Hui Zhou Gaoshengda Technology Co., LTD
NS-RCFCA-21
PAGE 1
Version 1.0
Remote control
Model Number: NS-RCFCA-21
Product Descrition
The NS-RCFCA-21 is a BLE5.0 remote control. This remote control is applied to control the TV device.
Remote control with Bluetooth voice control, also has the function of infrared remote control, The
RCU use 2xAAA batteries as power supply.
Bluetooth pairing: Press and hold the "Home" for 9 seconds.
Product Features
◆ Complies with BLE5.0
◆ Supports 1M bandwidth
◆ Low power consumption.
◆ Easy to install and configure.
◆ ROHS compliant
Product Specification
Model
NS-RCFCA-21
Product Name
Remote control
Standard
BLE5.0
Power supply
2 AAA batteries
Modulation Method
GFSK
Frequency Band
2402~2480 MHz
Operating Voltage
DC 3V
Current Consumption
＜15mA
Antenna Type
PCB
Operating
Temperature
-10 ~ 60°C ambient temperature
Storage Temperature
-40 ~ 80°C ambient temperature
Humidity
5 to 95 % maximum (non-condensing)
NOTICE:
◆Do not splash water or other liquid onto this product, otherwise it may cause damage;
◆Do not put this product near the heat source or direct sunlight, otherwise it may cause
deformation or malfunction;
◆please keep this product away from flammable or naked flame;
Hui Zhou Gaoshengda Technology Co., LTD NS-RCFCA-21
PAGE 2
Version 1.0
Statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences et
Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes :
1)L'appareil ne doit pas produire de brouillage;
2)L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
