User Manual
Register your product and get support at
www.philips.com/support
Gaming Projector
GamePix 800 Smart
Introduction ������������������������������������������������� 3
Dear customer ..............................................................3
About this user manual .............................................3
What’s in the box .........................................................3
Customer service centre.............................................3
1 General safety information ���������������� 4
Setting up the product ...............................................4
Repairs ............................................................................4
Power supply .................................................................5
2 Overview ������������������������������������������������ 5
Front view ......................................................................5
Back view .......................................................................5
Top view .........................................................................6
Bottom view ..................................................................6
Remote control ............................................................7
3 Initial setup �������������������������������������������� 8
Place the projector ......................................................8
Connect to power supply .......................................... 8
Prepare the remote control ...................................... 8
Power on and set up the projector.........................9
4 Connect to playback devices ������������ 10
Connect to devices through HDMI™ ...................10
Connect to a dongle .................................................10
Connect to devices through HDMI™ ARC ..........11
5 Connect to external speakers or
headphones ����������������������������������������� 11
6 Change settings ���������������������������������� 12
7 Maintenance ���������������������������������������� 15
Cleaning .......................................................................15
8 Troubleshooting ��������������������������������� 16
9 Appendixes ������������������������������������������ 18
Technical data .............................................................18
CE statement ...............................................................19
FCC statement.............................................................19
Canada regulatory compliance .............................19
Other notice ................................................................19
Table of contents
3 Philips · GamePix 800 Smart
Introduction
Dear customer
Thank you for purchasing this projector.
We hope you enjoy this product and the many
functions it offers!
About this user manual
The quick start guide supplied with this product
allows you to start using this product quickly
and easily. Detailed descriptions can be found in
the following sections of this user manual.
Read the entire user manual carefully. Follow
all safety instructions in order to ensure proper
operation of this product (see General safety
information, page 4). The manufacturer
accepts no liability if these instructions are not
followed.
Symbols used
Notice
This symbol indicates tips that will help
you use this product more effectively and
easily.
DANGER!
Danger of personal injury!
This symbol gives warning of danger
of personal injury. Physical injury or
damage can result from improper
handling.
CAUTION!
Damage to the product or loss of data!
This symbol gives warning of damage
to the product and possible loss of
data. Damage can result from improper
handling.
What’s in the box
a
GamePix 800 Smart projector (GMX800/INT)
b
Remote control with 2 AAA batteries
c
Quick Start Guide with Warranty Card
d
AC power cables with plugs x 4
e
Dongle
a
bc
de
Quick Start
Guide
Gaming
Projector
GamePix 800
Customer service centre
The Support page, warranty card, and user
manuals can be found here:
Web: www.philips.com/support
Support Contacts:
International Phone: +41 215 391 665
Please ask your provider for international call
costs!
Mail: philips.projector[email protected]
Access our FAQ websites:
https://support.philipsprojection.com
https://community.philipsprojection.com
4 Philips · GamePix 800 Smart
1 General safety
information
Take note of all warning and safety notes
indicated. Do not make any changes or settings
that are not described in this user manual.
Incorrect operation, and improper handling can
lead to physical injury, damage to the product or
loss of data.
Setting up the product
This product is for indoor use only. Place the
product securely on a stable, flat surface. To help
avoid possible injuries to persons or damage to
the product itself, position all cables in such a
way that no one will trip over them.
Do not operate the product in damp rooms.
Never touch the mains cable or the mains
connection with wet hands.
Never operate the product immediately after
moving it from a cold location to a hot location.
When the product is exposed to such a change
in temperature, moisture may condense on the
crucial internal parts.
The product must have sufficient ventilation and
must not be covered. Do not put the product in
closed cabinets, boxes, or other enclosures when
in use.
Protect the product from direct sunlight,
heat, intense temperature fluctuations and
moisture. Do not place the product in the
vicinity of heaters or air conditioners. Observe
the information on temperature listed in the
technical data (see Technical data, page 18).
Prolonged operation of the product causes the
surface to become hot. In case of overheating,
the product automatically switches to standby
mode.
Do not allow liquids to leak into the product.
Turn off the product and disconnect it from the
mains supply if liquids or foreign substances
leaked into the product. Have the product
inspected by an authorised service centre.
Always handle the product with care. Avoid
touching the lens. Never place heavy or sharp
objects on the product or on the power cable.
If the product gets too hot or emits smoke,
shut it down immediately and unplug the
power cable. Have your product checked by
an authorised service centre. Keep the product
away from open flames (e.g. candles).
The remote control is with batteries (type AAA).
DANGER!
Risk of explosion with incorrect type
of batteries!
There is a risk of explosion if the wrong
battery type is used.
Do not expose the batteries to excessive heat
such as sunshine, or open fire. Do not expose the
batteries to low air pressure at high altitude.
Under the following conditions, a layer of
moisture can appear inside the product which
can lead to malfunctions:
• if the product is moved from a cold to a
warm area;
• after a cold room is heated;
• when the product is placed in a damp
room.
Proceed as follows to avoid any moisture
buildup:
1 Seal the product in a plastic bag before
moving it to another room, in order for it to
adapt to room conditions.
2 Wait one to two hours before you take the
product out of the plastic bag.
The product should not be used in a very dusty
environment. Dust particles and other foreign
objects may damage the product.
Do not expose the product to extreme
vibrations. This may damage the internal
components.
Do not allow children to handle the product
without supervision. The packing materials
should be kept out of the hands of children.
For your own safety, do not use the product
during thunderstorms with lightning.
Repairs
Do not repair the product yourself. Improper
maintenance can result in injuries or damage to
the product. The product must be repaired by an
authorised service centre.
Please find the details of authorised service
centres on the warranty card supplied with this
product.
Do not remove the type label from this product,
as this will void the warranty.
5 Philips · GamePix 800 Smart
Power supply
Use only a power adapter which is certified for
this product (see Technical data, page 18).
Check whether the mains voltage of the power
supply matches the mains voltage available at
the setup location. This product complies with
the voltage type specified on the product.
The power outlet shall be installed near the
product and shall be easily accessible.
CAUTION!
Always use the button to turn the
projector off.
Turn off the product and unplug from the
power outlet before cleaning the surface (see
Cleaning, page 15). Use a soft, lint-free cloth.
Never use liquid, gaseous or easily flammable
cleaners (sprays, abrasives, polishes, alcohol). Do
not allow any moisture to reach the interior of
the product.
DANGER!
Risk of eye irritation!
This product is equipped with a high
power LED, which emits very bright
light. Do not look directly into the
projector lens during operation. This
could cause eye irritation or damage.
2 Overview
Front view
c
a
b
a
Projection lens
b
IR sensor
c
Adjuster foot
Back view
a f
bdce
a
AC power cable inlet
Connect to the power cable.
b
Earphone jack
Connect to the earphone.
c
HDMI
Connect to an HDMI™ output port on a
playback device.
d
USB-A
Connect to a USB dongle.
e
RS232
Connect to a RS232 cable.
f
HDMI
Connect to the supplied dongle.
6 Philips · GamePix 800 Smart
Top view
a
e
j
i
h
db gfc
m
lk
n
o
a
• Access the projector's settings menu.
• Leave current item or close the OSD
menu when there is OSD menu.
b
• Switch the projector on or to standby
mode.
• When the projector is on, the LED lights
up in green.
• When the projector is in standby mode,
the LED blinks green.
c
• Decrease the volume.
• Move to the left item when there is OSD
menu.
d
Switch to a different input source.
e
• Decrease the keystone value.
• Move to the next item when there is
OSD menu.
f
OK
Confirm a selection on the screen.
g
COLOR MODE
Choose a preset mode.
h
Light source indicator light
i
Temperature source indicator light
j
Power indicator light
k
• Increase the volume.
• Move to the right item when there is
OSD menu.
l
Turn the image to blank and show "Blank"
on screen. Press any key to return the image.
m
• Increase the keystone value.
• Move to the upper item when there is
OSD menu.
n
Focus ring
o
Zoom ring
Bottom view
a
a
a
198.96
199.57
45.1260.88
60.89
a
Tripod socket
Screw size: M4 (max. length = 25 mm; min.
length = 20 mm)
7 Philips · GamePix 800 Smart
Remote control
a
b
d
e
f
g
h
i
j
l
n
p
q
o
m
k
c
a
Power On/Off
Switch the projector on or to standby.
b
Color Mode
Choose a preset mode.
c
Voice
Close the projector OSD menu (if there it's
on), change the input source to the dongle
and call out Google assistant.
d
Navigation buttons (Up, Down, Left, Right);
Keystone keys
• Navigate items on the screen.
• Increase or decrease the keystone value.
• Press / to change the value for the
current setting when there is OSD menu.
e
Back
Return to upper level or close the OSD menu
when there is OSD menu.
f
Volume Up/Volume Down
• Increase the volume level.
• Decrease the volume level.
g
YouTube
Enter YouTube application under the dongle
source.
h
Prime video
Enter Prime video application under the
dongle source.
i
Input
Switch to a different input source.
j
Settings
• Access the projector's settings menu.
• Leave current item or close the OSD
menu when there is OSD menu.
k
OK
Confirm a selection on the screen.
l
Bookmark
Open or close the projector OSD menu.
m
Home
Close the projector OSD menu (if there it's
on), change the input source to the dongle
and go to Home.
Note:
• In Google TV source/Dongle settings, you
can adjust the auto shutdown time (the
default is 20 minutes).
• If the device remains idle for the designated
period, Google TV will automatically turn
off.
• Once Google TV has automatically shut
down, switching the input source back to
"Google TV" will result in the projector
displaying "No signal."
• To wake up Google TV, press the Home
button on the remote control twice. The
projector will then correctly display the
Google TV screen again.
n
Zoom In/Zoom Out
• Magnify the projected picture size.
• Reduce the projected picture size.
o
Mute
Toggle audio between on and off.
p
Netflix
Enter Netflix application under the dongle
source.
q
YouTube Music
Enter YouTube Music application under the
dongle source.
8 Philips · GamePix 800 Smart
3 Initial setup
Notice
Make sure all devices are disconnected
from their power supplies before
establishing or changing any connections.
Place the projector
1 Place the projector on a flat surface such as
a table in front of the projection surface.
This is the most common way to position the
projector for quick setup and portability.
2 If the projection direction is incorrect, press
on the projector or Settings on the
remote control to access the projector's
settings menu and select SYSTEM > Projector
Position > Front Table.
Connect to power supply
CAUTION!
Always use the button to turn the
projector on and off.
1 Select a supplied power cable with the
correct plug (EU/UK/US/AU).
2 Connect the power cable to the AC power
cable inlet.
3 Connect the power cable to an electrical
socket.
• The power LED on the projector blinks
green.
a
b
A power supply cord connected to a socket-
outlet with protective earthing connection.
Prepare the remote control
CAUTION!
The improper use of batteries can
lead to overheating, explosion, risk of
fire and injury. Leaking batteries can
possibly damage the remote control.
Never expose the remote control to
direct sunlight.
Avoid deforming, dismantling or
charging the batteries.
Avoid exposure to open fire and water.
Replace empty batteries immediately.
Remove the batteries from the remote
control if not in use for long periods of
time.
Dispose of the used batteries according
to the manufacturer's instructions and
local environment regulations for your
region.
1 Open the battery compartment.
2 Insert the supplied batteries (type AAA) with
correct polarity (+/-) indicated.
3 Close the battery compartment.
9 Philips · GamePix 800 Smart
• When using a remote control with infrared
signals, point the remote control at the IR
sensor on the projector, and make sure there
is no obstacle between the remote control
and the IR sensor.
Power on and set up the
projector
Power on/off the projector
• To turn on the projector, press on the
projector or remote control. The power LED
on the projector turns from blinking green
to green.
• To turn off the projector, press on the
projector/remote control. The projector
enters standby mode and its power LED
turns from green to blinking green.
• To fully shut down the projector, disconnect
the power cable from the electrical socket.
Set up the projector system
When you turn on the projector for the first
time or after it was reset to its factory default
settings, the projector system will start and
prompt you to set it up by making some basic
settings.
After the setup, you can start using the projector
or continue to make other adjustments.
Note: The default display language is English
and not all languages are available.
Screen size adjustment
The projection screen size (or size of images) is
determined by the distance between the lens of
the projector and the projection surface.
This projector has a projection distance of 2425
mm to 5197 mm, and thus creates a screen size
of 70" to 150".
Digital zooming
You can use the digital zooming function to
resize the screen size from 0.8x to 2.0x.
1 Press on the projector or Settings on the
remote control to access the settings menu,
go to DISPLAY > Zoom and press the OK
button.
2 Press
/
to adjust the screen size. The
changes take effect immediately.
Image focus adjustment
You can adjust the image focus manually.
• To manually adjust the image focus, rotate
the zoom ring on the projector.
Image shape adjustment
You can adjust the image shape manually.
To manually adjust the image shape:
1 Press on the projector or Settings on the
remote control to access the settings menu,
go to DISPLAY > Keystone and press the OK
button.
2 After the Keystone correction page displays.
Follow the on-screen instructions to adjust
the image shape.
10 Philips · GamePix 800 Smart
4 Connect to
playback devices
Notice
Make sure all devices are disconnected
from their power supplies before
establishing or changing any connections.
Connect to devices through
HDMI™
You can connect a playback device (e.g. a Blu-
ray player, gaming console, camcorder, digital
camera or PC) to the projector through HDMI™
connection. With this connection, images are
shown on the projection screen, and audio is
played on the projector.
1 Using an HDMI™ cable, connect the HDMI
port on the projector to an HDMI™ output
port on a playback device.
Game consoles
Phones
Tablets
C
omputers
Smart Sticks
DVD/VCR
2 If the projector does not automatically
switch to the correct input source, press
on the projector or Input on the remote
control to switch the input source to HDMI.
Connect to a dongle
You can connect the supplied dongle a
dongle (e.g. Amazon Fire Stick, Roku Stick or
Chromecast) to the projector to easily watch
videos over the internet. With this connection,
images are shown on the projection screen, and
audio is played on the projector.
1 Con
nect a dongle to the projector's HDMI
port using an HDMI™ cable.
2 Connect the dongle to the projector's
USB-A port using a USB cable
.
3 To install the supplied dongle, unscrew
the screw and remove the cover. Plug the
dongle into the HDMI port and connect the
USB cable. Replace the cover by tightening
the screw.
Ex
ternal Dongle (5V/2A)
(not included)
4 If the projector does not automatically
switch to the correct input source, press
on the projector or Input on the remote
control to switch the input source to HDMI.
11 Philips · GamePix 800 Smart
Connect to devices through
HDMI™ ARC
The HDMI port on the projector supports
Audio Return Channel (ARC). You can connect
a compatible audio system (e.g. a home cinema
system, AV receiver or sound bar) to the
projector through HDMI™ ARC connection.
With this connection, audio is streamed to the
connected audio system.
Tip: To get 5.1 surround sound, you typically
need to connect the projector to a 5.1 home
cinema system.
1 Using an HDMI™ cable, connect the HDMI
port on the projector to the HDMI™ ARC
port on a compatible audio system.
• The HDMI™ ARC port on your audio
system might be labeled differently. See
the documentation supplied with the
device for more information.
2 If the projector does not automatically
switch to the correct input source, press
on the projector or Source on the remote
control to switch the input source to HDMI.
3 To activate the HDMI™ ARC function on
the projector, press on the projector or
Settings on the remote control to access the
settings menu, go to BASIC > Audio Return,
press the OK button and select On.
5 Connect to
external speakers
or headphones
You can connect external speakers or
headphones to the projector. With this
connection, audio from the projector is played
through the external speakers or headphones.
• The internal speakers of the projector
are deactivated automatically when
external speakers or headphones are
connected to the projector.
DANGER!
Danger of hearing damage!
Before connecting the headphones, turn
down the volume on the projector.
Do not use the projector over a longer
time at high volume – especially when
using headphones. This could lead to
hearing damage.
12 Philips · GamePix 800 Smart
6 Change settings
1 Press on the projector or Settings on
the remote control to access the projector's
settings menu.
2 Use
the navigation buttons and the OK button
to select a menu item.
3 P
ress / or / to select a value for the
menu item.
4 Press
the OK button to make the change.
Note: For some menu items such as Digital
Zoom, the change takes effect once you select
a different value.
5 Press or Back one or more times to exit
the projector's settings menu.
DISPLAY settings
You can view and change the following display
settings.
• Aspect Ratio: Set the image's aspect ratio.
• Keystone: Manually correct the vertically
keystone by adjusting the corners of the
screen.
• Zoom: Scale down the projection image by
up to 80% or scale up the projection image
by up to 200%. The default value is 100% (no
scale-down).
• OverScan: Adjust the overscan rate from 0%
to 5%.
• Game mode: This function is favorable to
frame rate reducing. Quick response time
in native timing can be achieved. When
enabled, the following settings will return to
factory preset values: Aspect Ratio, OverScan,
Zoom.
IMAGE settings
You can view and change the following image
settings.
• Color Mode: Select a predefined color
brightness setting for picture and video
display, or select User 1/User 2 to customize
some of the sub-menus under the IMAGE
menu, according to your selected input
source. Tip: You can more quickly change
the picture preset by pressing COLOR MODE
on the projector or remote control.
• Brightness: Adjust the display brightness.
• Contrast: Adjust the display contrast.
• Color Temperature: Select 5500K to enhance
warm colors such as red; select 8000K to
make picture bluish; select 6500K for a
moderate color temperature.
• Advanced:
• Color: A lower setting produces less
saturated colors. If the setting is too
high, colors will be overpowering and
may appear unrealistic.
• Sharpness: Select different sharpness
level.
• Gamma: Gamma refers to the brightness
level of the projector’s grayscale levels.
• Brilliantcolor: This feature utilizes a new
color-processing algorithm and system
level enhancements to enable higher
brightness while providing truer, more
vibrant colors in the projected picture. It
enables a greater than 50% brightness
increase in mid-tone images, which are
common in video and natural scenes,
so the projector reproduces images in
realistic and true colors. If you prefer
images with that quality, select a level
that suits your need.
• Color Management: Color management
provides fine color control adjustment
to allow for more accurate color
reproduction. Select Primary Color first
and adjust its range/values in Hue,
Saturation and Gain.
• Reset Color Settings: Reset the color settings
to default.
POWER MANAGEMENT settings
You can view and change the following power
management settings.
• Auto Power On:
• Signal: Select HDMI allows the projector
to turn on automatically once the signal
is fed through the signal cable.
• CEC: Turn HDMI™ CEC (Consumer
Electronics Control) on or off. The
default value is Disable.
• Direct Power On: Allow the projector to
turn on automatically once power is fed
through the power cord.
• Smart Energy:
• Auto Power Off: Allow the projector to
turn off automatically after a set period
of time once no input source is detected
to prevent unnecessary waste of lamp
life. Tip: Disabling Auto Power Off will
increase energy consumption.
• Sleep Timer: Select a period of time
after which the projector turns off
automatically. The default value is
13 Philips · GamePix 800 Smart
Disable.
• Power Saving: Lower power consumption
if no input source is detected.
• Quick Power Off: When this function is
enabled, the projector will not enter the
cooling process after being shut down.
Tip: If you attempt to restart the projector
right after it’s been turned off, it may not
be turned on successfully and will rerun its
cooling procedure.
• USB A Power: When this function is enabled,
the USB Type A port can supply power.
BASIC settings
You can view and change the following basic
settings.
• Audio Settings:
• Mute: Select On to temporarily turn off
the projector’s internal speaker or the
volume being output from the audio
output jack.
• Audio Volume: Adjust the volume level
of the projector’s internal speaker or the
volume being output from the audio
output jack.
• Power On/Off Ring Tone: Turn on/off
the ring tone during the starting up and
shutting down process.
• Audio Return: Use an HDMI™ ARC
compatible device to output audio.
• Audio Format: Adjust the audio output
formats to achieve different audio
performance.
• Presentation Timer: Presentation timer
can indicate the presentation time on the
screen to help you achieve better time
management when giving presentations.
• Timer Period: Set the time period. If the
timer is already on, the timer will restart
whenever the Timer Period is reset.
• Timer Display: Allow you to decide if
you want the timer to show up on the
screen.
• Timer Position: Set the timer position.
• Timer Counting Direction: Set your
desired counting direction.
• Sound Reminder: Allow you to decide if
you want to activate a sound reminder.
Once enabled, a double beep sound
will be heard at the last 30 seconds of
counting down/up, and a triple beep
sound will be produced when the timer
is up.
• Start Counting/Off: Select Start Counting
to activate the timer. Select Off to cancel
it.
• Pattern: This function helps you adjust
the image size and focus, and checks for
distortion in the projected image.
• Blank Timer: Allow the projector to return
the image automatically after a period of
time when there is no action taken on the
blank screen. To display the blank screen,
press on the projector. Tip: Do not block
the projection lens as this could cause the
blocking object to become heated and
deformed or even cause a fire.
• Message: Set reminder messages On or Off.
• Splash Screen: Select which logo screen will
appear during projector start-up.
ADVANCED settings
You can view and change the following
advanced settings.
• HDR:
• HDR/HLG: The projector supports HDR
imaging sources. It can automatically
detect the dynamic range of the source,
and optimize image gamma and color
settings to reproduce contents under
wide range of light conditions. You also
select SDR.
• EOTF: The projector can automatically
adjust the brightness levels of your
image according to the input source.
Normally, the default setting “Mid”
is recommended. If the brightness of
the projected image is dark, please use
“Low”. When giving priority to gradation
property, please use “High”.
• 3D Settings:
• 3D Sync: Select the input signal's 3D
format when the input source is HDMI.
• 3D Sync Invert: If you have problems with
the left and right eye reversed when
using 3D glasses, please adjust 3D Sync
Invert from default Disable to Invert .
• HDMI Settings:
• HDMI Format: Select a suitable color
space according to the color space
setting of the output device connected.
• HDMI Range: Select a suitable HDMI
color range according to the color range
setting of the output device connected.
• Light Source Settings:
• Light Source Mode: Select a light source
mode.
14 Philips · GamePix 800 Smart
• Reset Light Source Hours: Reset the light
source timer after new lamp is installed.
• Light Source Information: Displays the
number of hours the light source has
been used.
• Reset Settings: Reset the settings to default.
SYSTEM settings
You can view and change the following system
settings.
• Language: Select the display language for
the projector.
• Projector Position: Adjust the projection
to the correct direction based on how the
projector is installed.
• Menu Settings:
• Menu Display Time: Set the settings
menu's display time.
• Menu Position: Set the settings menu's
position to Center, Top-Left, Top-Right,
Bottom-Left or Bottom-Right.
• High Altitude Mode: We recommend you
use the High Altitude Mode when your
environment is between 1,500 m to 3,000 m
above sea level, and ambient temperature is
between 0°C–40°C.
• Quick Auto Search: Allow the projector to
automatically search for the signals.
• Security Settings:
• Change Password: Follow the on-screen
instructions to change the password.
• Power on Lock: Set a password
after selecting On to help prevent
unauthorized access or use. To disable
the password function, select Off.
Tip: If the password function is activated, you
will be asked to enter the six-digit password
every time you turn on the projector. If you
enter the wrong password, the password error
message will appear for 5 seconds, and the
message ‘INPUT PASSWORD’ follows. If you enter
an incorrect password 5 times in succession, the
projector will automatically shut down in a short
time.
• Panel Key Lock: Lock the control keys on the
projector.
• Baud Rate: Selects a baud rate that is
identical with your computer’s so that you
can connect the projector using a suitable
RS-232 cable and control the projector with
RS-232 commands.
INFORMATION
You can view the following information.
• Source: Show the current input source.
• Color Mode: Show the selected mode in the
IMAGE menu.
• Resolution: Show the native resolution of the
input source.
• Color System: Show input system format.
• Firmware Version: Check firmware version of
this product.
• Game mode: Show whether the function is
activated or not.
• Serial Number: Check serial number of this
product.
15 Philips · GamePix 800 Smart
7 Maintenance
Cleaning
DANGER!
Follow the following instructions
when cleaning the projector:
Use a soft, lint-free cloth. Never use
liquid or easily flammable cleansers
(sprays, abrasives, polishes, alcohol, etc.).
Do not allow any moisture to reach the
interior of the projector. Do not spray
the projector with any cleaning fluids.
Wipe over the surfaces gently. Be careful
that you do not scratch the surfaces.
Cleaning the lens
Use a dry cloth for cleaning the lens of the
projector.
DANGER!
Do not use any liquid cleaning agents!
Do not use any liquid cleaning agents
for cleaning the lens, to avoid damaging
the coating film on the lens.
16 Philips · GamePix 800 Smart
8 Troubleshooting
Power cycling
If a problem occurs and you cannot resolve it using the instructions in this user manual, try the
following steps to resolve the problem.
1 Turn the projector off by pressing .
2 Wait at least 10 seconds.
3 Turn the projector on by pressing .
4 If the problem persists, contact one of our customer service centres or your dealer.
Problem Solution
The projector cannot be turned on. • Disconnect and reconnect the power cable, and try
to turn the projector on again.
The projector cannot be turned off.
• Press twice. If this does not work, disconnect the
power cable.
No image from the external HDMI™ device. 1. Check if the correct HDMI™ input is selected
(HDMI).
2. Disconnect the HDMI™ cable or switch off the
HDMI™ device.
3. Wait three seconds.
4. Reconnect the HDMI™ cable or switch on the
HDMI™ device again.
No sound from the external connected
device.
• Check the cables to the external device.
• Check that the sound is activated on the external
device.
• Only the original cables from the device
manufacturer may function.
No sound from external HDMI™ output
device.
• On the HDMI™ output device, set the audio setting
to Multichannel (Raw data) & Stereo (PCM).
No sound when you connect your computer
using an HDMI™ cable.
• Check that the sound is activated on the computer.
Only the home menu appears and not the
image from the external device.
• Check if the cables are connected to the correct
sockets.
• Check that the external device is turned on.
• Check if the video output of the external device is
turned on.
Only the home menu appears and not the
image from the connected computer.
• Check that the HDMI™ output of the computer is
turned on.
• Check if the resolution of the computer is set to
1920*1080.
The projector turns itself off. • When the projector is running for a long period of
time, the surface becomes hot.
• Check that the power cable is connected correctly.
The projector does not react to remote
control commands.
• Check the batteries of the remote control.
The temperature of the projector’s surface
is warm.
• For this projector it is normal to generate moderate
heat during operation.
17 Philips · GamePix 800 Smart
Problem Solution
The projector does not work after I connect
it to a laptop.
• Check that the HDMI™ cable is plugged in
correctly.
• Make sure that the laptop has been switched to
projector display.
Black dots (dead pixels) appear on the
screen.
DMD displays from Texas Instruments typically
contain a small number of pixels that do not function
normally. Your display has been inspected and is in
compliance with the manufacturer's specifications,
meaning that any pixel defects will not affect the
operation or use of your display. Without prejudice
to generality of the foregoing, a display with no more
than 7 dead pixels meets the factory specifications
and is not considered a defect under this warranty.
18 Philips · GamePix 800 Smart
9 Appendixes
Technical data
Technology/optical
Display technology ........................................... TI DLP
Light source ............................................................. LED
Colorimetry & metadata .............................. REC.709
Resolution .................................... 1920 × 1080 pixels
Light source lifetime .....................................................
.20,000 hours (Normal mode)/30,000 hours (Eco
mode)
FOFO contrast ratio ................................Min. 1500:1
Aspect ratio .................Auto/4:3/16:9/16:10/Real
Throw ratio ............... 1.49~1.64 (95” ±3% @ 3.1m)
Screen size (diagonal) ............................... 70" - 150"
Screen distance ....................... 2425 mm - 5197 mm
Lens protection ........................................................ no
Projection modes ........................................................ 4
Focus adjustment ............................................ manual
Keystone correction .......................................manual
TOF ............................................................................... no
4 corner correction .................................................. no
Digital zoom ........................................ yes (0.8x-2.0x)
Integrated media player ........................................ no
Sound
Built-in speakers .............................................. 1 x 5 W
Surround mode ........................................................ no
Equalization ............................................................. yes
Connection
HDMI™ in ....................................................................x 2
USB-A (5V/1.5A out + external drive) .................x1
USB-C ............................................................................ no
Bluetooth ......................Dongle for Mini B+HDMI 3
Power source
Power consumption ....operating: 156 W (typical)
...............standby: 0.5 W (max.) @100-240VAC
Integrated Media Player
....................................................................................... no
Dimensions and weight
Unpacked (W x D x H) ......... 302 x 222 x 119.4 mm
(including adjuster foot)
Packed (L x W x H) ...................410 x 170 x 313 mm
Weight ................................................. 2.3 kg / 5.07 lb
Temperature requirements
Operating temperature .......................... 0 °C - 40 °C
Storage temperature ........................... -20 °C - 60 °C
Package contents
1. GamePix 800 Smart projector
2. Remote control
3. Power cables (EU, UK, US, AU)
4. AAA batteries for remote control
5. Quick Start Guide with Warranty Card
6. Dongle
Model
GMX800/INT
EAN INT : 7640186962582
UPC: 667619993101
19 Philips · GamePix 800 Smart
CE statement
• The product shall only be connected to a
USB interface of version USB 2.0 or higher.
• Adapter shall be installed near the
equipment and shall be easily accessible.
• The operating temperature of the EUT can’t
exceed 35°C and shouldn’t be lower than
5°C.
• The plug is considered as disconnect device
of adapter.
• The UNII Band 5150-5250 MHz is for indoor
use only.
Hereby, Screeneo Innovation SA declares that
this product is in compliance with essential
requirements and other relevant provisions of
Directive 2014/53/EU.
The Declaration of Compliance can be consulted
on the site www.philips.com.
FCC statement
15�19 Labeling requirements�
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
15�21 Information to the user�
Any changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
15�105 Information to user�
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/
TV technician for help.
During operation, the separation distance
between the user and the antenna shall be at
least 20 cm. This separation distance will ensure
that there is sufficient distance from a properly
installed externally-mounted antenna to satisfy
the RF exposure requirements.
Canada regulatory
compliance
This device complies with Industry Canada CAN
ICES-3 (B)/NMB-3(B)
RSS-Gen & RSS-247 statement: This device
complies with Industry Canada RSS standard(s).
Operation is subject to the following two
conditions:
1 This device may not cause interference, and
2 This device must accept any interference,
including interference that may cause
undesired operation of the device.
RF Radiation Exposure statement: The device
meets the exemption from the routine evaluation
limits in section 2.5 of RSS102 and users can
obtain Canadian information on RF exposure and
compliance.
This device should be installed and operated with
a minimum distance of 7.8 inches (20centimetres)
between the device and your body.
Other notice
Preservation of the environment as part of a
sustainable development plan is an essential
concern of Screeneo Innovation SA. The desire
of Screeneo Innovation SA is to operate systems
respecting the environment and consequently
it has decided to integrate environmental
performances in the life cycle of these products,
20 Philips · GamePix 800 Smart
from manufacturing to commissioning use and
elimination.
Batteries: If your product contains batteries, they
must be disposed of at an appropriate collection
point.
Product: The crossed-out waste bin symbol on
the product means that the product belongs to
the family of electrical and electronic equipment.
In this respect, the European regulations ask you
to dispose of it selectively:
• At sales points in the event of the
purchase of similar equipment.
• At the collection points made available
to you locally (drop-off centre, selective
collection, etc.).
In this way you can participate in the reuse
and upgrading of Electrical and Electronic
Equipment Waste, which can have an effect on
the environment and human health.
The paper and cardboard packaging used can
be disposed of as recyclable paper. Have the
plastic wrapping recycled or dispose of it in
the non-recyclable waste, depending on the
requirements in your country.
Trademarks: The mentioned references in
this manual are trademarks of the respective
companies. The lack of the trademarks ® and
™ does not justify the assumption that these
dedicated terminologies are free trademarks.
Other product names used herein are for
identification purposes only and may be
trademarks of their respective owners. Screeneo
Innovation SA disclaims any and all rights in
those marks.
Neither Screeneo Innovation SA nor its affiliates
shall be liable to the purchaser of this product
or third parties for damages, losses, costs, or
expenses incurred by the purchaser or third
parties as a result of accident, misuse, or abuse
of this product or unauthorised modifications,
repairs, or alterations to this product, or failure
to strictly comply with Screeneo Innovation SA
operating and maintenance instructions.
Screeneo Innovation SA shall not be liable for
any damages or problems arising from the use of
any options or any consumable materials other
than those designated as original Screeneo
Innovation SA/PHILIPS products or Screeneo
Innovation SA/PHILIPS approved products.
Screeneo Innovation SA shall not be held liable
for any damage resulting from electromagnetic
interference that occurs from the use of any
interface cables other than those designated as
Screeneo Innovation SA/PHILIPS products.
All rights reserved. No part of this publication
may be reproduced, stored in a retrieval
system or transmitted in any form or by any
means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior
written permission of Screeneo Innovation SA.
The information contained herein is designed
only for use with this product. Screeneo
Innovation SA is not responsible for any use of
this information as applied to other devices.
This user manual is a document that does not
represent a contract.
Errors, printing errors and changes are reserved.
The terms HDMI, HDMI High-Definition
Multimedia Interface, HDMI Trade Dress and
the HDMI Logos are trademarks or registered
trademarks of HDMI Licensing Administrator,
Inc.
As with any bright light
source, do not stare
into the beam, RG2 IEC
62471-5:2015.
CAUTION
• Do not look into the lens while in use.
• Use of controls or adjustments or
performance of procedures other than those
specified herein may result in hazardous
radiation exposure.
• The use of optical instruments with this
product will increase eye hazard.
• Never allow children to stare into the
projector beam at any distance from the
projector.
• Do not turn on the projector with the
remote commander while in front of the
projection lens.
• Avoid the use of optical aids such as
binoculars or telescopes inside the beam.
21 Philips · GamePix 800 Smart
Rating label
Screeneo Innovation SA
Route de Lully 5c - 1131 Tolochenaz - Switzerland
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are
used under license. Screeneo Innovation SA is the warrantor in relation to the product with which
this booklet was packaged.
2025 © Screeneo Innovation SA. All rights reserved.
GamePix 800 Smart
EN
