Features:
• 12'' Slim Waterproof Subwoofer
• Completely Waterproof
• For Marine or Car Use
• PP Cone with Rubber Edge
• High-Powered Car Subwoofer
• Lab Tested Pro Audio Woofer Performance
• Massive Butyl Rubber Surround
• High Strength Engineering Plastic Basket
• Quick Connect Speaker Terminal
• Compatible with Sealed Enclosure Speaker Box Audio Setup
• Impressive Bass Response, Low-Resonance Frequency Output
• Designed for Custom Audio Car, Truck, Mobile Vehicle Applications
Installation Guide
Screw down each of the four Phillips
head screws. The locking tabs will
swivel into place and secure the unit
to the rear surface of the drywall.
Put in the strips of adhesive to
secure the grille.
Replace the metal grille.
12'' Slim Waterproof Subwoofer
500 Watts at 4-Ohm Car Audio Powered Subwoofer, PP Cone with Rubber Edge
PLSMRW124WT - PLSMRW124BK
www.PyleUSA.com
Cut the drywall.
Note: Always allow at least one-half
inch between a wall stud and the
speaker cutout or the locking tabs
will not be able to swivel into place.
Connect the speaker wires to the
speaker.
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: [email protected]
Connection Diagram
What's in the Box:
• 12'' Slim Waterproof Subwoofer
Technical Specs:
• Construction Materials: Engineered ABS
• Power Handling: 500W Max, 250W RMS
• Impedance: Dual 4 Ohms
• Voice Coil: 2.5'' -in
• Voice Coil Type: High-Temp Aluminum
• Magnet Size: 50 Oz
• Magnet Type: Barium Ferrite Magnet
• Frequency Response: 20Hz - 150Hz
• Sensitivity: 93 dB
• Product Dimensions: 12.6'' x 11.2'' x 3.3'' –inches
