E S S E N T I A L S FOR LIFE
User
Manual
MODELS
GGSDW6013W
GGSDW6013X
V1.5 1124
60cm Freestanding
Dishwasher
ContentsWelcome!
Safety Instructions 4
Product Overview 6
Installation Instructions 7
Using Your Dishwasher 9
Programming The Dishwasher 15
Maintenance and Cleaning 17
Troubleshooting 19
Technical Information 22
Purchase Details 24
Warranty 26
Congratulations on purchasing your new dishwasher!
The Sôlt brand is proudly distributed within Australia
by Residentia Group Pty Ltd.
Please refer to the warranty card at the rear of
this manual for information regarding your product’s
parts and labour warranty, or visit us online at
www.residentia.group
At Residentia Group, we are customer obsessed and
our Support Team are there to ensure you get the
most out of your appliance. Should you want to learn
more about the features, and importantly taking care
of your appliance when cleaning, our Support Team
are here to help.
You can use our online Support Centre at anytime by
visiting http://support.residentiagroup.com.au, or you
can contact us via calling us on 1300 11 HELP (4357).
It is important that you read through the following
use and care manual thoroughly to familiarise
yourself with the installation and operation
requirements of your appliance to ensure optimum
performance.
Again, thank you for choosing an Sôlt appliance and
we look forward to being of service to you.
Kind regards,
The Residentia Team
Residentia Group
—
Head Office.
165 Barkly Ave
Burnley
Victoria 3121
Australia
—
ACN.
600 546 656
—
Online.
residentia.group
Sôlt
—
Online.
www.solt.house
—
Instagram.
/solt.house
—
Facebook.
/solt.appliances
Customer Care
Sôlt recommends the use of original spare parts. When contacting our customer service team, please
ensure
that you have the following information at hand (which can be found on your appliances’ rating plate).
— Model Number
— Serial Number
4 5
Safety Instructions
Important
Please ensure that you read the entire instructions
before using your dishwasher.
Warning
When using your dishwasher, follow the
precautions listed below.
• Installation and repair can only be carried out
by a qualified technician.
• This appliance is intended to be used in
household and similar applications such as:
– staff kitchen areas in shops, offices and other
working environments;
– farm houses;
– by clients in hotels, motels and other
residential
type environments;
– bed and breakfast type environments.
• This appliance can be used by children aged
from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the appliance.
Cleaning and user maintenance shall not be
done by children without supervision.
• This appliance is not intended for use by
persons (including children ) with reduced
physical, sensory ormental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Packaging material could be dangerous for
children!
• This appliance is for indoor household use only.
• To protect against the risk of electrical shock, do
not immerse the unit, cord or plug in water or
other liquid.
• Please unplug before cleaning and performing
maintenance on the appliance.
• Use a soft cloth moistened with mild soap, and
then use a dry cloth to wipe it again.
• Extension sockets are forbidden.
Earthing Instructions
• This appliance must be earthed. In the event
of a malfunction or breakdown, earthing will
reduce the risk of an electric shock by providing
a path of least resistance of electric current.
This appliance is equipped with an earthing
conductor plug.
• The plug must be plugged into an appropriate
outlet that is installed and earthed in
accordance with all local codes and ordinances.
• Improper connection of the equipment-
earthing conductor can result in the risk of an
electric shock.
• Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded.
• Do not modify the plug provided with the
appliance. If it does not fit the outlet, have a
proper outlet installed by a qualified electrician.
• Do not abuse, sit on, or stand on the door or
dish rack of the dishwasher.
• Do not operate your dishwasher unless all
enclosure panels are properly in place.
• Open the door very carefully if the dishwasher is
operating, there is a risk of water splashing out.
• Do not place any heavy objects on or stand on
the door when it is open. The appliance could
tip forward.
• When loading items to be washed:
1) Locate sharp items so that they are not likely
to damage the door seal;
2) Warning: Knives and other utensils with
sharp points must be loaded in the basket
with their points facing down or placed in a
horizontal position.
• Some dishwasher detergents are strongly
alkaline. They can be extremely dangerous if
swallowed. Avoid contact with the skin and eyes
and keep children away from the dishwasher
when the door is open.
• Check that the detergent powder is empty after
completion of the wash cycle.
• Do not wash plastic items unless they are
marked “dishwasher safe” or the equivalent.
• For unmarked plastic items not so marked,
check the manufacturer’s recommendations.
• Use only detergent and rinse agents
recommended for use in an automatic
dishwasher.
• Never use soap, laundry detergent, or hand
washing detergent in your dishwasher.
• The door should not be left open, since this
could increase the risk of tripping.
• If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order to
avoid a hazard.
• During installation, the power supply must not
be excessively or dangerously bent or flattened.
• Do not tamper with controls.
• The appliance needs to be connected to the
main water valve using new hose sets.
• Old sets should not be reused.
• To save energy, in stand by mode , the
appliance will switch off automatically while
there is no any operation in 30 minutes .
Disposal
• For disposing of package and the appliance
please go to a recycling center. Therefore cut
off the power supply cable and make the door
closing device unusable.
• Cardboard packaging is manufactured from
recycled paper and should be disposed in the
waste paper collection for recycling.
• By ensuring this product is disposed of correctly,
you
will help prevent potential negative
consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling
of this product.
• For more detailed information about recycling
of this product, please contact your local city
office and your household waste disposal
service.
Important
Do not dispose this product as unsorted municipal
waste.
Collection of such waste separately for special
treatment is necessary.
Unpacking
During transportation, protective packaging
was used to protect the appliance against any
damage. After unpacking, please dispose of all
elements of packaging in a way that will not
cause damage to the environment. Please check
if the packaging materials are recyclable and are
marked with the appropriate symbol.
Caution!
During unpacking, the packaging materials (poly-
thene bags, polystyrene pieces, etc.) should be
kept out of reach of children.
5
The appliance needs to be connected to the main water valve using new hose sets.
Old sets should not be reused.
To save energy, in stand by mode , the appliance will switch off automatically
while there is no any operation in 30 minutes .
Disposal
For disposing of package and the appliance please go to a
recycling center. Therefore cut off the power supply cable and
make the door closing device unusable.
Cardboard packaging is manufactured from recycled paper and
should be disposed in the waste paper collection for recycling.
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling
of this product.
For more detailed information about recycli
ng of this product, please contact your
local city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
6 7
Product Overview Installation Instructions
Important
To get the best performance from your dishwasher, read all operating instructions before using it for the
first time.
Note
The diagrams above are only for reference, models may appear differently.
Cutlery basket
Lower basket
Upper spray arm
Upper basket
Cutlery rack
Cup rack
PRODUCT OVERVIEW
To get the best performance from your dishwasher, read all operating instructions
before using it for the first time.
IMPORTANT:
8
Pictures are only for reference, different models may be different. Please prevail
in kind.
NOTE:
Dispenser
Salt container
Filter assembly
Lower spray arm
Inner pipe
Inner pipe
Lower spray arm
Filter assembly
Dispenser
Cutlery basket
Upper basket
Lower basket
Cutlery rack Cup rackUpper spray arm
Warning
Electrical Shock Hazard
Disconnect electrical power before installing
dishwasher.
Failure to do so could result in death or electrical
shock.
Attention
The installation of the pipes and electrical equip-
ments should be done by professionals.
Power Connection
For personal safety:
• Do not use an extension cord or an adapter
plug with this appliance.
• Do not, under any circumstances, cut or remove
the earthing connection from the power cord.
Electrical requirements
Please look at the rating label to know the
rating voltage and connect the dishwasher to
the appropriate power supply. Use the required
fuse 10A, time delay fuse or circuit breaker
recommended and provide separate circuit
serving only this appliance.
Electrical connection
Ensure the voltage and frequency of the power
being corresponds to those on the rating plate.
Only insert the plug into an electrical socket
which is earthed properly. If the electrical socket
to which the appliance must be connected is
not appropriate for the plug, replace the socket,
rather than using a adapters or the like as they
could cause overheating and burns.
Warning
Ensure that proper earthing exists before use.
Water Supply and Drain
Cold water connection
Connect the cold water supply hose to a threaded
¾(inch) connector and make sure that it is
fastened tightly in place.
If the water pipes are new or have not been used
for an extended period of time, let the water
run to make sure that the water is clear. This
precaution is needed to avoid the risk of the water
inlet to be blocked and damage the appliance.
Note: Please close the hydrant after using.
Positioning the Appliance
Position the appliance in the desired location. The
back should rest against the wall behind it, and
the sides, along the adjacent cabinets or walls.
The dishwasher is equipped with water supply and
drain hoses that can be positioned either right or
the left sides to facilitate proper installation.
Levelling the appliance
Once the appliance is positioned for levelling,
the height of the dishwasher may be altered via
adjustment of the screwing level of the feet.
Do not incline the appliance more than 2°.
Freestanding Installation
Type 1: Fitting between existing cabinets
The height of the dishwasher, 845 mm, has been
designed in order to allow the machine to be fitted
between existing cabinets of the same height in
modern fitted kitchens.
The feet can be adjusted so that correct height is
reached.
The laminated top of the machine does not
require any particular care since it is heatproof,
scratchproof and stainproof.
Type 2: Underneath existing work top
(When fitting beneath a work top) In most modern
fitted kitchens there is only one single work top
under which cabinets and electrical appliances
are fitted. In this case remove the work top of the
dishwasher by unscrewing the
screws under the rear edge of the top (a).
8
Water Supply And Drain
Cold water connection
Connect the cold water supply hose to a threaded 3/4(inch)
connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an
extended period of time, let the water run to make sure that
the water is clear. This precaution is needed to avoid the risk of
the water inlet to be blocked and damage the appliance.
Please close the hydrant after using.
NOTE:
Position The Appliance
Position the appliance in the desired location. The back should rest against the wall
behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is
equipped with water supply and drain hoses that can be positioned either to the right
or the left sides to facilitate proper installation.
Levelling the appliance
Once the appliance is positioned for levelling,
the height of the dishwasher may be altered via
adjustment of the screwing level of the feet.
In any case, the appliance should not be inclined
more than 2°.
NOTE:
Only apply to the free standing dishwasher.
19
Free Standing Installation
Type 1: Fitting between existing carbinets
The height of the dishwasher, 845 mm, has
been designed in order to allow the machine
to be fitted between existing cabinets of the
same height in modern fitted kitchens. The
feet can be adjusted so that correct height is
reached.
The laminated top of the machine does not
require any particular care since it is
heatproof, scratchproof and stainproof.
厨下式用此页替换
Height (H)
Width (W)
Depth (D1)
Depth (D2)
815mm
(with the door closed)
1150mm (with the door opened 90°)
45机448，60机598
在独立式的基础上减30
独立式改为厨下式安装，专用版中的机器的尺寸需按下方修改
Position The Appliance
Position the appliance in the desired location. The back should rest against the wall
behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is
equipped with water supply and drain hoses that can be positioned either to the right
or the left sides to facilitate proper installation.
Levelling the appliance
Once the appliance is positioned for levelling, the
dishwasher may be altered via adjustment of the
screwing level of the feet. In any case, the
appliance should not be inclined more than 2°.
Type 2: Underneath existing work top
(When fitting beneath a work top)
In most modern fitted kitchens there is only one
single work top under which cabinets and
electrical appliances are fitted. In this case remove
the work top of the dishwasher by unscrewing the
screws under the rear edge of the top (a).
a
a
b
b
After removing the work top, the screws must be screwed again under the rear edge
of the top (b).
Attention
8 9
Connection of Drain Hoses
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink,
making sure to avoid bending or crimping it. The height of drain pipe must be less than 1000mm.
The free end of the hose must not be immersed in water to avoid the back flow of it.
Warning
Please securely fix the drain hose in either position A or position B.
How to drain excess water from hoses
If the sink is 1000mm higher from the floor, the excess water in hoses cannot be drained directly
into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container
that is held outside and lower than the sink.
Water outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water drain hose is not kinked or squashed.
Syphon connection
The waste connection must be at a height less than 100 cm (maximum) from the bottom of the dish.
The water drain hose should be fixed .
Extension hose
Water outlet
How to drain excess water from hoses
Syphon connection
If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained
directly into the sink. It will be necessary to drain excess water from hoses into a bowl
or suitable container that is held outside and lower than the sink.
Connect the water drain hose. The drain hose must be correctly fitted to avoid water
leaks. Ensure that the water drain hose is not kinked or squashed.
The waste connection must be at a height less than 100 cm (maximum) from the
bottom of the dish. The water drain hose should be fixed .
If you need a drain hose extension, make sure to use a similar drain hose.
It must be no longer than 4 meters; otherwise the cleaning effect of the dishwasher
could be reduced.
Connection Of Drain Hoses
Please securely fix the drain hose in either position A or position B
B
A
MAX 1000mm
Counter
Drain hose
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run
into the sink, making sure to avoid bending or crimping it. The height of drain pipe
must be less than 1000mm. The free end of the hose must not be immersed in water
to avoid the back flow of it.
Back of dishwasher
Water Inlet
Drain Pipe
Mains Cable
9
40mm
Using Your Dishwasher
Control Panel
1 Power
Press this button to turn on your dishwasher.
2 Program
Select the appropriate washing program, the
selected program. The program indicator will
be lit.
3 Delay
Press the button to set the delay time,
corresponding indicator will be lit.
4 Half Load
When you have about or less than 6 place
setting dishware to wash, you can choose this
function to save energy and water. (It can only
be used with Intensive, ECO, Glass and 90 min.)
5 Extra Dry
For better drying result. (It can only be used
with Intensive, ECO, Glass and 90 min.)
6 Child lock
This option allows you to lock the buttons
on the control panel -except the Power
button - so children cannot accidentally
start the dishwasher by pressing the buttons
on the panel. To lock or unlock the buttons
on the control panel, press and hold the
Half-load button and Extra drying button for
3 seconds simultaneously.
7 Start/Pause
To start the selected washing program or pause
it when the dishwasher is working.
8 Warning Indicators
Rinse Aid
If the indicator is lit, it means the dishwasher
is low on dishwasher rinse aid and requires
a refill.
Program end
When the program is end, the indicator
will be lit.
9 Program Indicators
Intensive
For heaviest soiled crockery, and normally soiled
pots, pans, dishes etc. With dried-on food.
ECO
This is standard program, it is suitable to clean
normally soiled tableware and it is the most
efficient program in terms of its combined
energy and water consumption for that type
of tableware.
Glass
For lightly soiled crockery and glass.
90 Minutes
For normally soiled loads that need quick wash.
Rapid
A shorter wash for lightly soiled loads that do not
need drying.
10 Delay Indicators
To show the delay time. (3h/6h/9h/12h)
E
E
C
C
O
O
3h 6h 9h 12h
1 8
6
54310 72 9
10 11
Rinse Aid and Detergent
The rinse aid is released during the final rinse
to prevent water from forming droplets on your
dishes, which can leave spots and streaks. It also
improves drying by allowing water to roll off the
dishes. Your dishwasher is designed to use liquid
rinse aids.
Warning
Only use branded rinse aid for dishwasher.
Never fill the rinse aid dispenser with any other
substances such as dishwasher cleaning agent
or liquid detergent as they may damage the
appliance.
When to refill the rinse aid dispenser
Unless the rinse-aid warning light ( ) on the
control panel is lit, you can always estimate the
amount from the color of the optical level indicator
located next to the cap.
When the rinse-aid container is full, the indicator
will be fully dark. The size of the dark dot
decreases as the rinse aid diminishes. You should
never let the rinse aid level be less than 1/4 full.
As the rinse aid diminishes, the size of the black
dot on the rinse aid level indicator changes, as
illustrated below:
Function of detergent
The chemical ingredients that compose the
detergent are necessary to remove, crush and
dispense all dirt out of the dishwasher. Most of the
commercial quality detergents are suitable for this
purpose.
Warning
Use only detergent specifically made for
dishwashers use. Keep your detergent fresh and
dry.
Don’t put powdered detergent into the dispenser
until you are ready to wash dishes.
Dishwasher detergent is corrosive!
Keep dishwasher detergent out of the reach
of children.
Filling the Rinse Aid Reservoir
1 Remove the rinse aid reservoir cap by rotating it
counterclockwise.
2 Carefully pour in the rinse-aid into its dispenser,
whilst avoiding it to overflow.
Clean up any spilled rinse aid with an
absorbent cloth
to avoid excessive foaming during the
next wash.
3 Close the rinse aid reservoir cap by rotating it
clockwise.
Adjusting the rinse aid reservoir
Turn the rinse aid indicator dial to a number
between
1 and 6. The higher the number, the more rinse aid
the dishwasher uses. If the dishes are not drying
properly or are spotted, adjust the dial to the
next higher number until your dishes are spot-
free. Reduce it if there are sticky white stains on
your dishes or a bluish film on glassware or knife
blades.
Filling the Detergent Dispenser
1 Press the release catch on the detergent
dispenser to open the cover.
2 Add detergent into the larger cavity (A) for the
main wash cycle. For more heavily soiled wash
loads, also add some detergent into the smaller
cavity (B) for the pre-wash cycle.
3 Close the cover and press on it until it locks into
place.
Note
• Be aware that depending on the soiling of
water, setting may be different.
• Please observe the manufacturer’s
recommendations on the detergent packaging.
Tips for using the Basket
Adjusting the upper basket
The height of the upper basket can be easily
adjusted to accommodate taller dishes in either
the upper or lower basket.
To adjust the height of the upper rack, follow these
steps:
1 Pull out the upper basket.
2 Remove the upper basket.
3 Re-attach the upper basket to upper or lower
roller.
4 Push in the upper basket.
The rinse aid is released during the final rinse to prevent water from forming droplets
on your dishes, which can leave spots and streaks. It also improves drying by allowing
water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
WARNING
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser
with any other substances (e.g. Dishwasher cleaning agent, liquid detergent).
This would damage the appliance.
Function Of The Rinse Aid And Detergent
When to refill the rinse aid dispenser
Unless the rinse-aid warning light ( ) on the control
panel is on, you can always estimate the amount from the
color of the optical level indicator located next to the cap.
When the rinse-aid container is full, the indicator will be
fully dark. The size of the dark dot decreases as the rinse-
aid diminishes. You should never let the rinse aid level be
less than 1/4 full.
Full
3/4 full 1/2 full 1/4 full
Empty
Optical level indicator
As the rinse aid diminishes, the size of the black dot on the rinse aid level indicator
changes, as illustrated below.
Function of detergent
The chemical ingredients that compose the detergent are necessary to remove, crush and
dispense all dirt out of the dishwasher. Most of the commercial quality detergents are
suitable for this purpose.
12
WARNING
Proper Use of Detergent
Use only detergent specifically made for dishwashers use. Keep your detergent
fresh and dry.
Don't put powdered detergent into the dispenser until you are ready to wash
dishes.
Dishwasher detergent is corrosive! Keep dishwasher
detergent out of the reach of children.
13
3
Close the rinse aid reservoir cap by
rotating it clockwise.
NOTE:
Clean up any spilled rinse aid with
an absorbent cloth to avoid
excessive foaming during the next
wash.
1 2
Remove the rinse aid reservoir cap
by rotating it counterclockwise.
Carefully pour in the rinse-aid into
its dispenser, whilst avoiding it to
overflow.
Filling The Rinse Aid Reservoir
Adjusting the rinse aid reservoir
AAddjjuusstt lleevveerr((RRiinnssee))
Turn the rinse aid indicator dial to a number between 1 and 6.
The higher the number, the more rinse aid the dishwasher uses.
If the dishes are not drying properly or are spotted, adjust the
dial to the next higher number until your dishes are spot-free.
Reduce it if there are sticky whitish stains on your dishes or a
bluish film on glassware or knife blades.
13
3
Close the rinse aid reservoir cap by
rotating it clockwise.
NOTE:
Clean up any spilled rinse aid with
an absorbent cloth to avoid
excessive foaming during the next
wash.
1 2
Remove the rinse aid reservoir cap
by rotating it counterclockwise.
Carefully pour in the rinse-aid into
its dispenser, whilst avoiding it to
overflow.
Filling The Rinse Aid Reservoir
Adjusting the rinse aid reservoir
AAddjjuusstt lleevveerr((RRiinnssee))
Turn the rinse aid indicator dial to a number between 1 and 6.
The higher the number, the more rinse aid the dishwasher uses.
If the dishes are not drying properly or are spotted, adjust the
dial to the next higher number until your dishes are spot-free.
Reduce it if there are sticky whitish stains on your dishes or a
bluish film on glassware or knife blades.
13
3
Close the rinse aid reservoir cap by
rotating it clockwise.
NOTE:
Clean up any spilled rinse aid with
an absorbent cloth to avoid
excessive foaming during the next
wash.
1 2
Remove the rinse aid reservoir cap
by rotating it counterclockwise.
Carefully pour in the rinse-aid into
its dispenser, whilst avoiding it to
overflow.
Filling The Rinse Aid Reservoir
Adjusting the rinse aid reservoir
AAddjjuusstt lleevveerr((RRiinnssee))
Turn the rinse aid indicator dial to a number between 1 and 6.
The higher the number, the more rinse aid the dishwasher uses.
If the dishes are not drying properly or are spotted, adjust the
dial to the next higher number until your dishes are spot-free.
Reduce it if there are sticky whitish stains on your dishes or a
bluish film on glassware or knife blades.
13
3
Close the rinse aid reservoir cap by
rotating it clockwise.
NOTE:
Clean up any spilled rinse aid with
an absorbent cloth to avoid
excessive foaming during the next
wash.
1 2
Remove the rinse aid reservoir cap
by rotating it counterclockwise.
Carefully pour in the rinse-aid into
its dispenser, whilst avoiding it to
overflow.
Filling The Rinse Aid Reservoir
Adjusting the rinse aid reservoir
AAddjjuusstt lleevveerr((RRiinnssee))
Turn the rinse aid indicator dial to a number between 1 and 6.
The higher the number, the more rinse aid the dishwasher uses.
If the dishes are not drying properly or are spotted, adjust the
dial to the next higher number until your dishes are spot-free.
Reduce it if there are sticky whitish stains on your dishes or a
bluish film on glassware or knife blades.
14
Filling The Detergent Dispenser
1 2
Press the release catch on the detergent
dispenser to open the cover.
Push latch to open
AA
B
Add detergent into the larger cavity
(A) for the main wash cycle .
For more heavily soiled wash loads,
also add some detergent into the
smaller cavity (B) for the pre-wash
cycle .
3
Close the cover and press on it until
it locks into place.
NOTE:
Be aware that depending on the soiling of water, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.
14
Filling The Detergent Dispenser
1 2
Press the release catch on the detergent
dispenser to open the cover.
Push latch to open
AA
B
Add detergent into the larger cavity
(A) for the main wash cycle .
For more heavily soiled wash loads,
also add some detergent into the
smaller cavity (B) for the pre-wash
cycle .
3
Close the cover and press on it until
it locks into place.
NOTE:
Be aware that depending on the soiling of water, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.
14
Filling The Detergent Dispenser
1 2
Press the release catch on the detergent
dispenser to open the cover.
Push latch to open
A
A
B
Add detergent into the larger cavity
(A) for the main wash cycle .
For more heavily soiled wash loads,
also add some detergent into the
smaller cavity (B) for the pre-wash
cycle .
3
Close the cover and press on it until
it locks into place.
NOTE:
Be aware that depending on the soiling of water, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.
Adjusting the upper basket
The height of the upper basket can be easily adjusted to accommodate taller dishes
in either the upper or lower basket.
To adjust the height of the upper rack, follow these steps:
4
1
Pull out the upper basket.
2
Remove the upper basket.
3
Re-attach the upper basket to upper
or lower rollers.
Push in the upper basket.
lower position
upper position
Basket Used Tips
Folding back the cup shelves
To make room for taller items in the upper basket, raise the cup rack upwards.
You can then lean the tall glasses against it. You can also remove it when it is not
required for use.
15
Adjusting the upper basket
The height of the upper basket can be easily adjusted to accommodate taller dishes
in either the upper or lower basket.
To adjust the height of the upper rack, follow these steps:
4
1
Pull out the upper basket.
2
Remove the upper basket.
3
Re-attach the upper basket to upper
or lower rollers.
Push in the upper basket.
lower position
upper position
Basket Used Tips
Folding back the cup shelves
To make room for taller items in the upper basket, raise the cup rack upwards.
You can then lean the tall glasses against it. You can also remove it when it is not
required for use.
15
Adjusting the upper basket
The height of the upper basket can be easily adjusted to accommodate taller dishes
in either the upper or lower basket.
To adjust the height of the upper rack, follow these steps:
4
1
Pull out the upper basket.
2
Remove the upper basket.
3
Re-attach the upper basket to upper
or lower rollers.
Push in the upper basket.
lower position
upper position
Basket Used Tips
Folding back the cup shelves
To make room for taller items in the upper basket, raise the cup rack upwards.
You can then lean the tall glasses against it. You can also remove it when it is not
required for use.
15
Adjusting the upper basket
The height of the upper basket can be easily adjusted to accommodate taller dishes
in either the upper or lower basket.
To adjust the height of the upper rack, follow these steps:
4
1
Pull out the upper basket.
2
Remove the upper basket.
3
Re-attach the upper basket to upper
or lower rollers.
Push in the upper basket.
lower position
upper position
Basket Used Tips
Folding back the cup shelves
To make room for taller items in the upper basket, raise the cup rack upwards.
You can then lean the tall glasses against it. You can also remove it when it is not
required for use.
15
12 13
Loading the lower basket
We suggest that you place large items and the
most difficult to clean items are to be placed into
the lower basket: such as pots, pans, lids, serving
dishes and bowls, as shown in the figure below. It
is preferable to place serving dishes and lids on
the side of the racks in order to avoid blocking the
rotation of the top spray arm.
The maximum diameter advised for plates in front
of the detergent dispenser is of 19 cm, this not to
tamper the opening of it.
Loading the cutlery basket
Cutlery should be placed in the cutlery rack
separately from each other in the appropriate
positions, and do make sure the utensils do not
nest together, this may cause bad performance.
Warning
• Do not let any item extend
through the bottom.
• Always load sharp utensils with
the sharp point down!
Removing the dishes
To prevent water dripping from the upper basket
into the lower basket, we recommend that you
empty the lower basket first, followed by the
upper basket.
Warning: Items will be hot!
To prevent damage, do not take glass and cutlery
out of the dishwasher for around 15 minutes after the
program has ended.
Loading The Baskets
Upper basket
1 Cups
2 Saucers
3 Glasses
Lower basket
4 Dinner plates
5 Saucers
6 Soup plates
7 Cutlery basket
Folding back the rack shelves
The spikes of the lower basket are used for holding
plates and platters. They can be lowered to make
more room for bulky items.
Preparing and Loading Dishes
• Consider buying utensils which are identified
as dishwasher-proof.
• For particular items, select a program with the
lowest possible temperature.
• To prevent damage, do not take glass and
cutlery out of the dishwasher immediately after
the program has ended.
Washing the following are not suitable:
• Cutlery with wooden, horn china or mother-of-
pearl handles
• Plastic items that are not heat resistant
• Older cutlery with glued parts that are not
temperature resistant
• Bonded cutlery items or dishes
• Pewter or cooper items
• Crystal glass
• Steel items subject to rusting
• Wooden platters
• Items made from synthetic fibers
Washing the following are of limited suitability:
• Some types of glasses can become dull after a
large number of washes
• Silver and aluminum parts have a tendency to
discolor during washing
• Glazed patterns may fade if machine washed
frequently
Recommendations for loading the dishwasher
Scrape off any large amounts of leftover food.
Soften remnants of burnt food in pans. It is not
necessary to rinse the dishes under running water.
For best performance of the dishwasher, follow
these loading guidelines.
Place objects in the dishwasher in following way:
• Items such as cups, glasses, pots, pans, etc. are
faced downwards.
• Curved items, or ones with recesses, should be
loaded aslant so that water can run off.
• All utensils are stacked securely
and can not tip over.
• All utensils are placed in the way that the spray
arms can rotate freely during washing.
• Load hollow items such as cups, glasses,
pans etc. with the opening facing downwards
so that water cannot collect in the container
or a deep base.
• Dishes and items of cutlery must not lie inside
one another, or cover each other.
• To avoid damage, glasses should not touch
one another.
• The upper basket is designed to hold more
delicate and lighter dishware such as glasses,
coffee and tea cups.
• Long bladed knives stored in an upright position
are a potential hazard!
• Long and sharp items of cutlery such as carving
knives must be positioned horizontally in the
upper basket.
• Please do not overload your dishwasher. This is
important for good results and for reasonable
consumption of energy.
Note
Very small items should not be washed in the
dishwasher
as they could easily fall out of the basket.
Loading the upper basket
The upper basket is designed to hold more
delicate and lighter dishware such as glasses,
coffee and tea cups and saucers, as well as plates,
small bowls and shallow pans
(as long as they are not too dirty). Position the
dishes and cookware so that they will not get
moved by the spray of water.
raise upwards fold backwards
Folding back the rack shelves
The spikes of the lower basket are used for holding plates and a platter.
They can be lowered to make more room for large items.
Preparing And Loading Dishes
Consider buying utensils which are identified as dishwasher-proof.
For particular items, select a program with the lowest possible temperature.
To prevent damage, do not take glass and cutlery out of the dishwasher
immediately after the program has ended.
Cutlery with wooden, horn china or mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not temperature resistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types of glasses can become dull after a large number of washes
Silver and aluminum parts have a tendency to discolor during washing
Glazed patterns may fade if machine washed frequently
For washing the following cutlery/dishes
Are not suitable
Are of limited suitability
16
Loading the upper basket
The upper basket is designed to hold more delicate and
lighter dishware such as glasses, coffee and tea cups and
saucers, as well as plates, small bowls and shallow pans
(as long as they are not too dirty). Position the dishes
and cookware so that they will not get moved by the
spray of water.
Loading the lower basket
We suggest that you place large items and the most
difficult to clean items are to be placed into the lower
basket: such as pots, pans, lids, serving dishes and bowls,
as shown in the figure below. It is preferable to place
serving dishes and lids on the side of the racks in order to
avoid blocking the rotation of the top spray arm.
The maximum diameter advised for plates in front of the
detergent dispenser is of 19 cm, this not to hamper the
opening of it.
WARNING
Do not let any item extend through the bottom.
Always load sharp utensils with the sharp point down!
Loading the cutlery basket
Cutlery should be placed in the cutlery rack separately from each other in the
appropriate positions, and do make sure the utensils do not nest together, this may
cause bad performance.
To prevent water dripping from the upper basket into the lower basket, we
recommend that you empty the lower basket first, followed by the upper basket.
Removing the dishes
WARNING
Items will be hot! To prevent damage, do not take glass and
cutlery out of the dishwasher for around 15 minutes after the
program has ended.
18
Loading the upper basket
The upper basket is designed to hold more delicate and
lighter dishware such as glasses, coffee and tea cups and
saucers, as well as plates, small bowls and shallow pans
(as long as they are not too dirty). Position the dishes
and cookware so that they will not get moved by the
spray of water.
Loading the lower basket
We suggest that you place large items and the most
difficult to clean items are to be placed into the lower
basket: such as pots, pans, lids, serving dishes and bowls,
as shown in the figure below. It is preferable to place
serving dishes and lids on the side of the racks in order to
avoid blocking the rotation of the top spray arm.
The maximum diameter advised for plates in front of the
detergent dispenser is of 19 cm, this not to hamper the
opening of it.
WARNING
Do not let any item extend through the bottom.
Always load sharp utensils with the sharp point down!
Loading the cutlery basket
Cutlery should be placed in the cutlery rack separately from each other in the
appropriate positions, and do make sure the utensils do not nest together, this may
cause bad performance.
To prevent water dripping from the upper basket into the lower basket, we
recommend that you empty the lower basket first, followed by the upper basket.
Removing the dishes
WARNING
Items will be hot! To prevent damage, do not take glass and
cutlery out of the dishwasher for around 15 minutes after the
program has ended.
18
Loading the upper basket
The upper basket is designed to hold more delicate and
lighter dishware such as glasses, coffee and tea cups and
saucers, as well as plates, small bowls and shallow pans
(as long as they are not too dirty). Position the dishes
and cookware so that they will not get moved by the
spray of water.
Loading the lower basket
We suggest that you place large items and the most
difficult to clean items are to be placed into the lower
basket: such as pots, pans, lids, serving dishes and bowls,
as shown in the figure below. It is preferable to place
serving dishes and lids on the side of the racks in order to
avoid blocking the rotation of the top spray arm.
The maximum diameter advised for plates in front of the
detergent dispenser is of 19 cm, this not to hamper the
opening of it.
WARNING
Do not let any item extend through the bottom.
Always load sharp utensils with the sharp point down!
Loading the cutlery basket
Cutlery should be placed in the cutlery rack separately from each other in the
appropriate positions, and do make sure the utensils do not nest together, this may
cause bad performance.
To prevent water dripping from the upper basket into the lower basket, we
recommend that you empty the lower basket first, followed by the upper basket.
Removing the dishes
WARNING
Items will be hot! To prevent damage, do not take glass and
cutlery out of the dishwasher for around 15 minutes after the
program has ended.
18
25
1.Upper basket:
2.Lower basket:
1
2
3
Cups
Saucers
Glasses
Item
Number
4
5
6
7
Dessert dishes
Dinner plates
Soup plates
Cutlery basket
Item
Number
LOADING THE BASKETS
ACCORDING TO AS/NZS 2007.1:
66
5577
44
55 44 44
3
3
3
3
2
2
3
3
3
3
1
1
1
1
1
1
1
1
1
1
4
4
Please place the light flat wares on the rack. The total weight is less than
1.5kg.
NOTE:
25
1.Upper basket:
2.Lower basket:
1
2
3
Cups
Saucers
Glasses
Item
Number
4
5
6
7
Dessert dishes
Dinner plates
Soup plates
Cutlery basket
Item
Number
LOADING THE BASKETS
ACCORDING TO AS/NZS 2007.1:
6
6
5
5
7
7
4
4
5
5
4
4
4
4
33
33
22
33
33
11
11
11
11
11
44
Please place the light flat wares on the rack. The total weight is less than
1.5kg.
NOTE:
14 15
Cutlery Rack
Cutlery Basket
1 Forks
2 Soup spoons
3 Dessert spoons
4 Teaspoons
5 Knives
Information for comparability tests in accordance
with (*AS/NZS 2007.1 )
Capacity: 13 place settings
Position of the upper basket: lower position
Program: ECO
Rinse aid setting: 6
Detergent(Pre/main): 5g/27.5g
Door is open at the end of the drying cycle for the drying performance test and
last 40mins. (Door position: Open 50 mm)
Programming The Dishwasher
Wash Cycle Table
The table below shows which programs are best for the levels of food residue on them and how much
detergent is needed.
It also show various information about the programs. Consumption values and program duration are
only indicative except for ECO program.
Note
( ) The need to fill rinse into the Rinse-Aid Dispenser.
Program Description of Cycle
Detergent
Pre/Main
Running
Time (min)
Energy
(Kwh)
Water
(L)
Rinse Aid
Intensive
Prewash
Wash (72°C)
Rinse
Rinse (70°C)
Drying
5/26.25g
-
1 or 2 tabs
178 1.920 15.4
ECO
(*AS/NZS 2007.1)
Wash (45°C)
Rinse
Rinse (45°C)
Drying
5/26.25g
-
1 or 2 tabs
185 0.792 10.98
Glass
Prewash
Wash (42°C)
Rinse
Rinse (60°C)
Drying
5/26.25g
-
1 or 2 tabs
125 0.900 14.6
90 Minutes
Wash (65°C)
Rinse
Rinse (66°C)
Drying
31.25g
-
1 tab
90 1.200 11.6
Rapid
Wash (40°C)
Rinse
Rinse (45°C)
27.5 g 30 0.600 11.7
Note
*AS/NZS 2007.1: This program is the test cycle. The information for comparability test in accordance with
*AS/NZS 2007.1.
3.Cutlery rack:
1
2
3
4
5
Soup spoons
Forks
Knives
Tea spoons
Dessert spoons
Item
Number
Information for comparability tests in accordance
with (*AS/NZS 2007.1 )
Capacity: 13 place settings
Position of the upper basket: lower position
Program: ECO
Rinse aid setting: 6
Detergent(Pre/main): 5g/27.5g
Door is open at the end of the drying cycle for the drying performance test and
last 40mins. (Door position: Open 50 mm)
26
Please place the light flat wares on the shelf. The total weight is less than 1.5kg.
4.Cutlery basket:
NOTE:
1 32 444 5
44
11 11 11 11
11
11
11 11 11
11 11 11 11
22 22 22
33 33 33
44 44
44 44 44 44
4444444444
44
55 55
55 55
55 55 55 55 55
55
55 55 55
3
2
3.Cutlery rack:
1
2
3
4
5
Soup spoons
Forks
Knives
Tea spoons
Dessert spoons
Item
Number
Information for comparability tests in accordance
with (*AS/NZS 2007.1 )
Capacity: 13 place settings
Position of the upper basket: lower position
Program: ECO
Rinse aid setting: 6
Detergent(Pre/main): 5g/27.5g
Door is open at the end of the drying cycle for the drying performance test and
last 40mins. (Door position: Open 50 mm)
26
Please place the light flat wares on the shelf. The total weight is less than 1.5kg.
4.Cutlery basket:
NOTE:
1 32 444 5
44
11 11 11 11
11
11
11 11 11
11 11 11 11
22 22 22
33 33 33
44 44
44 44 44 44
4444444444
44
55 55
55 55
55 55 55 55 55
55
55 55 55
3
2
3.Cutlery rack:
1
2
3
4
5
Soup spoons
Forks
Knives
Tea spoons
Dessert spoons
Item
Number
Information for comparability tests in accordance
with (*AS/NZS 2007.1 )
Capacity: 13 place settings
Position of the upper basket: lower position
Program: ECO
Rinse aid setting: 6
Detergent(Pre/main): 5g/27.5g
Door is open at the end of the drying cycle for the drying performance test and
last 40mins. (Door position: Open 50 mm)
26
Please place the light flat wares on the shelf. The total weight is less than 1.5kg.
4.Cutlery basket:
NOTE:
1 32 444 5
4
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
3
2
1 32 4 5
16 17
Saving Energy
1. Pre-rinsing of tableware items leads to increased
water and energy consumption and is not
recommended.
2. Washing tableware in a household dishwasher
usually consumes less energy and water in the
use phase than hand dishwashing when the
household dishwasher is used according to the
instructions.
Starting A Cycle Wash
1 Draw out the lower and upper basket, load the
dishes and push them back.
It is commended to load the lower basket first,
then the upper one.
2 Pour in the detergent.
3 Insert the plug into the socket. The power
supply refer to last page”Product fiche”.
Make sure that the water supply is turned on to
full pressure.
4 Close the door, press the Power button, to
switch on the machine.
5 Choose a program, the response light will turn
on.
Then press the Start/Pause button, the
dishwasher will start its cycle.
Changing The Program Mid-cycle
A wash cycle can only be changed if it has been
running for a short time otherwise, the detergent
may have already been released and the
dishwasher may have already drained the wash
water.
If this is the case, the dishwasher needs to be reset
and the detergent dispenser must be refilled. To
reset
the dishwasher, follow the instructions below:
1 Press the Start/Pause button to pause the
washing.
2 Press the Program button for more than 3
seconds, the dishwasher will enter standby
mode.
3 Press the Program button to select the desired
program.
4 Press the Start/Pause button, the dishwasher
will run after 10 seconds.
Forget to add a dish?
A forgotten dish can be added any time before the
detergent dispenser opens. If
this is the case, follow the instructions below:
1 Press the Start/Pause button to pause the
washing.
2 After the spray arms stop working, you can
open the door completely.
3 Add the forgotten items.
4 Close the door.
5 Press the Start/Pause button after 10 seconds,
the dishwasher will start.
Warning
It is dangerous to open the door mid-cycle, as hot
steam may scald you.
Forget To Add A Dish?
After 5 sec
WARNING
It is dangerous to open the door
mid-cycle, as hot steam may
scald you.
A forgotten dish can be added any time before the detergent dispenser opens. If
this is the case, follow the instructions below:
1. Press the Start/Pause button to pause the washing.
2. After the spray arms stop working, you can open the door completely.
3. Add the forgotten dishes.
4. Close the door.
5. Press the Start/Pause button after 10 seconds, the dishwasher will start.
23
Forget To Add A Dish?
After 5 sec
WARNING
It is dangerous to open the door
mid-cycle, as hot steam may
scald you.
A forgotten dish can be added any time before the detergent dispenser opens. If
this is the case, follow the instructions below:
1. Press the Start/Pause button to pause the washing.
2. After the spray arms stop working, you can open the door completely.
3. Add the forgotten dishes.
4. Close the door.
5. Press the Start/Pause button after 10 seconds, the dishwasher will start.
23
Maintenance and Cleaning
External Care
The door and the door seal
Clean the door seals regularly with a soft
damp cloth to remove food deposits. When the
dishwasher is being loaded, food and drink
residues may drip onto the sides of the dishwasher
door. These surfaces are outside the wash cabinet
and are not accessed by water from the spray
arms. Any deposits should be wiped off before the
door is closed.
The control panel
If cleaning is required, the control panel should be
wiped with a soft damp cloth only.
Warning
• To avoid penetration of water into the door lock
and electrical components, do not use a spray
cleaner of any kind.
• Never use abrasive cleaners or scouring pads on
the outer surfaces because they may scratch the
finish.
Some paper towels may also scratch or leave
marks on the surface.
Internal Care
Filtering system
The filtering system in the base of the wash
cabinet retains coarse debris from the washing
cycle. The collected coarse debris may cause the
filters to clog. Check the condition of the filters
regularly and clean them if necessary under
running water.
Follow the steps below to clean the filters in the
wash cabinet.
1 Hold the coarse filter and rotate it anticlockwise
to unlock the filter.
Lift the filter upwards and out of the
dishwasher.
2 The fine filter can be pulled off the bottom
of the filter assembly. The coarse filter can
be detached from the main filter by gently
squeezing the tabs at the top and pulling it
away.
3 Larger food remnants can be cleaned by rinsing
the filter under running water. For a more
thorough clean, use a soft cleaning brush.
4 Reassemble the filters in the reverse order of the
disassembly, replace the filter insert, and rotate
clockwise to the close arrow.
Warning
• Do not over tighten the filters. Put the filters
back in sequence securely, otherwise coarse
debris could get into the system and cause a
blockage.
• Never use the dishwasher without filters in
place. Improper replacement of the filter may
reduce the performance level of the appliance
and damage dishes and utensils.
1 2
Hold the coarse filter and rotate it
anticlockwise to unlock the filter.
Lift the filter upwards and out of
the dishwasher.
The fine filter can be pulled off the
bottom of the filter assembly.
The coarse filter can be detached
from the main filter by gently
squeezing the tabs at the top and
pulling it away.
3 4
Larger food remnants can be
cleaned by rinsing the filter under
running water.
For a more thorough clean, use a
soft cleaning brush.
Reassemble the filters in the reverse
order of the disassembly, replace the
filter insert, and rotate clockwise to
the close arrow.
Do not over tighten the filters. Put the filters back in sequence securely,
otherwise coarse debris could get into the system and cause a blockage.
Never use the dishwasher without filters in place. Improper replacement of
the filter may reduce the performance level of the appliance and damage
dishes and utensils.
WARNING
Main filter Main filter
Coarse filterCoarse filter
Fine filter
25
1 2
Hold the coarse filter and rotate it
anticlockwise to unlock the filter.
Lift the filter upwards and out of
the dishwasher.
The fine filter can be pulled off the
bottom of the filter assembly.
The coarse filter can be detached
from the main filter by gently
squeezing the tabs at the top and
pulling it away.
3 4
Larger food remnants can be
cleaned by rinsing the filter under
running water.
For a more thorough clean, use a
soft cleaning brush.
Reassemble the filters in the reverse
order of the disassembly, replace the
filter insert, and rotate clockwise to
the close arrow.
Do not over tighten the filters. Put the filters back in sequence securely,
otherwise coarse debris could get into the system and cause a blockage.
Never use the dishwasher without filters in place. Improper replacement of
the filter may reduce the performance level of the appliance and damage
dishes and utensils.
WARNING
Main filter Main filter
Coarse filterCoarse filter
Fine filter
25
1 2
Hold the coarse filter and rotate it
anticlockwise to unlock the filter.
Lift the filter upwards and out of
the dishwasher.
The fine filter can be pulled off the
bottom of the filter assembly.
The coarse filter can be detached
from the main filter by gently
squeezing the tabs at the top and
pulling it away.
3 4
Larger food remnants can be
cleaned by rinsing the filter under
running water.
For a more thorough clean, use a
soft cleaning brush.
Reassemble the filters in the reverse
order of the disassembly, replace the
filter insert, and rotate clockwise to
the close arrow.
Do not over tighten the filters. Put the filters back in sequence securely,
otherwise coarse debris could get into the system and cause a blockage.
Never use the dishwasher without filters in place. Improper replacement of
the filter may reduce the performance level of the appliance and damage
dishes and utensils.
WARNING
Main filter Main filter
Coarse filter
Coarse filter
Fine filter
25
1 2
Hold the coarse filter and rotate it
anticlockwise to unlock the filter.
Lift the filter upwards and out of
the dishwasher.
The fine filter can be pulled off the
bottom of the filter assembly.
The coarse filter can be detached
from the main filter by gently
squeezing the tabs at the top and
pulling it away.
3 4
Larger food remnants can be
cleaned by rinsing the filter under
running water.
For a more thorough clean, use a
soft cleaning brush.
Reassemble the filters in the reverse
order of the disassembly, replace the
filter insert, and rotate clockwise to
the close arrow.
Do not over tighten the filters. Put the filters back in sequence securely,
otherwise coarse debris could get into the system and cause a blockage.
Never use the dishwasher without filters in place. Improper replacement of
the filter may reduce the performance level of the appliance and damage
dishes and utensils.
WARNING
Main filter Main filter
Coarse filterCoarse filter
Fine filter
25
18 19
Spray arms
It is necessary to clean the spray arms regularly for
hard water chemicals will clog the spray arm jets
and bearings.
To clean the spray arms, follow the instructions
below:
1 To remove the upper spray arm, hold the nut,
rotate the arm clockwise to remove it.
2 To remove the lower spray arm, pull out the
spray arm upward.
3 Wash the arms in soapy and warm water and
use a soft brush to clean the jets. Replace them
after rinsing them thoroughly.
Caring For The Dishwasher
Frost precaution
Please take frost protection measures on the
dishwasher in winter. Every time after washing
cycles, please operate as follows:
1 Cut off the electrical power to the dishwasher at
the supply source.
2 Turn off the water supply and disconnect the
water inlet pipe from the water valve.
3 Drain the water from the inlet pipe and water
valve. (Use a pan to gather the water)
4 Reconnect the water inlet pipe to the water
valve.
5 Remove the filter at the bottom of the tub and
use a sponge to soak up water in the sump.
After every wash
After every wash, turn off the water supply to the
appliance and leave the door slightly open so that
moisture and odors are not trapped inside.
Remove the plug
Before cleaning or performing maintenance,
always remove the plug from the socket.
No solvents or abrasive cleaning
To clean the exterior and rubber parts of the
dishwasher, do not use solvents or abrasive
cleaning products. Only use a cloth with warm
soapy water.
To remove spots or stains from the surface of
the interior, use a cloth dampened with water
an a little vinegar, or a cleaning product made
specifically for dishwashers.
When not in use for a longtime
It is recommend that you run a wash cycle with the
dishwasher empty and then remove the plug from
the socket, turn off the water supply and leave the
door of the appliance slightly open. This will help
the door seals to last longer and prevent odors
from forming within the appliance.
Moving the appliance
If the appliance must be moved, try to keep it in
the vertical position. If absolutely necessary, it can
be positioned on its back.
Seals
One of the factors that cause odours to form in the
dishwasher is food that remains trapped in the
seals. Periodic cleaning with a damp sponge will
prevent this from occurring.
Spray arms
Wash the arms in soapy and warm
water and use a soft brush to clean
the jets. Replace them after rinsing
them thoroughly.
It is necessary to clean the spray arms regularly for hard water chemicals will clog the
spray arm jets and bearings.
To clean the spray arms, follow the instructions below:
2
3
To remove the lower spray arm, pull
out the spray arm upward.
1
To remove the upper spray arm,
hold the nut, rotate the arm
clockwise to remove it.
26
Spray arms
Wash the arms in soapy and warm
water and use a soft brush to clean
the jets. Replace them after rinsing
them thoroughly.
It is necessary to clean the spray arms regularly for hard water chemicals will clog the
spray arm jets and bearings.
To clean the spray arms, follow the instructions below:
2
3
To remove the lower spray arm, pull
out the spray arm upward.
1
To remove the upper spray arm,
hold the nut, rotate the arm
clockwise to remove it.
26
Spray arms
Wash the arms in soapy and warm
water and use a soft brush to clean
the jets. Replace them after rinsing
them thoroughly.
It is necessary to clean the spray arms regularly for hard water chemicals will clog the
spray arm jets and bearings.
To clean the spray arms, follow the instructions below:
2
3
To remove the lower spray arm, pull
out the spray arm upward.
1
To remove the upper spray arm,
hold the nut, rotate the arm
clockwise to remove it.
26
Troubleshooting
Before Calling For Service
Reviewing the charts on the following pages may save you from calling for service.
If in doubt, or the following doesn’t offer a solution, please contact our After Sales Support on: 1300 11 4357
Problem Possible Causes What To Do
Dishwasher
doesn’t start
• Fuse blown, or the circuit break
tripped
• Power supply is not turned on
• Water pressure is low
• Door of dishwasher not properly
closed
• Replace fuse or reset circuit breaker. Remove any
other appliances sharing the same circuit with the
dishwasher
• Make sure the dishwasher is turned on and the
door is closed securely. Make sure the power cord
is properly plugged into the wall socket
• Check that the water supply is connected properly
and the water is turned on
• Make sure to close the door properly and latch it
Water not
pumped form
dishwasher
• Twisted or trapped drain hose
• Filter clogged
• Kitchen sink clogged
• Check the drain hose
• Check coarse the filter
• Check the kitchen sink to make sure it is draining
well.
If the problem is the kitchen sink that is not
draining, you may need a plumber rather than a
service technician for this issue
Suds in the tub
• Wrong detergent
• Spilled rinse-aid
• Use only the special dishwasher detergent to
avoid suds. If this occurs, open the dishwasher
and let suds evaporate. Add 3.5 litres of cold
water to the bottom of the dishwasher. Close the
dishwasher door, then select any cycle. Initially,
the dishwasher will drain out the water. Open the
door after draining stage is complete and check if
the suds have disappeared
Repeat if necessary.
• Always wipe up rinse-aid spills immediately
Stained tub
interior
• Detergent with colourant may
have been used
• Make sure that the detergent has no colourant
White film on
inside surface
• Hard water minerals • To clean the interior, use a damp sponge with
dishwasher detergent and wear rubber gloves.
Never use any other cleaner than dishwasher
detergent otherwise, it may cause foaming or
suds
There are rust
stains on cutlery
• The affected items are not
corrosion resistant
• The items should be corrosion resistant
Knocking noise in
the dishwasher
• A spray arm is knocking against
an item in a basket
• Interrupt the program and rearrange the items
which are obstructing the spray arm
20 21
Troubleshooting continued
Problem Possible Causes What To Do
Rattling noise in
the dishwasher
• tems of crockery are loose in the
dishwasher.
• Interrupt the program and rearrange the items
of crockery.
Knocking noise
in the water
pipes
• This may be caused by on-site
installation or the cross-section of
the piping
• This has no influence on the dishwasher
function.
If in doubt, contact our After Sales Support on:
1300 11 4357
The dishes are
not clean
• The dishes were not loaded correctly
• The program was not powerful
enough
• Not enough detergent was
dispensed
• Items are blocking the movement of
the spray arms
• The filter combination is not clean or
is not correctly fitted in the base of
wash cabinet.
This may cause the spray arm jets to
get blocked.
• Refer to the “Preparing and Loading Dishes”
section of this manual
• Select a more intensive program
• Use more detergent, or change your detergent.
• Rearrange the items so that the spray can
rotate freely.
• Clean and/or fit the filter correctly.
Clean the spray arm jets.
Cloudiness on
glassware
• Combination of soft water and too
much detergent
• Use less detergent if you have soft water and
select a shorter cycle to wash the glassware
and to get them clean.
Black or grey
marks on dishes
• Aluminium utensils have rubbed
against dishes
• Use a mild abrasive cleaner to eliminate those
marks.
Detergent left in
dispenser
• Dishes block detergent dispenser • Re-load the dishes properly.
The dishes
aren’t drying
• Improper loading
• Too little rinse-aid
• Dishes are removed too soon
• Wrong program has been selected.
• Use of cutlery with a low-quality
coating.
• Load the dishwasher as suggested in this
manual.
• Increase the amount of rinse-aid/refill the
rinse-aid dispenser
• Do not empty your dishwasher immediately
after washing. Open the door slightly so that
the steam can come out. Take out the dishes
until the inside temperature is safe to touch.
Unload the lower basket first to prevent the
dropping water from the upper basket.
• With a short program, the washing
temperature is lower, decreasing cleaning
performance.
Choose a program with a long washing time.
• Water drainage is more difficult with these
items. Cutlery or dishes of this type are not
suitable for washing in the dishwasher.
Error Codes
If there is a malfunction, the dishwasher will display error codes to identify these:
Codes Meanings Possible Causes
The Rapid
indicator
flashes
frequently
Longer inlet time. Faucets is not opened, or water intake is
restricted,
or water pressure is too low.
The 90 minutes
and Rapid
indicator
flashes
frequently
Not reaching required temperature. Malfunction of heating element.
The Glass
indicator
flashes
frequently
Overflow. Some element of dishwasher leaks.
The ECO, Glass
and Rapid
indicator
flashes
frequently
Failure of communication between
main circuit board with display
circuit board.
Open circuit or a break in wiring.
Warning
• If overflow occurs, turn off the main water supply before calling a service
• If there is water in the base pan because of an overfill or small leak, the water should be removed
before restarting the dishwasher
• If there is an error code that cannot be solved, please request professional assistance
22 23
Technical Information
Product Dimensions
Product Information
Models GGSDW6013X / GGSDW6013W
Standard place settings 13
Energy efficiency class
(MEPS)
3 Stars
Water consumption
class
(WELS)
4.5 Stars
Standard cleaning cycle ECO
Energy consumption of
the standard cleaning
cycle
0.792 kWh
Water consumption of
the standard cleaning
cycle
10.98 litre
Program duration of the
standard cleaning cycle
185 min
Noise level 52 dB(A) re 1 pW
Mounting Freestanding
Could be built-in Yes
Power consumption 1760–2100W
Rated voltage /
frequency
AC 220-240V/50Hz
Water pressure
(flow pressure)
0.04-1.0MPa=0.4-10 bar
TECHNICAL INFORMATION
Height (H)
Width (W)
Depth (D1)
Depth (D2)
845mm
598mm
600mm (with the door closed)
1175mm (with the door opened 90°)
W
W
D1
D1
H
H
32
D2
D2
Height (H): 845mm
Width (W): 598mm
Depth (D1): 600mm (with the door closed)
Depth (D2): 1175mm (with the door opened 90°)
24 25
Attach your receipt to this page
For future reference, please record the following information which can be found on
the rating plate and the date of purchase which can be found on your sales invoice.
STORE DETAILS
STORE NAME
|
ADDRESS
|
TELEPHONE
|
PURCHASE DATE
|
PRODUCT DETAILS
MODEL NO.
|
SERIAL NO.*
|
Purchase Details
26 27
Warranty Information
WARRANTY TERMS & CONDITIONS
DISHWASHERS
This document sets out the terms and conditions of the
product warranties for Residentia Group Appliances. It is
an important document. Please keep it with your proof of
purchase documents in a safe place for future reference
should you require service for your Appliance.
1. IN THIS WARRANTY
(a) ‘acceptable quality’ as referred to in clause 10 of
this warranty has the same meaning referred to
in the ACL;
(b) ‘ACL’ means Trade Practices Amendment
(Australian Consumer Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Residentia Group product
purchased by you accompanied by this document;
(d) ‘ASR’ means Residentia Group authorised service
representative;
(e) ‘Residentia Group’ means Residentia Group Pty Ltd
of 165 Barkly Ave, Burnley VIC 3121, ACN 600
546 656 in respect of Appliances purchased in
Australia;
(f ) ‘major failure’ as referred to in clause 10 of this
warranty has the same meaning referred to
in the ACL and includes a situation when an
Appliance cannot be repaired or it is uneconomic
for Residentia Group, at its discretion, to repair an
Appliance during the Warranty Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for personal,
domestic or household use (i.e. normal
single family use) as set out in the instruction
manual, the Appliance is warranted against
manufacturing defects for 24 months,
following the date of original purchase of the
Appliance;
(h) ‘you’ means the purchaser of the Appliance not
having purchased the Appliance for re-sale, and
‘your’ has a corresponding meaning.
2. This warranty only applies to Appliances purchased
and used in Australia and is in addition to (and does
not exclude, restrict, or modify in any way) any
non-excludable statutory warranties in Australia.
3. During the Warranty Period Residentia Group or its
ASR will, at no extra charge if your Appliance is readily
accessible for service, without special equipment and
subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Residentia
Group or its ASR may use remanufactured parts to
repair your Appliance. You agree that any replaced
Appliances or parts become the property of Residentia
Group. This warranty does not apply to light globes,
batteries, filters or similar perishable parts.
4. Parts and Appliances not supplied by Residentia
Group are not covered by this warranty.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
The Australian Consumer Law requires
the inclusion of the following statement
with this warranty:
5. You will bear the cost of transportation, travel and
delivery of the Appliance to and from Residentia
Group or its ASR. If you reside outside of the service
area, you will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance
to and from Residentia Group or its ASR, in all
instances, unless the Appliance is transported
by Residentia Group or its ASR, the Appliance is
transported at the owner’s cost and risk while in
transit to and from Residentia Group or its ASR.
6. Proof of purchase is required before you can make a
claim under this warranty.
7. You may not make a claim under this warranty unless
the defect claimed is due to faulty or defective parts
or workmanship. Residentia Group is not liable in the
following situations (which are not exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly
maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm damage or
incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate
operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional
instructions supplied with the Appliance;
(b) the Appliance is modified without authority from
Residentia Group in writing;
(c) the Appliance’s serial number or warranty seal
has been removed or defaced;
(d) the Appliance was serviced or repaired by anyone
other than Residentia Group, an authorised
repairer or ASR.
8. This warranty, the contract to which it relates and the
relationship between you and Residentia Group are
governed by the law applicable where the Appliance
was purchased.
9. To the extent permitted by law, Residentia Group
excludes all warranties and liabilities (other than as
contained in this document) including liability for any
loss or damage whether direct or indirect arising from
your purchase, use or non use of the Appliance.
10. For Appliances and services provided by Residentia
Group in Australia, the Appliances come with a
guarantee by Residentia Group that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled
to have the Appliance repaired or replaced if the
Appliance fails to be of acceptable quality and
the failure does not amount to a major failure. The
benefits to you given by this warranty are in addition
to your other rights and remedies under a law in
relation to the Appliances or services to which the
warranty relates.
11. At all times during the Warranty Period, Residentia
Group shall, at its discretion, determine whether
repair, replacement or refund will apply if an
Appliance has a valid warranty claim applicable to it.
12. Missing parts are not covered by warranty. Residentia
Group reserves the right to assess each request
for missing parts in a case by case basis. Any parts
that are not reported missing in the first week after
purchase will not provide free of charge.
13. To enquire about claiming under this warranty, please
follow these steps:
(a) carefully check the operating instructions, user
manual and the terms of this warranty;
(b) have the model and serial number of the
Appliance available;
(c) have the proof of purchase (e.g. an invoice)
available;
(d) telephone the numbers shown below.
14. You accept that if you make a warranty claim,
Residentia Group and its ASR may exchange
information in relation to you to enable Residentia
Group to meet its obligations under this warranty.
IMPORTANT
Before calling for service, please ensure that the steps in
point 13 have been followed.
Telephone contacts
► Service: Please call 1300 11 HELP (4357)
T. 1300 11 4357
E. support@residentiagroup.com.au
E S S E N T I A L S FOR LIFE
An initiative by
Residentia Group
www.solt.house
