www.coyoteoutdoor.com
C3-DA2436 INSTALL
GUIDE
Model No. Height Width Depth
Model No. Height Width Depth
C3-DA2436
C3-DA2436
Cutout Dimensions for Island
Overall Product Dimensions
2"
5"
20-1/2"
24"
10
1
/4"
OPENING HEIGHT
CUTOUT WIDTH
CUTOUT
HEIGHT
GRILL OPENING WIDTH
FRONT VIEW
1
1
/2" MIN
SUGGESTED
FOR
FRAMING
INCLUDING
COUNTERTOP
2"
INTERIOR
DEPTH
TOP VIEW
31-3/4"
OVERALL
HEIGHT
24"
20
1
/2"
OVERALL WIDTH
OVERALL WIDTH
1"
EXTERIOR DEPTH
CUTOUT WIDTH
31-3/4"
DIMENSIONAL RENDERINGS
2 anchor points are located on each side of the doors interior frame (top, bottom, left and right)
Due to wide variance of possible building materials, anchors are not included
When inserting your anchors be sure to use a framing square to ensure the door is not pulled out of square
These specs are accurate but we always suggest having the product physically on site to ensure full understanding of how this
product will coordinate with your build
35-1/2"
35-1/2"
31-3/4"
35-1/2"
Install Notes:
(HANDLE EXTENDS 1" FURTHER)
