BKP18C600
Original instructions
2
2
Important!
It is essential that you read the instructions in this manual before
assembling, operating and maintaining the product.
Subject to technical modifications.
3
3
1
7
10
11
12
2
3
4
5
6
8
9
1. Short cartridge Holder (300ml)
2. Short plunger rod (for 300ml cartridge)
3. Trigger lock
4. Trigger
5. Speed dial
6. Handle, insulated gripping surface
7. Battery port
8. Belt clip
9. Belt clip screw
10. Long Cartridge Holder (600ml)
11. Nozzle
12. 600ml Plunger Rod
4
4
8
9
10
11
6
7
8
5
START
STOP
5
5
1
2
3
Remove the battery pack before starting any
work on the machine.
6
6
1
2
2
1
click
7
7
78-100 %
33-54 %
55-77 %
10-32 %
<10 %
8
8
2
1
2
1
START
16
STOP
Remove the battery pack before starting any
work on the machine.
1
2
9
9
1
2
3
4
Remove the battery pack before starting any
work on the machine.
2
1
1
2
1
2
Long Plunger rod (for
600ml cartridge)
Replacing short 300ml cartridge holder
with long 600ml cartridge holder.
10
10
5
6
7
1
2
8
1
2
Long Plunger rod (for
600ml cartridge)
11
11
++
2
3
1
4
5
6
12
12
BATTERY AND CHARGER
Compatible battery pack
(not included)
Compatible charger
(not included)
L1815R
L1820R
L1825R
L1830R
L1840R
L1850R
L1860R
L1860B
L1860R-X5
L1890R
AL18G
AL1218G
BL1218
BLK1218
BL18DP-X5
BL18DP2-X5
Use AEG 18V battery and charger only
WARNING! Read all safety warnings, instructions, illustrations
and specifications provided with this power tool. Failure to follow
all instructions listed below may result in electric shock, fire and/
or serious injury. Save all warnings and instructions for future
reference.
CAULKING GUN SAFETY WARNINGS
Keep hands out of the piston and rod area of the caulking gun. Fingers
can be pinched between the tube holder and the piston.
Never reach into the danger area of the product when it is running.
Immediately switch o the product in case of considerable vibrations
or if other malfunctions occur. Check the product in order to find out
the cause.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG Distributors oer to retrieve old batteries to
protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System GBS chargers for charging System GBS battery
packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only in dry
rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load
or extreme temperatures. In case of contact with battery acid wash
it o immediately with soap and water. In case of eye contact rinse
thoroughly for at least 10 minutes and immediately seek medical
attention.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of fire, personal injury, and product
damage due to a short circuit, never immerse your tool, battery pack
TECHNICAL DATA CORDLESS CAULKING GUN
BKP18C600
Rated voltage 18V
No-load speed
Setting 1 5.08 cm/min
Setting 2 10.16 cm/min
Setting 3 15.24 cm/min
Setting 4 22.86 cm/min
Setting 5 43.18 cm/min
Setting 6 66.04 cm/min
Weight - not including battery pack 2.33 kg
Recommended ambient operating temperature -18 to + 50 °C
Measured values determined according to EN 60745. Typically, the A-weighted noise levels of the tool are:
A-weighted sound pressure level L
P
= 56.5 dB(A)
Uncertainty K 3 dB(A)
A-weighted sound power level L
W
= 67.5 dB(A)
Uncertainty K 3 dB(A)
Wear ear protectors.
The vibration total values (triaxial vector sum) determined according to EN 60745:
Vibration emission value a
h
< 2.5 m/s
2
Uncertainty K 1.5 m/s
2
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and
may be used to compare one tool with another. It may be used for a preliminary assessment of exposure. The declared vibration emission level
represents the main applications of the tool. However if the tool is used for dierent applications, with dierent accessories or poorly maintained,
the vibration emission may dier. This may significantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is running but
not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration such as: maintain the tool and the accessories, keep the
hands warm, organisation of work patterns.
13
13
or charger in fluid or allow a fluid to flow inside them. Corrosive or
conductive fluids, such as seawater, certain industrial chemicals, and
bleach or bleach containing products, etc., can cause a short circuit.
SPECIFIED CONDITIONS OF USE
The caulking gun is intended to be used only by adults who have
read and understood the instructions and warnings in this manual
and can be considered responsible for their actions. The caulking gun
is designed for the following purposes:
Ŷ Sealing cracks to keep your home’s conditioned air inside while
keeping unconditioned air outside, increasing your home’s energy
efficiency.
Ŷ Filling holes and cracks before painting.
Ŷ Creating a moisture barrier around areas that could be damaged
by water.
Ŷ Sealing cracks to keep insects from crawling inside your home.
Ŷ Applying adhesive.
Do not use the product in any way other than those stated for
intended use.
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of
the battery pack. Avoid extended exposure to heat or sunshine (risk
of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C and away
from moisture.
Store the battery packs in a 30% - 50% charged condition.
Every six months of storage, charge the pack as normal.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
Ŷ The user can transport the batteries by road without further
requirements.
Ŷ Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
Ŷ Ensure that battery contact terminals are protected and insulated
to prevent short circuit.
Ŷ Ensure that battery pack is secured against movement within
packaging.
Ŷ Do not transport batteries that are cracked or leaking.
Check with forwarding company for further advice.
BATTERY PACK PROTECTION
The battery pack has overload protection that protects it from being
overloaded and helps to ensure long life. Under extreme stress the
battery electronics switch o the machine automatically. To restart,
switch the machine o and then on again. If the machine does not
start up again, the battery pack may have discharged completely. In
this case it must be recharged in the battery charger.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should components
need to be replaced which have not been described, please contact
one of our AEG service agents (see our list of guarantee/service
addresses).
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label and
order the drawing at your local service agents or directly at:
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797
New Zealand
SYMBOLS
Safety alert
n
Rated speed
V
Volts
Direct current
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Please read the instructions carefully before starting
the machine.
Parts or accessories sold separately
Do not dispose of electric tools together with
household waste material. Electric tools and
electronic equipment that have reached the end of
their life must be collected separately and returned
to an environmentally compatible recycling facility.
Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley, VIC 3149
Australia
Techtronic Industries N.Z. Limited
2 Landing Drive, Mangere
Auckland, 2022, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
961003035-01A
