8-Piece Hex/
XZN Triple Square Spline/
Torx Bit Socket Set
1
SAFETY INFORMATION
• The instructions provided herein are only for general information. ALWAYS perform all repairs
in full compliance with your vehicle’s service manual. After any repair, test your engine and
vehicle in your workshop and at low speed before returning to normal use. Failure to do so may
result in serious property damage and severe personal injury.
• ONLY use this product for its intended purpose, loosening and tightening vehicular fasteners.
• DO NOT allow use by children, by persons whose mental or physical condition precludes safe
use, or by persons unfamiliar with this product and its compatible vehicle systems.
• DO NOT use while under the inuence of alcohol, drugs, or any medication that negatively
aects your judgment or reexes. Keep children and bystanders away during use.
• Keep your work site clean and well lit. Cluttered and dark work areas invite accidents. For best
results, keep the kit clean and dry. Remove any uid, oil, or grease before and after work.
• ALWAYS use personal protective equipment (PPE) suitable to your task. Always wear ANSI
and OSHA-approved eye, breathing, and hand protection while using this product. Normal use
of this product typically produces microscopic particles known to the state of California to cause
cancer, birth defects, or other reproductive harm. Nonslip footwear is also highly recommended.
Other equipment such as ear, head, and body protection may also be necessary depending on
your work, work environment, and other equipment.
• Dress properly for automotive servicing. Do not wear loose clothing or jewelry and keep hair,
clothing, gloves, hoses, and tools away from any moving parts during use.
• ALWAYS know and understand the specic safety warnings and instructions for your vehicle
before using this kit. Use the correct uids, pressures, adapters, etc. for your vehicle. Make
sure the vehicle is fully supported and parked before beginning any work. Take care to never
touch any heated surface with exposed skin.
• ALWAYS be mindful of the control arm, snap rings, and other components under tension as
they are released. Be mindful of where components might y or land at all points during use.
• DO NOT overreach. Keep proper footing and balance at all times.
• Maintain this product. Check for misalignment, binding, wear, or other damage before use. If
any damage is detected, repair or replace the problematic components before further use.
• Automotive repair is an inherently dangerous activity. This manual and the separate vehicle
service manual cannot cover all possible situations that may arise, and training, common sense,
and care must be supplied by the operator.
Warning!
2
SPECIFICATIONS
Case Dimensions
10×5×2 in. 255×127×50 mm
Material
Cr-Mo 25×13.4×21 cm
XZN Triple Square Spline Bit Socket (A001)
Pieces
8
Socket
Sizes M5, M6, M8, M10, M12, M14, M16, & M18
Drive ½ in.
Torx Bit Socket (A002)
Pieces
8
Socket
Sizes T30, T40, T45, T50, T55, T60, T70, & T80
Drive ½ in.
Hex Allen Bit Socket (A003)
Pieces
8
Socket
Sizes H5, H6, H8, H10, H12, H14, H17, H19
Drive ½ in.
OPERATION
Caution! These products need to be used with a ratchet. DO NOT use power or pneumatic
tools, whose excessive torque will cause damage to the tool and your fasteners.
1. Select the appropriate socket according to your vehicle’s service manual and the specications
of target nuts.
2. Connect the socket to a ½ in. ratchet wrench (not included).
3. Position the socket precisely over the nut that requires adjustment, ensuring it aligns accurately
with the specic nut you intend to work on to avoid any slippage or damage.
ALWAYS tighten the fasteners to the torque as stated in your vehicle’s service manual.
4. Repeat steps 1–3 for each of the nut that requires loosening or tightening.
3
MAINTENANCE
• Clean the tools with a soft damp cloth using a mild detergent or solution after use. Do not rinse
them or use abrasive cleaners or caustic chemicals.
• Check the tools periodically for any wear or damage. Repair or replace any problematic piece
before further use.
• If the tools will not be used for an extended period of time, clean and lubricate them and store
them in a cool dry place inaccessible to children.
CONTACT US
Thank you for choosing our products! If you have any questions or comments,
contact us at support@orionmotortech.com and we'll resolve your issue
ASAP!
For a .pdf copy of the latest version of these instructions, use the appropriate
app on your smartphone to scan the QR code to the right.
NSS-A001-00 NSS-A002-00 NSS-A003-00
Rev. 15 Aug. 2023
