FREEZER CUPS
MODEL RC500
DESCRIPTION OF THE PARTS
The LED lights switch on just
pressing the pipe over the bell.
It works thanks to 2 batteries
installed inside the glass cooler.
Press down the pipe over
the bell to get the CO2 out.
Acess cover for replacing
batteries.
Fixing part of the cooler to
any surface ( counter top,
table, cabinet...) This part
holds the cooler down with
a screw ( it doesn't need to
make a hole)
Joint pipe from the cooler
to the gas cylinder. The
manufacturer recommeds
a dimensions of 178 cm.
COMPULSORY:
Gas cylinder key. It has to be
closed if the equipment is not
used for more than 1 hour.
Empty as well the pressure
of the pipe.
Tightening part;
joint nut of the pipe
with the gas cylinder.
COMPULSORY
- You must never release the nut gas pipe without having closed first the entry of gas of the bottle
and release the pressure from the pipe.
- It is compulsory to install the bottle and equipment in a fresh place, and with a temperature lower
than 30ºC.
- The gas cylinder or bottle must be far away from any heat supply. The gas won't cool anything with
temperatures higher than 25ºC
- Put the metal wire in the bottleneck.
- It is essential to fulfill these advices to get a good working of the machine and for warranty reasons.
It is compuslory to
introduce the metal
wire in the neck of
the bottleneck.
Líquid
CO2
Gas
Optional part for
the mobile cart.
CO2
Gas cylinder
with
dip tube
