1.SAFETYINSTRUCTIONS

•Donotoperatetheapplianceifitisvisiblydamaged.

•Donotblockthegapsofthefridgewiththingslikepin,wire,etc.

•Donotexposetheappliancetorainorsoakitinwater.

•Donotplacetheappliancenearnakedﬂamesorotherheatsources(heaters,directsunlight,

gasovensetc.)

•Donotstoreanyexplosivesubstanceslikespraycanswithaﬂammablepropellant.

•Ensurethesupplycordisdryandnottrappedordamaged.Donotlocatemultipleportable

socket-outletsorportablepowersuppliesattherearoftheappliance.

•Checkthevoltagespeciﬁcationonthetypeplatecorrespondstothatoftheenergysupply.

Theapplianceisonlytobeusedwiththepowersupplyunitprovidedwiththeappliance.

•Donotuseelectricalappliancesinsidethefoodstoragecompartmentsoftheappliance,

unlesstheyareofthetyperecommendedbythemanufacturer.

•Onceunpackedandbeforeturningon,theappliancemustbeplacedonalevelsurfacefor

morethan6hours.

•Makesurethattheappliancestayshorizontallywhenitisrunning.Thetiltanglemustbeless

than5°forlongtimerunningandbelessthan45°forshorttimerunning.

•Keeptheventilationopeningsintheunitcasingorinthebuilt-instructurefreeofobstacles.

•Keeptheappliancestableonthegroundorinthecar;Donotdrainupsidedown.

•Repairsmayonlybecarriedoutbyqualiﬁedpersonnel.Incorrectrepairmaycausedanger.

Thelampandsupplycordmustbereplacedbythemanufacturerorqualiﬁedpersons.

•TheinstallationofDCpowerintheboatmustbehandledbyqualiﬁedelectricians.

•Theappliancecanonlyuseourdedicatedrechargeablebatteries,non-rechargeablebatteries

areprohibited,otherwisetheremaybeadangerofﬁreandexplosion.

•Inuseorduringstorage,batteryfoundtherehasbeenhighfever,leakage,odor,distortion

andotheranomalies,pleasestopusingitimmediatelyandstayawayfromthebattery.

•Batteryendoflifeshouldbeimmediatelyremovedfromtheequipment,pleaseproperly

handlesecurityofspentbatteries,donotputintoﬁreorwater.

•Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshallnotbemade

bychildrenwithoutsupervision.

CAUTION!

WARNING!

•Theappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswith

reducedphysical,sensoryormentalcapabilitiesorlackofexperienceandknowledgeif

they'vebeengivensupervisionorinstructionconcerninguseofthedeviceinasafewayand

understandthehazards.

NOTICE!

•Disconnectthepowersupplybeforeeachcleaningandmaintenanceandaftereveryuse.

•Donotusesharptoolstodefrost;Donotdamagetherefrigerantcircuit.

Lid

latch

Sealing

strip

Control

panel

Charging

port

Fridge

base

Cup

holder

Phone

holder

Storage

room

Machine

compartment

Detachable

battery

2.PRODUCTFEATURES

•Riskofchildentrapment.Beforeyouthrowawayyouroldrefrigeratororfreezer:takeoﬀthe

doors:leavetheshelvesinplacesothatchildrenmaynoteasilyclimbinside.

•Checkifthecoolingcapacityoftheapplianceissuitableforstoringthefoodormedicine.

Foodmayonlybestoredinitsoriginalpackagingorinsuitablecontainers.

•Iftheapplianceisleftemptyforlongperiods,switchoﬀ,defrost,clean,dry,andleavethe

dooropentopreventmoulddevelopingwithintheappliance.

•Theapplianceisintendedtobeusedinhouseholdandsimilarapplicationssuchas:

-Staﬀkitchenareasinshops,oﬃcesandotherworkingenvironments;

-Camping,Farmhousesandbyclientsinhotels,motelsandotherresidentialenvironments;

-Bedandbreakfasttypeenvironments;

-Cateringandsimilarnon-retailapplications.

•Information,illustrationsandspeciﬁcationsinthismanualreﬂectthemostcurrentavailable

atthetimeofpublication,aresubjecttochangewithoutpriornotice.

Pleaseaccordingtolocalregulationsregardingdisposaloftheapplianceforitsﬂammable

refrigerantandblowinggas.

3.PRODUCTSTRUCTURE

• 采⽤⾼效节能直流压缩机及转换模块，可靠性⾼，使⽤寿命⻓；

• 采⽤⽆氟保温层，保温性能好，低能耗；

• ，使⽤专⽤适配器使⽤DC12/24V 或AC100~240V( )；

•快速制冷⾄-20°C/-4°F（测试环境温度为25°C/77°F）；

采⽤智能汽⻋电池保护系统，呵护您的爱⻋电池；•

贴⼼设计内置LED灯，把⼿，防倒⽀架。• ：

•High-eﬃciencyDCcompressorandconversionmodule.

•CFCfreeand greatheatinsulation.

• DC12/24VorAC100~240V(using dedicatedadapter)powersupply.

• Fastcoolingto-20°C/-4°F(basedon25°C/77°Froomtemperature).

• Threestagebatteryprotectionsystempreventsvehiclerunoutofbattery.

• Speciﬁcparts:interiorLEDlight,handle,ﬂatstraightbracket.

Machinecompartment

Controlpanel

Doorlatch

Sealingstrip

Storageroom

Handle

Flatstraightbracket

Chargingport

4.INSTALLATIONINSTRUCTIONS

1.Alignthe ﬂatstraightbracketwiththemetal

slots.(Note:thesmoothsideofthe ﬂatstraight

bracketmustbe upwards.）

2.Whenplacingtherefrigeratoragainstthe

wall,alignandinserttheﬁrstorthird

convexslotoftheﬂatstraightbracketinto

themetalslot.

Flatstraightbracketinstallation:

3.Whenplacingtherefrigeratorindependently,

alignand insetthemiddleconvexslotofthe

ﬂatstraightbracketintothemetalslot.

4.Theinstallationiscompleted.

Flat straight bracket disassembly：

1.Removetheﬂatstraightbracket.

2.Thedisassemblyiscompleted.

metalslot

convexslot

metalslot

convexslot

metalslot

convexslot

•Reset：switchoﬀthe fridge,long pressforthreesecondsuntilE1 displays,underE1

mode,long pressatthesametime forthreesecondstoresetit.

•TemperatureUnitSetting：switchoﬀthefridge,longpressforthreesecondsuntilE1

displays,keeppressinguntilE5displays.thenpressor toselectCelsiusor

Fahrenheit.(*Factorysettingis°C.)

•Recommendedtemperatureforcommonfood:

Drinks

5°C/41°F

Fruits

Vegetable

Delicatessen Wine Icecream

Meat

3~10°C/37~50°F

4°C/39°F

10°C/50°F

-10°C/14°F -18°C/0°F

5~8°C/41~46°F

6.BATTERYOPERATION

•Battery ON/OFF:longpressthepowerbuttononthebatterytoswitchON/OFF.When

thebatteryis OFF,shortpressthepowerbuttontoshowcurrentbattery.

①PowerIndicator(Green:charging;Blue:discharging)

②BatteryIndicator(showcurrentbattery)

③PowerButton④DCChargingPort

Warning:donotdisassemblethebattery!

Model:FSAK-002

Capacity:15600mAh/173Wh

RatedVoltage:11.1V

ChargingLimitedVoltage(DC):12.6V

ChargingLimitedCurrent(DC):3A

•Batterycharging(forreference only):

WalloutletAC100~240V

(usingdedicatedadapter)

Carcigarettelighter

DC12/24V

Solar

12~50V

chargeintherefrigerator

chargeseparately

Chargingstation(optional)

Batterycharger(optional)

(Connectto the "SOLAR"port of the refrigerator)

(Connectto the DC chargingport of the battery)

(Chargingtime≈8h)

(instandbymode)

(WhentheInputvoltage>13.5V,

chargingtime≈8h)

(Whenusing100Wsolarpanel,

chargingtime≈5h)

(Chargingtime≈8h)

(Chargingtimeofasinglebattery≈4h)

①

②

③

④

•Battery ON/OFF:longpressthepowerbuttononthebatterytoswitchON/OFF.When

thebatteryis OFF,shortpressthepowerbuttontoshowcurrentbattery.

①PowerIndicator

(Green:charging;Blue:discharging)

②BatteryIndicator(showcurrentbattery)

③PowerButton

④DCChargingPort

(oldmodelbatteryonly)

ChargingLimitedVoltage(DC):12.6V

ChargingLimitedCurrent(DC):3A

Warning:

donotdisassemblethebattery!

Model:FSAK-002

Capacity:15600mAh/173Wh

RatedVoltage:11.1V

*Note：TheoldmodelbatteryhasaDCchargingportontheside,thenewmodelbattery

doesnothaveDCchargingport,refertotheinstructionsbelowformoredetails.

Itisrecommendedtousethenewmodelbattery.

④

①

②

①

③

Oldmodelbattery

Newmodelbattery

5.FUNCTIONANDOPERATION

TEMPERATURECONTROL

LEDDISPLAY

ON/OFF

*the voltageistheoreticalvalue,theremaybeadeviationindiﬀerentsceneries.

• PowerSupply:connecttoDC12V/24VorAC100-240Vpower(usingdedicatedadapter).

•Display ScreenInitialization：connecttothepowersupplyandthedisplaywillbe onfor

3secondsthenenterthenormal operatingmode.

VoltageReference:

•PowerON/OFF：presstoswitchON/OFF.

•TemperatureSetting：under therunningstate,pressandtoenterthe temperature

setting.Presstoincreasetemperature,andpresstodecreasetemperature.Keep

pressingortoadjustthe temperaturequickly.Thesettingwillbesavedautomatically

afterstoppingoperatingfor3seconds.Note:thetemperaturedisplayedis thecurrent

temperatureofthecompartments,it’lltakeawhiletoreachthesettemperature.

Temperaturesettingrange:-20~20°C（-4~68°F）.

•BatteryProtectionMode：factorysettingisM(Medium)anditisnotadjustable.

•TemperatureUnitSetting：switchOFFthe fridge,long pressatthesametimefor

3secondsuntildisplaysE1,andswitchtoE5bypressing,thenpressortoswitch

Celsiusor Fahrenheit.

•Cooling Mode：factorysettingisMAX(fastcoolingmode)anditisnotadjustable.

•Reset：switchOFFthe fridge,long pressatthesametimeforthreeseconds,itwill

displayE1, underE1mode,longpressatthesametimeagainforthreesecondsuntil

thescreenﬂasheswhichmeansithasbeenreset.

23.7V

CUTIN

DC24V

CUTIN

11.4V

INPUT

MODE

22.3V

CUTOUT

10.1V

DC12V

•Recommendedtemperatureforcommonfood:

Drinks

5°C/41°F

Fruits

Vegetable

Delicatessen Wine Icecream

Meat

3~10°C/37~50°F

4°C/39°F

10°C/50°F

-10°C/14°F -18°C/0°F

5~8°C/41~46°F

•显⽰屏初始化： 接通电源时，数码屏全亮3秒，然后进⼊正常运⾏模式。

•电源：可接直流电压12/24V或交流电压100~240V(使⽤专⽤适配器);

•开/关机： 接通电源，短按电源键 开/关机。

•温度设置： 在开机状态下，短按 和进⼊温度设置。短按升⾼温度，短按降低温度，⻓按

或可快速调节温度。如3秒内⽆任何操作，屏幕停⽌闪烁，则退出预设温度状态。注：屏幕停⽌闪烁

后显⽰为当前温度，如调节幅度⼤，需要⼀段时间才能达到设定温度。温度可调范围：-20~+20°C。

•制冷模式设置：出⼚默认值为MAX（快速制冷模式），不可调节。

•电池保护设置： 出⼚设置默认为中档保护，不可调节。

⽔/饮料

5°C

⽔果

蔬菜

熟⻝

酒类冰淇淋

⾁类

3~10°C

4°C

10°C

-10°C -18°C

5~8°C

•常⻅保存⻝物及推荐保存温度：

•温度单位转换：关机状态下，同时⻓按和3秒显⽰E1，短按,依次从E1,E2󶙾󶙾切换⾄E5,

再短按或切换摄⽒度°C或华⽒度°F。



•恢复出⼚设置：关机状态下，同时⻓按和3秒显⽰E1，E1模式下再同时⻓按和3秒，屏幕

全亮，则恢复出⼚设置成功。

电压值参考表:

退出保护

11.4V

输⼊电压

保护等级

23.7V

22.3V

启动保护

退出保护

10.1V

中

DC12V

DC24V

*电压值是理论值,可能会存在⼀定的偏差。

Note:It issuggestedtoswitchoﬀtherefrigeratorwhenchargingthe battery(thepower

supplymay mainlypowerthe compressorwhentherefrigeratorisrunning).

• Switchoﬀandunplugthedeviceﬁrsttoavoidelectricshock.

• Usewetclothtocleanthedeviceanddry it.

• Donotsoakthe fridgeinwateranddonotwashitdirectly.

• Donotuseabrasivecleaningagentsduringcleaningasthesecandamagethedevice.

■Cleaning:

Ifthe devicewill notbe inuseforalongtime,pleasefollowtheinstruction:

• Switchoﬀandunplugthedevice.

• Takeoutalltheitemsstoredinthedevice.

• Wipeoﬀexcesswaterwithasoftrag.

• Putthefridgeinacoolanddryplace.

• Leavethelidslightlyopentopreventodorsfromforming.

• Recommendedstorageenvironment:

ambient temperature:25°C,ambienthumidity:≤ 75%.

■Storage:

Humiditycanformfrostintheinteriorofthecoolingdeviceorontheevaporator.

Thisreducesthe coolingcapacity.Defrostthe devicein goodtime toavoidthis.

• Switchoﬀandunplugthedeviceﬁrsttoavoidelectricshock.

• Takeoutalltheitemsstoredinthedevice.

• Keepthelid open.

• Wipeoﬀthedefrostedwater.

■Defrosting:

Neverusehardor pointedtoolstoremoveiceortoloosenobjectswhichhave

frozeninplace.

6.CAREANDMAINTENANCE

•Dischargingtime(forreference only):Inthelowbatteryprotectionmode,thebatterycan

lastabout4hoursafterbeingfullycharged.Whenthetemperatureof therefrigeratorisset

between2~8°C(ambienttemperature25°C),it canlast12hoursafterthe internaltemperature

stabilizes.Removeor switchoﬀthebatterytopreventself-dischargewhen notinuse.

Note:the outputofthesolarpanelisunstable,soitcannotpowertherefrigeratordirectly.

Whenusing asolarpanel,thebatteryshould beputintotherefrigerator.

Itissuggestedtouse100Wsolar panel.

MAXSolar InputVoltage:50V;MAXSolarInput Current:10A.

Whenconnecttoasolar panel,pleaseplacetherefrigeratorin acoolplacetodissipateheat.

Thecharginginputpowershouldbehigherthantheworkingpowerofthe refrigerator(about

40-45W),or switchoﬀtherefrigerator,otherwisethebatterywillrunout.

•Batterycharging(forreference only):

WalloutletAC100~240V

(usingdedicatedadapter)

Carcigarettelighter

DC12/24V

Solar

12~50V

chargeintherefrigerator

chargeseparately

Chargingstation(optional)

Batterycharger(optional)

(Connectto the "SOLAR"port of the refrigerator)

(Connectto the DC charging port of the battery)

(Chargingtime≈8h)

(instandbymode)

(WhentheInputvoltage>13.5V,

chargingtime≈8h)

(Whenusing100Wsolarpanel,

chargingtime≈5h)

(Chargingtime≈8h)

(Chargingtimeofasinglebattery≈4h)

Newmodel

battery

Batterycharger(optional)

(Connectto the chargingportof the battery)

Oldmodel

battery

(Chargingtime≈8h)

•Dischargingtime(forreference only):Inthelowbatteryprotectionmode,thebatterycan

lastabout4hoursafterbeingfullycharged.Whenthetemperatureof therefrigeratorisset

between2~8°C(ambienttemperature25°C),it canlast12hoursafterthe internaltemperature

stabilizes.Removeor switchoﬀthebatterytopreventself-dischargewhen notinuse.

Whenconnecttoasolar panel,pleaseplacetherefrigeratorin acoolplacetodissipateheat.

Thecharginginputpowershouldbehigherthantheworkingpoweroftherefrigerator(about

40-45W),or switchoﬀtherefrigerator,otherwise thebatterywillrunout.Itissuggestedto

use100Wsolarpanel.MAXSolarInputVoltage:50V;MAXSolarInputCurrent:10A.

Note:It issuggestedtoswitchoﬀtherefrigeratorwhenchargingthebattery(thepower

supplymay mainlypowerthe compressorwhentherefrigeratorisrunning).

Note:the outputofthesolarpanelisunstable,soitcannotpowertherefrigeratordirectly.

Whenusing asolarpanel,thebatteryshould beputintotherefrigerator.

Issues

Cause/Suggestions

Refrigeratordoes

notwork

•Check if the switch is on.

•Check if the plug and socket are connected well.

•Check if the fuse has been burnt.

•Checkifthepowersupplyismalfunctioned.

•Switchon/oﬀthefridgefrequentlymaycausestartdelayofthecompressor.

Refrigerator

compartments

aretoowarm

•Thedoorisopenedfrequently.

•Alargeamountofwarmorhotfoodwasstoredrecently.

•Therefrigeratorhasbeendisconnectedforalongtime.

Foodisfrozen

Thereis"waterﬂow"

noisefrominsidethe

refrigerator

•Thetemperaturewassettoolow.

•It'sanormalphenomenon,causedbytheﬂowofrefrigerant.

Therearewaterdrops

aroundtherefrigerator

casingordoorgap

•It'sanormalphenomenon,themoisturewillcondenseto

waterwhenittouchesacoldsurfaceoftherefrigerator.

Thecompressoris

slightlynoisywhen

starting

•It'sanormalphenomenon,thenoisewillbereduced

afterthecompressorworksstably.

CodeF1displayed

•Possiblecause:lowvoltagetofridge.

AdjustthebatteryprotectionfromHightoMediumorfromMediumtoLow.

CodeF2displayed

•Possiblecause:condenserfanisoverloaded.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

CodeF3displayed

•Possiblecause:thecompressorstartstoofrequently.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

CodeF4displayed

•Possiblecause:compressornotkickingin.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

CodeF5displayed

•Possiblecause:overheatingofthecompressor&electronics.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

•Possiblecause:temperaturesensorisfaulty.

Contactmanufacturerforservice.

CodeF6displayed

CodeF7orF8displayed

•Possiblecause:noparametercanbedetectedbythecontroller.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

7.TROUBLESHOOTING

-20~+20°C/-4~+68°F

8.WARRANTY

Ifthe devicegetsmalfunctional,limitedwarrantywillbeprovidedfor1yearfromthedateof

purchase,exceptfollowingsituations:

• Contriveddamage.

• Damagecausedbyforcemajeuresuchas earthquake,conﬂagration,etc.

• Damagefrominappropriateuseor violatingthisinstruction.

• Damageormalfunctioncausedbydisassembling.

9.TECHNICALINFORMATION

DC12/24VorAC100~240V(usingdedicatedadapter)

≤45dB

T/ST/N/SN

45W

*Duetoproductimprovement,the technicalinformationmight bediﬀerentfromactual

information,pleaserefertotheratinglabelontheproduct.

MODEL

RATEDVOLTAGE

RATEDPOWER

CAPACITY

NOISE

TEMPERATURE

SETTINGRANGE

CLIMATECATEGORY

DIMENSIONS(L*W*H)

NETWEIGHT

KCF15

14.6L/0.52Cu.Ft.

584*240*382mm

2215/16*97/8*151/16inch

8.5kg/18.7lb

*由于产品改良，技术参数会与实际参数有差异，请以产品铭牌参数为准。

DC12/24V或AC100~240V(使⽤专⽤适配器)

型号

容量

额定电压

噪⾳

额定功率

⽓候类型

温度范围

产品尺⼨(⻓*宽*⾼)

产品净重

-20~+20°C

KCF15

14.6L

≤45dB

T/ST/N/SN

45W

8.5kg

584*240*382mm

Alpicool KCF15 Portable Fridge Freezer

Product's Documents

Alpicool KCF15 User Manual

Specifications

Alpicool KCF15 Questions and Answers
