AIR PURIFIER
OZONE GENERATOR
USER MANUAL
CAUTION:
Read manual carefully for proper installation and operation
2
CONTENTS
Getting Started
1. Introduction ………………………………………….3
2. How Ozone Works ………………………………...3
3. Specifications& Components ……………………..3
4. Features ………………………………………………4
5. Applications ……………………………………………5
How To Use
6. Using Your Ozone Generator …………………….6
7. Operating …………………………………………………6
Care And Troubleshooting
8. Cautions
……………………………………………………
7
9. Replacing the Fuse
……………………………………
7
10.Troubleshooting
………………………………………
8
Warranty Terms
11.Warranty and Service
………………………………
9
12.Warranty Card
…………………………………………
9
3
INTRODUCTION
Thank you for your purchase of the ONAMOR Ozone Generator! We
are committed to providing innovative and safe designs that can
improve your health and quality of life. Please feel free to contact us
with any questions or concerns you might have.
Email: customer.us@namorstar.com
HOW OZONE WORKS
1. The Ozone generator creates O₃ in a special process that uses
electricity to turn oxygen into Ozone.
2. O₃ is effective to clean by decomposing odors and other pollutants
from the source. When pollutants meet ozone, oxidation occurs and
both parties are destroyed, while the O₃ will turn into oxygen
naturally in about 30 minutes.
3. As a natural air cleaner, O₃ can be created by nature in many ways.
For example, we’ve all taken a walk after a thunderstorm and
experienced the clean, fresh smell in the air. That’s O₃ at work.
SPECIFICATIONS&COMPONENTS
Model
NM-006
NM-007
NM-008
NM-009
Power
55W
80W
100W
100W
Power Supply
AC 110-120V 50-60Hz. (for US and CA Models)
Air Flow Volume
Max 106 CFM
Noise
＜45dB Max
Timer
0-180 Minute/HOLD
Unit Dimensions
240*225*198mm
9.5*9.0*7.8inches
Weight: N.E/G.W
2.2kg/2.65kg（4.85ponuds/5.85ponuds）
Ozone Generator
1 PCS
AC Power Cable
1.5m*1 PCS
Manual
1 PCS
Warning card
1 PCS
4
FEATURES
FRONT
BACK
5
● Brand new design: Horizontal air duct design, no ozone will be
blown directly on the face during operation.
● Rugged and durable: Practical and exquisite metal shell and
handle, long-life ozone sheet, durable and easy to clean.
● Powerful functions: Low noise, large air volume, quick heat
dissipation and easy maintenance.
● Safety: The heat sink reduces the heat on the ozone board and
prolongs the service life.
● Easy to use: The timer knob can be set for up to 180 minutes, and
the "HOLD" setting can also be used to continuously produce ozone.
● Utilizing controlled corona discharge ozone technology developed.
● Stainless steel pre-filter to remove large particle.
● Protect plastic box for timer and switch, more reliable.
APPLICATIONS
Scope:
Where?
Home & Kitchen
Offices & Stores
Cars Boats
Hotels Restaurants
Hospitals Clinics
Attics & Basements
Bars
Against what?
Pet Odors
Cooking Odors
Musty Smell
Smoking Smell
Chemical Odors (Formaldehyde)
Virus
Bacteria
6
USING YOUR OZONE GENERATOR
1. Before beginning ozone treatment, thoroughly clean up the source
of the odor first. And then close doors and windows, making sure the
room is sealed completely.
2. Insert the power cord into an electrical outlet. Set a timer to
desired time and leave the room. The unit will produce ozone
according to the default settings.
3. Allow 40 minutes before re-entering the treated space.
★ Please note that all ozone machines have to be used in
unoccupied spaces only. (Make sure no humans, animals, or
pets are present in the area before starting the treatment.)
★ In such environments as motels that have individual heating and
cooling systems, turn the fan on and set it on re-circulate.
★ When placing the device, set it on top of something solid to give it
a steady base and prevent it from tipping over.
★ Place the unit at least 15 inches away from TVs, radios, and other
electronic products. Make sure there's plenty of space to spread
Ozone. Position the unit as close as possible to the odor source.
★ DISCLAIMER
Please make sure the operating voltage is the same as shown on the
parametric label.
This unit will not work properly with external devices that alter or
convert voltage or frequency of electricity.
OPERATING
Timer
When the rotary switch is kept at HOLD, the device will keep
working until the switch is turned off manually or the device
will not shut down and stop working (use this function, please
remember to turn off the machine manually).
You can set the working time of the device from 0 to 180 minutes
according to your needs. When the set time is over, the machine will
automatically shut down.
7
Treatment Reference
Treatmen
t Time
30mins
60mins
90mins
150 mins
180 mins
Room
Size
0-200
Sqft
200-500
Sqft
500-1000
Sqft
1000-200
0 Sqft
2000+ Sqft
Location
Car
Kitchen
Bedroom
Boat
Garage
Basement
Living
room
Office Bar
Pet Clinic
Dining
hall
Farm
Supermarket
★ FREQUENCY:
It depends on your needs. At least once a week to keep fresh air
indoors.
★ ATTENTION:
Use in unoccupied space ONLY!
There might be an ozone smell remaining in the room after treatment.
Open doors and windows to ventilate for at least 40 minutes (or
longer according to your treatment time and room area)after the
treatment and before people return to the space.
★ STORAGE:
If you are not going to use the product for an extended period of time,
unplug it from the electrical outlet, clean and store it in a cool and dry
place out of direct sunlight.
CAUTIONS
● Never use the product when people or pets are around.
● Exposed to high concentration of Ozone will be harmful. Make sure
all Ozone is converted to oxygen before you enter the space, which
takes approximately 30 minutes.
● Do not insert objects into the air filter.
● No covering it by placing on a soft surface or in a position where it
will be blocked by an object (common objects: magazine, tissue paper,
hair and anything similar)..
● Do not operate this device near fire.
● Keep away from children. It is NOT a toy!
● This product is for indoor use.
8
REPLACING THE FUSE
Fuse holder(located on the back of the unit next to the power
cord)
※ How to replace the fuse:
● To replace fuse, pull out the plastic fuse holder
● Remove old fuse and insert new fuse
● Replacement fuse must be 1 or 2 amp(0.97inch)
TROUBLE SHOOTING
Unit fails to turn on or doesn’t produce ozone???
※ If you suspect a problem with your unit check the following:
Unit is plugged in properly.
1. It’s important that the Commercial Air Purifier be properly
grounded to avoid potential shock.
2. Fuse is installed properly and in good condition.
3. If these solutions don’t fix your problem, please contact your
authorized distributor for a repair or replacement
★ Do not open the machine privately for maintenance
WARRANTY AND SERVICE
Thank you for choosing ONAMOR Ozone Generator. We guarantee
your investment in our product is a solid one. Extensive thought,
research, planning and design goes into every product we make. High
quality components combined with precision manufacturing allows us
to maintain the highest possible production standards. All items are
guaranteed against detects in materials and craftsmanship.
ONAMOR's products come with a complete 18-month warranty. This
warranty is non-transferable and proof of purchase required when
seeking warranty assistance. ONAMOR features outstanding quality
control. If something goes wrong with any of our products, we will
repair it freely. If the product cannot be repaired, we will replace the
9
product. If the product has been discontinued, we will replace the
product with either the newest version of mentioned product or
current equivalent.
If any situation your purchase displays a manufacturer's defect during
the warranty period and does not function correctly, please contact
WARRANTY CARD
Hey there,
Thank you for purchasing an ONAMOR Product!
1 –year Extended Warranty
Your comments are very helpful to us. If you make valuable
comments on our products within one month after purchase, we
will extend the warranty period for you for 1 year free of charge.
◆ Customer Support
Don’t know how to operate?
Any defect with your package?
Not satisfied with your unit?
If you said yes to any of the above questions, we are here to help!
ONAMOR Customer Support
customer.us@namorstar.com
