Owner's Manual

This is the main product document for model PMP150.

The file format is pdf, 16 pages, you can download this manual here .

background
V PMP150-101518
Owner’s Manual
WWW.BODYSOLID.COM
PMP150
MULTIPRESS RACK
background
2
WARNING
Safety and Maintenance
of Cables
IMPORTANT: Cables are
wear items. It is your
responsibility to prevent
unexpected breakage.
Cable inspection should
be performed daily.
Inspect all cables, the
nylon coating on all
cables, and the area
near the fitting at each
end of each cable.
Replace any damaged or
worn cable immediately.
Do not allow the machine
to be used until damaged
or worn cables are
replaced. Using or allowing
a machine to be used
with a suspect cable can
result in serious injury. See
Owner’s Manual for more
information.
For Body-Solid Customer Service
Call 1-800-556-3113


background
3
PMP150
TABLE OF CONTENTS
•SAFETY INSTRUCTIONS.......................
•PREPARATION.......................................
•PART/HARDWARE LIST..........................
•HARDWARE ILLUSTRATION.................
•ASSEMBLY INSTRUCTIONS.................
•EXPLODED VIEW...................................
•CONTACT PAGE.....................................
PAGE 4
PAGE 5
PAGE 6
PAGE 7
PAGE 8
PAGE 15
PAGE 16
background
4
PMP150
SAFETY INSTRUCTIONS
When using exercise equipment,
you should always take basic
precautions including the
following:
• ReadallinstructionsbeforeusingthePMP150.These
instructionsarewrittentoensureyoursafetyandto
protecttheunit.
• Donotremoveanysafetylabelsfromthe
machine.
• Donotallowchildrenonorneartheequipment.
• Usetheequipmentonlyforitsintendedpurpose
asdescribedinthisguide.Donotuseaccessory
attachmentsthatarenotrecommendedbythe
manufacturer.Suchattachmentsmightcauseserious
injuries.
• Wearproperexcerciseclothingandshoesforyour
workout,nolooseclothing.
• Keephands,limbs,looseclothing,andlonghairwell
outofthewayofallmovingparts
• Usecarewhengettingonorofftheunit.
• Donooverexertyourselforworktoexhaustion.
• Ifyoufeelanypainorabnormalsymptoms,stopyour
workoutimmediatelyandconsultyourphysician.
• Neveroperateunitwhenithasbeendroppedor
damaged.Returntheequipmenttoaservicecenter
forexaminationandrepair.
• Neverdroporinsertobjectsintoanyopeninginthe
equipment.
• Alwayschecktheunitanditscablesbeforeeachuse.
Makesurethatallfastenersandcablesaresecure
andingoodworkingcondition.
• Donotusetheequipmentoutdoorsornearwater.
Personal Safety During Assembly
• Beforebeginningassembly,pleasetakethetimeto
readtheinstructionsthoroughly.
• Readeachstepintheassemblyinstructionsand
followthestepsinsequence.Donotskipahead.If
youskipahead,youmaylearnlaterthatyouhave
todisassemblecomponentsandthatyoumayhave
damagedtheequipment
• AssembleandoperatethePMP150onasolid,level
surface.Locatetheunitafewfeetfromthewallsor
furnituretoprovideeasyaccess.
ThePMP150isdesignedforyourenjoyment.By
followingtheseprecautionsandusingcommonsense,
youwillhavemanysafeandpleasurablehoursof
healthfulexercisewithyourPowerlineMultiPress
Rack.
Afterassembly,youshouldcheckallfunctionsto
ensurecorrectoperation.Ifyouexperienceproblems,
rstrechecktheassemblyinstructionstolocateany
possibleerrorsmadeduringassembly.Ifyouare
unabletocorrecttheproblem,callthedealerfrom
whomyoupurchasedthemachineorcall1-800-556-
3113forthedealernearestyou.
Obtaining Service
PleaseusethisOwner’sManualtomakesurethat
allpartshavebeenincludedinyourshipment.When
orderingparts,youmustusethepartnumberand
descriptionfromthisOwner’sManual.Useonly
PowerlinebyBodySolidreplacementpartswhen
servicingthismachine.Failuretodosowillvoidyour
warrantyandcouldresultinpersonalinjury.
Forinformationaboutproductoperationor
service,checkouttheofcialPowerlinewebsite
atwww.bodysolid.comorcontactanauthorized
PowerlinedealeroraPowerlinefactory-authorized
servicecompanyorcontactBody-Solidcustomer
serviceatoneofthefollowing:
TollFree:1-800-556-3113
Phone: 1-708-427-3555
Fax: 1-708-427-3556
Email: [email protected]
Orwriteto:Body-Solid,Inc.
ServiceDepartment
1900S.DesPlainesAve.
ForestPark,IL60130USA
Retain this Owner’s Manual for
furture reference. Part numbers
are required when ordering parts.
background
PMP150
PREPARATION
Required tools
Thebasictoolsthatyoumustobtainbeforeassembling
thePMP150includebutarenotlimitto:
•StandardWrenchSet
•MetricWrenchSet
•AdjustableWrench
•Standard/MetricAllenKeySet
Installation Requirements
Followtheseinstallationrequirementswhenassembling
thePMP150:
SetupthePMP150onasolid,atsurface.Asmooth,at
surfaceunderthemachinehelpskeepitlevel.
Provideamplespacearoundthemachine.Openspace
aroundthemachineallowsforeasieraccess.
Foraestheticpurposes,insertallboltsinthesame
directionunlessspecied(intextorillustrations)todo
otherwise.
Leaveroomforadjustments.Tightenfastenerssuchas
bolts,nuts,andscrewssotheunitisstable,butleave
roomforadjustments.Donotfullytightenfastenersuntil
instructedintheassemblystepstodoso.
Filloutandmailthewarrantycard.
Ordering Replacement Parts
Ifyouneedtoorderreplacementpartspleasebe
preparedtoprovidethefollowinginformation
whencontactingussothatwecanassistyoubetter.
1.ModelNumber
2.PlaceofPurchase
3.SerialNumber(S/N)
4.Part#andDescription
Assembly Tips
Readall“Notes”oneachpagebeforebeginningeachstep.
WhileyoumaybeabletoassemblethePMP150usingthe
illustrationsonly,importantsafetynotesandothertipsmaybe
includedinthetext.
Somepiecesmayhaveextraholesthatyouwillnotuse.Use
onlythoseholesindicatedintheinstructionsandillustrations.
NOTE: Withsomanyassembledparts,proper
alignmentandadjustmentiscritical.While
tighteningthenutsandbolts,besuretoleave
roomforadjustments.
NOTE: Thebottlesthataremarked“Poison”isyour
touchuppaint.Keepawayfromchildren.
CAUTION:Obtainassistance!Ifyoufeellikeyoucan’t
assemblethePMP150byyourselfthendo
notattempttodosoasthiscouldresultin
injury.ReviewtheInstallationRequirements
beforeproceedingwiththefollowingsteps.
5
↑
YOUR S/N # CAN
BE FOUND HERE
background
PMP150
PART LIST
6
Part #
A
B
C
D
E
F
G
H
J
K
1
2
3
4
5
6
7
8
QTY
2
2
2
1
4
4
1
1
1
1
20
8
40
10
2
2
2
16
DESCRIPTION
FRONT UPRIGHT
SIDE CROSSMEMBER
REAR UPRIGHT
CENTER CROSSMEMBER
WEIGHT HORN
STEEL PLATE
LEFT J-CUP
RIGHT J-CUP
RIGHT SPOTTER ARM
LEFT SPOTTER ARM
M10x75mm HEX HEAD BOLT
M5x10mm FLAT HEAD CAP SCREW
M10 WASHER
M10 NYLON LOCKNUT
PLASTIC PAD, 90x46mm
PLASTIC PAD, 53x46mm
PLASTIC PAD, 310x46mm
PROTECTIVE FILM
background
PMP150
HARDWARE ILLUSTRATION
7
Part #4 M10 NYLON LOCKNUT QTY.10
Part #3 M10 WASHER QTY. 40
Part #1 M10x75mm HEX HEAD BOLT QTY. 20
Part #2 M5x10mm FLAT HEAD CAP SCREW QTY. 8



































































































































































background
PMP150
STEP 1
BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE
SEQUENCE THAT THEY ARE PRESENTED.
NOTE:
finger tighten all hardware FIRST. some components may be pre-assem-
bled.
1A. attach Rear Uprights (C) to Center Crossmember (D)
using:
4 - (#1) m10x75mm hex head bolt
8 - (#3) m10 flat washer
4 - (#4) m10 nylon lock nut
2 - ( E ) Weight Horn
8
background
PMP150
STEP 1
9
above shows step 1 assembled
and completed
background
PMP150
STEP 2
BE CAREFUL TO ASSEMBLE ALL COMPONENTS
IN THE SEQUENCE THAT THEY ARE PRESENTED.
NOTE:
finger tighten all hardware FIRST. wrench tighten all hardware
at the END of step 2C. some components may be pre-assembled.
nylon lock nuts will not fully screw onto bolts, must wrench tighten.
2A. attach Front Uprights (A) to Rear Uprights (C) using:
4 - (#1) m10x75mm hex head bolt
8 - (#3) m10 flat washer
4 - (#4) m10 nylon lock nut
2B. attach Side Crossmembers (B) to Rear Uprights (C)
using:
4 - (#1) m10x75mm hex head bolt
8 - (#3) m10 flat washer
4 - (#4) m10 nylon lock nut
2 - ( F ) steel plate
2C. attach Side Crossmembers (B) to Front Uprights (A)
using:
4 - (#1) m10x75mm hex head bolt
8 - (#3) m10 flat washer
4 - (#4) m10 nylon lock nut
10
background
PMP150
STEP 2
11
above shows step 2 assembled
and completed
background
PMP150
STEP 3
BE CAREFUL TO ASSEMBLE ALL COMPONENTS
IN THE SEQUENCE THAT THEY ARE PRESENTED.
NOTE:
some components may be pre-assembled. nylon lock nuts will not fully
screw onto bolts, must wrench tighten.
3A. attach Weight Horns (E) to Rear Uprights (C) using:
4 - (#1) m10x75mm hex head bolt
8 - (#3) m10 flat washer
4 - (#4) m10 nylon lock nut
2 - ( F ) steel plate
Adjustable J Cups & Spotter Arms
3B. attach J cups (H & G) to Front Uprights.
3C. Attach Spotter Arms (J & K) to front uprights.
12
background
PMP150
STEP 3
13
above shows step 3 assembled
and completed
background
14
PMP150
NOTE
background
PMP150
EXPLODED VIEW
15
background
PMP150
S/N # 014794-��-��-����-����
please write your serial number in the boxes below
