F5816-H
The F5816-H is an 16-port UHF RFID reader developed by the technical team at sanray , based on the next-generation
Impinj E710 RFID chip.
It is a high-performance and cost-effective UHF RFID reader module. The output power is configurable from 5dBm to
33dBm, with a tag reading distance of over 12meters (depending on antenna gain and tag size), and it offers excellent
multi-tag inventory performance.
The SIMx400 module is stable and reliable, featuring advanced multi-tag identification algorithms that enable fast tag
reading whether the tags are stationary or in motion. Its superior anti-interference design and carrier cancellation
functionality ensure consistent operation in various environments. With multiple configuration modes, it is widely
applicable in scenarios such as
warehousing, logistics, production lines, and inspection systems.
Product advantages
2011-2026 Shenzhen Sanray Technology Co., Ltd.
www.sanrayrfid.com
RFID HARDWARE/RFID SOFTWARE
• ARMv7-M architecture 32bit Cortex-M4 CPU, integrated FPU, MPU, DSP, the highest work main
frequency is 200MHz, 512KByte Flash
• Support ISO 18000-6C/UHF EPC Class1 Gen2&Gen2X
• Provide Windows，Linux and Android SDK, and API based on C, C#/.NET, JAVA
• Support inventory of temperature tags, the output parameters include the RSSI and phase value
of the tag return signal
• Maximum 33dBm power output
• Excellent anti-collision algorithm and high sensitivity. The fastest speed of inventory tags is
greater than 1000tag/s
• Multiple inventory modes suitable for most applications.
• The UART serial communication baud rate can be set from 9600bp to 921600bps
• 2 inputs 2 outputs GPIO
• Max power 33dBm, power consumption 15W
2011-2026 Shenzhen Sanray Technology Co., Ltd.
www.sanrayrfid.com
Product Technical Parameters
NO Name Parameter
1 Size 263 x 146 x 30mm
2 Weight 248g
3 Connector material Brass gold plated
4 PCB FR$ gold plated
5 Shield Material Aluminum Alloy
6 Chip Impinj E710
7 Air Protocol
EPC global UHF Class 1 Gen 2
(ISO 18000-6C)&Gen2X
8 Frequency
NA: 902 ~ 928MHz
EU: 865 ~ 868MHz
CN: 920 ~ 925MHz
OPEN:860 ~ 960MHz
9 Sensitivity -84dBm@10%BER
10 RF power -82dBm
11 Antenna interface Non-standard RF output port
12 RF Power 5dBm ~ 30 or 33dBm (±1dB)
13 Working Mode Fixed / Hop frequency
14 Temp. detect Support
15
Ant. detect Support
16
Inventory peak speed >1000 tags/s
17
read range >13m（8dBi antenna）
18
tag cache 1000pcs, @96 bit EPC
19 Hardware interface
UART serial port (power, TTL,GPIO)
9600~921600bps,@115200bps
20 GPIO 2 GPI, 2 GPO （3.3V TTL）
21 Communication 15pin connector Uart3.3V（TTL）
22 Voltage DC 5V±5%
23 Consumption
15W（peak）, 3A@5V
1.05W（standby）,0.21A@5V
0.1W（Low power mode
standby）,0.02A@5V
24
Work Temp. -25°C ~ +65°C
25 Storage Temp. -40°C ~ +85°C
2011-2026 Shenzhen Sanray Technology Co., Ltd.
www.sanrayrfid.com
Product Technical Parameters
NO Name Parameter
26 Humidity 5 ~ 95%, Non-condensing (+25°C)
27
Electrostatic
Protection
Contact discharge: 6KV (antennaport)
Contact discharge: 6KV (IO port)
28 Heat dissipation External heat sink air cooling
29 API support C, C#/.NET, Java
