Parts List
Number: 71381
Issued: 5-12-2017
Revision: 2-23-2018
hoshizakiamerica.com
Condenser Unit
Models
URC-26J
2
CONTENTS
Auxiliary Codes ...................................................................................................................... 3
Note About Ordering Parts .................................................................................................... 4
A. Condenser Unit ................................................................................................................. 5
B. Accessories & Labels ........................................................................................................ 6
3
Auxiliary Codes
URC-26J
G-0 January 2017
H-0 January 2018
4
Auxiliary Code Breakdown
Auxiliary Codes "-5"
The auxiliary code is the rst two characters in the serial number. The rst character
indicates the year. Years progress or regress in alphabetical order. The series runs from
"A" through "V" and the letters "I" and "O" are skipped. The second character indicates
signicant part changes within a year. Base is "5" and this number advances for each
change.
Auxiliary Codes "-0"
The auxiliary code is the rst two characters in the serial number. The rst character
indicates the year. Years progress or regress in alphabetical order. The series runs from
"A" through "V" and the letters "I" and "O" are skipped. The second character indicates
signicant part changes within a year. Base is "0" and this number advances for each
change.
Note About Ordering Parts
Most assemblies cannot be ordered as complete units; parts in the assemblies generally
must be ordered separately.
5
A. Condenser Unit
URC-26J
G-0, H-0
1
2
3
4
4
5
6
7
8
9
10
Title: A. Condenser Unit Model: URC-26J
Index
No. Description
Material or
Model Number Part Number
Required Number
G-0
H-0
1 Condenser 1A3506-01 1
2 Shroud 2A7185-01 1
3 Fan Motor 4A3201-01 2
4 Fan Blade 4A1493-01 2
5 Capacitor 10.0MFD,
250VAC
443192-01 2
6 Louver Panel 2A7110-01 1
7 Right Side Panel 2A1926-01 1
8 Left Side Panel 2A1925-01 1
9 Top Panel 3A7977-01 1
10 Headmaster (Condensing
Pressure Regulator)
4A0229-01 1
6
B. Accessories & Labels
URC-26J
G-0, H-0
1
1a
1b
1b
1a
2
3
Title: B. Accessories & Labels Model: URC-26J
Index
No. Description
Material or
Model Number Part Number
Required Number
G-0
H-0
1 Leg 3A7823-01 4
1a Hex Head Bolt W/Washer 8x20 7B0130820 10
1b Hex Nut M8 7N11-0800 10
2 T2 Screw 4x8 7P31-0408 4
3 Plate 3A3872-01 2
