WIRELESS SPEAKER
USER MANUAL
BOC244
Model: BOC244
Bluetooth Version: 5.3
Connection Distance: 10M approx.
SNR: 85dB
Battery: 2000mah 3.7V 7.4Wh
Playing time: 5.6Hrs (At 100% Volume)
Speaker Size: Φ52mm
Power: 3Ω/7W RMS
Frequency: 150HZ-20KHZ
Dimensions: 115.9*54*90.4mm
Weight: 360g
Input: 5V⎓1A
1. Internationally advanced wireless chip and
circuit design technology, supporting all
wireless devices.
2. With Hi-Fi speaker, to make sure the clear
and bright sound.
3. 10 meters wireless working distance, can
connect all external wireless devices (mobile
phone/tablet/TV) to play music.
4. Built-in microphone for hands-free calling.
5. Support True Wireless Stereo Dual
Pairing.
PRODUCT SPECIFICATIONS:
PRODUCT FEATURE:
1. Internationally advanced wireless chip and
circuit design technology, supporting all
wireless devices.
2. With Hi-Fi speaker, to make sure the clear
and bright sound.
3. 10 meters wireless working distance, can
connect all external wireless devices (mobile
phone/tablet/TV) to play music.
4. Built-in microphone for hands-free calling.
5. Support True Wireless Stereo Dual
Pairing.
KEY AND SLOT FUNCTIONS:
①. During music playback, press the "+" button
once to increase the volume, long press the
"+" button to skip to the next song.
②. Play Button:
1) Short press to play or pause;
2) Call Mode: Short press to answer/end calls.
Long press for 2 seconds to reject calls.
③. During music playback, press the"-" button
once to decrease the volume, long press the
"-" button to return to the previous song.
③
②
①
④
⑤
⑥
⑦
⑧
⑨
④. Connection Button:
1) Short press: Switch between modes
(BT/TF);
2) Long press: Enter pairing mode;
3) TWS Pairing: After turning on the two
speakers, double-click the connection
button of one of the speakers and the
speakers will automatically perform TWS
pairing.
⑤. Indicator Light: The red light stays on
during charging, and turns off when fully
charged.
⑥. Microphone Location
⑦. Type C Port: DC 5V Slot, use standard
Type C charging cable to charge.
⑧. TF Card Slot: After inserting the TF card
into the card slot, it can decode and play
audio in MP3/WAV format.
⑨. Power Switch: Long press for "ON/OFF "
to turn on or turn off.
RESET: Long press ON/OFF for 10
seconds to reset.
④. Connection Button:
1) Short press: Switch between modes
(BT/TF);
2) Long press: Enter pairing mode;
3) TWS Pairing: After turning on the two
speakers, double-click the connection
button of one of the speakers and the
speakers will automatically perform TWS
pairing.
⑤. Indicator Light: The red light stays on
during charging, and turns off when fully
charged.
⑥. Microphone Location
⑦. Type C Port: DC 5V Slot, use standard
Type C charging cable to charge.
⑧. TF Card Slot: After inserting the TF card
into the card slot, it can decode and play
audio in MP3/WAV format.
⑨. Power Switch: Long press for "ON/OFF "
to turn on or turn off.
RESET: Long press ON/OFF for 10
seconds to reset.
