SUSPENSION BOOM MIC STAND
FLOOR-STANDING
QUICK GUIDE
PMKSH28
A
B
C
D
E
F
11.81 in diameter
19.68 in
19.68 in
39.37 in
Accessories:
Mic Holders
How to use:
1. Tighten the two poles into one pole (E), then screw the pole end to
the iron base (F).
2. Screw the adaptor( D) to the iron base( E).
3. Unscrew the knob of the adaptor( D), then put the recording mic
stand(C) bottom inside the hole of the adaptor(D).
4. Screw the shock mount (B) on the arm frame connection of the
recording mic stand(C)
5. Adjust the recording mic stand(C) to desired height.
6. Screw the pop lter(A) on the right place of the recording mic
stand(C)
7. Slide your microphone into the shock mount(B).
Materials:
A. Pop lter: plastic and steel
B. Shock mount: steel
C. Recording mic stand: steel
D. Adaptor: Aluminum w/ plastic knob
E. Two poles: steel
F. Iron base: steel
