WARNING! Ensure all Health and Safety, local authority, and
general workshop practice regulations are strictly adhered to when
using tools.
DO NOT use tools if damaged or worn.
Maintain the tools in good and clean condition for best and safest
performance.
Ensure all threads are clean and well lubricated.
Ensure vehicle is adequately supported with axle stands, ramps,
etc. as appropriate.
Wear suitable clothing to avoid snagging. DO NOT wear jewellery.
Tie back long hair.
Wear approved eye protection. A full range of personal safety
equipment is available from your Sealey dealer.
Account for all tools and parts being used and DO NOT leave them
in or on the vehicle.
IMPORTANT: Always refer to the vehicle manufacturer’s service
instructions, or proprietary manual, to establish the correct
procedure and data for the specific vehicle you are working on.
These instructions for use are provided as a guide only.
1. HUB SCREW NUT 5. VEHICLE HUB
2. WASHER 6. SLEEVE
3. DRIFTS 7. SLEEVE CAP
4. BEARING 8. HUB SCREW
Comprehensive kit of tools for the fast and effective removal and
installation of wheel bearings on front-wheel drive vehicles. Reduces
chances of damage to hub and bearing. Heavy-duty steel drifts with
phosphate coating to prevent corrosion. Heavyweight drive screw for use
with impact tools. Also suitable for removing and installing large
industrial bearings. Supplied in carry-case.
Drift Sizes Ø: 50, 55, 60, 64, 67, 73, 75, 78, 82, 84,
88mm
Sleeve Ø External: 76, 86, 92, 101mm
Hub screw length: 210mm
Hub screw drive: 32, 38mm
BEARING REMOVAL: Identify the correct sleeve (6) to sit on the
outside of the bearing housing and the correct drift (3) to drive the
sleeve cap (7). Keep the hub screw and nut well lubricated whilst driving
out the bearing.
BEARING INSTALLATION: Identify the correct sleeve cap (7) to sit on
the outside of the bearing housing and the correct
diameter drift (3) to drive the new bearing into the housing. Assemble as
driving the new bearing into the housing.
IMPORTANT : PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT
CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL
INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
2. INTRODUCTION
4. INSTRUCTIONS
3. SPECIFICATIONS
Refer to
instruction
manual
Wear eye
protection
Thank you for purchasing this product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
WHEEL BEARING REMOVAL & INSTALLATION KIT
Instruction Manual
