluid.
Pure aluminium wire voice coil.
Rear chamber.
Woofer: 15 cm polypropylene cone.
75 mm pure aluminium wire voice coil.
Cabinet: Front baffle 22 mm MDF.
Port plugs included.
Macnetic shielded.
