1. Plug in your hub and wait until the LED
blinks orange and blue.
Note: If the LED is not blinking orange and blue, press and
hold the SYNC button for 5 seconds to reset the hub.
01/ Power Up Your Device
2. Remove the battery insulation tab to
power up your sensor. The LED should
begin to blink.
Note: If the LED is not blinking, refer to the reverse side for
reset instructions.
SYNC Button
Status LED
02/ Set Up Your Device
1. Get the Tapo app from the App Store
or Google Play, and log in.
OR
2. Tap the button in the app and select
Hubs. Follow the in-app instructions to
set up and connect your Tapo sensors
or more to the hub.
Note: You can also tap the button. Select Sensors and
then your model, and choose the added hub for your
sensors.
03/ Mount Your Sensor
1. Stick the included adhesives on the
sensor and magnet.
x2
x1
≥ 0.39 inches (10 mm)
2. Choose where you’d like to install the
sensor (but don’t attach it yet). Place
the magnet near the edge of the door
or window that moves.
Note:
· Leave at least 0.39 inches (10 mm) of space so you can open
the battery compartment.
Images may dier from actual products.
Security Sensor Starter Kit
Quick Start Guide
©2025 TP-Link 7106511929 REV1.0.0
*The installation height should not be higher than 6.56 ft (2 m).
Setup Video
Scan QR code or visit
https://www.tp-link.com/support/
setup-video/#smart-hub
• Hub
Scan QR code or visit
https://www.tp-link.com/support/
setup-video/#smart-sensors
• Sensor
3. Align the magnet and sensor with no
more than 0.59 inches (15 mm)
between them when the door or
window is closed.
Peel the backing from the adhesive and
press the sensor and magnet into
place.
≤ 0.59 inches (15 mm)
Alignment
Lines
0
cm
1 2
3. Replace the battery with a fresh cell.
How to replace the battery
Avoid replacement of a battery with an incorrect type that can defeat a
safeguard.
Avoid disposal of a battery into re or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion.
Do not leave a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of ammable
liquid or gas; Do not leave a battery subjected to extremely low air
pressure that may result in an explosion or the leakage of ammable liquid
or gas.
CAUTION!
This product contains a coin / button cell battery. If the coin / button cell
battery is swallowed, it can cause severe internal burns in just 2 hours and
can lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop using the
product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part
of the body, seek immediate medical attention.
CAUTION: Do not ingest battery, Chemical Burn Hazard
• INGESTION HAZARD: This
product contains a button
cell or coin battery.
• DEATH or serious injury
can occur if ingested.
• A swallowed button cell or
coin battery can cause
Internal Chemical Burns in
as little as 2 hours.
• KEEP new and used
batteries OUT OF REACH
of CHILDREN
• Seek immediate medical
attention if a battery is
suspected to be swallowed
or inserted inside any part
of the body.
Risk of explosion if the battery is replaced by an incorrect type.
CAUTION!
a) Remove and immediately recycle or dispose of used batteries according
to local regulations and keep away from children. Do NOT dispose of
batteries in household trash or incinerate.
b) Even used batteries may cause severe injury or death.
c) Call a local poison control center for treatment information.
d) Tapo T110 includes button/coin cell batteries of type CR2032;
e) The nominal voltage of the button/coin cell batteries is +3V.
f) Non-rechargeable batteries are not to be recharged.
g) Do not force discharge, recharge, disassemble, heat above 60°C/140°F or
incinerate. Doing so may result in injury due to venting, leakage or explosion
resulting in chemical burns.
Ensure the batteries are installed correctly according to polarity (+ and -).
Do not mix old and new batteries, dierent brands or types of batteries, such
as alkaline, carbon-zinc, or rechargeable batteries.
Remove and immediately recycle or dispose of batteries from equipment not
used for an extended period of time according to local regulations.
Always completely secure the battery compartment. If the battery
compartment does not close securely, stop using the product, remove the
batteries, and keep them away from children.
Safety Information
• Do not install in a socket facing downward.
• Keep the device away from water, re, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need
service, please contact us.
• Do not use the device where wireless devices are not allowed.
• The socket-outlet shall be installed near the equipment and shall be easily
accessible.
Please read and follow the above safety information when operating the
device. We cannot guarantee that no accidents or damage will occur due to
improper use of the device. Please use this product with care and operate at
your own risk.
Warning! This product contains a button cell or coin battery. Avoid
ingestion hazard. Death or serious injury can occur if ingested.
Explanation of the symbol on the product
5s
After removing the cover, use a pin to
press and hold the Reset button for 5
seconds until the front LED starts
blinking.
Support
For technical support, warranty and more,
please visit https://www.tapo.com/support/
How to reset your sensor
1. Remove the cover of your sensor.
A
B
OPEN
OR
OPEN
2. Use a screwdriver to open the battery
cover.
