Quick Start Guide
1.Air Tube
2.Nozzle
3.Ball Needle Adapter x2
4.Power Button
5.Plus Button
6.Minus Button
7.Mode Button &Illumination Button
① Install the air tube and choose
an applicable adapter, which
depends on the inflatable target.
- 01 - - 02 -
尺寸：540*53mm
材质：105g铜版纸
颜色：四色
Get pumped
like an MVP
5.Attention
4.Specifications3.Light
Avoid moisture, sand and fall.
Keep away from combustible and explosives.
Do not store the product in a place that is too cold or hot.
This product is not a toy and should not be used by kids whose age is below
3 years old.
It is forbidden to throw the product into fire or discard it at random due to the
built -in lithium battery.
Keep a safe distance between little kids and needle adapter. It can help avoid
risk of swallowing by accident.
●
●
●
●
●
●
Product Name
Product Model
Inflation Pressure Range
Storage Temperature
Working Temperature
Battery capacity
Charging input
Product Size
Weight
Smart digtal air inflator for balls
X8 Nano
0-19.9 PSI
-10°C~45°C
0°C~45°C
2200mAh/8.14Wh
5V/2A
100*61*39mm
245g
Press the Mode button more than 2 seconds to turn the inflator's light
on when it's off. The light makes it easy to see in the dark , such as
connecting the air compressor to a valve.
When the light is on, press the mode button as above to cycle
through SOS and OFF.
Note: After 30 minutes, the light will automatically turn off. .
- 07 - - 09 - - 10 -- 08 -
www.fanttik.com
METASEE LLC
5205 Broadway #634 Pearland Texas 77581
User Manual
Please read this instruction manual carefully
before use and keep it for future reference.
AIR INFLATOR
② Connect the inflator to the air valve of
the inflatable target securely.
③ Long press the Power Button and the
inflator will be turned on in manual mode.
Press “+”/“-” Button to adjust the target
pressure value in manual mode, or press
the Mode Button to select a preset mode.
Press the Power Button to start inflating.
- 03 -
④ The inflator will automatically stop at the
target pressure value. Disconnect it from
the target.
⑤ Long press the Power Button to turn off
the inflator and store it properly. Then
store the ball needle in the product setting
position.
- 04 -
1.Product Overview
1. Battery indicator
2. Preset mode
3. Target pressure value
4. Real-time pressure value
5. Pressure unit
6. Neddle adapter storage bin
7. USB-C port
8. Air outlet
Warm Tips:
USB-C port is used for charging X8 Nano with USB cable.
Air outlet is used for connecting with air tube.
6
7
1
5
2
3 4
8
- 05 -
2.Air Pressure Reference Table
Category
Balls
Type
Basketball
Soccer Ball
Volleyball
Football
7-9 PSI
8-16 PSI
4-5 PSI
12-14 PSI
Recommended Pressure Range
- 06 -
12-Month Coverage
Your Warranty Includes
Within 12 months of purchase, we will provide timely and effective online
after-sales service. We will repair or replace any defective product (due to
manufacturing fault) within the warranty period.
How to Return Your Fanttik Product
Contact [email protected] with your order number.
If your purchase was fulfilled by Amazon, please use Amazon’s
30-day return service.
Warranty info
