Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
For Best Results,
Use 3.0 Amp Hour Battery
or Greater
Grinding Wheel, Battery and
Charger Sold Separately
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual (or month and year of purchase if product has no number). Keep this manual and the receipt
in a safe and dry place for future reference. 22b
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright
©
2021 by Harbor Freight Tools
®
. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ols required for assembly and se rv ic e m ay n ot b e i nc lu de d .
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 56401
SAFEty OpERAtiOn MAintEnAnCESEtUp
table of Contents
Safety ........................................................................2
Specifications ............................................................8
Setup .........................................................................8
Operation ..................................................................10
Maintenance .............................................................13
Warranty ...................................................................16
WARninG SyMBOLS AnD DEFinitiOnS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
iMpORtAnt SAFEty inFORMAtiOn
General power tool Safety Warnings
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Work Area Safety
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
3. Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
Page 3For technical questions, please call 1-888-866-5797.Item 56401
SAFEtyOpERAtiOnMAintEnAnCE SEtUp
Electrical Safety
Do not expose power tools to rain or wet conditions.
personal Safety
1. Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment
2. Use safety equipment. Always wear eye
protection.
dust mask, non-skid safety shoes, hard hat,
3. prevent unintentional starting. Ensure
the switch/trigger is in the off-position
before connecting to power source and/
or battery pack, picking up or carrying the
tool.
have the switch on invites accidents.
4. Remove any adjusting key or wrench
before turning the power tool on.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control
6. Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry
7. if devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
these devices can reduce dust-related hazards.
8. Only use safety equipment that has been approved
by an appropriate standards agency. Unapproved
safety equipment may not provide adequate
protection. Eye protection must be ANSI-approved
and breathing protection must be NIOSH-approved
for the specific hazards in the work area.
power tool Use and Care
1. Do not force the power tool.
Use the correct power tool for your application.
safer at the rate for which it was designed.
2. Do not use the power tool if the switch/trigger
does not turn it on and off.
3. Disconnect the battery pack from the
power tool before making any adjustments,
changing accessories, or storing power
tools.
4. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
5. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. if damaged, have the
power tool repaired before use. Many accidents
6. Keep cutting tools sharp and clean.
bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
intended could result in a hazardous situation.
Page 4 For technical questions, please call 1-888-866-5797. Item 56401
SAFEty OpERAtiOn MAintEnAnCESEtUp
Battery tool use and care
1. Recharge only with the charger specified by
the manufacturer. A charger that is suitable
2. Use power tools only with specifically
designated battery packs. Use of any other
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
if contact accidentally occurs, flush with water.
if liquid contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
Service
Have your power tool serviced by a qualified repair person using only identical replacement parts.
Safety Warnings Common for Grinding Operations
1. this power tool is intended to function
as a grinder. Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
2. Operations such as sanding, wire brushing,
polishing, or cutting-off are not recommended
to be performed with this power tool. Operations
for which the power tool was not designed may
create a hazard and cause personal injury.
3. Do not use accessories which are not
specifically designed and recommended
by the tool manufacturer. Just because the
4. the rated speed of the accessory must be at
least equal to the maximum speed marked on
the power tool. Accessories running faster than
5. the outside diameter and the thickness of your
accessory must be within the capacity rating
of your power tool. Incorrectly sized accessories
cannot be adequately guarded or controlled.
6. the arbor size of wheels, flanges, backing
pads or any other accessory must properly
fit the spindle of the power tool. Accessories
with arbor holes that do not match the mounting
7. Do not use a damaged accessory.
Before each use inspect the accessory such
as abrasive wheels for chips and cracks.
if power tool or accessory is dropped,
inspect for damage or install an undamaged
accessory. After inspecting and installing an
accessory, position yourself and bystanders
away from the plane of the rotating accessory
and run the power tool at maximum no-load
speed for one minute. Damaged accessories
8. Wear personal protective equipment. Depending
on application, use face shield, safety goggles
or safety glasses. As appropriate, wear dust
mask, hearing protectors, gloves and workshop
apron capable of stopping small abrasive or
workpiece fragments. the eye protection must
be capable of stopping flying debris generated
by various operations.
intensity noise may cause hearing loss.
9. Keep bystanders a safe distance away
from work area. Anyone entering the
work area must wear personal protective
equipment.
broken accessory may fly away and cause
10. Hold power tool by insulated gripping surfaces
only, when performing an operation where
the accessory may contact hidden wiring
or its own cord. An accessory contacting a
Page 5For technical questions, please call 1-888-866-5797.Item 56401
SAFEtyOpERAtiOnMAintEnAnCE SEtUp
11. never lay the power tool down until the
accessory has come to a complete stop.
12. Do not run the power tool while carrying
it at your side. Accidental contact with the
13. Regularly clean the power tool’s air vents.
The motor’s fan will draw the dust inside
14. Do not operate the power tool near flammable
materials.
15. Do not use accessories that require liquid
coolants. Using water or other liquid coolants
may result in electrocution or shock.
16. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
17. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
18. Do not depress the spindle lock when
starting or during operation.
19. Do not leave the tool unattended when the
Battery Pack is connected. Turn off the tool,
and remove the Battery Pack before leaving.
20. Use clamps (not included) or other practical
ways to secure and support the workpiece to
a stable platform. Holding the work by hand
or against your body is unstable and may
lead to loss of control and personal injury.
21. The battery charger gets hot during
use. The charger’s heat can build up to
unsafe levels and create a fire hazard if
it does not receive adequate ventilation,
due to an electrical fault, or if it is used in a hot
environment.
Do not place the charger on a flammable surface.
Do not obstruct any vents on the charger.
Especially avoid placing the charger on carpets
and rugs; they are not only flammable, but they
also obstruct vents under the charger.
22. This product is not a toy.
Keep it out of reach of children.
23. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
In addition, people with pacemakers should:
• Avoid operating alone.
• Do not use with power switch locked on.
• Properly maintain and inspect
to avoid electrical shock.
• Properly ground power cord. Ground Fault Circuit
Interrupter (GFCI) should also be implemented
– it prevents sustained electrical shock.
24. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or
snagged rotating wheel, backing pad, brush
or any other accessory. Pinching or snagging
causes rapid stalling of the rotating accessory
which in turn causes the uncontrolled power
tool to be forced in the direction opposite of the
accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or
pinched by the workpiece, the edge of the wheel that
is entering into the pinch point can dig into the surface
of the material causing the wheel to climb out or kick
out. The wheel may either jump toward or away from
the operator, depending on direction of the wheel’s
movement at the point of pinching. Abrasive wheels
may also break under these conditions.
Kickback is the result of power tool misuse and/or
incorrect operating procedures or conditions and can be
avoided by taking proper precautions as given below.
1. Maintain a firm grip on the power tool and
position your body and arm to allow you to
resist kickback forces. Always use auxiliary
handle, if provided, for maximum control over
kickback or torque reaction during start-up.
2. never place your hand near the
rotating accessory. Accessory may
kickback over your hand.
3. Do not position your body in the area where
power tool will move if kickback occurs.
Page 6 For technical questions, please call 1-888-866-5797. Item 56401
SAFEty OpERAtiOn MAintEnAnCESEtUp
4. Use special care when working corners, sharp
edges etc. Avoid bouncing and snagging the
accessory.
have a tendency to snag the rotating accessory
and cause loss of control or kickback.
5. Do not attach a saw chain woodcarving
blade or toothed saw blade. Such blades
create frequent kickback and loss of control.
Safety Warnings Specific for Grinding and
Abrasive Cutting-off Operations
1. Use only wheel types that are recommended
for your power tool and the specific
guard designed for the selected wheel.
cannot be adequately guarded and are unsafe.
2. the guard must be securely attached
to the power tool and positioned for
maximum safety, so the least amount of
wheel is exposed towards the operator.
wheel fragments and accidental contact with wheel.
3. Wheels must be used only for recommended
applications. For example: do not grind with
the side of cut-off wheel. Abrasive cut-off wheels
4. Always use undamaged wheel flanges
that are of correct size and shape for your
selected wheel.
breakage. Flanges for cut-off wheels may
be different from grinding wheel flanges.
5. Do not use worn down wheels from larger
power tools. Wheel intended for larger
6. Dress appropriately. Wear leather leggings
and fire resistant footwear during use. Do
Lithium Battery Safety Warnings
LitHiUM BAttERiES StORE A
LARGE AMOUnt OF EnERGy
AnD WiLL VEnt FiRE OR
EXpLODE iF MiStREAtED:
1. Keep Battery pack dry.
2. DO nOt DO Any OF tHE FOLLOWinG
tO tHE BAttERy pACK:
a. Open,
b. Drop,
c. Short-circuit,
d. puncture,
e. incinerate, or
f. Expose to temperatures greater than 265°F.
3. Charge Battery Pack only according
to its Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.
SAVE tHESE inStRUCtiOnS.
Page 7For technical questions, please call 1-888-866-5797.Item 56401
SAFEtyOpERAtiOnMAintEnAnCE SEtUp
Grounding
tO pREVEnt ELECtRiC SHOCK AnD DEAtH FROM
inCORRECt GROUnDinG WiRE COnnECtiOn:
Check with a qualified electrician if you are in doubt as to whether the outlet is properly
grounded. Do not modify the power cord plug provided with the tool. never remove the
grounding prong from the plug. Do not use the tool if the power cord or plug is damaged. if damaged,
have it repaired by a service facility before use. if the plug will not fit the outlet, have a proper outlet
installed by a qualified electrician.
Double insulated tools: tools with two prong plugs
Outlets for 2-prong plug
1. Tools marked “Double Insulated” do not
require grounding. They have a special
double insulation system which satisfies OSHA
requirements and complies with the applicable
standards of Underwriters Laboratories, Inc.,
the Canadian Standard Association,
and the National Electrical Code.
2. Double insulated tools may be used in either of the
120 volt outlets shown in the preceding illustration.
(See Outlets for 2-prong plug.)
Extension Cords
note: Extension cords must not be used with this item’s Charger.
Symbology
Double Insulated
V
Volts
~
Alternating Current
Direct Current
A
Amperes
n xxxx/min.
Rated Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
WARNING marking concerning Risk
of Respiratory Injury. Wear NIOSH-
approved breathing protection rated
for the hazards in your work area.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
Page 8 For technical questions, please call 1-888-866-5797. Item 56401
SAFEty OpERAtiOn MAintEnAnCESEtUp
Specifications
Battery Type
Bauer 20V Li-ion:
64816 (sold separately)
Charger Type
Bauer 20V Li-ion:
63947 (sold separately)
No Load Speed n
0
: 7000/min
Spindle Thread 5/8″ – 11 UNC
Wheel Diameter 4-1/2″
Setup - Before Use:
Read the EntiRE iMpORtAnt SAFEty inFORMAtiOn section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
tO pREVEnt SERiOUS inJURy FROM ACCiDEntAL OpERAtiOn:
Make sure that the trigger Switch is in the off-position and remove the
Battery pack before performing any procedure in this section.
installing the Wheel Guard
tO pREVEnt SERiOUS inJURy: Do not operate this tool without the Wheel Guard properly installed.
1. Pull the Clamp Handle out, away from the
Grinder, to unlock and loosen the Wheel Guard.
2. Slide the collar of the Wheel Guard
over the rim of the Gear Housing.
3. Rotate the Wheel Guard as needed to
shield you during the planned work.
4. Once positioned, push to close and
lock the Clamp Handle in place.
5. Check the Wheel Guard to ensure
it is firmly in place. Adjust if
necessary before proceeding.
Wheel Guard
Clamp Handle
Page 9For technical questions, please call 1-888-866-5797.Item 56401
SAFEtyOpERAtiOnMAintEnAnCE SEtUp
installing the Auxiliary Handle
tO pREVEnt SERiOUS inJURy:
Do not operate this tool with one hand only or without the Auxiliary Handle properly installed.
1. The Auxiliary Handle may be installed
in one of two positions, on either
side of the Gear Housing.
2. Screw the threaded end of the
Auxiliary Handle into the selected position.
Tighten securely before beginning work.
Auxiliary Handle positions
Functions
Auxiliary
Handle
Spindle Lock
Button
trigger Switch
Wrench
Wheel
Guard
Grinding Wheel
(sold separately)
Battery
Receptacle
Page 10 For technical questions, please call 1-888-866-5797. Item 56401
SAFEty OpERAtiOn MAintEnAnCESEtUp
Operating instructions
Read the EntiRE iMpORtAnt SAFEty inFORMAtiOn section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
tool Set Up
tO pREVEnt SERiOUS inJURy FROM ACCiDEntAL OpERAtiOn:
Make sure that the trigger Switch is in the off-position and remove the
Battery pack before performing any procedure in this section.
installing a non-threaded Grinding Wheel
1. The Grinding Wheel (sold separately) MUST be:
• rated to at least 7,000 RPM
• 4-1/2″ (115 mm) in diameter
• fitted with a 7/8″ round arbor hole
• 1/4" (6mm) thick or less
• suitable for surface grinding, not edge grinding
• dry and clean
• proven undamaged by inspection
2. Press in and hold the Spindle Lock Button
to prevent the Spindle from turning.
3. Remove the Outer Flange.
Keep the Inner Flange in
position on the Spindle.
4. Closely inspect the Grinding
Wheel before mounting.
WARninG! tO pREVEnt SERiOUS inJURy:
Do not use worn or damaged wheels.
5. Place the Grinding Wheel onto the Spindle.
note: The Outer Flange has a step for improved
stability with thick accessories. Keep this step
on the inside for thick accessories. To allow
proper clamping for thin accessories, flip Outer
Flange so this step is on the outside.
6. Thread the Outer Flange onto the Spindle.
Wrench tighten only enough so that the wheel is
securely held on the spindle.
WARninG: to prevent serious injury,
do not overtighten flange. Overtightening can
damage the wheel, causing wheel failure.
Grinding
Wheel
Wrench
Spindle Lock
Button
Outer
Flange
Spindle
Wheel
Guard
Page 11For technical questions, please call 1-888-866-5797.Item 56401
SAFEtyOpERAtiOnMAintEnAnCE SEtUp
installing a threaded Accessory
1. The accessory MUST be:
• rated to at least 7,000 RPM
• 4-1/2″ (115 mm) in diameter
• fitted with a threaded opening of 5/8″ – 11 UNC
• undamaged
• a grinding wheel suitable for surface grinding,
not edge grinding (accessories not included).
2. Press in and hold the Spindle Lock Button
to prevent the Spindle from turning.
3. Remove the Outer Flange and Inner
Flange and keep in a safe place.
4. Thread disc accessory onto the Spindle.
Wrench tighten onto the Spindle.
Battery Charging
Charge battery pack before using this tool. Follow instructions included
with battery charger. Battery Pack and Charger sold separately.
installing the Battery pack
note: Battery Pack sold separately.
1. With the Trigger Switch in the “OFF” position,
insert a fully charged battery pack into the
Battery Receptacle until it clicks in place.
2. to remove, push the latch on the
battery back and slide it out.
Latch
Battery pack
Battery
Receptacle
Workpiece and Work Area Set Up
1. Designate a work area that is clean and well-lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Secure loose workpieces using a vise or clamps
(not included) to prevent movement while working.
3. There must not be hazardous objects, such
as utility lines or foreign objects, nearby
that will present a hazard while working.
4. You must use personal safety equipment including,
but not limited to, ANSI-approved eye and hearing
protection, as well as heavy-duty work gloves.
5. Before beginning work, provide for sparks
and debris that will fly off the work surface.
Page 12 For technical questions, please call 1-888-866-5797. Item 56401
SAFEty OpERAtiOn MAintEnAnCESEtUp
Grinding instructions
tO pREVEnt SERiOUS inJURy: Grip the tool firmly in both hands.
1. Make sure that the Trigger Switch is in the
“OFF” position, then connect the battery pack.
2. Place one hand on the motor housing and the
other on the side handle before starting the tool.
3. Start the tool by pressing the Trigger Switch
down and then forward until it locks in place.
4. Allow the tool to come up to full speed
before touching the work material.
5. Apply the wheel to the work material at a 10°– 15°
angle, allowing the tool to operate at full speed.
If the tool bogs down, use lighter pressure.
6. To create a smoother surface,
keep the tool moving over the work surface.
7. tO pREVEnt ACCiDEntS, AFtER USE:
Turn off the tool by pushing the
Trigger Switch backward.
WARninG! tO pREVEnt SERiOUS inJURy: Allow
the tool to come to a complete stop before setting
it down.
Remove the tool’s Battery Pack. Clean, then
store the tool indoors out of children’s reach.
Page 13For technical questions, please call 1-888-866-5797.Item 56401
SAFEtyOpERAtiOnMAintEnAnCE SEtUp
Maintenance and Servicing
procedures not specifically explained in this manual must
be performed only by a qualified technician.
tO pREVEnt SERiOUS inJURy FROM ACCiDEntAL OpERAtiOn:
Make sure that the trigger Switch is in the off-position and remove its
Battery pack before performing any procedure in this section.
tO pREVEnt SERiOUS inJURy FROM tOOL FAiLURE:
Do not use damaged equipment. if abnormal noise or vibration occurs,
have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect the general
condition of the tool. Check for:
• leaking, swollen, or cracked battery pack
• loose hardware
• misalignment or binding of moving parts
• cracked or broken parts
• damaged electrical wiring
• any other condition that may
affect its safe operation.
2. AFtER USE, wipe external surfaces
of the tool with clean cloth.
3. Disconnect battery pack and store battery pack,
charger, and tool in dry, indoor area out of
reach of children and away from metal objects
(i.e., paperclips, coins) to prevent shorting.
4. Li-ion BAttERy MUSt BE RECyCLED OR
DiSpOSED OF pROpERLy.
Do not short, incinerate or open battery.
5. Periodically, wear ANSI-approved safety goggles
and NIOSH-approved breathing protection
and blow dust and grit out of the motor
vents using dry compressed air.
Accessory Storage and Handling
1. Handle accessories carefully to prevent
dropping or bumping. Do not use wheels
that have been dropped or bumped.
2. Store accessories in shelves, racks, boxes,
or drawers. Keep storage area dry and
above freezing. Any grinding or cut-off
wheels exposed to humidity or freezing
temperatures must not be used.
Page 14 For technical questions, please call 1-888-866-5797. Item 56401
SAFEty OpERAtiOn MAintEnAnCESEtUp
troubleshooting
problem possible Causes Likely Solutions
Tool will not start. 1. Battery Pack not properly connected.
2. Battery Pack not properly charged.
3. Battery Pack stopped working.
4. Tool’s thermal reset
breaker tripped (if equipped).
5. Internal damage or wear. (Carbon
brushes or power switch, for example.)
1. Remove Battery Pack, make sure there
are no obstructions, reinsert the Battery
Pack according to its shape (it should
only fit one way), and press firmly until
the Battery Pack locks in place.
2. Make sure Charger is connected and
operating properly. Give enough time
for Battery Pack to recharge properly.
3. Dispose of old Battery Pack
properly or recycle. Replace Battery Pack.
4. Turn off tool and allow to cool.
Press reset button on tool.
5. Have technician service tool.
Tool operates slowly. 1. Excess pressure applied to workpiece.
2. Battery Pack power low.
3. Battery Pack wearing out.
1. Decrease pressure, allow
tool to do the work.
2. Recharge Battery Pack.
3. Dispose of old Battery Pack
properly or recycle. Replace Battery Pack.
Performance
decreases over time.
1. Carbon brushes worn or damaged.
2. Battery Pack wearing out.
1. Have qualified technician replace brushes.
2. Battery Pack capacity will gradually
decrease through use. If symptoms
are severe, recycle old Battery Pack
(or dispose of properly) and replace it.
Excessive noise
or rattling.
Internal damage or wear.
(Carbon brushes or bearings, for example.)
Have technician service tool.
Overheating. 1. Forcing tool to work too fast.
2. Blocked motor housing vents.
1. Allow tool to work at its own rate.
2. Wear ANSI-approved safety goggles
and NIOSH-approved dust mask/
respirator while blowing dust out of
motor using compressed air.
Tool does not
grind effectively.
1. Accessory loose.
2. Accessory damaged, worn or
wrong type for the material.
1. Confirm accessory arbor is correct
and Outer Flange/Arbor Nut is tight.
2. Check condition and type of disc accessory.
Use only proper type of disc
accessory in good condition.
Follow all safety precautions whenever diagnosing or servicing
the tool. Disconnect power supply before service.
Page 15For technical questions, please call 1-888-866-5797.Item 56401
SAFEtyOpERAtiOnMAintEnAnCE SEtUp
Record product’s Serial number Here:
note: If product has no serial number, record month and year of purchase instead.
note: Replacement parts are not available for this item. Refer to UPC 193175465269.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability
standards, and warrants to the original purchaser that this product is free from defects in materials
and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to
damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside
our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent,
special or consequential damages arising from the use of our product. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation of exclusion
may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
