TemPolor Melo-D Generative AI Guitar
Product User Manual
Catalogue
Specifications
Important Safety Notes
TemPolor Warranty Service Certificate
FCC Warning
Warranty Card
08
09-10
11-12
13
14
In the Box
1. TemPolor Melo-D Smart Guitar
2. Type-C Charging Cable
3. User Manual
4. Guitar Strap
5. Quick Start Guide
6. Gig Bag
1
6
01
2
3
4
5
In the box
Get to Know Your TemPolor Melo-D
Folding, Unfolding TemPolor Melo-D & Attaching Strap
Melo-D Smart Guitar Section Introduction
Play a Chord Right Away
One-Man Band: Using the Drum Machine
01
02
03
04-05
06
07
Get to Know Your
TemPolor Melo-D
Support
Handle
I/O Ports
Power On/Off and
Volume Control
Type-C
Charging Port
SpeakerFoldable
Touch Screen
Indicator
Light Strip
OTG / Mobile Recording
and Output Interface
Microphone
Jack
Headphone
Jack
Playing Area
Rainbow Strings Magnetic Picks
Chord Pad
Capo
Transposition
02
1 3 4
2
Improper folding may damage the instrument. Please fold as shown.
!
Folding, Unfolding TemPolor Melo-D & Attaching Strap
Fold the neck outward until it lies
flat. When you hear a “click” at the
joint, the neck latch is locked.
Rotate the handle from the
speaker toward the power switch
to unfold.
To fold for storage, press the
release button at the hinge to
disengage the latch, then fold
the neck toward the power
switch.
Fasten both ends of the guitar
strap to the strap buttons
indicated above.
03
Drum Machine Mute
Melo-D Smart Guitar Section Introduction
From left to right:
Transpose Down - Reset -
Transpose Up
Foldable Screen
Capo Transposition Area
Transpose Down: Single click to
lower the key; press and hold to
continue lowering
Reset: Single click to reset to C;
press and hold to switch between
7-key/21-key chord pad modes
Transpose Up: Single click to raise
the key; press and hold to
continue raising
Chord Pad
7-key Mode: All three grids per level on the
chord pad map to the same chord.
21-key Mode: The three grids per level on the
chord pad map to different chords.
Default mode: 7-key Mode.
For details, connect to the ocial APP to view
and customize chord mappings.
Forced shutdown:
Flip the screen upward. There is a small
circular hole at the top-left of the
"TemPolor" logo on the bottom. Insert a
pin into the hole to force shutdown.
Indicator Light Strip
Quick Start ButtonBack Button
04
05
Power Knob
Press and hold: Power On/Off Rotate: Adjust Volume
Click: Change Preset
Change the preset to a customized mode. In the
ocial APP you can set multiple default presets
(including fingerboard chords, drum machine patterns,
pick patterns and instrument timbres)
Restoring factory settings must be done in the ocial app.
I/O Ports
From left to right:
-Headset/Audio Interface
-Microphone Interface (*Do not
connect 48V phantom power)
-OTG/Mobile Recording and
Output Interface
Charging Port
During charging, the guitar
foldable screen will display the
current battery level and
charging status
Melo-D Smart Guitar Section Introduction
Rainbow Strings
Single-string: Corresponds to the chord
notes of the six strings of the guitar;
supports plucking and strumming
Magnetic Picks
Short pick: Default arpeggio
Long pick: Default strumming
Then press any magnetic
pick to play a full chord
Hold any chord pad
06
Play a Chord Right Away
Hold the drum pad and press any pick:
start the drum machine and bass line
Hold the drum pad and press two picks simultaneously:
stop the drum machine and bass line
Tap the drum pad alone:
adjust the playing speed (BPM)
One-Man Band: Using the Drum Machine
Hold the mute pad to
immediately stop all playback
07
Specifications
Item
Product Name
Model
Dimensions
N.W.
Operating Environment
Materials
Battery Capacity
Power
Battery Life
Auto Shutdown
Screen
Speaker Unit
Amplifier Maximum Power
Crossover Technology
Sampling Technology
Mixing Technology
Audio Chip
Wireless Technology
Parameter
TemPolor Melo-D Generative AI Guitar
Melo-D
Folded: 468.5 x 243 x 81 mm; Unfolded: 894.5 x 274.5 x 81 mm
2.2kg
0-40°C
Plastics: PC+ABS ; Metal: Stainless steel alloy
5000mAh, 7.3V, 36.5Wh
Input: MAX 5V⎓3A, 15W; Charging time: 2.5h
Built-in Speaker：5h External Speaker：Theoretical>10h
10min
2.4 inch LCD touch screen
Tweeter: 10W 0.75 inch 4Ω; Woofer: 20W 3 inch 4Ω
20W
Digital active crossover
Multi-Layer Dynamic Real Sampling
Dual-stage DSP acoustic shaping architecture (post-stage active digital crossover + pre-stage custom acoustic processing)
Dream professional-grade audio DSP
WIFI 4 (supports only 2.4 GHz); BLE 5.0; Bluetooth Audio 5.0
Microphone: 3.5mm TRS Wireless Microphone Input
Ports
Charging: USB Type-C; Digital Audio: USB Type-C OTG (real-time audio mobile recording and audio output); Headphones: 3.5mm TRS Lineout Output;
08
Important Safety Notes
Please read the following precautions carefully before use to avoid damaging the device or causing personal injury.
The precautions include but are not limited to the following:
1. Read and understand all instructions.
2. Keep these instructions properly.
3. Pay attention to all warnings.
4. Follow all instructions.
5. If the device will not be used for an extended period, turn it off, unplug the charging cable
from the power source, and ensure it is charged once every six months.
6. Do not place the device in an unstable location to prevent accidental falls.
7. Do not place heavy objects on the device.
8. Before moving the instrument, unplug all connection cables to prevent damage to the cables
or tripping hazards.
9. When moving the product, place it securely to avoid injury from the product tipping over.
10. Avoid placing the device in poorly ventilated areas.
11. Do not open the device by yourself, and prevent any metal objects from falling into the
device to avoid fire or electric shock.
12. Do not plug or unplug the power cord with wet hands.
13. Before cleaning the device, remove the USB cable and turn off the device. Use a soft dry
cloth for cleaning. Do not use gasoline, alcohol, acetone, turpentine or any other organic
solvent; do not use liquid cleaners, sprays or overly wet cloths.
14. Avoid using the device near water or in damp places, such as bathtubs, sinks, swimming
pools, or similar locations.
15. Avoid water droplets from splashing or spilling on the product, and do not place any containers
with liquids (such as vases) on the product.
16. When cleaning, take care to prevent water from entering the device.
17. If any liquid enters the device, immediately cut off the power and unplug the power cord from
the outlet.
18. Do not place lit candles on the product; burning objects may tip over and cause a fire.
19. Do not install the product near heat sources.
20. Do not expose the device to high temperatures, flames or direct sunlight.
21. Unplug the power plug during lightning storms or when the device will not be used for a long
time.
22. Do not use the device when there is a gas leak nearby.
23. Do not block the ventilation openings.
24. Operation of this device may be complex; keep the device and its accessories out of reach of
children.
25. This device contains small parts that could detach and pose a hazard; prevent children from
accidentally damaging the device and its accessories or swallowing small parts, which may cause
suffocation or other hazards.
26. Do not allow children or pets to bite or chew the device or its accessories to avoid injury or
damage to the device or explosion.
09
11
TemPolor Warranty Service Certificate
Thank you for purchasing the TemPolor Melo-D Smart Guitar. When any non-human-induced
functional failure failure occurs during your use of the product, you are entitled to TemPolor's
service
commitment of “repair, replacement and return” (the “Three Guarantees”).
To protect your rights, please keep the Three-Guarantee certificate and the receipt after
purchasing the TemPolor Melo-D Smart Guitar. The validity period of the Three Guarantees
starts from the date you receive the product (hereinafter referred to as the ‘receipt date’) and
is valid for 12 months.
1. Within 7 days from the date of receipt, if the received product is in good physical condition
(with intact packaging and complete accessories) but has a functional failure not caused by
human damage, you may choose to refund the full purchase price according to the invoice, or
replace it with a product of the same model and specification, or repair it free of charge.
2. From the 8th to the 15th day after receipt, if the product has a performance failure not
caused by human damage, it may be replaced with a product of the same model and
specification.
The replacement is the responsibility of the seller.
3. Within the Three-Guarantee period, if after two product replacements the product still cannot
function normally, after TemPolor's verification you may, with valid replacement records
provided by the seller in the Three-Guarantee certificate, choose to repair or replace it with a
product of the same model and specification. Replacement is the responsibility of the seller.
To protect your legitimate rights and interests, please go to a TemPolor seller to enjoy the
Three-Guarantee service.
When requesting Three-Guarantee service, you need to provide:
1. The original product purchased;
2. The original invoice at the time of purchase or proof of purchase from the seller;
3. A valid Three-Guarantee certificate
How to Obtain Three-Guarantee Service
After-sales email address:
Service Information
· Products beyond the Three-Guarantee validity period;
· No Three-Guarantee certificate and valid invoice, and unable to prove that the purchased product
is within the Three-Guarantee period;
Circumstances not covered by the warranty:
Three-Guarantee Content
27. The device has built-in speakers; do not use it continuously at high or uncomfortable volume levels for long periods, as this may cause permanent
hearing damage.
28. Before connecting the device to other electronic equipment, turn off the power switches of all devices. Before turning the power switches on or
off, set all volumes to minimum.
29. If the battery power is low, the maximum output of the speakers will decrease and the volume of the two speakers may differ.
30. When the battery power is low, the device will automatically turn off; please charge it promptly.
31. When you decide to dispose of the product or its battery, please follow local environmental laws and guidelines.
32. A slight temperature rise during charging is normal.
33. A slight temperature rise with prolonged screen operation is normal.
34. Use a 5V⎓3A adapter to charge the product; using an inappropriate adapter may damage the instrument.
35. Do not pluck the Rainbow Strings with hard or sharp objects.
Note: TemPolor shall not be liable for any loss, data loss, or damage caused by improper use or unauthorized operation of this device.
Warning: To avoid the risk of electric shock, do not open the rear cover or other components. There are no user-serviceable parts inside the product.
All repair work must be entrusted to qualified professionals.
The lightning symbol with an arrow inside an equilateral triangle is intended to remind users that there is uninsulated dangerous voltage inside
the product casing, and the magnitude of this voltage may be sucient to pose an electric shock hazard.
The exclamation mark inside an equilateral triangle is intended to remind users that there are important operating and maintenance
instructions in the documents accompanying the device.
For safe use only in non-tropical climate conditions.
For safe use only in areas below 2000 meters above sea level.
10
12
· The warranty certificate does not match the product model identification or the warranty certificate is altered;
· Damage caused by failure to use, maintain, and care for the product as required by the User Manual, or by using non-original accessories;
· Unauthorized repairs, alterations, misuse, collision, dropping, crushing, water ingress, or corrosion;
· Product labels, seals or serial numbers (SN) that have been torn, altered or cannot be identified;
· Damage caused by force majeure such as floods, fire, or lightning;
· Defects due to normal wear or normal aging of the product;
· TemPolor Melo-D Smart Guitars not sold in mainland China.
If the product does not meet the warranty conditions and fees are required, TemPolor will calculate an appropriate repair fee based on costs of parts and
labor, and will provide you
with a repair quotation. After obtaining your consent and payment, TemPolor will provide repair services for your product.
This policy is formulated strictly in accordance with the Consumer Rights Protection Law and the Product Quality Law of the People's Republic of China.
Paid Service Guarantee
All rights reserved.© Guangzhou Yundong Zhiyue Information Technology Co., Ltd.
The product description images in this manual are for illustration only; please refer to the actual product.
Ocial website: [email protected]
Rights Statement
13
FCC Warning
Labeling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Information to user.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC RF Exposure Warning Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment can be used in portable exposure conditions.
Warranty Card
14
Product Name and Model
Name
Contact Phone Number
Contact Address
Purchase Channel
Name of Purchasing Store
Order Number of Purchase Channel
Serial Number
Date of Purchase
Date of Receipt
Invoice Number
Follow the Ocial Account and download the ocial app to
watch demos and tutorials, and unlock device settings, basic
strumming & singing, AI fingerpicking, and AI composition.
Connect your Melo-D to the ocial app via Bluetooth or Wi-Fi to unlock more AI
features (e.g., AI transcription and AI composition) and additional customization
options.
