en Table of contents
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
INFORMATION FOR USE
1 Safety ........................................................................ 2
2 Preventing material damage .................................. 5
3 Environmental protection and saving energy ...... 6
4 Familiarising yourself with your appliance .......... 7
5 Operating modes ..................................................... 9
6 Accessories ........................................................... 10
7 Before using for the first time .............................. 11
8 Basic operation ..................................................... 12
9 Time-setting options ............................................. 13
10 Microwave ............................................................ 15
11 Dishes ................................................................... 16
12 Favourites ............................................................ 18
13 Childproof lock .................................................... 18
14 Basic settings ...................................................... 18
15 HomeConnect ................................................... 20
16 Cleaning and servicing ...................................... 21
17 Cleaning aid ........................................................ 23
18 Drying .................................................................. 24
19 Appliance door .................................................... 24
20 Rails ..................................................................... 25
21 Troubleshooting ................................................. 26
22 Disposal ............................................................... 28
23 Customer Service ............................................... 28
24 Information regarding Free and Open Source
Software ............................................................... 28
25 Declaration of Conformity .................................. 29
26 How it works ........................................................ 29
27 INSTALLATION INSTRUCTIONS ....................... 37
27.1 General installation instructions .................... 37
Safety 1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product
information safe for future reference or for
the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
This appliance is designed only to be built into
kitchen units. Read the special installation in-
structions.
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡ To prepare meals and drinks.
¡ For household use and similar applications,
such as: In kitchens for employees in shops,
offices and other commercial sectors; in ag-
riculture; by customers in hotels and other
residential facilities; in bed and breakfasts.
¡ Up to an altitude of 4000m above sea level.
This appliance complies with the standards EN
55011 and CISPR 11. It is a group 2, class B
product. Group 2 means that microwaves are
produced for the purpose of heating food.
Class B means that the appliance is suitable
for private households.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
2
Safety en
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
Always place accessories in the cooking com-
partment the right way round.
"Accessories", Page10
WARNING‒Risk of fire!
Combustible objects that are left in the cook-
ing compartment may catch fire.
Never store combustible objects in the cook-
ing compartment.
If smoke is emitted, the appliance must be
switched off or the plug must be pulled out
and the door must be held closed in order to
stifle any flames.
Loose food remnants, fat and meat juices may
catch fire.
Before using the appliance, remove the
worst of the food residues and remnants
from the cooking compartment, heating ele-
ments and accessories.
Opening the appliance door creates a draught.
Greaseproof paper may come into contact with
the heating element and catch fire.
Never place greaseproof paper loosely over
accessories when preheating the appliance
and while cooking.
Always cut greaseproof paper to size and
use a plate or baking tin to hold it down.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
Caution should be exercised here in order to
avoid touching heating elements.
Young children under 8 years of age must
be kept away from the appliance.
Accessories and cookware get very hot.
Always use oven gloves to remove ac-
cessories or cookware from the cooking
compartment.
When the cooking compartment is hot, any al-
coholic vapours inside may catch fire. The ap-
pliance door may spring open. Hot steam and
jets of flame may escape.
Only use small quantities of drinks with a
high alcohol content in food.
Do not heat spirits (≥ 15% vol.) when undi-
luted (e.g. for marinating or pouring over
food).
Open the appliance door carefully.
WARNING‒Risk ofscalding!
The accessible parts of the appliance become
hot during operation.
Never touch these hot parts.
Keep children at a safe distance.
Hot steam may escape when you open the ap-
pliance door. Steam may not be visible, de-
pending on the temperature.
Open the appliance door carefully.
Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
Never pour water into the cooking compart-
ment when the cooking compartment is hot.
WARNING‒Risk of injury!
Scratched glass in the appliance door may de-
velop into a crack.
Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the oven door, as they may scratch the
surface.
The appliance and its parts that can be
touched may have sharp edges.
Take care when handling and cleaning them.
If possible, wear protective gloves.
The hinges on the appliance door move when
the door is opened and closed, which could
trap your fingers.
Keep your hands away from the hinges.
Components inside the appliance door may
have sharp edges.
Wear protective gloves.
Alcoholic vapours may catch fire in the hot
cooking compartment, and the appliance door
may spring open and may fall off. The door
panels may shatter and fragment.
"Preventing material damage", Page5
Only use small quantities of drinks with a
high alcohol content in food.
Do not heat spirits (≥ 15% vol.) when undi-
luted (e.g. for marinating or pouring over
food).
Open the appliance door carefully.
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be car-
ried out by trained specialist staff.
Only use genuine spare parts when repairing
the appliance.
If the power cord or the appliance power
cable of this appliance is damaged, it must
be replaced with a special power cord or
special appliance power cable, which is
3
en Safety
available from the manufacturer or its Cus-
tomer Service.
If the power cord of this appliance is dam-
aged, it must be replaced by trained special-
ist staff.
If the insulation of the power cord is damaged,
this is dangerous.
Never let the power cord come into contact
with hot appliance parts or heat sources.
Never let the power cord come into contact
with sharp points or edges.
Never kink, crush or modify the power cord.
An ingress of moisture can cause an electric
shock.
Do not use steam- or high-pressure cleaners
to clean the appliance.
If the appliance or the power cord is damaged,
this is dangerous.
Never operate a damaged appliance.
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
If the appliance or the power cord is dam-
aged, immediately unplug the power cord or
switch off the fuse in the fuse box.
Call customer service.
Page28
Once the appliance has been installed, the
openings in the back panel of the appliance
must not be accessible to children.
Read the special installation instructions.
WARNING‒Risk of suffocation!
Children may put packaging material over their
heads or wrap themselves up in it and suffoc-
ate.
Keep packaging material away from chil-
dren.
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
1.5 Microwave
CAREFULLY READ THE IMPORTANT SAFETY
INSTRUCTIONS AND KEEP THEM SAFE FOR
FUTURE USE
WARNING‒Risk of fire!
Using the appliance for anything other than its
intended purpose is dangerous and may
cause damage. For example, heated slippers
and pillows filled with grain or cereal may
catch fire, even several hours later.
Never dry food or clothing with the appli-
ance.
Never heat up slippers, pillows filled with
grain or cereal, sponges, damp cleaning
cloths or similar with the appliance.
The appliance must only be used to prepare
food and drink.
Food and its packaging and containers may
catch fire.
Never heat food in heat-retaining packaging.
Do not leave food unattended while it is
heating in containers made of plastic, paper
or other combustible materials.
Never set the microwave power too high or
the cooking time too long. Follow the instruc-
tions provided in this user manual.
Never use the microwave to dry food.
Never defrost or heat food with a low water
content, such as bread, at too high a mi-
crowave power or for too long.
Cooking oil may catch fire.
Never use the microwave to heat cooking oil
on its own.
WARNING‒Risk of explosion!
Liquids and other food may easily explode
when in containers that have been tightly
sealed.
Never heat liquids or other food in contain-
ers that have been tightly sealed.
WARNING‒Risk of burns!
Foods with peel or skin may burst or explode
during heating, or even afterwards.
Never cook eggs in their shell or heat hard-
boiled eggs in their shell.
Never cook shellfish or crustaceans.
Always prick the yolk of eggs before mi-
crowaving.
The skin of foods that have a peel or skin,
such as apples, tomatoes, potatoes and
sausages, may burst. Before heating, prick
the peel or skin.
Heat is not distributed evenly through baby
food.
Never heat baby food in closed containers.
Always remove the lid or teat.
Stir or shake well after heating.
Check the temperature before giving the
food or drink to a child.
4
Preventing material damage en
Heated food gives off heat. The cookware may
become hot.
Always use oven gloves to remove cook-
ware or accessories from the cooking com-
partment.
Airtight packaging may burst when food is
heated.
Always follow the instructions on the pack-
aging.
Always use oven gloves to remove the
dishes from the cooking compartment.
The accessible parts of the appliance become
hot during operation.
Never touch these hot parts.
Keep children at a safe distance.
At the highest settings in microwave only
mode, the drying function will automatically
switch on an additional heating element to
heat the cooking compartment.
Never touch the inside surfaces of the cook-
ing compartment or the heating elements
while they are hot.
Keep children at a safe distance.
WARNING‒Risk ofscalding!
There is a possibility of delayed boiling when a
liquid is heated. This means that the liquid
reaches the boiling temperature without the
usual steam bubbles rising to the surface. Ex-
ercise caution even when only gently shaking
the container. The hot liquid may suddenly boil
over and splatter.
Always place a spoon in the container when
heating liquids. This prevents delayed boil-
ing.
WARNING‒Risk of injury!
Unsuitable cookware may crack. Porcelain or
ceramic cookware can have small perforations
in the handles and lid. These perforations con-
ceal a cavity below. If moisture penetrates this
cavity, it could cause the cookware to crack.
Only use microwave-safe cookware.
Cookware and containers made from metal or
cookware with metal edging may lead to
sparks being formed during simple microwave
operation. The appliance is damaged.
Never use metal containers during mi-
crowave-only operation.
Only use microwave-safe cookware or use
the microwave in combination with a type of
heating.
WARNING‒Risk of electric shock!
The appliance uses a high voltage.
Never remove the casing.
WARNING‒Risk of serious harm to
health!
Inadequate cleaning may destroy the surface
of the appliance, reduce its service life, and
lead to dangerous situations, such as escap-
ing microwave energy.
Clean the appliance on a regular basis, and
remove any food residue immediately.
Always keep the cooking compartment, door
seal, door and hinge clean.
"Cleaning and servicing", Page21
Never operate the appliance if the cooking
compartment door or the door seal is dam-
aged. Microwave energy may escape.
Never use the appliance if the cooking com-
partment door, the door seal or the plastic
door frame is damaged.
Any repair work must only be carried out by
customer service.
Microwave energy will escape from appliances
that do not have any casing.
Never remove the casing.
For any maintenance or repair work, contact
the customer service.
Preventing material damage2 Preventing material damage
2.1 General
ATTENTION
Alcoholic vapours may catch fire in the hot cooking
compartment and cause permanent damage to the ap-
pliance. The appliance door may spring open due to an
explosion and it may fall off. The door panels may shat-
ter and fragment. Due to the resulting negative pres-
sure, the cooking compartment may become consider-
ably deformed inwards.
Do not heat spirits (≥ 15% vol.) when undiluted (e.g.
for marinating or pouring over food).
5
en Environmental protection and saving energy
If there is water on the cooking compartment floor when
operating the appliance at temperatures above 120°C,
this will damage the enamel.
Do not use the appliance if there is water on the
cooking compartment floor.
Wipe away any water on the cooking compartment
floor before operation.
Objects on the cooking compartment floor at over
50°C will cause heat to build up. The baking and roast-
ing times will no longer be correct and the enamel will
be damaged.
Do not place any accessories, greaseproof paper or
foil of any kind on the cooking compartment floor.
Only place cookware on the cooking compartment
floor if a temperature under 50°C has been set.
When the cooking compartment is hot, any water inside
it will create steam. The change in temperature may
cause damage.
Never pour water into the cooking compartment when
it is still hot.
Never place cookware containing water on the cook-
ing compartment floor.
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
Allow the cooking compartment to dry after use.
Do not keep moist food in the cooking compartment
for a long time with the door closed.
Do not store food in the cooking compartment.
Take care not to trap anything in the appliance door.
Fruit juice dripping from the baking tray leaves stains
that cannot be removed.
When baking very juicy fruit flans, do not pack too
much on the baking tray.
If possible, use the deeper universal pan.
Using oven cleaner in a hot cooking compartment dam-
ages the enamel.
Never use oven cleaner in the cooking compartment
when it is still warm.
Remove all food remnants from the cooking compart-
ment and the appliance door before you next heat up
the appliance.
If the seal is very dirty, the appliance door will no longer
close properly during operation. This may damage the
front of adjacent kitchen units.
Keep the seal clean at all times.
Never operate the appliance if the seal is damaged or
missing.
Sitting or placing objects on the appliance door may
damage it.
Do not place, hang or support objects on the appli-
ance door.
Do not place cookware or accessories on the appli-
ance door.
With certain models, accessories may scratch the door
pane when closing the appliance door.
Always push accessories fully into the cooking com-
partment.
If aluminium foil comes into contact with the door pane,
it could cause permanent discolouration.
Do not allow aluminium foil in the cooking compart-
ment to come into contact with the door pane.
2.2 Microwave
Follow these instructions when using the microwave.
ATTENTION
Metal touching the wall of the cooking compartment will
cause sparks, which may damage the appliance or the
inner door pane.
Metal (e.g. a spoon in a glass) must be kept at least
2cm from the cooking compartment walls and the in-
side of the door.
Using accessories directly on top of one another causes
sparks.
Do not combine the wire rack with the universal pan.
Always place accessories on different levels.
The universal pan and baking tray are not suitable for
use with microwave-only mode. Using either of these
may create sparks, which will damage the cooking com-
partment.
Place accessories on the wire rack supplied.
Placing aluminium containers in the appliance may
cause sparks, which will damage the appliance.
Do not use aluminium containers in the appliance.
Operating the appliance without food in the cooking
compartment may lead to overloading.
Do not switch on the microwave unless there is food
inside. The only exception to this rule is when per-
forming a short cookware test.
If you prepare microwave popcorn at a microwave
power level that is too high, the door pane may crack
due to overloading.
Never set a microwave power level that is too high.
Use a maximum microwave output of 600 watts.
Always place the popcorn bag on a glass plate.
Environmental protection and saving energy3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compatible
and can be recycled.
Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Only preheat the appliance if the recipe or the recom-
mended settings tell you to do so.
"How it works", Page29
6
Familiarising yourself with your appliance en
Not preheating the appliance can reduce the energy
used by up to 20%.
Use dark-coloured, black-coated or enamelled baking
tins.
These types of baking tin absorb the heat particularly
well.
Open the appliance door as little as possible during op-
eration.
This maintains the temperature in the cooking com-
partment and eliminates the need for the appliance to
reheat.
When baking multiple dishes, do so in succession or in
parallel.
The cooking compartment is heated after baking the
first dish. This reduces the baking time for the sub-
sequent cakes.
For longer cooking times, you can switch the appliance
off 10minutes before the cooking time ends.
There is sufficient residual heat to finish cooking the
dish.
Remove any accessories that are not being used from
the cooking compartment.
Accessories that are not being used do not need to
be heated.
Allow frozen food to defrost before cooking.
This saves the energy that would otherwise be re-
quired to defrost it.
Switch off the display in the basic settings.
"Basic settings", Page18
Energy is saved when the display is switched off.
Heat two glasses or cups of liquid at the same time.
Heating several dishes at the same time requires less
energy than heating dishes one after the other.
Note: In accordance with the EU Ecodesign Directive
2023/826, this appliance is in a different state when
switched off. This is referred to below as low power
mode.
Even when the main function is not active, the appliance
needs energy for:
Detecting operation of the touch keys
Monitoring door opening
Editing the time (without display)
By definition, therefore, there is neither an “off” nor a
“standby” mode, which is why the term low power mode
is used. EN IEC 60350-1:2023 must be used to meas-
ure low power mode.
Familiarising yourself with your appliance4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
On certain models, specific details such as colour and
shape may differ from those pictured.
1
2 2
Display with setting ring
You can use the digital setting ring to set the appli-
ance via the display.
You will see the current setting values, options or
relevant information.
"Display", Page8
Buttons
You can use the buttons to directly set various
functions.
"Buttons", Page7
4.2 Buttons
You can use the buttons to directly select various func-
tions.
Button Function
Switch the appliance on or off.
"Basic operation", Page12
Select the microwave operating mode dir-
ectly.
"Microwave", Page15
Open the "Operating modes" menu.
"Operating modes", Page9
Go back one setting.
Start or pause operation.
"Basic operation", Page12
Select the timer.
"Setting the timer", Page14
Press and hold for approx. 4seconds to
activate the childproof lock.
"Childproof lock", Page18
7
en Familiarising yourself with your appliance
4.3 Display
The display is divided into different areas.
Digital setting ring
Use the digital setting ring on the outside of the display
to change the setting values.
When you reach the minimum or maximum value avail-
able, this value remains in the display. If required, use
the setting ring to turn the value back again.
Status indicator
Status information is shown at the top of the display.
Symbol Meaning
Timer is activated.
"Setting the timer", Page14
Childproof lock is activated.
"Childproof lock", Page18
Wi-Fi signal strength for HomeConnect.
The more lines of the symbol are filled,
the better the signal.
If the symbol is struck through , there is
no Wi-Fi signal.
If there is an "x" at the symbol , there is
no connection to the HomeConnect
server.
"HomeConnect ", Page20
Remote start with HomeConnect is activ-
ated.
"HomeConnect ", Page20
Remote diagnostics with HomeConnect
for maintenance is activated.
"HomeConnect ", Page20
Settings area
The settings area is in the centre of the display.
You can see current options and settings that have
already been made in the settings area.
The menu and other setting options are arranged hori-
zontally. Selection lists for functions are vertically ar-
ranged. Swipe over the display to scroll in the settings
area. To select a function, press the function on the dis-
play.
"Setting the operating mode", Page12
Possible symbols in the settings area
Symbol Meaning
Confirm the setting value.
Reset the setting value.
Change the setting value while the appli-
ance is in operation.
Note: A blue marking "new" or a blue dot on a function
indicates that a new function, a new favourite or an up-
date was downloaded to your appliance using the
HomeConnect app.
4.4 Cooking compartment
Various functions in the cooking compartment provide
support when operating your appliance.
Shelf supports
The shelf supports in the cooking compartment enable
you to place accessories at different heights.
"Accessories", Page10
Your appliance has 3 shelf positions. The shelf positions
are numbered from bottom to top.
You can remove the shelf supports, e.g. for cleaning.
"Rails", Page25
Lighting
One or more oven lights illuminate the cooking compart-
ment.
When you open the appliance door, the light in the
cooking compartment switches on. If the appliance door
remains open for longer than around 18 minutes, the
light switches off again.
For most operating modes, the lighting is switched on
during operation. The lighting switches off again when
the operation ends.
Cooling fan
The cooling fan switches on and off depending on the
appliance's temperature. The hot air escapes above the
door.
ATTENTION
Covering the ventilation slots will cause the appliance to
overheat.
Do not cover the ventilation slots.
To cool down the appliance and remove residual mois-
ture from the cooking compartment, the cooling fan runs
for a certain time after operation.
Note: You can change the run-on time in the basic set-
tings. If you frequently prepare very moist food or keep
it warm in the cooking compartment, set a longer run-on
time.
"Basic settings", Page18
Appliance door
If you open the appliance door during operation, the op-
eration stops. If you close the appliance door, operation
resumes automatically.
In microwave mode, if you close the appliance door,
you must continue the operation.
8
Operating modes en
Operating modes5 Operating modes
This is where you can find an overview of your appli-
ance's operating modes and main functions.
Press to open the menu.
Operating
mode
Use
Types of
heating
Select finely tuned types of heating for the
optimal preparation of your food.
"Types of heating", Page9
"Basic operation", Page12
Microwave Cook, heat or defrost more quickly with
the microwave.
"Microwave", Page15
Favourites Use your own saved settings.
"Favourites", Page18
Dishes Use programmed, recommended settings
for various types of food.
"Dishes", Page16
Operating
mode
Use
Cleaning Select the cleaning function for the cook-
ing compartment.
"Cleaning aid", Page23
"Drying", Page24
Basic set-
tings
Adjust the basic settings.
"Basic settings", Page18
HomeConnect
With HomeConnect, you can connect and remotely con-
trol the oven with a mobile device, and use the full func-
tionality of the appliance.
Depending on the appliance type, additional or more
comprehensive functions are available for your appli-
ance with the HomeConnect app. You can find more in-
formation about this in the app.
"HomeConnect ", Page20
5.1 Types of heating
To ensure that you always find the right type of heating to cook your food, we explain the differences and applica-
tions below.
The symbols for each type of heating help you to remember them.
When you select a type of heating, the appliance suggests a suitable temperature or setting. You can use these val-
ues or change them within the specified range.
Symbol Type of heating Temperature
range
What it's used for and how it works
2D hot air 30 - 230 °C Bake or roast on one level.
The fan in the back panel of the oven distributes the heat evenly
throughout the cooking compartment.
Top/bottom heating 30 - 230°C Traditionally bake or roast on one level. This type of heating is es-
pecially good for cakes with moist toppings.
The heat is emitted evenly from above and below.
Hot air gentle 125 - 230 °C Cook selected dishes gently on one level without preheating.
The fan in the back panel of the oven distributes the heat evenly
throughout the cooking compartment.
The food is cooked in phases using residual heat. Always keep
the appliance door closed when cooking. If you open the appli-
ance door even briefly, the appliance will continue to heat without
utilising any residual heat.
This type of heating is used to determine the energy consumption
in air recirculation mode and the energy efficiency class.
Air Fry 30 - 230 °C Cook until crispy, on one level with little fat. Especially suitable for
food that is usually fried in oil, e.g. chips.
Top/bottom heating
gentle
150 - 230 °C Gently cook selected dishes.
Heat is emitted from above and below.
The food is cooked in phases using residual heat. Always keep
the appliance door closed when cooking. If you open the appli-
ance door even briefly, the appliance will continue to heat without
utilising any residual heat.
This type of heating is used to measure the energy consumption
in the conventional mode.
Circulated air grilling 30 - 230°C Roast poultry, whole fish or larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan
circulates the hot air around the food.
Full-surface grill Fixed grill set-
ting
Grill flat items such as sausages, or make toast. Gratinate food.
The entire area below the grill element becomes hot.
9
en Accessories
Symbol Type of heating Temperature
range
What it's used for and how it works
Centre-area grill Fixed grill set-
ting
Grill small quantities such as sausages, or make toast. Gratinate
small quantities of food.
The central area below the grill element becomes hot.
Bottom heating 30 - 230°C Final baking or cooking food in a bain marie.
The heat is emitted from below.
Plate warming 30 - 90°C Preheat cookware.
5.2 Temperature
With most types of heating , you can read the current
temperature in the cooking compartment from ap-
prox.30°C and the set temperature side-by-side on the
display during heating, e.g.120|210°C.
When you are preheating the appliance, the optimal
time to place the food in the cooking compartment is as
soon as the displayed temperature in the cooking com-
partment and the set temperature are the same.
Note: Due to thermal inertia, the temperature that is dis-
played may differ slightly from the actual temperature in-
side the cooking compartment.
Residual heat indicator
When the appliance is switched off, a red line around
the control ring indicates the residual heat in the cook-
ing compartment. The further the temperature drops, the
darker the ring. The ring goes out completely at approx.
60°C.
5.3 Microwave output settings
This is where you can find an overview of the different microwave output settings and recommendations on when to
use them.
Microwave output in
watts
Maximum cooking
time in hours
Use
90W 1:30 Defrost delicate foods.
180W 1:30 Defrost food and continue cooking.
360W 1:30 Cook fish and meat. Heat up delicate foods.
600W 1:30 Heat and cook food.
900W "Boost" 00:30 Heat liquids.
Notes
To protect the appliance, the maximum microwave
output "Boost" is gradually reduced to 600watts dur-
ing the first few minutes. Maximum output is made
available again after a cooling period.
The microwave output settings do not correspond
with the real power consumption of the appliance.
Accessories6 Accessories
Use original accessories. These have been made especially for your appliance.
Note: Accessories may become deformed if they get hot. Deformation has no effect on function. As the accessory
cools down, it will regain its original shape.
The accessories supplied may differ depending on the appliance model.
Accessories Use
Wire rack Cake tins
Ovenproof dishes
Cookware
Meat, e.g. roasting joints or steak
Frozen meals
Universal pan Moist cakes
Baked items
Bread
Large roasts
Frozen meals
Catch dripping liquids, e.g. fat when grilling
food on the wire rack.
10
Before using for the first time en
Accessories Use
Air Fry & Grill Tray,
enamelled, perforated
Bake until crispy, for food that is usually
fried in oil, e.g. chips.
Grilling food.
6.1 Information on accessories
Some accessories are only suitable for certain types of
heating.
Microwave accessories
The wire rack that is supplied is only suitable for opera-
tion solely using the microwave.
Baking trays, e.g. the universal pan or the baking tray,
may create sparks and are not suitable.
Observe the information about the microwave.
"Cookware and accessories with microwave",
Page15
6.2 Locking function
The locking function prevents the accessories from tilt-
ing when they are pulled out.
You can pull out the accessories approximately halfway
without them tipping. The accessories must be inserted
into the cooking compartment correctly for the tilt pro-
tection to work properly.
6.3 Sliding accessories into the cooking
compartment
Always slide the accessory into the cooking compart-
ment the right way round. This is the only way to ensure
that accessories can be pulled out approximately
halfway without tipping.
1.
Turn the accessories so that the notch is at the rear
and is facing downwards.
2.
Insert the accessory between the two guide rods for a
shelf position.
Wire rack Insert the wire rack with the open side
facing the appliance door and the
curved lip facing downwards.
Tray
E.g. univer-
sal pan or
baking tray
Slide the tray in with the sloping edge
towards the appliance door.
3.
Push the accessory all the way in, making sure that it
does not touch the appliance door.
Note: Take any accessories that you will not be using
out of the cooking compartment while the appliance is
in operation.
6.4 Other accessories
You can purchase other accessories from our customer
service, specialist retailers or online.
You will find a comprehensive range of products for
your appliance in our brochures and online:
www.bosch-home.com
Accessories are appliance-specific. When purchasing
accessories, always quote the exact product number (E
no.) of your appliance.
You can find out which accessories are available for
your appliance in our online shop or from our customer
service.
Before using for the first time7 Before using for the first time
Configure the settings for initial start-up. Clean the appli-
ance and accessories.
7.1 Performing initial start-up
After connecting the appliance to the power supply, you
must configure the settings for its initial start-up. It may
take a few minutes for the settings to appear on the dis-
play.
1.
Press to switch the appliance on.
The first setting appears.
2.
To change the setting as required, press a value in
the list or change the value using the setting ring.
Possible settings:
– Language
– HomeConnect
"HomeConnect ", Page20
– Time
"Setting the time", Page19
3.
Press and switch to the next setting.
4.
Work through the settings and make changes as re-
quired.
After the last setting, a message appears on the dis-
play confirming that the initial start-up is complete.
5.
To check the appliance before heating for the first
time, open and close the appliance door once.
11
en Basic operation
7.2 Cleaning the appliance before using it
for the first time
Before using the appliance to cook food for the first
time, you must clean the cooking compartment and ac-
cessories.
1.
Remove the product information and the accessories
from the cooking compartment. Remove any leftover
packaging, such as polystyrene pellets, and any ad-
hesive tape that is in or on the appliance.
2.
Wipe the smooth surfaces in the cooking compart-
ment with a soft, damp cloth.
3.
Press to switch the appliance on.
4.
Apply the following settings:
Type of heating 2Dhot air
Temperature Maximum
Cooking time 1hour
"Basic operation", Page12
5.
Start the operation.
Ventilate the kitchen while the appliance is heating.
When the time has elapsed, a signal sounds. A mes-
sage appears on the display confirming that the oper-
ation has finished.
6.
Press to switch the appliance off.
7.
Once the appliance has cooled down, clean the
smooth surfaces in the cooking compartment with a
detergent solution and a dish cloth.
8.
Clean the accessories thoroughly using a detergent
solution and a dish cloth or soft brush.
Basic operation8 Basic operation
8.1 Switching on the appliance
Press to switch the appliance on.
The display shows the menu.
8.2 Switching off the appliance
Switch your appliance off when you are not using it. The
appliance will switch itself off automatically if it is not
used for a certain period of time.
Press to switch the appliance off.
The appliance switches off. Any functions currently in
progress are cancelled.
The time or residual heat indicator appears on the
display.
8.3 Starting the operation
You must start each operation.
ATTENTION
If there is water on the cooking compartment floor when
operating the appliance at temperatures above 120°C,
this will damage the enamel.
Do not use the appliance if there is water on the
cooking compartment floor.
Wipe away any water on the cooking compartment
floor before operation.
Press to start the operation.
The settings appear on the display.
8.4 Interrupting the operation
You can interrupt the operation and then continue again.
1.
To interrupt the operation, press .
2.
Press again to resume the operation.
8.5 Setting the operating mode
After you have switched on the appliance, the menu ap-
pears on the display.
1.
To scroll through the various selection options, swipe
to the left or right on the display.
Swipe right or left to scroll through the menu and
other setting options.
Swipe down or up to scroll through selection lists.
2.
To select a function, press the function on the display.
Depending on the function, possible setting values or
other tiles are available for selection.
3.
To go back to a setting if necessary, press .
4.
To change the setting values, use the digital setting
ring:
Swipe over the setting ring clockwise or anticlock-
wise, as required.
Or press a specific position on the setting ring.
Or, as soon as the setting ring is pressed, press
the symbol that appears and enter the value dir-
ectly via the number field.
5.
Use to confirm the setting.
6.
Press to start the operation.
7.
If the operation is ended:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
Note: You can save your settings as "Favourites" and
use these again.
"Favourites", Page18
8.6 Setting the type of heating and the
temperature
1.
Press "Types of heating" in the menu.
2.
Press the type of heating that you want to use.
3.
Press the temperature in °C or, depending on the
type of heating, the setting.
4.
Use the setting ring to set the temperature.
5.
Press on the display to confirm the set temperat-
ure.
If required, you can implement additional settings:
–
"Time-setting options", Page13
–
"Microwave", Page15
6.
Press to start the operation.
The appliance starts heating.
The setting values and how long the appliance has
already been in operation are shown on the display.
7.
If the operation is ended:
If required, you can select other settings and restart
the operation.
12
Time-setting options en
When the food is ready, use to switch the appli-
ance off.
Note: The most suitable type of heating for your food
can be found in the description of the type of heating.
"Types of heating", Page9
Changing the type of heating
When you change the type of heating, the other settings
are also reset.
1.
Press .
2.
Press .
3.
Press the type of heating that you want to use.
4.
Reset the operation and use to start.
Changing the temperature
Once the operation has started, you can change the
temperature at any time.
1.
Press on the display.
2.
Press the temperature.
3.
Change the temperature with the setting ring.
4.
To confirm the change, press on the display.
The change is applied.
8.7 Displaying information
In most cases, you can call up information about the
function that you have just started. The appliance auto-
matically displays certain information, e.g. to ask you to
do/confirm something or to issue a warning.
1.
Press "Info".
Information is displayed for a few seconds.
2.
To scroll through lots of content in the message,
swipe over the display.
3.
If necessary, use to exit the message.
8.8 Keeping warm over an extended period
You can use your appliance to keep meals warm for up
to 24 hours without changing the behaviour of the appli-
ance. Use the time functions and change the basic set-
tings.
Note: If you open the appliance door during operation,
the appliance stops heating. When you close the appli-
ance door, the appliance continues to heat again. To
ensure that the behaviour of the appliance is not
changed during operation, only open the appliance door
once the set time has elapsed.
1.
Change the basic settings.
"Basic settings", Page18
Change the "Lighting" basic setting to "Always off".
Change the "Standby screen" basic setting to "On".
Change the "Signal tone" basic setting to "Very
short duration".
This will ensure that the light in the cooking compart-
ment is always off while the appliance is in operation
and when you open the appliance door. The clock
display does not change. The duration of the signal
tone is reduced at the end of the operation.
2.
Set the required operating mode.
"Setting the operating mode", Page12
"Setting the type of heating and the temperature",
Page12
3.
Set the required cooking time depending on the oper-
ating mode.
"Setting the cooking time", Page13
"Time-setting options", Page13
4.
Use "End time" to set the time at which the operation
should end.
"Setting the end time", Page14
"Time-setting options", Page13
5.
Place the food in the cooking compartment before
the appliance starts to heat.
6.
Press to start the operation.
The display shows the time remaining until the opera-
tion starts. The appliance is in standby mode.
Once the start time has been reached, the appliance
starts heating and the cooking time starts counting
down.
7.
When the operation has ended, remove the food from
the cooking compartment. The appliance automatic-
ally switches off completely after approximately 15 to
20minutes.
Note: If required, change the different basic settings
again.
Time-setting options9 Time-setting options
For an operation, you can set the cooking time and the
time at which the operation should be finished. The
timer runs independently of the operation.
Time-setting
option
Use
Cooking time If you set a cooking time, the appli-
ance stops heating automatically once
this time has elapsed.
End time Along with the cooking time, you can
set the time at which you want the op-
eration to end. The appliance starts up
automatically so that the operation fin-
ishes at the required time.
Timer You can set the timer to run independ-
ently of the appliance during operation.
It does not affect the appliance.
9.1 Setting the cooking time
You can set the cooking time for the operation up to
24hours.
Requirement: An operating mode and temperature or
level have been set.
1.
Press "Cooking time".
2.
To set the cooking time, press the relevant time
value, e.g. hour display "h" or minute display "m".
The selected value is marked in blue.
3.
Use the setting ring to set the cooking time.
If required, use to reset the setting value.
4.
To confirm the set cooking time, press on the dis-
play.
13
en Time-setting options
5.
Press to start the operation.
The appliance starts to heat and the time counts
down.
When the time has elapsed, a signal sounds. A mes-
sage appears on the display confirming that the oper-
ation has finished.
6.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
Changing the cooking time
You can change the cooking time at any time.
1.
Press to pause the operation.
2.
Press the cooking time .
3.
Use the setting ring to change the cooking time.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
Cancelling the cooking time
You can cancel the cooking time at any time.
1.
Press to pause the operation.
2.
Press the cooking time .
3.
Reset the cooking time using .
Note: For operating modes that always require a
cooking time, the appliance resets the cooking time
to the preset value.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
9.2 Setting the end time
You can delay the time at which the cooking time for the
operation is due to end by up to 24 hours.
Notes
To achieve good cooking results, do not delay the
time once the operation has already started.
Food will spoil if you leave it in the cooking compart-
ment for too long.
Requirements
An operating mode and temperature or level have
been set.
A cooking time is set.
1.
Press "End time".
2.
To set the time, press the hour display or the minute
display.
The selected value is marked in blue.
3.
Use the setting ring to delay the time.
If required, use to reset the setting value.
4.
To confirm the set time, press on the display.
5.
Press to start the operation.
The display shows the time remaining until the opera-
tion starts. The appliance is in standby mode.
Once the start time has been reached, the appliance
starts heating and the cooking time starts counting
down.
When the time has elapsed, a signal tone sounds. A
notification appears on the display confirming that the
operation has finished.
6.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
Changing the end time
To achieve good cooking results, only change the set
time before the operation starts and before the cooking
time starts counting down.
1.
Press to pause the operation.
2.
Press the end time .
3.
Use the setting ring to change the end time.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
Cancelling the end time
You can delete the set end time at any time.
1.
Press to pause the operation.
2.
Press the end time .
3.
Use to reset the end time.
Note: For operating modes that always require a
cooking time, the appliance resets the time at which
the cooking time ends to the next possible time.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
9.3 Setting the timer
The timer runs independently during the operation. You
can set the timer for up to 24hours. The timer has its
own signal so that you can tell whether it is the timer or
a cooking time that has elapsed.
1.
Press .
2.
To set the timer, press the relevant time value on the
display, e.g. minute display "m" or second display "s".
The selected value is marked in blue.
3.
Set the timer using the setting ring.
If required, use to reset the setting value.
4.
To start the timer, press on the display.
The timer counts down.
The timer remains visible on the display if the appli-
ance is switched off.
When the appliance is switched on, the display
shows the settings for the current operation. The
timer is displayed in the status display.
Once the timer has elapsed, a signal sounds. A noti-
fication appears on the display confirming that the
timer has finished.
Changing the timer
You can change the timer at any time.
1.
If the timer is running in the background, use to se-
lect the timer beforehand.
2.
Press .
3.
Change the timer using the setting ring.
4.
Press to confirm.
Cancelling the timer
You can cancel the timer at any time.
1.
If the timer is running in the background, use to se-
lect the timer beforehand.
2.
Press .
3.
Reset the timer using .Reset the timer using .
14
Microwave en
Microwave10 Microwave
You can use the microwave to cook, heat up, bake or
defrost food very quickly.
10.1 Cookware and accessories with
microwave
To heat food evenly and avoid damaging your appli-
ance, it is important to only use the right cookware and
accessories.
Follow the cookware manufacturer's instructions.
Unless otherwise specified, place the cookware and ac-
cessory on level 1.
Microwave-safe cookware
Cookware made from heat-resistant, microwave-safe
material:
Glass
Glass ceramic
Porcelain
Temperature-resistant plastic
Fully glazed ceramic without cracks
Serving dishes
Only use cookware with decorative gold or silver trim
if the manufacturer guarantees its suitability for mi-
crowave use.
Supplied wire rack
In microwave-only operation, sheets and trays, e.g.
the universal pan or the baking tray, may create
sparks and are not suitable.
These materials allow microwaves to pass through and
are not damaged.
Cookware that is not microwave-safe
Note: Observe the specifications for preventing material
damage.
"Microwave", Page6
Metal cookware and bakeware
Microwaves cannot pass through metal. The food is
barely heated or not heated at all. Metal may create
sparks in microwave-only operation.
Cookware when adding microwave to an operating
mode
If you switch on the microwave for another operating
mode, metal is also an option, in addition to microwave-
safe cookware and accessories:
Metal cookware and bakeware
Metal must be kept at least 2cm from the cooking
compartment walls and the inside of the door.
Always place metal cookware or bakeware in the
centre of the supplied wire rack.
Accessories supplied:
Wire rack
Universal pan
Baking tray
Air Fry & Grill Tray
Testing cookware for microwave suitability
If you are unsure whether your cookware is suitable for
use in the microwave, carry out a cookware test.
ATTENTION
Operating the appliance without food in the cooking
compartment may lead to overloading.
Do not switch on the microwave unless there is food
inside. The only exception to this rule is when per-
forming a short cookware test.
WARNING‒Risk of burns!
The accessible parts of the appliance become hot dur-
ing operation.
Never touch these hot parts.
Keep children at a safe distance.
1.
Place the empty cookware in the cooking compart-
ment.
2.
Set the appliance to run for 30 seconds to 1 minute
at maximum power.
3.
Start the operation.
4.
Check the cookware several times:
If the cookware remains cold or warm to the touch,
it is suitable for microwave use.
If the cookware becomes hot or sparks are cre-
ated, stop the cookware test. The cookware is not
microwave-safe.
10.2 Setting options with the microwave
The microwave can be used on its own, or in combina-
tion with a different operating mode.
Microwave-only operation
The electromagnetic waves of the microwave alone gen-
erate energy and this is converted into heat in food, for
example.
Added microwave
Adding the microwave to an operating mode reduces
the cooking time.
You can combine the microwave with the following func-
tions:
Types of heating
Page12
– 2Dhot air
– Top/bottom heating
– Circulated air grilling
– Full-surface grill
– Centre-area grill
"Dishes", Page16
Possible microwave outputs combined with an operating
mode include:
90watts
180watts
360watts
15
en Dishes
10.3 Setting the microwave
Note
Note the correct way to operate the microwave:
"Safety", Page2
"Preventing material damage", Page5
"Microwave output settings", Page10
"Cookware and accessories with microwave",
Page15
1.
Press "Microwave" in the menu.
Or select the microwave directly using the but-
ton.
2.
Press the microwave output ("Boost").
3.
Use the setting ring to set the microwave output.
4.
To confirm the set microwave output, press on the
display.
5.
Press "Cooking time".
A cooking time must always be set to operate the mi-
crowave.
6.
To change the preset cooking time, press the relevant
time value, e.g. minute display "m" or second display
"s".
The selected value is marked in blue.
7.
Use the setting ring to set the cooking time.
If required, use to reset the setting value.
8.
To confirm the set cooking time, press on the dis-
play.
9.
Press to start the operation.
The microwave starts and the cooking time counts
down. The display shows the performance reduction
for the maximum microwave output "Boost".
"Microwave output settings", Page10
When the time has elapsed, a signal tone sounds. A
notification appears on the display confirming that the
operation has finished.
10.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
11.
If condensation has formed in the cooking compart-
ment, dry the cooking compartment.
"Drying", Page24
Note: If you open the appliance door during operation,
the operation stops. If you close the appliance door, you
must continue the operation. If you have changed the
basic setting for this, make sure that the microwave
does not resume operation without food inside.
"Basic settings", Page18
Changing the microwave output
You can change the microwave output at any time.
1.
Press on the display.
2.
Press the microwave output .
3.
Use the setting ring to set the microwave output.
4.
To confirm the change, press on the display.
The change is applied.
Changing the cooking time
You can change the cooking time at any time.
1.
Press to pause the operation.
2.
Press the cooking time .
3.
Use the setting ring to change the cooking time.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
10.4 Setting added microwave
Note
Note the correct way to operate the microwave:
"Safety", Page2
"Preventing material damage", Page5
"Microwave output settings", Page10
"Cookware and accessories with microwave",
Page15
Requirement: Observe the information about the re-
spective operating mode.
"Setting options with the microwave", Page15
1.
Press the operating mode that you require in the
menu.
2.
Select the settings for the operating mode, e.g. type
of heating and temperature.
3.
Press "Added microwave".
4.
Use the setting ring to set the microwave output.
5.
To confirm the set microwave output, press on the
display.
6.
Press "Cooking time" and set the cooking time.
7.
Press to start the operation.
The appliance starts to heat and the time counts
down.
When the time has elapsed, a signal sounds. A mes-
sage appears on the display confirming that the oper-
ation has finished.
8.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
Changing added microwave
You can change or deactivate the added microwave at
any time.
1.
Press on the display.
2.
Press the microwave output .
3.
Change or deactivate added microwave with the set-
ting ring.
4.
To confirm the change, press on the display.
The change is applied.
Dishes11 Dishes
The "Dishes" operating mode helps you to use your ap-
pliance to prepare different meals by selecting the op-
timum settings automatically.
11.1 Cookware for dishes
The cooking result depends on the composition of the
meat and the size of cookware.
You should therefore use heat-resistant cookware that is
suitable for temperatures up to 300°C. Glass or glass
16
Dishes en
ceramic cookware is best. The joint should cover ap-
prox.2/3 of the cookware base.
Cookware made from the following material is not suit-
able:
Bright, shiny aluminium
Unglazed clay
Plastic or plastic handles
Note: For some dishes, the appliance switches on the
microwave. A notification appears in the display stating
that you should use cookware that is suitable for mi-
crowave use.
"Cookware and accessories with microwave",
Page15
11.2 Setting options for the dishes
To cook the dishes perfectly, the appliance uses differ-
ent settings depending on the dish.
The display shows you the settings that are used. You
can adjust certain settings. Follow the instructions on
the display.
Note: The cooking result depends on the quality and
composition of the food. Use fresh and, ideally, chilled
food. Use frozen food straight from the freezer.
Tips and information about the settings
If you set a dish, the display shows relevant information
for this dish, e.g.:
Suitable shelf position
Suitable accessory or cookware
Added liquid
Time for turning or stirring
When this time is reached, a signal sounds.
To call up the information, press "Info". Some mes-
sages are displayed automatically.
Programmes
The optimum type of heating, temperature and cooking
time are preset for programmes.
To achieve an optimal cooking result, you must also set
the weight, thickness or the cooking level. You can set
the weight only in the intended range.
Unless otherwise indicated, set the total weight for your
dish.
11.3 Overview of the dishes
You can find out which individual dishes are available to
you on the appliance when you call up the operating
mode. The selection of dishes depends on the features
of your appliance.
Note: In the basic settings, you can regionally specialise
the displayed dishes.
"Basic settings", Page18
Dishes
Pavlova
Muffins
Scones
Part-cooked bread rolls or baguette
Bake, savoury, fresh, cooked ingredients
Potato gratin, raw ingredients, 4cm deep
Lasagne, fresh
Fruit crumble
Chicken, unstuffed
Chicken pieces
Duck, unstuffed
Small turkey, unstuffed
Turkey breast
Turkey, crown - British style
Sirloin, medium
Beef Slow roast joint - British style
Beef Top side, top rump - British style
Leg of lamb on the bone, well done
Boned leg of lamb, medium
Lamb Shoulder, boned and rolled - British style
Meat loaf made from fresh mince
Roast fish, whole
Pizza, frozen, with thin base, x 1
Lasagne, frozen
Baked potatoes, whole
Boiled potatoes
Long-grain rice
Vegetables, fresh
Vegetables, frozen
Defrosting fish fillet
11.4 Setting a dish
1.
Press "Dishes" in the menu.
2.
Press the required dish.
Tip: For some dishes, you can select a preferred
cooking method.
"Setting options for the dishes", Page17
The settings for the dish appear on the display.
3.
Adjust the settings if required.
You can adjust only certain settings depending on the
dish.
"Setting options for the dishes", Page17
4.
For information about the accessory and shelf posi-
tion, for example, press "Info".
5.
Press to start the operation.
The appliance starts to heat and the time counts
down.
Once the dish is ready, a signal sounds. The appli-
ance stops heating.
6.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
11.5 Automatic switch-off function
The automatic switch-off function for the dishes al-
lows you to bake and fry without any stress.
When the operation has finished, the appliance automat-
ically stops heating.
To achieve an optimum cooking result, remove your
dish from the cooking compartment once the operation
has finished.
17
en Favourites
Favourites12 Favourites
In the "Favourites", you can save your settings and use
these again.
Note: Depending on the appliance type/software status,
you must first download this function to your appliance.
You can find more information in the HomeConnect
app.
12.1 Saving favourites
You can save up to 10 different operating modes as
your favourites.
To save an operating mode as a favourite, you must
use the HomeConnect app. When your appliance is
connected, follow the instructions in the app.
12.2 Selecting favourites
If you have saved favourites, you can use these to set
the operation.
1.
Press "Favourites" in the menu.
2.
Press the required favourites.
3.
If required, you can change the settings.
4.
Press to start the operation.
The setting values are shown on the display.
Note
Observe the instructions for the various operating
modes:
"Microwave", Page15
12.3 Changing favourites
You can change, sort or delete your saved favourites at
any time.
To change the favourites, you must use the
HomeConnect app. When your appliance is connec-
ted, follow the instructions in the app.
Childproof lock13 Childproof lock
You can secure your appliance to prevent children from
accidentally switching it on or changing the settings.
13.1 Activating the childproof lock
The childproof lock can be activated regardless of
whether the appliance is on or off.
Press and hold for approx. 4seconds to activate
the childproof lock.
A confirmation message appears on the display.
The control panel is locked. The appliance can only
be switched off using .
When the appliance is switched on, lights up.
When the appliance is switched off, does not light
up.
13.2 Deactivating the childproof lock
You can deactivate the childproof lock at any time.
1.
Press anywhere on the display.
2.
To deactivate the childproof lock:
Follow the instructions on the display so that the
graphic on the ring fills up completely.
Alternatively, press and hold for approximately
4seconds.
A confirmation message appears on the display.
Basic settings14 Basic settings
You can configure the basic settings for your appliance
to meet your needs.
14.1 Overview of the basic settings
Here you can find an overview of the basic settings and
factory settings. The basic settings depend on the fea-
tures of your appliance.
You can find more information about the individual basic
settings on the display using "Info".
Basic settings Selection
Language See selection on the appliance.
HomeConnect Connect the oven to a mobile device
and remotely control it.
"HomeConnect ", Page20
Basic settings Selection
Clock Time in 24-hour format.
Display Selection
Brightness Levels 1, 2, 3, 4 and 5
1
Standby screen On for a limited time
On (this setting increases energy
consumption)
Off
1
Clock Digital
1
Analogue
Alignment Align the display horizontally and
vertically.
1
Factory setting (may vary according to model)
18
Basic settings en
Tone Selection
Button tone On
1
Off
Signal tone Very short duration (once)
Short duration (approx.5seconds)
Medium duration
(approx.10seconds)
1
Long duration (approx.30seconds)
Appliance set-
tings
Selection
Fan run-on time Minimum
Recommended
1
Long
Very long
Lighting When cooking and when the door is
opened
1
Only when the door is opened
Always off
Microwave out-
put presetting
90 W
180W
360 W
600W
Boost
1
Continue to mi-
crowave
Off
1
On
Personalisa-
tion
Selection
Brand logo Display
1
Do not display
Operation after
switch-on
Main menu
1
Types of heating
Microwave
Dishes
Favourites
Elapsed cook-
ing time
Do not display
Display
1
Microwave bak-
ing tray
On
1
Off
Regional
dishes
All
1
European dishes
British dishes
Dishes All
1
No pork
Kosher only
Childproof lock Available
1
Deactivated
Factory set-
tings
Selection
Factory set-
tings
Restore
Info Indicator
Appliance in-
formation
Display technical information about the
appliance.
14.2 Changing the basic settings
1.
Press "Basic settings" in the menu.
2.
Press the required basic settings area.
3.
Press the required basic setting.
4.
Press to select the required basic setting.
The change is applied directly for most basic set-
tings.
5.
To change additional basic settings, use to go
back and select a different basic setting.
6.
To exit the basic settings, use to go back to the
main menu or switch off the appliance using .
The changes are saved.
Note: Your changes to the basic settings will be re-
tained even after a power failure.
14.3 Setting the time
1.
Press "Basic settings" in the menu.
2.
Press "Time".
3.
To set the time, press the hour display or the minute
display.
The selected value is marked in blue.
4.
Use the setting ring to set the time.
5.
To exit the basic settings, use to go back to the
main menu or switch off the appliance using .
The time is saved.
1
Factory setting (may vary according to model)
19
en HomeConnect
HomeConnect 15 HomeConnect
This appliance is network-capable. Connecting your ap-
pliance to a mobile device lets you control its functions
via the HomeConnect app, adjust its basic settings and
monitor its operating status.
The HomeConnect services are not available in every
country. The availability of the HomeConnect function
depends on the availability of HomeConnect services in
your country. You can find information about this at:
www.home-connect.com
.
The HomeConnect app guides you through the entire
login process. Follow the instructions in the HomeCon-
nect app to configure the settings.
Tip: Please also follow the instructions in the
HomeConnect app.
Notes
Please note the safety precautions in this instruction
manual and make sure that they are also observed
when operating the appliance via the HomeConnect
app.
"Safety", Page2
Operating the appliance on the appliance itself al-
ways takes priority. During this time it is not possible
to operate the appliance using the HomeConnect
app.
In networked standby mode, the appliance requires a
maximum of2W.
15.1 Setting up HomeConnect
Requirements
The appliance is connected to the power supply and
is switched on.
You have a mobile device with a current version of
the iOS or Android operating system, e.g. a smart-
phone.
The appliance is receiving signals from the WLAN
home network (Wi-Fi) at its installation location.
The mobile device and the appliance are within range
of your home network's Wi-Fi signal.
1.
Scan the following QR code.
You can install the HomeConnect app and connect
your appliance via the QR code.
2.
Follow the instructions in the HomeConnect app.
15.2 HomeConnect settings
You can adjust the HomeConnect settings and network settings in your appliance's basic settings.
Which settings the display shows will depend on whether HomeConnect has been set up and whether the appliance
is connected to your home network.
Basic setting Possible settings Explanation
Home Connect assist-
ant
Start the assistant
Disconnect
You can connect your appliance to the Home Connect app via
the Home Connect assistant.
Note: If you are using the Home Connect assistant for the first
time, only the "Start assistant" setting is available.
Wi-Fi On
Off
You can use the Wi-Fi to switch off the network connection for
your appliance. When you have connected successfully once,
you can deactivate the Wi-Fi and not lose your detailed data. As
soon as you activate Wi-Fi again, the appliance connects auto-
matically.
Note: In networked standby mode, the appliance requires a
maximum of 2W.
Remote control status Monitoring
Manual remote start
Permanent remote start
During monitoring, you can only view the operating status of the
appliance in the app.
If you convert from monitoring or permanent remote start to
manual remote start, you must activate the remote start each
time. You can open the appliance door within 15 minutes of
having activated remote start. Remote start will not be deactiv-
ated by this. Once 15 minutes have elapsed, opening the appli-
ance door will deactivate manual remote start.
For permanent remote start, you can start and operate the ap-
pliance remotely at any time. If you often operate the appliance
remotely, it is helpful to set the remote start to "Permanent".
20
Cleaning and servicing en
15.3 Operating the appliance with the
HomeConnect app
You can use the HomeConnect app to set and start the
appliance remotely.
WARNING‒Risk of fire!
Combustible objects that are left in the cooking com-
partment may catch fire.
Never store combustible objects in the cooking com-
partment.
If smoke is emitted, the appliance must be switched
off or the plug must be pulled out and the door must
be held closed in order to stifle any flames.
Requirements
The appliance is switched off.
The appliance is connected to the home network and
to the HomeConnectapp.
In order to be able to set the appliance via the app,
the manual or permanent remote start must be selec-
ted in the "Remote control status" basic setting.
1.
To activate manual remote start, press .
You only have to confirm on the oven if you are
switching from monitoring or permanent remote start
to manual remote start.
With permanent remote start, you do not need to con-
firm on the oven.
2.
Configure a setting in the HomeConnectapp and
send it to the appliance.
Notes
When you start the oven using the controls on the
appliance itself, the remote start function is activ-
ated automatically. You can use the HomeCon-
nectapp to adjust the settings or start a new pro-
gramme.
You can open the appliance door within 15
minutes of having activated remote start. Remote
start will not be deactivated by this. Once 15
minutes have elapsed, opening the appliance door
will deactivate manual remote start.
15.4 Software update
Your appliance's software can be updated using the
software update function, e.g. for the purposes of optim-
isation, troubleshooting or security updates. This may
lead to minor changes of visualizations and operation in
the display.
To do this, you must be a registered HomeCon-
nectuser, have installed the app on your mobile device
and be connected to the HomeConnectserver.
As soon as a software update is available, you will be
informed via the HomeConnectapp and will be able to
start the software update via the app. Once the update
has been successfully downloaded, you can start in-
stalling it via the HomeConnectapp if you are in your
home network (Wi-Fi). The HomeConnectapp informs
you once installation is successful.
Notes
The software update consists of two steps.
– The first step is the download.
– The second step is the installation on your appli-
ance.
You can continue to use your appliance as normal
while updates are downloading. Depending on your
personal settings in the app, software updates can
also be set to download automatically.
Installation takes a few minutes. You cannot use your
appliance during installation.
We recommend that you install security updates as
soon as possible.
15.5 Remote diagnostics
Customer Service can use Remote Diagnostics to ac-
cess your appliance if you contact them, have your ap-
pliance connected to the HomeConnect server and if
Remote Diagnostics is available in the country in which
you are using the appliance.
Tip: For further information and details about the avail-
ability of Remote Diagnostics in your country, please
visit the service/support section of your local website:
www.home-connect.com
.
15.6 Data protection
Please see the information on data protection.
The first time your appliance is registered on a home
network connected to the Internet, your appliance will
transmit the following types of data to the HomeCon-
nect server (initial registration):
Unique appliance identification (consisting of appli-
ance codes as well as the MAC address of the in-
stalled Wi-Fi communication module).
Security certificate of the Wi-Fi communication mod-
ule (to ensure a secure data connection).
The current software and hardware version of your
appliance.
Status of any previous resetting to factory settings.
This initial registration prepares the HomeConnect func-
tions for use and is only required when you want to use
the HomeConnect functions for the first time.
Note: Please note that the HomeConnect functions can
only be utilised with the HomeConnect app. Information
on data protection can be retrieved in the HomeCon-
nect app.
Cleaning and servicing16 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
16.1 Cleaning products
In order to avoid damaging the various oven surfaces
on the appliance, do not use unsuitable cleaning
products.
21
en Cleaning and servicing
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
Do not use steam- or high-pressure cleaners to clean
the appliance.
ATTENTION
Unsuitable cleaning agents damage the surfaces of the
appliance.
Do not use harsh or abrasive cleaning products.
Do not use cleaning products with a high alcohol con-
tent.
Do not use hard scouring pads or cleaning sponges.
Do not use any special cleaners for cleaning the ap-
pliance while it is hot.
Using oven cleaner in a hot cooking compartment dam-
ages the enamel.
Never use oven cleaner in the cooking compartment
when it is still warm.
Remove all food remnants from the cooking compart-
ment and the appliance door before you next heat up
the appliance.
If different cleaning agents are mixed together, there
may be a chemical reaction between these.
Do not mix cleaning agents.
Completely remove any cleaning agent residue.
Salt contained in new sponge cloths may damage sur-
faces.
Wash new sponge cloths thoroughly before use.
Suitable cleaning agents
Only use cleaning agents that are suitable for the different surfaces on your appliance.
Follow the instructions on cleaning the appliance.
"Cleaning the appliance", Page23
Appliance front
Surface Suitable cleaning agents Information
Stainless steel Hot soapy water
Special stainless steel
cleaning products suit-
able for hot surfaces
To prevent corrosion, remove any patches of limescale, grease,
starch or albumin (e.g. egg white) from stainless steel surfaces imme-
diately.
Apply a thin layer of the stainless steel cleaning product.
Plastic or painted
surfaces
Hot soapy water Do not use glass cleaner or a glass scraper.
To avoid permanent stains, immediately remove any descaling agent
that gets onto the surface.
Glass Hot soapy water Do not use glass cleaner or a glass scraper.
Appliance door
Range Suitable cleaning agents Information
Door panels Hot soapy water
Oven cleaner
Steel wool
Do not use a glass scraper.
Tip: Remove the door panels in order to clean them thoroughly.
"Appliance door", Page24
Stainless steel in-
terior door frame
Stainless steel cleaner Discolouration can be removed using stainless steel cleaner.
Do not use stainless steel care products.
Door handle Hot soapy water To avoid permanent stains, immediately remove any descaling agent
that gets onto the surface.
Door seal Hot soapy water Do not remove or scrub.
Cooking compartment
Range Suitable cleaning agents Information
Enamel surfaces Hot soapy water
Vinegar solution
Oven cleaner
Steel wool
Soak any heavily soiled areas and use a brush or steel wool.
Leave the appliance door open to dry the cooking compartment after
cleaning it.
Notes
Enamel burns at very high temperatures, causing minor discoloura-
tion. The functionality of your appliance is not affected by this.
The edges of thin trays cannot be completely enamelled and may
be rough. This does not impair the corrosion protection.
Food residues leave a white coating on the enamel surfaces. The
coating does not pose a health risk. The functionality of your appli-
ance is not affected by this. You can remove residues with lemon
juice.
Shelf supports Hot soapy water
Steel wool
Soak any heavily soiled areas and use a brush or steel wool.
22
Cleaning aid en
Range Suitable cleaning agents Information
Note: To clean thoroughly, detach the shelf supports.
"Rails", Page25
Accessories Hot soapy water
Oven cleaner
Steel wool
Soak any heavily soiled areas and use a brush or steel wool.
Enamelled accessories are dishwasher-safe.
16.2 Cleaning the appliance
In order to avoid damaging the appliance, you must
clean your appliance only as specified, and with suitable
cleaning products.
WARNING‒Risk of burns!
The appliance and its parts that can be touched be-
come hot during use.
Caution should be exercised here in order to avoid
touching heating elements.
Young children under 8 years of age must be kept
away from the appliance.
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices may catch
fire.
Before using the appliance, remove the worst of the
food residues and remnants from the cooking com-
partment, heating elements and accessories.
Requirement: Read the information on cleaning
products.
"Cleaning products", Page21
1.
Clean the appliance using hot soapy water and a dish
cloth.
For some surfaces, you can use alternative clean-
ing agents.
"Suitable cleaning agents", Page22
2.
Dry with a soft cloth.
Cleaning aid17 Cleaning aid
The cleaning aid is a quick alternative for occasionally
cleaning the cooking compartment. The cleaning aid
softens dirt by evaporating the soapy water. It is then
easier to remove the dirt.
17.1 Setting the cleaning aid
WARNING‒Risk ofscalding!
If there is water in the cooking compartment when it is
hot, this may create hot steam.
Never pour water into the cooking compartment when
the cooking compartment is hot.
Note: The oven light does not come on while the clean-
ing aid is running.
Requirement: The cooking compartment must have
cooled down completely.
1.
Remove any accessories from the cooking compart-
ment.
2.
ATTENTION‒Distilled water in the cooking compart-
ment leads to corrosion.
Do not use distilled water.
Mix 0.4litres water with a drop of washing-up liquid
and pour into the centre of the cooking compartment
floor.
3.
Press "Cleaning" in the menu.
4.
Press "Cleaning aid".
The duration cannot be changed.
5.
Press .
A notification stating that you should carry out the ne-
cessary preparatory work for the cleaning aid ap-
pears on the display.
6.
Confirm the message.
The cleaning aid starts and the duration counts down.
Once the cleaning aid has ended, a signal tone
sounds. A message appears on the display confirm-
ing that the operation has finished.
7.
Press to switch the appliance off.
8.
.
"Cleaning the cooking compartment after using the
cleaning aid", Page23
17.2 Cleaning the cooking compartment
after using the cleaning aid
ATTENTION
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
After using the cleaning assistance, wipe the cooking
compartment and allow it to dry completely.
1.
Allow the appliance to cool down.
2.
Wipe out the remaining water in the cooking compart-
ment using an absorbent sponge cloth.
3.
Clean the smooth enamel surfaces in the cooking
compartment with a dish cloth or a soft brush. Re-
move stubborn food remnants using a stainless steel
scouring pad.
4.
Remove limescale with a cloth soaked in vinegar, and
wipe this away with clean water.
5.
Dry the cooking compartment with a soft cloth.
6.
To dry the cooking compartment completely, leave
the appliance door open for approx.1hour or use the
drying function.
"Setting the drying process", Page24
23
en Drying
Drying18 Drying
To prevent residual moisture, dry the cooking compart-
ment following microwave-only operation and after using
the cleaning aid.
ATTENTION
If there is water on the cooking compartment floor when
operating the appliance at temperatures above 120°C,
this will damage the enamel.
Do not use the appliance if there is water on the
cooking compartment floor.
Wipe away any water on the cooking compartment
floor before operation.
18.1 Drying the cooking compartment
You can leave the cooking compartment to dry or use
the drying function.
1.
Allow the appliance to cool down.
2.
Remove any dirt from the cooking compartment.
3.
Wipe away any water in the cooking compartment.
4.
Dry the cooking compartment.
To dry the cooking compartment, leave the appli-
ance door open for 1hour.
To use the drying function, set "Drying function".
"Setting the drying process", Page24
Setting the drying process
Requirement:
"Drying the cooking compartment", Page24
1.
Press "Cleaning" in the menu.
2.
Press "Drying function".
The duration cannot be changed.
3.
Press .
A notification stating that you should carry out the ne-
cessary preparatory work for the drying appears on
the display.
4.
Confirm the message.
The drying process starts and the duration counts
down.
Once the drying has ended, a signal tone sounds. A
message appears on the display confirming that the
operation has finished.
5.
Press to switch the appliance off.
6.
To dry the cooking compartment completely, leave
the appliance door open for 1 to 2minutes.
Appliance door19 Appliance door
To clean the appliance door thoroughly, you can disas-
semble the appliance door.
19.1 Detaching the door outer pane
WARNING‒Risk of injury!
The hinges on the appliance door move when the door
is opened and closed, which could trap your fingers.
Keep your hands away from the hinges.
Components inside the appliance door may have sharp
edges.
Wear protective gloves.
1.
Open the appliance door.
2.
Place a folded-up tea towel in the appliance door.
3.
Undo and remove the screws on the left and
right of the appliance door.
4.
Close the appliance door.
5.
Use two hands on the handle to pull the front pane
upwards and remove it .
6.
Set the front pane down on a level surface with the
door handle facing down.
7.
WARNING‒Risk of serious harm to health!
If the screws are undone, the safety of the appliance
can no longer be guaranteed. Microwave energy may
escape.
Never undo the screws.
24
Rails en
Never unscrew the screws on the frame.
8.
Clean the appliance door.
"Suitable cleaning agents", Page22
9.
Dry the door panels and refit them.
"Attaching the door outer pane", Page25
10.
WARNING‒Risk of serious harm to health!
By removing and refitting the intermediate pane, the
safety of your appliance can no longer be guaran-
teed.
Never bend the bending tabs upwards.
Never remove the intermediate pane.
19.2 Attaching the door outer pane
1.
Attach the front pane downwards into the left- and
right-hand retainers .
2.
Push the front panel in at the top.
3.
Push the front pane in at the bottom until you hear
it click into place.
4.
Screw both screws back in on the left and right of the
appliance door.
5.
Open the appliance door slightly and remove the tea
towel.
6.
Close the appliance door.
Note: Do not use the cooking compartment again until
the door panes have been correctly fitted.
Rails20 Rails
To thoroughly clean the rails and the cooking compart-
ment, or to replace the rails, you can remove the rails.
20.1 Detaching the rails
WARNING‒Risk of burns!
The shelf supports get very hot
Never touch the shelf supports when hot.
Always allow the appliance to cool down.
Keep children at a safe distance.
1.
Lift the rail forwards and detach it .
2.
Swivel the entire rail outwards and unhook it at the
rear .
3.
Clean the rail.
25
en Troubleshooting
20.2 Fitting the retainers
The retainers may fall out when you detach the rails.
Note: The retainers at the front differ from those at the
rear.
1.
Hook the front retainers with the hook into the round
hole at the top and set them at a slight angle .
2.
Hook the front retainers in at the bottom and
straighten them .
3.
Hook the rear retainers with the hook into the top
hole and push them into the bottom hole .
20.3 Attaching the rails
1.
Set the rear rail at an angle, hooking it into the retain-
ers at the top and bottom .
2.
Pull the rail forwards .
3.
Hook in the rail at the front and press it down .
Troubleshooting21 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-
sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
If the appliance is defective, call Customer Service.
"Customer Service", Page28
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord or the appliance power cable of this appliance is damaged, it must be replaced with a special
power cord or special appliance power cable, which is available from the manufacturer or its Customer Service.
If the power cord of this appliance is damaged, it must be replaced by trained specialist staff.
21.1 Malfunctions
Fault Cause and troubleshooting
The appliance is not working. The circuit breaker in the fuse box has tripped.
Check the circuit breaker in the fuse box.
26
Troubleshooting en
Fault Cause and troubleshooting
The appliance is not working. There has been a power cut.
Check whether the lighting in your room or other appliances are working.
Electronics fault
1.
Disconnect the appliance from the power supply for at least 30 seconds by
switching off the fuse.
2.
Reset the basic settings to the factory settings.
"Basic settings", Page18
"Sprache Deutsch" appears in the
display.
There has been a power cut.
Configure the initial configuration settings.
"Performing initial start-up", Page11
The operation does not start or is
interrupted.
Different causes are possible.
Check the notifications that appear on the display.
"Displaying information", Page13
Malfunction
Call .
"Customer Service", Page28
Appliance does not heat up. Demo mode is switched on.
1.
Briefly disconnect the appliance from the power supply by switching the circuit
breaker in the fuse box off and then on again.
2.
Switch off demo mode in the basic settings within approx.5minutes.
"Changing the basic settings", Page19
There has been a power cut.
Open and close the appliance door once after a power failure.
The appliance is checked and is ready to use.
The time is not displayed when
the appliance is switched off.
Basic setting has been changed.
Change the basic setting for the time display.
"Basic settings", Page18
HomeConnect is not working
properly.
Different causes are possible.
Go to
www.home-connect.com
.
The interior lighting does not
work.
Basic setting has been changed.
Change the basic setting for the lighting.
"Basic settings", Page18
The LED light is defective.
Call .
"Customer Service", Page28
Maximum operating time
reached.
To prevent an unwanted permanent operation, the appliance automatically stops
heating after several hours if the settings are unchanged. A message appears in
the display.
The point at which the maximum operating time is reached is determined by the
corresponding settings for an operating mode.
1.
To continue operation, switch the appliance off and on again using . Reset
and start the operation.
2.
If you do not need to use the appliance, press to switch it off.
Tip: To prevent the appliance from switching off when you do not want it to, set a
cooking time.
"Time-setting options", Page13
Error code made up of letters
and numbers appears on the dis-
play, e.g. E0111.
The electronics have detected a fault.
1.
Switch the appliance off and on again.
If the fault was a one-off, the message disappears.
2.
If the message appears again, call the after-sales service. Please specify the
exact error message when calling.
"Customer Service", Page28
The cooking result is not satis-
factory.
Settings were unsuitable.
Adjustment values, e.g. temperature or cooking time, depend on the recipe,
quantity and food.
27
en Disposal
Fault Cause and troubleshooting
The cooking result is not satis-
factory.
Next time, set lower or higher values.
Tip: A lot of other information about the preparation, corresponding adjustment
values and recipes can be found in the HomeConnect app or on our website
www.bosch-home.com
.
Disposal22 Disposal
22.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are avail-
able from your specialist dealer or local authority.
This appliance is labelled in accordance
with European Directive 2012/19/EU
concerning used electrical and elec-
tronic appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the framework
for the return and recycling of used ap-
pliances as applicable throughout the
EU.
Customer Service23 Customer Service
Detailed information about the warranty period and the
warranty conditions in your country is available via the
QR code on the enclosed document on service con-
tacts and warranty conditions, from our customer ser-
vice or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.), the production number (FD)
and the consecutive numbering (Z-Nr.) of your appli-
ance.
You can find the contact details for our customer ser-
vice via the QR code on the enclosed document on ser-
vice contacts and warranty conditions or on our website.
This product contains light sources from energy effi-
ciency class G. These light sources are available as a
spare part and should only be replaced by trained spe-
cialist staff.
23.1 Product number (E-Nr.), production
number (FD) and consecutive numbering (Z-
Nr.)
You can find the product number (E-Nr.), the production
number (FD) and the consecutive numbering (Z-Nr.) on
the appliance's rating plate.
You will see the rating plate with these numbers if you
open the appliance door.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
You can also display the appliance information in the
basic settings.
"Basic settings", Page18
Information regarding Free and Open Source Software24 Information regarding Free and Open Source Software
This product includes software components that are li-
censed by the copyright holders as free or open source
software.
The applicable licence information is stored on your
home appliance. You can also access the applicable li-
cence information via your HomeConnect app: "Profile
-> Legal information -> Licence Information".
1
You can
download the licence information on the brand product
website. (Please search on the product website for your
appliance model and additional documents). Alternat-
ively, you can request the relevant information from oss-
[email protected] or BSH Hausgeräte GmbH, Carl-
Wery-Str. 34, 81739 Munich, Germany.
The source code will be made available to you on re-
quest.
Please send your request to [email protected] or
BSH Hausgeräte GmbH, Carl-Wery-Str.34, 81739 Mu-
nich, Germany.
1
Depending on the appliance specifications
28
Declaration of Conformity en
Subject: „OSSREQUEST“
The cost of performing your request will be charged to
you. This offer is valid for three years from the date of
purchase or at least as long as we offer support and
spare parts for the relevant appliance.
Declaration of Conformity25 Declaration of Conformity
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essen-
tial requirements and other relevant provisions of Directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found online at
www.bosch-home.com
among the additional docu-
ments on the product page for your appliance.
2.4 GHz band (2400–2483.5MHz): Max. 100mW
5-GHz band (5150–5350MHz + 5470–5725MHz): max. 150mW
BE BG CZ DK DE EE IE EL ES
FR HR IT CY LI LV LT LU HU
MT NL AT PL PT RO SI SK FI
SE NO CH TR IS UK (NI)
5GHz WLAN (Wi-Fi): For indoor use only.
AL BA MD ME MK RS UK UA
5GHz WLAN (Wi-Fi): For indoor use only.
25.1 Statement of Compliance for Great
Britain
Product type
This statement of compliance covers the products de-
scribed in this information for use whose model identi-
fier group is seen on the title page. The full model identi-
fier is made up of the characters before the slash in the
product number (E no.) which can be found on the rat-
ing plate. Alternatively, you can also find the model iden-
tifier in the first line of the UK Energy Label.
Name and address of manufacturer
BSH Hausgeräte GmbH, Carl-Wery-Strasse 34, 81739
München, Germany
This statement of compliance is prepared by the manu-
facturer.
The manufacturer, BSH Hausgeräte GmbH deems that it
has complied with
provision 5.1-1 of ETSI EN 303 645 v2.1.1 and,
where relevant, provision 5.1-2 of ETSI EN 303 645
v2.1.1;
provision 5.2-1 of ETSI EN 303 645 v2.1.1;
provision 5.3-13 of ETSI EN 303 645 v2.1.1.
Support period
BSH Hausgeräte GmbH will provide security updates
that are necessary to maintain the main functions free of
charge until at least 28/02/2034.
How it works26 How it works
Here, you can find the ideal settings for various types of
food as well as the best accessories and cookware. We
have perfectly tailored these recommendations to your
appliance.
Tip: A lot of other information about the preparation,
corresponding adjustment values and recipes can be
found in the HomeConnect app or on our website
www.bosch-home.com
.
26.1 General cooking tips
Take note of the following information when cooking all
types of food.
The temperature and cooking time depend on the
amount of food and the recipe. Settings ranges are
specified for this reason. Try using the lower values to
start with.
The setting values apply to food placed in the cook-
ing compartment while the cooking compartment is
still cold. If you want to preheat anyway, do not place
accessories into the cooking compartment until it has
finished preheating.
Remove any accessories that are not being used
from the cooking compartment.
ATTENTION
Acidic food may damage the wire rack
Do not place acidic food, such as fruit or food with an
acidic marinade directly on the wire rack.
Information for those allergic to nickel
In rare cases, small amounts of nickel may pass into the
food.
29
en How it works
You can buy suitable accessories from customer ser-
vice, from specialist retailers or online.
"Other accessories", Page11
26.2 Baking tips
Dark-coloured metal baking tins are most suitable for
baking cakes, bread and other baked goods.
Use wide, shallow cookware for bakes and gratins.
Food takes longer to cook in deep, narrow cookware
and it browns more on top.
If you are cooking bakes directly in the universal pan,
place the universal pan into the cooking compartment
at level1.
The setting values for bread dough apply to both
dough placed on a baking tray and dough placed in
a loaf tin.
The recommended settings for baking in combination
with the microwave mode are for metal baking tins.
ATTENTION
When the cooking compartment is hot, any water inside
it will create steam. The change in temperature may
cause damage.
Never pour water into the cooking compartment when
it is still hot.
Never place cookware containing water on the cook-
ing compartment floor.
Shelf positions
If you are baking on one level, use shelf position 1.
26.3 Roasting, braising and grilling tips
The recommended settings are for fridge-temperature
food and unstuffed, oven-ready poultry.
Place the poultry onto the cookware breast-side or
skin-side down.
Turn roasting joints, grilled items or whole fish after
approx. ½ to ⅔ of the specified time.
Roasting on the wire rack
Food roasted on the wire rack will become very crispy
on all sides. You can roast large poultry, for example, or
multiple individual pieces at the same time.
Roast pieces of a similar weight and thickness. The
grilled food will brown evenly and will remain succu-
lent and juicy.
Place the food to be roasted directly on the wire rack.
To catch any liquids that drip down, place the univer-
sal pan into the cooking compartment one level be-
low the wire rack.
Add up to ½litre of water to the universal pan, de-
pending on the size and type of food that you want to
roast.
You can make a sauce from the juices that are collec-
ted. This also means that less smoke is produced
and the cooking compartment does not become as
dirty.
Roasting in cookware
If you cover the cookware when you cook your food,
this will keep the cooking compartment cleaner.
General information about roasting in cookware
Use heat-resistant, ovenproof cookware.
Place the cookware on the wire rack.
Glass cookware is best.
Follow the manufacturer's instructions for your roast-
ing dishes.
Roasting in uncovered cookware
Use a deep roasting dish.
If you do not have any suitable cookware, you can
use the universal pan.
Roasting in covered cookware
Use a suitable lid that seals well.
When roasting meat, there should be at least 3cm
between the food and the lid. The meat may expand.
WARNING‒Risk ofscalding!
Very hot steam may escape when the lid is opened after
cooking. Steam may not be visible, depending on the
temperature.
Lift the lid in such a way that the hot steam can es-
cape away from you.
Keep children away from the appliance.
Grilling
Grill food if you want it to be crispy.
The "Grill" type of heating is good for cooking thinner
pieces of poultry, meat and fish such as steaks, drum-
sticks and burgers. It is also excellent for toasting
bread.
Circulated air grilling is very well suited to cooking
whole poultry and fish, as well as meat, e.g. roast pork
with crackling.
When grilling several food items, choose pieces that
are of a similar weight and thickness. The grilled food
will brown evenly and will remain succulent and juicy.
Place the food to be grilled directly onto the wire
rack.
To catch any liquids that drip down, place the univer-
sal pan into the cooking compartment at least one
level below the wire rack.
Notes
The grill element switches on and off continuously.
This is normal. The grill setting that you use determ-
ines how frequently this occurs.
Smoke may be produced when grilling.
26.4 Microwave cooking
If you cook food using the microwave mode, you can re-
duce the cooking time considerably.
General information
When using the microwave mode, the cooking time is
determined based on the total weight.
If you want to cook a quantity that differs from the
specified quantity, the general rule is Double the
quantity requires just under double the cooking
time.
The food transfers heat to the cookware. The cook-
ware may become very hot.
The main part of the instruction manual contains in-
formation on how to configure the microwave and mi-
crowave boost oven settings.
"Microwave", Page15
30
How it works en
Tip
You can find more microwave recipes here:
"Defrosting", Page34
"Warming up food using the microwave mode",
Page34
Cooking, braising or steaming using the
microwave mode
Use microwave-safe cookware with a lid. Alternatively,
you can use a plate or special microwaveable film to
cover the dish.
For cereal products, e.g. rice, use deep cookware
with a lid. Cereal products foam a lot during cooking.
Add liquid in accordance with the instructions and in-
formation provided in the recommended settings
tables.
Do not wash or dry food. Add 1-3 tablespoons of wa-
ter or lemon juice to the food.
Spread the food out so that as much of it as possible
is in contact with the bottom of the cookware. Food
that is in contact with the bottom will cook more
quickly than food that is piled up.
Use salt and seasoning sparingly. When cooking food
using the microwave mode, most of the food's natural
flavour will be retained.
Turn or stir the food 2-3times during cooking.
After cooking, leave the food to rest for 2-3minutes.
26.5 Cooking instructions for ready meals
The cooking result greatly depends on the quality of
the food. Pre-browning and irregularities may already
be present in the food before cooking.
Do not use frozen products that are covered with a
thick layer of ice. Remove any ice on the food.
Take ready meals out of the packaging.
If you are warming or cooking the ready meal in
cookware, make sure that the cookware is heat-resist-
ant.
Distribute foods that are in the form of separate
pieces, such as bread rolls and potato products, so
that they are spread out flat and evenly on the ac-
cessory. Leave a little space between the individual
pieces.
Follow the manufacturer's instructions on the pack-
aging.
To achieve best results, we recommend that you re-
heat food or ready meals at 600 watts. If the pack-
aging specifies a higher microwave output setting, ex-
tend the time.
26.6 List of foods
Recommended settings for a variety of foods, sorted
into food categories.
Recommended settings for various types of food
Food Accessories/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C/grill setting
Microwave
power set-
ting inW
Cooking
time in
mins
Sponge cake, simple Ring-shaped tin
or
Loaf tin
1 160-180 90 30-40
Sponge cake, delicate Ring-shaped tin
or
Loaf tin
1 150-170 - 60-80
Fruit tart or cheesecake
with shortcrust pastry
base
Springform cake
tin, diameter 26 cm
1 170-180 - 80-90
Fruit tart or cheesecake
with shortcrust pastry
base
Springform cake
tin, diameter 26 cm
1 1. 170-180
2. 100
1. 180
2. -
1. 30-40
2. 20
Sponge flan, 6 eggs Springform cake tin
Ø 28 cm
1 150-170
1
- 30-50
Sponge flan, 6 eggs Springform cake tin
Ø 28 cm
1 150-160 - 50-60
Shortcrust tart with moist
topping
Universal pan 1 160-180 - 60-80
Yeast cake with moist
topping
Universal pan 1 180-190 - 30-45
Swiss roll Baking tray 1 180-190
1
- 10-20
Muffins Muffin tray 1 170-190 - 15-30
Small yeast cakes Baking tray 1 160-170 - 30-40
Biscuits Baking tray 2 140-160 - 15-30
Bread, 750g Universal pan 1 1. 210-220 - 1. 10-15
1
Preheat the appliance.
31
en How it works
Food Accessories/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C/grill setting
Microwave
power set-
ting inW
Cooking
time in
mins
or
Loaf tin
2. 180-190
1
2. 25-35
Bread, 1500g Universal pan
or
Loaf tin
1 1. 210-220
2. 180-190
1
- 1. 10-15
2. 40-50
Bread, 1500g Universal pan
or
Loaf tin
1 200-210 - 35-45
Flatbread Universal pan 1 220-230 - 25-35
Bread rolls, fresh Baking tray 1 180-190 - 25-35
Pizza, fresh Baking tray 1 200-220 - 25-35
Pizza, fresh, thin-crust, on
a pizza tray
Pizza tray 1 210-230 - 20-30
Börek Universal pan 1 180-190 - 35-45
Quiche Dark coated quiche
tin
1 180-190 - 30-40
Tarte flambée Universal pan 1 220-230
1
- 15-25
Bake, savoury, cooked
ingredients
Ovenproof dish 1 200-220 - 35-55
Bake, savoury, cooked
ingredients
Ovenproof dish 1 140-160 360 20-30
Lasagne, frozen,
350-450g, 3cm deep
Uncovered cook-
ware
1 200-210 180 20-25
Lasagne, frozen,
600-1000g, 4-5cm
deep
Uncovered cook-
ware
1 200-210 180 35-45
Potato gratin, raw ingredi-
ents, 4cm deep
Ovenproof dish 1 170-180 - 50-65
Potato gratin, raw ingredi-
ents, 4cm deep
Ovenproof dish 1 150-170 360 25-30
Chicken, 1.3kg, un-
stuffed
Uncovered cook-
ware
1 200-220 - 60-70
Chicken, halved Uncovered cook-
ware
1 180-200 360 25-35
Small chicken portions,
250g each
Wire rack 2 220-230 - 30-35
Small chicken portions,
250g each
Uncovered cook-
ware
1 190-210 360 20-30
Goose, unstuffed, 3kg Uncovered cook-
ware
1 160-170 - 120-150
Joint of pork without rind,
e.g. neck, 1.5kg
Uncovered cook-
ware
1 180-200 - 120-130
Joint of pork without rind,
e.g. neck, 1.5kg
Covered cookware 1 180-200 180 55-65
Joint of pork without rind,
e.g. neck, 1.5kg
Uncovered cook-
ware
1 180-190 - 120-140
Fillet of beef, medium,
1kg
Uncovered cook-
ware
1 210-220 - 40-50
Pot-roasted beef, 1.5 kg Covered cookware 1 200-220 - 130-140
Pot-roasted beef, 1.5 kg Covered cookware 1 200-220 - 140-160
1
Preheat the appliance.
32
How it works en
Food Accessories/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C/grill setting
Microwave
power set-
ting inW
Cooking
time in
mins
Sirloin, medium, 1.5kg Uncovered cook-
ware
1 220-230 - 60-70
Leg of lamb, boned, me-
dium, 1.5kg
Uncovered cook-
ware
1 170-190 - 50-70
Meat loaf, 1kg + 50ml
water
Uncovered cook-
ware
1 170-190 360 30-40
Fish, grilled, whole,
300g, e.g. trout
Uncovered cook-
ware
1 170-190 - 20-30
Vegetables, fresh, 250g Covered cookware 1 - 600 8-12
1
Mixed vegetables, 250g,
+ 25ml water
Covered cookware 1 - 600 10-14
1
Baked potatoes, halved,
1 kg
Universal pan 2 200-220 360 15-20
Peeled boiled potatoes,
quartered, 500g
Covered cookware 1 - 600 12-15
1
Long-grain rice, 250g +
500ml water
Covered cookware 1 - 1. 600
2. 180
1. 7-9
2. 13-16
Millet, whole, 250g, +
600ml water
Covered cookware 1 - 1. 600
2. 180
1. 8-10
2. 10-15
Polenta or maize semo-
lina, 125g + 500ml wa-
ter
Covered cookware 1 - 600 6-8
1
Desserts
Making yoghurt
1.
Remove the accessories and shelves from the cook-
ing compartment.
2.
Heat 1litre of whole milk (3.5% fat) to 90°C on the
hob and then leave it to cool down to 40°C.
It is sufficient to heat UHT milk to 40°C.
3.
Mix 150g of chilled yoghurt into the milk.
4.
Pour the mixture into small containers, e.g. cups or
small jars.
5.
Cover the containers with film, e.g. cling film.
6.
Place the containers on the cooking compartment
floor.
7.
Use the recommended settings when configuring the
appliance settings.
8.
After making the yoghurt, leave it to cool in the refri-
gerator for at least 12hours.
Making blancmange from blancmange powder
1.
Use a deep, microwave-safe receptacle.
2.
Pour the blancmange powder and all of the milk and
sugar into the receptacle and mix.
3.
Place the receptacle onto the wire rack and slide the
rack into the cooking compartment.
4.
Use the recommended settings when configuring the
appliance settings.
5.
As soon as the milk starts to rise, stir thoroughly.
6.
Repeat the process until the required consistency is
achieved.
Using the microwave mode to make popcorn
WARNING‒Risk of burns!
Airtight packaging may burst when food is heated.
Always follow the instructions on the packaging.
Always use oven gloves to remove the dishes from
the cooking compartment.
1.
Use a microwave-safe, shallow ovenproof dish.
Do not use porcelain or deep plates.
2.
Place the popcorn bag onto the cookware in accord-
ance with the instructions on the packaging.
3.
Use the recommended settings when configuring the
appliance settings.
4.
The time may need to be adjusted, depending on the
product and quantity in question.
5.
Remove the popcorn bag after 1½minutes and
shake it to ensure that the popcorn does not burn.
6.
Place the popcorn bag back into the oven and leave
it to continue popping.
7.
Once you can only hear popping noises once every
2-3seconds, switch off the appliance and take the
popcorn bag out of the oven.
8.
Wipe the cooking compartment clean afterwards.
1
Stir the food one or two times during cooking.
33
en How it works
Recommended settings for desserts and compote
Food Accessory/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C
Microwave
power set-
ting in W
Cooking
time in
mins
Blancmange made from
blancmange powder
Covered cookware 1 - 600 5-8
1
Yoghurt Individual moulds Cooking
compart-
ment floor
40-45 - 8–9 hrs
Microwave popcorn, 1 x
100g bag
2
Uncovered cook-
ware
1 - 600 4-6
26.7 Special cooking methods and other
applications
Information and recommended settings for special
cooking methods and other applications, e.g. low-tem-
perature cooking.
Defrosting
You can defrost frozen food in your appliance.
Tips for defrosting food
You can use the "microwave" mode to defrost frozen
fruit, vegetables, poultry, meat, fish or baked goods.
Remove frozen food from its packaging before you
defrost it.
Use heat-resistant, microwave-safe cookware.
The recommended settings are for freezer-temperat-
ure food (-18°C).
Defrosting works best if you divide it into more than
one step. The steps are listed one after the other in
the recommended settings tables.
Stir or turn the food 1-2times during defrosting.
Turn large items several times. Split the food into
smaller pieces as it defrosts.
Remove pieces that have already defrosted from the
cooking compartment.
Once the food has defrosted, switch off the appliance
and leave the food in the appliance for another 10 to
30minutes to allow the temperature to equalise.
Recommended settings for defrosting food
Food Accessory/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C
Microwave
power set-
ting in W
Cooking
time in
mins
Bread, 500g Uncovered cook-
ware
1 - 1. 180
2. 90
1. 3
2. 10-15
Bread rolls Wire rack 1 140-160 90 2-4
Cake, moist, 500g Uncovered cook-
ware
1 - 1. 180
2. 90
1. 2
2. 10-15
Cake, dry, 750g Uncovered cook-
ware
1 - 90 10-15
Chicken, whole, 1.3kg Uncovered cook-
ware
1 - 1. 180
2. 90
1. 10
2. 10-20
3
Meat, whole, e.g. joint,
raw meat, 1kg
Uncovered cook-
ware
1 - 1. 180
2. 90
1. 15
2. 20-30
3
Minced meat, mixed,
500g
Uncovered cook-
ware
1 - 1. 180
2. 90
1. 5
2. 10-15
3
Fish, whole, 300g Uncovered cook-
ware
1 - 1. 180
2. 90
1. 3
2. 10-15
3
Berries, 300g Uncovered cook-
ware
1 - 180 5-10
Butter, defrosting, 125g Uncovered cook-
ware
1 - 90 7-9
Warming up food using the microwave mode
You can use the microwave mode to warm up food or
to defrost and warm up food in a single step.
Tips for warming up food using the microwave mode
Use microwave-safe cookware with a lid.
Turn or stir the food 2-3times during warming.
1
Stir the food one or two times during cooking.
2
Place the sealed bag on the cookware.
3
Turn the dish halfway through the cooking time.
34
How it works en
After warming up the food, leave it to rest for
1-2minutes.
The food transfers heat to the cookware. The cook-
ware can become very hot.
Make sure that you do the following when you are
warming up baby food:
– Place bottles on the wire rack without the teat or
lid.
– Shake or stir the baby food well after warming it
up.
– Always check the temperature of the baby food.
Wipe the cooking compartment dry after using it to
warm up food.
WARNING‒Risk ofscalding!
There is a possibility of delayed boiling when a liquid is
heated. This means that the liquid reaches the boiling
temperature without the usual steam bubbles rising to
the surface. Exercise caution even when only gently
shaking the container. The hot liquid may suddenly boil
over and splatter.
Always place a spoon in the container when heating
liquids. This prevents delayed boiling.
ATTENTION
Metal touching the wall of the cooking compartment will
cause sparks, which may damage the appliance or the
inner door pane.
Metal (e.g. a spoon in a glass) must be kept at least
2cm from the cooking compartment walls and the in-
side of the door.
Recommended settings for heating and reheating
Food Accessory/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C
Microwave
power set-
ting in W
Cooking
time in
mins
Drinks, warming up,
200ml
Uncovered cook-
ware
1 - Max. 1-3
1
Baby food, heating up,
e.g. baby bottle, 150ml
Uncovered cook-
ware
1 - 360 1-3
1
Vegetables, chilled,
250g
Covered cookware 1 - 600 3-8
Vegetables, frozen, loose,
250g
Covered cookware 1 - 600 8-12
Plated meal, chilled,
1portion
Covered cookware 1 - 600 4-8
Soup, stew, chilled,
400ml
Covered cookware 1 - 600 5-7
Side dishes, e.g. pasta,
dumplings, potatoes, rice,
chilled
Covered cookware 1 - 600 5-10
Plated meal, frozen,
1portion
Covered cookware 1 - 600 11-15
Soup, stew, frozen,
200ml
Covered cookware 1 - 600 4-6
1
Side dishes, 500g, e.g.
pasta, dumplings, pota-
toes, rice, frozen
Covered cookware 1 - 600 7-10
1
Bakes, 400g, e.g.
lasagne, potato gratin,
frozen
Uncovered cook-
ware
1 180-200 180 20-25
26.8 Test dishes
The information in this section is provided for test insti-
tutes to facilitate testing of the appliance in accordance
with EN 60350-1 or IEC 60350-1 and EN 60705 or IEC
60705.
Baking
The setting values apply to food that is placed into a
cold cooking compartment.
Take note of the information on preheating in the re-
commended settings tables. These setting values ap-
ply without rapid heat-up.
1
Stir the food well.
35
en How it works
For baking, use the lower of the temperatures indic-
ated first.
Items that are placed in the appliance on baking trays
or in baking tins/dishes at the same time will not ne-
cessarily be ready at the same time.
Hot water sponge cake
– As an alternative to a pan support, you can also
use the Air Fry baking tray offered by us.
Recommended settings for baking
Food Accessory/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C
Microwave
power set-
ting in W
Cooking
time in
mins
Shortbread Baking tray 1 150-160
1
- 20-30
Shortbread Baking tray 1 140-150
1
- 25-35
Small cakes Baking tray 1 160
1
- 25-35
Small cakes Baking tray 1 150
1
- 25-35
Hot water sponge cake Springform cake
tin, diameter 26 cm
1 160-170
2
- 25-35
Hot water sponge cake Springform cake
tin, diameter 26 cm
1 160-170
2
- 25-35
Grilling
Recommended settings for grilling
Food Accessories/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C/grill setting
Microwave
power set-
ting inW
Cooking
time in
mins
Toasting bread Wire rack 3 Max.
3
- 3-5
Microwave cooking
Recommended settings for defrosting food using the microwave
Food Accessory/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C
Microwave
power set-
ting in W
Cooking
time in
mins
Meat Uncovered cook-
ware
1 - 1. 180
2. 90
1. 5
2. 10-15
Recommended settings for cooking food using the microwave
Food Accessory/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C
Microwave
power set-
ting in W
Cooking
time in
mins
Custard Uncovered cook-
ware
1 - 1. 360
2. 180
1. 20
2. 20-25
Sponge Uncovered cook-
ware
1 - 600 7-9
Meat loaf Uncovered cook-
ware
1 - 600 22-27
Recommended settings for cooking in combination with the microwave
Food Accessory/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C
Microwave
power set-
ting in W
Cooking
time in
mins
Potato gratin Uncovered cook-
ware
1 150-170 360 25-30
1
Preheat the appliance for five minutes. Do not use the rapid heating function.
2
Preheat the appliance. Do not use the rapid heating function.
3
Do not preheat the appliance.
36
Installation instructions en
Food Accessory/cook-
ware
Shelf po-
sition
Type of
heating
Temperature in
°C
Microwave
power set-
ting in W
Cooking
time in
mins
Cakes Uncovered cook-
ware
1 190-210 180 12-18
Chicken, halved Uncovered cook-
ware
1 180-200 360 25-35
Installation instructions27 Installation instructions
Observe this information when installing the appliance.
27.1 General installation instructions
Follow these instructions before you start in-
stalling the appliance.
¡ There should be a gap of at least 35mm
between the wall and the cabinet base as
well as the rear panel of the cabinet situated
above.
¡ Ventilation slots and intake openings must
not be covered.
¡ The safe operation of this appliance can only
be guaranteed if it has been installed to a
professional standard in accordance with
these installation instructions. The installer
shall be liable for damages incurred as a
result of incorrect installation.
¡ Check the appliance for damage after un-
packing it. Do not connect the appliance if it
has been damaged in transit.
¡ Before starting up the appliance, remove any
packaging material and adhesive film from
the cooking compartment and the door.
¡ Proceed in accordance with the installation
sheets for installing accessories.
¡ Fitted units must be heat-resistant up to
95°C, and adjacent unit fronts up to 70°C.
¡ Do not install the appliance behind a decor-
ative door or the door of a kitchen unit.
There is a risk of overheating.
¡ Cut-out work on the units should be carried
out before installing the appliance. Remove
any shavings. Otherwise, the correct opera-
tion of electrical components may be ad-
versely affected.
¡ Position the appliance on a horizontal sur-
face.
¡ The mains socket for the appliance must
either be located in the hatched area or
outside of the area where the appliance is in-
stalled.
1
2.
Any unsecured units must be secured to the
wall using a standard bracket .
¡ Wear protective gloves so that you do not
cut yourself. Parts that are accessible during
installation may have sharp edges.
¡ Dimensions of the figures in mm.
WARNING‒Risk of electric shock!
Once the appliance has been installed, the
openings in the back panel of the appliance
must not be accessible to children, not even
through the drawers and kitchen cabinets un-
derneath. This must be ensured through the in-
stallation. In the case of an island unit, a
closed back panel is required.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord
and non-approved adapters.
Do not use extension cables or multiple
socket strips.
Only use adapters and power cords ap-
proved by the manufacturer.
If the power cord is too short and a longer
one is not available, please contact an elec-
trician to have the domestic installation ad-
apted.
37
en Installation instructions
ATTENTION
Carrying the appliance by the door handle
could break it. The door handle cannot sup-
port the weight of the appliance.
Do not carry or hold the appliance by the
door handle.
27.2 Appliance dimensions
You will find the dimensions of the appliance here
27.3 Installation below a worktop
Observe the installation dimensions and the installation
instructions when installing below a worktop.
To ventilate the appliance, the intermediate floor must
have a ventilation cut-out.
The worktop must be secured to the fitted unit.
Observe any available installation instructions for the
hob.
Observe different national installation instructions for
the hob.
27.4 Installation underneath a hob
If the appliance is installed under a hob, the following minimum dimensions must be adhered to (including substruc-
ture, if applicable).
The minimum worktop thickness a is based on the required minimum clearance .
Hob type a raised in mm a flush in mm b in mm
Induction hob 42 43 5
Full-surface induction hob 52 53 5
Gas hob 32 43 5
1
Electric hob 32 35 2
1
Observe different national installation instructions for the hob.
38
Installation instructions en
27.5 Installation in a tall unit
Observe the installation dimensions and the installation
instructions when installing in a tall unit.
To ventilate the appliance, the intermediate floors
must have a ventilation cut-out.
In order to ensure sufficient ventilation of the appli-
ance, there must be a ventilation opening of at least.
200cm² in the base area. To do this, trim the base
panel or fit a ventilation grille. Ensure that the air ex-
change is guaranteed in accordance with the dia-
gram.
Only fit the appliance up to a height which allows ac-
cessories to be easily removed.
27.6 Installing two appliances on top of each
other
Your appliance can also be installed above or below an-
other appliance. Observe the installation dimensions
and the installation instructions when installing appli-
ances on top of each other.
To ventilate the appliances, the intermediate floor
must have a ventilation cut-out.
To ensure sufficient ventilation of the two appliances,
there must be a ventilation opening of at least
200cm² in the base area. To do this, trim the base
panel or fit a ventilation grille.
Ensure that air exchange is guaranteed in accord-
ance with the diagram.
Only fit appliances up to a height that allows ac-
cessories to be easily removed.
27.7 Corner installation
Observe the installation dimensions and the installation
instructions when installing in a corner.
To ensure that the appliance door can be opened,
you must take the minimum dimensions into consider-
ation when installing in a corner. The dimension is
dependent on the thickness of the unit front and the
handle.
27.8 Electrical connection
In order to safely connect the appliance to the electrical
system, follow these instructions.
The appliance corresponds to protection class I and
must only be operated with a protective earth connec-
tion.
The fuse protection must correspond to the power rat-
ing specified on the appliance's rating plate and to
the local regulations.
The appliance must be disconnected from the power
supply whenever installation work is being carried
out.
The appliance must only be connected using the
power cable provided.
39
en Installation instructions
The power cable must be plugged in at the rear of
the appliance until you hear a clicking sound. A 3 m
power cable can be obtained from customer service.
The power cable must only be replaced with a cable
from the original manufacturer. This is available from
after-sales service.
Contact protection must be guaranteed by the install-
ation.
If the display on the appliance remains dark, it has
not been connected correctly. Disconnect the appli-
ance from the mains and check the connection.
Electrically connect the appliance with the
protective contact plug
Note: The appliance must only be connected to a pro-
tective contact socket that has been correctly installed.
Insert the plug into the protective contact socket.
When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access
is not possible, an isolating switch must be integrated
into the permanent electrical installation according to
the installation regulations.
Electrically connecting an appliance without a
protective contact plug
Note: Only licensed specialists may connect the appli-
ance. Damage caused by incorrect connection is not
covered under the warranty.
An isolating switch must be integrated into the perman-
ent electrical installation according to the installation
regulations.
1.
Identify the phase and neutral conductors in the
socket.
The appliance may be damaged if it is not connected
correctly.
2.
Connect the hob in accordance with the connection
diagram.
See the rating plate for the voltage.
3.
Connect the wires of the mains power cable accord-
ing to the colour coding:
Green/yellow = Protective conductor
Blue = Neutral conductor
Brown = Phase (external conductor)
27.9 Installing the appliance
1.
Slide the appliance in fully and centre it.
2.
Screw the appliance into place.
Note: The gap between the worktop and the appliance
must not be closed by additional battens.
Thermal insulation strips must not be fitted to the side
panels of the surround unit.
27.10 For handleless kitchens with vertical
bar handle strips:
1.
Attach a suitable filling piece on both sides in order
to cover any sharp edges and to guarantee safe in-
stallation.
2.
Secure the filling piece to the unit.
40
Installation instructions en
3.
Pre-drill the filling piece and the unit to establish a
screw connection.
4.
Secure the appliance using a suitable screw.
27.11 Removing the appliance
1.
Disconnect the appliance from the power supply.
2.
Undo the fastening screws.
3.
Lift the appliance slightly and pull it out completely.
41
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
*9001885461*
9001885461 (050327) REG25
en
