RADIANT HEATER
11” | 1500 � 1250W
MODEL 1VAHW11
OWNER’S MANUAL
2 3
CONTENTSCONTENTS
(Continued)
Safety Information .............................................................................................4-6
In The Box ...............................................................................................................7
Product Diagram ................................................................................................ 7-8
Instructions For Assembly .....................................................................................9
Instructions For Use ............................................................................................10
Maintenance .........................................................................................................11
IMPORTANT NOTE:
Read the manual carefully. Make sure to save this manual for future reference.
Illustrations in this manual are for explanatory purposes only, your actual
product may look slightly dierent.
CONSUMER PRODUCT INFORMATION
For your own records, please attach a copy of your sales receipt to this manual.
Also, write the store name/location and date purchased below:
Store Name: ___________________________________________________________
Location: ______________________________________________________________
Date Purchased: _______________________________________________________
TECHNICAL DATA
Model: 1VAHW11
Voltage: 120V~ / 125 Amps
Watts: 1250 / 1500W
4 5
SAFETY GUIDELINES
WARNING: Read and understand this entire owner’s manual, including
all safety information, before plugging in or using this product. Failure to do so
could result in re, electric shock, or serious personal injury.
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to
reduce the risk of re, electric shock and injury to persons, including the following:
1. Read all the instructions before using this unit.
2. CAUTION: Risk of Electric Shock. DO NOT open or try to repair the heater
yourself.
3. This heater may get hot when in use. To avoid burns, DO NOT let bare skin
touch hot surfaces. If provided, use handle(s) when moving this heater. DO
NOT place it against walls, furniture, curtains, etc.
4. The output of this heater may vary and its temperature may become
intense enough to burn exposed skin. Use of this heater is not
recommended for persons with reduced sensitivity to heat or an inability
to react to avoid burns.
5. Keep combustible materials, such as furniture, pillows, bedding, paper,
clothes, and curtains at least 3 ft from the front of the heater and keep
them away from the sides, top, and rear. DO NOT place towels or other
objects on the heater.
6. Extreme caution is necessary when any heater is used. DO NOT leave
invalids or children unattended with an operating heater. DO NOT leave
heaters unattended when in use.
7. Always unplug heater when not in use.
8. DO NOT operate any heater with a damaged cord or after the heater
malfunctions, has been dropped, or damaged in any manner. Discard
damaged heater or return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
9. This heater is not intended for use in bathrooms, laundry areas, showers
or swimming pools and similar locations. NEVER locate heater where
it may fall into a bathtub or other water container. To protect against
electrical hazards, DO NOT immerse in water or other liquids.
SAFETY GUIDELINES
10. DO NOT touch the control panel or plug with a wet hand.
11. DO NOT run cord under carpeting. DO NOT cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trac area and where it will not be
tripped over.
12. DO NOT insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or re or damage the heater.
13. To prevent a possible re, DO NOT block the air intakes or exhaust in any
manner. DO NOT use on soft surfaces, like a bed, where openings may
become blocked.
14. A heater has hot and arcing or sparking parts inside. DO NOT use in areas
where gasoline, paint, explosive and/or ammable liquids are used or
stored. Keep unit away from heated surfaces and open ames.
15. To avoid re or shock hazard, plug the unit directly into a 120V AC
electrical outlet.
16. To prevent overloading a circuit, do not plug the heater into a circuit that
already has other appliances working.
17. It is normal for the plug to feel warm to the touch; however, a loose t
between the AC outlet (receptacle) and plug may cause overheating and
distortion of the plug. Contact a qualied electrician to replace loose or
worn outlet.
18. To disconnect heater, turn controls to OFF, then remove plug from outlet.
Pull rmly on the plug, DO NOT unplug by pulling on the cord.
19. Always unplug the unit before moving or cleaning, or whenever the heater is
not in use.
20. Use only for intended household use as described in this manual. Any other
use not recommended by the manufacturer may cause re, electric shock,
or injury to persons. The use of attachments not recommended or sold by
unauthorized dealers may cause hazards.
21. Always use on a dry, level surface. Use on oor only.
22. DO NOT use outdoors.
23. WARNING: To reduce the risk of re or electric shock, DO NOT use this unit
with any solid-state speed control device.
(Continued)
6 7
HEADLINE
(Continued)
FRONT
Base Feet
Control Panel
PRODUCT DIAGRAM
SAFETY GUIDELINES
IN THE BOX
• Infrared Radiant Heater
• Owner’s Manual
• Base Feet
• Screws (4 Pcs.) Screws are pre-assembled inthe bottom of the unit
PRODUCT DIAGRAM
24. DO NOT attempt to repair or adjust any electrical or mechanical functions
on this unit. Doing so will void your warranty. The inside of the unit contains
no user service able parts.
25. Always use the product in an upright position.
26. This heater cannot achieve accurate temperature control of the
environment, and thus cannot be used as insulation device for storage
environment, items, animals and plants.
27. Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause re, electric shock, or injury
to persons.
CAUTION: Always plug heaters directly into a wall outlet. Never use with
an extension cord or power strip.
TIP-OVER SAFETY FEATURE
This heater is equipped with a shut-o safety feature. Once the heater is tipped
over, an internal switch will automatically shut the heater o. Once the heater is
restored to an upright position, the heater will reset.
OVERHEAT SAFETY FEATURE
This heater is equipped with an overheat safety feature. When
the heater’s internal components reach a certain temperature that could cause
overheating and possible re, the heater will automatically shut o.
• A thermal overload protector is built in to prevent overheating. When an
“overheat” temperature is reached, the heater will automatically shut o.
Operation can resume only when the user resets the unit.
• To reset the unit, unplug the heater, ensure the power is turned o, and
wait 15 to 20 minutes for the unit to cool down.
• Follow OPERATING INSTRUCTIONS to return heater to operating mode.
WARNING: It is normal for the power cord to feel warm to the touch;
however, a loose t between the outlet and the plug may cause overheating of
the plug. If this occurs, try inserting the plug into a dierent outlet. Contact a
qualied electrician to inspect the original outlet for damage.
(Continued)
Hot Air Outlet
Control
Panel
Base Feet
Carry
Handle
FRONT
BACK
Air
Intake
8 9
(Continued) INSTRUCTIONS FOR ASSEMBLYPRODUCT DIAGRAM
CONTROL PANEL
Power Indicator Light
ON/OFF Switch
Power Level
Thermostat
Control
Alarm Indicator Light
To complete assembly, please follow these steps in order:
1. Place heater upside down.
2. Ensure Front of Heater and Front of Legs are in correct position. (Fig. 1)
3. Insert Base Feet into notches on bottom of heater. Slide toward front of heater
until secure. (Fig. 2)
4. Use 2 screws to secure each leg. Ensure they are tightened securely. (Fig. 3)
NOTE: The heater cannot be operated without the feet attached. It is essential to
ensure that the feet are securely fastened to the unit before turning it on.
Front
of Leg
Base Feet
Protrusions
Base Feet
Notches
Back
of Leg
Heater Front
Fig. 1 Fig. 2
Fig. 3
Slide to Front
Base Feet
Notches
Front
of Leg
Back
of Leg
Base Feet
Protrusions
10 11
MAINTENANCEINSTRUCTIONS FOR USE
1. Place the product on arm, level surface, only in the upright position.
2. With the power in the OFF position, plug the unit directly into a 120V AC
electrical outlet.
3. Turn ON the power switch at the front of the product.
STARTING UNIT AND SELECTING HEAT MODE
SWITCH ON PANEL FUNCTION
Turn the heater ON by pressing the HEAT ON/OFF button.
Turn the heater OFF by pressing the HEAT ON/OFF button.
Press the Mode button to toggle between the heat modes.
HIGH Mode (1500W) LOW Mode (1250W)
SELECTING DESIRED TEMPERATURE
SWITCH ON PANEL FUNCTION
a. To lower temperature, rotate the Knob counter-
clockwise toward the “LOW” position.
b. To raise temperature, rotate the knob clockwise
toward the “HIGH” position.
NOTICE: When the heat function is used for the rst time, a slight odor
may be present. This is normal and should not occur again unless the heater
is not used for an extended period of time.
NOTICE: Do not plug the heater into a circuit that is servicing other
electrical needs.
NOTE: After room has reached the desired temperature, slowly rotate
the temperature knob counter-clockwise until the heater shuts o (you
should hear a faint “click”). By leaving the thermostat at this setting it will
automatically maintain this temperature.
1. Turn the POWER OFF.
2. Unplug the unit and let it cool completely.
3. To keep the heater clean, the outer shell may be cleaned with a soft,
damp cloth. You may use a mild detergent if necessary.
4. After cleaning, dry the unit with a soft cloth.
5. Wait until the unit is completely dry before use.
WARNING
• DO NOT let liquid enter the heater.
• DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough
brushes to clean the heater. This may cause damage or deterio ration to the
surface of the heater.
• DO NOT immerse the heater in water.
• DO NOT operate the heater without the gril in place.
• DO NOT
use the heater if it has malfunctioned or become damaged in any way.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt
build-up, use the original packaging to repack the unit.
TROUBLESHOOTING
If the heater will not operate, please check the following:
1. Check if the power cord is plugged into an electrical outlet.
If not, plug in to appropriate outlet.
2. Check if electricity to the outlet is working.
3. Ensure power is turned to ON position.
4. Make sure heater is placed on a at solid surface.
5. See SAFETY FEATURES section for additional information.
NOTICE:
The product is equipped with an overheat safety feature protector
which will switch o the heater in case of accidental over heating (ex.
Obstruction of air intake and outlet grills, motor turning slowly or not at all).
833-950-1185 | support@visionairproducts.com
www.visionairproducts.com
4560 W. 160th Street
Cleveland, OH 44135
Printed in China | 0423_M029
