SPECIFICATIONS
6505
®
Slant / 6505 Straight
Designed to the exacting specifications of our original 1992 version with a few basic updates that have been requested
by countless artists over the years. The all-new Sheffield 1230+ speakers harken back to the earliest original Sheffield
design that initially sealed the deal back in 1991. These are loaded in a biplanar-aligned, infinite baffle, closed-back
cabinet. Dual 1/4” jacks with Stereo/Mono selector. 300W(rms) power handling. Solid Birch plywood construction,
recessed handles, and heavy-duty pop-out casters. 16 Ohms mono, 8 Ohms per side stereo.
The 6505 series amplifiers and enclosures are the result of extensive research and development to produce the ulti-
mate products for guitarists. With the 6505-1992 Original, 6505 II, and 6505MH heads, you’ll experience super rock
crunch, harmonic-rich sustain, and screaming drive like you’ve never heard before. Production models are identical
to those used by countless legendary artists for recording, as well as on tour.
Features Spec s
• 4 - 12” Sheffield 1230+ speakers • 30”W x 32-3/8”H x 14-1/8”D
• 300W handling • 96 lbs.
• Dual 1/4” jacks
• Stereo/Mono switch
• High-density Birch plywood construction
• Recessed handles
• Heavy-duty pop-out casters
• 16 ohms mono, 8 Ohms per side stereo
Logo referenced in Directive 2002/96/EC Annex IV
(OJ(L)37/38,13.02.03 and defined in EN 50419: 2005
The bar is the symbol for marking of new waste and
is applied only to equipment manufactured after
13 August 2005
Features and specications are subject to change without notice.
Peavey Electronics Corporation • 5022 Hartley Peavey Drive •
Merid-
ian, MS 39305 • (601) 483-5365
• www.peavey.com
80307546 ©2022 Printed in the U.S.A.
