PLD64C
2 Pcs. 6.5'' SVC Speakers
WIRING CONNECTION
1. Connect the crossover to the positive and negative poles accordingly.
2. T (Tweeter), W (Woofer), IN (input from amplier)
www.PyleUSA.com
input from amplier
IN
W
T
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: suppor[email protected]om
Features:
• One Pair 6.5'' Three-Way Component Speaker Systems
• Non-fatiguing Butyl Rubber Surround
• 1.5'' High-Temperature ASV Voice Coil
• Standard 6.5'' Size Fits OEM Locations
• Ensures Low Distortion
• Flush and Surface Mount Capability
• 12dB Octave Passive Crossover Network
What's in the Box:
• (2) 6.5” Woofers
• (2) Aluminum Tweeters
• (2) Crossover Network
• Grilles
• Wires
• Mounting Hardware
Technical Specs:
• Power Handling: 120 Watts Max, (Tweeter); 150 Watts Peak Power (Woofer)
• Impedance: 4 Ohm
• Sensitivity: 101 dB
• Frequency Response (woofer): 60Hz - 5000Hz
• Frequency Response (tweeter): 1.5KHz - 20KHz
• Voice Coil: 1.5''
• Tweeter Size: 3.8”
• Product Dimension: 4.13'' x 2.59'' x 1.22'' -inches (Crossover)
• Product Dimension with Grill: 6.81'' x 6.81'' x 3.07'' -inches (Woofer)
www.PyleUSA.com
IN
W
T
