CAT I V
CAT III
1.3 Symbols
Note-Important safety information, refer to the
instruction manual.
Complies with European (EU) safety standards
Earth (ground) TERMINAL
Caution, possibility of electric shock
Equipment protected throughout by double insulation
or reinforced insulation.
Both direct and alternating current
1.4.3 To avoid incorrect readings causing electric shock or
personal injury, when low battery symbol “ ” appears,
replace betteries immediately.
1.4.4 The meter can be cleaned with a soft cloth to remove any
oil, grease or grime. Do not use liquid solvent or detergent.
CAT III: MEASUREMENT CATEGORY III is applicable to
test and measuring circuits connected to the distribution
part of the building's low-voltage MAINS installation.
CAT IV: MEASUREMENT CATEGORY IV is applicable to
test and measuring circuits connected at the source of the
building’s low-voltage MAINS installation.
Conforms to UL STD. 61010-1, 61010-2-032,
61010-2-033; Certified to CSA STD C22.2 NO.
61010-1, 61010-2-032,61010-2-033
10pF
Replace test leads if leads become damaged or worn.
Use meet EN 61010-031 standard, rated CAT III 1000V, or
better test leads.
WARNING
5.2 Replacing Test Leads
