WX125317A
ORIGINAL SAFETY AND
OPERATING INSTRUCTIONS
20V CORDLESS POLE HEDGE TRIMMER
Thank you for buying a WORKPROX CORDLESS POLE HEDGE TRIMMER. Your new CORDLESS POLE
HEDGE TRIMMER has been engineered and manufactured to WORKPROX's high standard for dependabili-
ty, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free
performance.
Made in China
Shangcheng District
2
2
1
FIG. 1
20V 2.0AH
1. Extension pole handle
2. Lock-off button
3. Shoulder strap attachment
4. Rotational button
5. Blade
6. 0n/off switch
7. Battery pack
8. Blade sheath
9. Trimmer head locking sleeve
10. Inner pole
11. Inner pole release lever
2
6
7
3
9 10 11
5
8
4
3
INTRODUCTION
Tools for private and hobby gardens are not suitable for use in public facilities, parks and sport centers, along
roadways, on farms or in the forestry sector. For the tool to be used properly it is imperative to follow the
instructions set out in the manufacturer’s directions for use.
WARNING!
It is prohibited to use the tool to chop material for composting because of the potential danger to persons and
property.
The machine is to be used only for its prescribed purpose. Any other use is deemed to be a case of misuse. The
user / operator and not the manufacturer will be liable for any damage or injuries of any kind caused as a result of
this.
Please note that our equipment has not been designed for use in commercial, trade or industrial businesses or
for equivalent purposes.
4
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
If operating a power tool in a damp location is
unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) Personal safety
Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with
your nger on the switch or energising power tools
that have the switch on invites accidents.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action
can cause severe injury within a fraction of a
second.
4) Power tool use and care
Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it
was designed.
1) Work area safety
Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2) Electrical safety
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce
risk of electric shock.
Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
DANGER!
When using the equipment, a few safety precautions must
be observed to avoid injuries and damage. Please read
the complete operating instructions and safety regulations
with due care. Keep this manual in a safe place, so that
the information is available at all times. If you give the
equipment to any other person, hand over these operating
instructions and safety regulations as well. We cannot
accept any liability for damage or accidents which arise
due to a failure to follow these instructions and the safety
instructions.
Read all safety warnings, instructions, illustrations and
specications provided with this power tool. Failure
to follow all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operat-
ed (cordless) power tool.
1. GENERAL POWER TOOL SAFETY
WARNING
WARNING!
5
d. When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a re.
e. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
or burns.
ADDITIONAL SAFETY INSTRUCTIONS
RELATED TO THE BATTERY PACK AND
BATTERY SAFETY
Use only the WORKPROX batteries supplied with
the WORKPROX Tool or WORKPROX-approved
replacements.
Do not use the battery to power any device other
than the WORKPROX tool it was sold with.
Charge the battery only with the WORKPROX
charger supplied with the tool or WORKPROX-ap-
proved replacements and according to the
instructions in the WORKPROX Instruction
Manual.
Do not charge the battery in a place where static
electricity is generated nor let the battery touch
something that is statically charged.
The battery can be stored at temperatures
between 40°F(4°C) and 104°F(40°C).
Never store or leave your lithium ion battery in
temperatures over that recommended otherwise
re may occur.
DO NOT store the Lithium Ion battery anywhere that
the temperature can easily reach higher temperatures
than recommended -this includes garden type sheds,
and Vehicles where the inside temperature can climb
to dangerous levels in the direct sunlight and on high
temperature days. THINK BEFORE LEAVING YOUR
LITHIUM ION BATTERY PACK IN STORAGE.
The battery can be charged or operated at tempera-
tures between 40°F(4°C) and 104°F(40°C). NEVER
CHARGE YOUR LITHIUM ION BATTERY BELOW
OR ABOVE TEMPERATURES RECOMMENDED
OTHERWISE FIRE OR SERIOUS DAMAGE TO THE
BATTERY PACK MAY OCCUR.
T
he most suitable temperatures to charge the
battery pack are between 68°F(20°C) -77°F(25°C).
Always allow the battery pack to cool down after
charging, do not place it in a hot environment
such as a metal shed or open trailer left in the sun.
Take care where the tool is stored. Do not store in
areas of corrosive fumes, or salt air or similar
conditions. Try and store the tool in the packaging
supplied with the tool.
Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many
accidents are caused by poorly maintained power
tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits
etc. In accordance with these instructions, taking
into account the working conditions and the work
to be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling
and control of the tool in unexpected situations.
5) Service
Have your power tool serviced by a qualied repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
6) Battery tool use and care
a. Ensure the switch is in the off position before inserting
battery pack. Inserting the battery pack into power
tools that have the switch on invites accidents.
b. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one
type of battery pack may create a risk of re when
used with another battery pack.
c. Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
6
Do not dispose of the battery in a re or put the
battery into a microwave oven, conventional oven,
dryer, or high-pressure container. Under these
conditions, the battery may explode.
Never attempt to open the battery pack, puncture
the battery or subject the battery to strong
physical shock.
If the plastic housing of the battery pack breaks
open or cracks, immediately discontinue its use
and do not recharge it. Ensure the battery pack
clip is in good condition and will not allow the
pack to fall free from the tool. If the clip is
damaged or for any reason is not locking the pack
in place, Do Not continue to use.
Stop using the battery if it exhibits abnormal heat,
odour, colour, deformation, or is in an abnormal
condition.
If you detect leakage or a foul odour, it is
especially important to keep the battery away from
re. If battery liquid leaks onto your skin or
clothes, wash well with clean water immediately. If
liquid leaking from the battery gets into your eyes,
do not rub your eyes. Rinse your eyes well (for at
least 10 minutes) with clean water, and consult a
doctor immediately.
Do not use a leaking battery.
Handle batteries with care to avoid shorting the
battery with conducting materials, such as nails,
screws, metal watch bands, rings, bracelets, and
keys. The battery may overheat and could burn
you.
After the battery has reached the end of its useful
life, we recommend recycling the materials at your
local municipal council recycling centre. DO NOT
attempt to replace the battery cells in the battery
pack, repair or modify any part of the battery pack
assembly.
When recycling, make it nonconductive by
applying insulating tape to the terminals located
on the battery.
WHEN TO CHARGE THE BATTERY
New batteries are shipped in a low charged
condition and should be fully charged before Use.
The battery pack can be recharged at any time
during use, provided the pack is not overheated.
If the battery pack starts to cut out due to low
voltage, or previous tasks undertaken can no
longer be performed, it is suggested to stop using
the tool and recharge the battery.
For storage, it is suggested to recharge the battery
between 50% and 75% charge.
Charge the device at least once in 3-6 months to
preserve battery life span.
2. HEDGE TRIMMER SAFETY WARNINGS
Keep all parts of the body away from the cutter
blade. Do not remove cut material or hold material
to be cut when blades are moving. Make sure the
switch is off when clearing jammed material.
Blades coast after turn off. A moment of inattention
while operating the hedge trimmer may result in
serious personal injury.
Carry the hedge trimmer by the handle with the
cutter blade stopped. When transporting or
storing the hedge trimmer always t the cutting
device cover. Proper handling of the hedge trimmer
will reduce possible personal injury from the cutter
blades.
Hold the power tool by insulated gripping
surfaces only, because the cutter blade may
contact hidden wiring or its own cord.Cutter
blades contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give
the operator an electric shock.
Keep hands away from blade.Contact with blade
will result in serious personal injury.
Use both hands when operating the hedge
trimmer. Using one hand could cause loss of
control and result in serious personal injury.
Only use with handle and guard properly
assembled to hedge trimmer. The use of the
hedge trimmer without the proper guard or handle
provided may result in serious personal injury.
Check the hedge for foreign objects, e.g. wire
fences.
3. EXTENDED-REACH HEDGE TRIMMER
SAFETY WARNINGS
Do not use the extended-reach hedge trimmer
in bad weather conditions, especially when
there is a risk of lightning.This decreases the risk
of being struck by lightning.
To reduce the risk of electrocution, never use
near any electrical power lines. Contact with or
use near power lines may cause serious injury or
electric shock resulting in death.
Always use two hands when operating the
extended-reach hedge trimmer. Hold the
extended-reach hedge trimmer with both hands to
avoid loss of control.
Always use head protection when operating the
extended-reach hedge trimmer overhead.Falling
debris can result in serious personal injury.
Keep bystanders, especially children at a safe
distance during the operation of the extended
reach hedge trimmer.
Keep a rm footing and balance during
operating.
7
SAVE THESE INSTRUCTIONS
Refer to them frequently and use them to instruct
others who may use this tool. If you loan someone
this tool, loan them these instructions also.
SYMBOLS
Danger notices and information are clearly marked
throughout these instructions for use. The
following symbols are used:
4. KNOW YOUR PRODUCT (FIG.1)
1. Extension pole handle
2. Lock-off button
3. Shoulder strap attachment
4. Rotational button
5. Blade
6. On/Off switch
7. Battery pack
8. Blade sheath
9. Trimmer head locking sleeve
10. Inner pole
11. Inner pole release lever
UNPACKING
Instructions
Carefully remove the Cordless Pole Hedge
Trimmer and check to see that all of the above
items are supplied.
Inspect the product carefully to make sure no
breakage or damage occurred during shipping. If
you nd damaged or missing parts, please
contact us at the rst time.
Carton contents
Cordless Pole Hedge Trimmer
Blade
Battery Pack
USB-C Charging Cable
Original Safety And Operating Instructions
NOTE: Do not discard the shipping carton and
packaging material until you are ready to use your
new Cordless Pole Hedge Trimmer. The packaging
is made of recyclable materials. Properly dispose of
these materials in accordance with local regulations.
DANGER!
Keep all other persons away from the danger zone.
Hazard symbols with information on prevention of
personal injury and property damage
Protect the tool from the damp and never expose
it to rain.
Guaranteed sound power level.
91
1
2
3
20V 2.0AH
4
5
6 7
8
Read the operating instructions to reduce the risk
of inquiry.
IMPORTANT!
The cutter blades continue to run after the motor is switched
off. Wait for the blades to come to a standstill. Risk of
injury!
FIG. 1
9
10 11
No-load speed
Total reach
Trimmer head rotation
angle
Maximum cutting length
of blade
Maximum prining
diameter of blade
Weight (without battery)
8
20V Cordless Grass Shear & Shrubbery Trimmer
1200/min
9.19' (2.8m)
Battery Pack
Capacity
Voltage
Usb-C Input / Output
2000mAh
Maximum: 20V
Nominal:18V
5. TECHNICAL DATA
6. OPERATION
a) Battery capacity indicator(Fig.2)
The battery pack has an LED screen, and press the
can display real-time power level. The screen will
automatically turn off in three seconds.
b) Recharge the battery pack (Fig. 3)
To charge your battery pack, connect one end of the
USB cable with a USB-C port to the corresponding
USB-C port on the battery pack, and connect the other
end to a USB-C or USB-A interface charger.
The area to be cut must rst be cleared of stones and
other solid objects. The safety lock-off (5) prevents the
tool being started unintentionally.
17.72" (450mm)
ф 0.7"(ф18mm)
6.61lbs (3.0kg)
-90 to 60 degrees
(11 positions)
Usb-A Output
Max. 30W, 5V/3A,
9V/3A, 12V/2.5A,
15V/2A, 20V/1.5A
Max. 15W,5V/3A
CAUTION!
Risk of injury! Comply with all safety instructions when
handling rechargeable devices.
WARNING
!
CAUTION!
NOTE: Do not touch the rotating blades.
The blades continue to move for a few seconds after the
tool is switched OFF. Turn OFF the tool and wait until the
blades come to a complete stop before adjusting or
cleaning.
Never touch the blade rail while the tool is in operation
and be aware of the sharp edges even when the
Cordless Pole Hedge Trimmer is not in use.
NOTICE
!
Risk of damage to the unit! Do not press the On/Off
switch after the device has deactivated automatically.
IMPORTANT
!
The equipment and packaging material are not toys. Do
not let children play with plastic bags, foils or small parts.
These items can be swallowed and pose a suffocation
risk!
Fig. 2
Fig. 3
9
c) Charge portable device (Fig.4 & Fig. 5)
Press the button as shown in Fig. 4, the indicator will
light up green to indicate that the battery pack is active
and that the USB ports are ready to be used.
After charging, disconnect the USB cables, press the
buttonto turn the indicator off.
Plug the USB cable into the correct port, and the other
end of the cable into your device to begin charging the
device.(Fig. 5)
d) To remove or install battery pack (Fig. 6&7)
Attaching and releasing the extension pole
(Fig. 8)
Fig. 6
Fig. 7
Fig. 8
NOTE:
The green light remains on during output.
After pressing the button (as shown in Fig. 4), if no
USB cable is connected for an extended period, the
green light will automatically turn off after 5 minutes.
ASSEMBLY
Fig. 5
Fig. 4
2
1
3
10
Removing the blade sheath （Fig.11 ）
Switching on (Fig.12)
Adjusting the head angle (Fig.10)
Extending the inner pole (Fig. 9)
Switching off
To switch off the equipment, let go of the ON/OFF switch.
Top cutting （Fig. 13)
Fig. 9
Fig. 11
Fig. 12
Fig. 13
WARNING!
Failure to properly secure the trimmer head may result in
personal injury and/or property damage.
WARNING
!
Remove battery from the socket before carrying out any
adjustment, servicing or maintenance.
WARNING
!
If any parts are missing, damaged or broken, do not operate
your hedge trimmer until all damaged parts have been
replaced or repaired. Failure to do so could result in serious
personal injury.
Activate the safety lock-off by rst pressing the safety
lock-off button(2) and then pressing the ON/OFF
switch(6)
1
2
1
2
Fig. 10
3
7. CLEANING AND MAINTENANCE
CLEANING
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible. Wipe
the equipment with a clean cloth or blow it with
compressed air at low pressure.
We recommend that you clean the device immediately
each time you have nished using it. Clean the
equipment regularly with a moist cloth and some
soft soap. Do not use cleaning agents or solvents,
these could attack the plastic parts of the equipment.
Ensure that no water can seep into the device.
A few drops of oil (e.g. sewing machine oil) will improve
the cutting performance of the blades, but never apply
any grease to the blades.
To ensure constant exact cutting it is also important
to remove grass remnants and dirt from between the
upper and lower blade.
11
Side cutting (Fig. 14)
FIG. 14
WARNING!
Stop operating the trimmer before rotating the handle.
Risk of injury! Before any maintenance or cleaning
work:
Remove the battery.
Let the device cool down.
CAUTION
!
Never clean the tool under running water and particularly
never with high pressure washer, because of the potential
danger to persons and property. Keep your cordless
grass and shrubbery shear in a dry and frost-proof
place. Choose a place that children are unable to enter.
MAINTENANCE
To achieve good results you should keep the blades
sharp at all times. In particular we recommend that
you immediately level off any jags or ridges caused by
stones or the like. The tool should be thoroughly
cleaned both before and after use. There are no parts
inside the equipment which require additional
maintenance.
Avoid using solvents when cleaning plastic parts.
Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged
by their use. Use clean cloths to remove dirt, dust, oil,
grease, etc.
8. STORING AND TRANSPORT
Storage
Store the device in a dry and dustproof location and
out of reach of children.
Remove the rechargeable battery from the device
before storing the device.
The optimum storage temperature for the battery
and device is between 32°F/0℃ and 104°F/40°C.
Avoid extreme cold or heat during storage, so that
the battery does not lose performance.
Charge the device at least once in 3-6 months to
preserve battery life span.
TRANSPORT
Secure the appliance against slipping.
If shipping, use the original packaging wherever
possible.
WARNING
!
9. Disposal
A crossed-out wheelie bin icon means: Batteries and rechargeable batteries, electrical or electronic
devices must not be disposed of with household waste. They may contain substances that are harmful
to the environment and human health.
Consumers must dispose of waste electrical devices, spent portable batteries and rechargeable
Disposal of the packaging
batteries separately from household waste at an ofcial collection point to ensure that these items are processed
correctly. Information on returning these items is available from the seller. Sellers are required to
accept these items free of charge. Batteries and rechargeable batteries, which are not permanently installed in
waste electrical devices, must be removed prior to disposal and must be disposed of separately. Lithium
batteries and battery packs in all systems must only be retuned to a collection point when discharged. Batteries
must always be protected against short circuits by covering the poles with adhesive tape.
All end users are responsible for deleting any personal data stored on waste devices prior to their disposal.
Disposal of an exhausted battery pack
To preserve natural resources, please recycle or dispose of the battery pack properly. This battery pack
contains Li-ion batteries. Consult your local waste authority for information regarding available recycling
and/or disposal options. Discharge your battery pack by operating your tool, then remove the battery
pack from the tool housing and cover the battery pack connections with heavy-duty adhesive tape to
prevent short circuit and energy discharge. Do not attempt to open or remove any of the components.
The packaging consists of cardboard and correspondingly marked plastics that can be recycled. Make
these materials available for recycling.
Disposal of the appliance
12
Li-ion
13
