COOLER MANUAL
BW-25D1
PLEASE READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE USE.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN BODILY
INJURY, AND/OR PROPERTY LOSS.
RETAIN INSTRUCTION MANUAL FOR FUTURE USE.
(213)516-2282
1
Index
Ⅰ. STRUCTURE …………................................................2
Ⅱ. TECHNICAL DATA ………………………......................2
Ⅲ. GENERAL SAFETY PRECAUTIONS………………….3
Ⅳ. OPERATION OF REFRIGERATOR………………........4
Ⅴ. PARTICULAR PRECAUTIONS…………………………4
Ⅵ. MAINTENANCE…………………………………………..5
Ⅶ. TROUBLE SHOOTING……………………………….....5
Ⅷ. ELECTRIC PRINCIPLE DIAGRAM…………………….6
Ⅸ． DISPOSAL………………………………………………..6
X．
GUARANTEE…………………………………………6
2
I. STRUCTURE
Ⅱ
.TECHNICAL DATA
Model Capacity
Rating
power
Rating
Voltage
Frequency
Cooling
Temp.
Outside
Size(mm)
Net weight
BW-25D1 25L 70W 1.2A
115V
60 Hz
8--- 18°C
46
°F—65°F
260X495X475 9.8Kg
1.Cabinet 2.Vent hole 3.Handle 4.Adjustable leg 5.Glass door
6.Cover 7.Control panel 8.Rack 9.Door gasket 10.Light
Fahrenheit LED
Celsius LED
3
III. GENERAL SAFETY PRECAUTIONS
● After removing the cooler from the package, make sure it is in good condition.
In case of doubt, do not use it and contact an authorized service center.
● Plastic bags, nails, etc. Should be kept out of the reach the operation manual
carefully and check that the rating data on the rating nameplate corresponds
to your power supply.
● This cooler can only be used in the use of which it was designed. The
manufacturer will not respond for any damage due to improper use or repairs
made by unqualified personnel.
● Before cleaning the cooler, make sure it is unplugged. Never clean the unit
with an acid preparation, medical, dilution, gasoline, oil or any other kind of
chemical substance that could damage the refrigerator.
● Repair should only be made by authorized service centers.
Caution：
1. To reduce the risk of fire, replace only with same type fuse.
2. Free standing installation only.
3. Do not use extension cords.
Warning:
1. If the supply cord is damaged, it must be replaced by the manufacturer or
service agent or similarly qualified person in order to avoid hazard.
2. Please screw off the door before throwing it away.
3. Please keep the appliance away from any flammable substances.
4. To avoid a hazard due to the instability of the appliance, it must be fixed
according to the instructions.
5. Do not use electrical appliances inside the food storage compartments of the
appliance.
6. This appliance is not intended for use by persons (including children) with
reduced physical,
7. Children should be supervised to ensure that they do not play with the
appliance.
8. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety
.
9. Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
4
I
Ⅴ
. OPERATION OF REFRIGERATOR
Clean the inside before use.
Fix the shelves properly according to the instruction.
When first time use (or haven’t used it for a long time), you should adjust the
temperature to minimum and have the cabinet empty running for 2 hours,
and then put your wine in it and adjust the desired temperature.
When the power is connected, cooling system starts to work. The
TEMP-ADJ button is set on certain position, which means that if the
temperature in the cooler reaches the point set, Self-control Temperature
System stops cooling system so the temperature in the cabinet rises
gradually.
When the inside temperature rises above the set point, Cooling Self-control
Temperature starts to work again, the cooler enter into cooling circles.
When you want to change the temperature in the cabinet, You can push
“Temp +” and“ Temp –” to increase and decrease the temperature.
You can push the “°C/°F” button to switch between Celsius and Fahrenheit
or push the “Lamp” button to control the light inside.
NOTE:
After you setting the temperature, the LED display will return to show the
temperature in the cooler, but it could turn to the point that you have set
gradually.
V. PARTICULAR PRECAUTIONS
Please unplug the cooler before moving.
If there is a long distance to move, please use a cart for delivery
Please check if all the parts are ready before installation.
In order to function at its potential, this cooler needs to be placed on flat
floor, with 5cm spaces at each side and 10 cm at the backside.
The height of the cooler is adjustable by adjusting the four legs, but cannot
be over 20 mm of each.
Keep ventilation holes clear, and keep at a distance of 50 mm from
surroundings.
5
Please keep away from the heat resources or gas.
Avoid direct sunshine and carry high temperature.
Do not place heavy articles on the top of the cooler.
VI. MAINTENANCE
● Shut off power supply before cleaning cabinet.
● Take out wines and shelves, and then clean the cabinet with clean water.
● Do not use soap or detergent for the cabinet.
● Clean the cooler regularly.
VII. TROUBLE SHOOTING
Symptoms
Possible cause
Solutions
No cooling
Plug not put in
Low voltage
Fuse broken
Put in the plug
Ensure normal voltage
Change fuse
Not cold enough
temperature
inside
The cooler is near
heat source;
Poor ventilation;
Fans don’t work;
Keep the cooler away from
sunshine or other heat source;
Place the cooler on the place
with good ventilation and Keep
things away from the fans;
Check whether the plug is
connected or change the fan;
Moisture build
on inter or
exterior cooler
High humidity
Gap between cabinet
and door gasket
Prolonged or
frequent door
openings
Please use a soft and dry cloth
to clean the dew.
Ensure door gaskets for
proper seal.
Reduce time and frequency
when door is open
6
VIII
．
ELECTRIC PRINCIPLE DIAGRAM
Ⅸ．
DISPOSAL:
Do not dispose this product as unsorted municipal waste. Collection of such waste
separately for special treatment is necessary.
It is prohibited to dispose of this appliance in domestic household waste.
For disposal there are several possibilities:
a) The municipality has established collection systems, where electronic waste
can be disposed of at least free of charge to the user.
b) The disposal of your old appliance must follow the legal guide lines of the
country where the appliance has been disposed.
c) As old product contains valuable resources, they can be sold to scrap metal
dealers.
Wild disposal of waste in forests and landscapes endangers your health when
hazardous substances leak into the ground-water and find their way into the food
chain.
X
．
Guarantee:
The guarantee of the cooler is regulated by the representative distribution
organization, in the country where the appliance has been purchased. The
supplier where you bought the appliance can give additional information.
You need the original purchase receipt and the date of purchase at any case, to
be able to use your guarantee.
