WALL LAMP FITTING
TECHNICAL DATA
INTRODUCTION & WARRANTY
WARNING
MODEL
VT-81050
MAX WATTS
60W
SKU
24087
IP RATING
IP44
HOLDER
E27 [Bulb not included]
BODY TYPE
Aluminium + Glass
UNIT COLOR
Matt Black
INPUT VOLTAGE
AC:220-240V, 50/60Hz
DIMENSION
120x145x265mm
INSTRUCTION MANUAL
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read
these instructions carefully before starting the installation and keep this manual handy for future
reference. If you have any another query, please contact our dealer or local vendor from whom
you have purchased the product. They are trained and ready to serve you at the best. The warran-
ty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused
by incorrect installation or abnormal wear and tear. The company gives no warranty against
damage to any surface due to incorrect removal and installation of the product. This product is
warranted for manufacturing defects only.
• Please make sure to turn o the power before starting the installation.
• Installation must be performed by a qualified electrician.
• Proper grounding should be ensured throughout the installation.
• User should prepare necessary accessories and spare parts (Not Provided)
• For Indoor Use only
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
WEEE Number: 80133970
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTALLATION DIAGRAM
1.Turn o the power.
2. Align and prepare the mounting bracket.
3. Mark and drill holes using the bracket as a guide.
Insert provided wall anchors into the drilled holes.
Secure the bracket using screws.
4. Connect the wires correctly, brown (L) to brown, blue
(N) to blue, and green/yellow ( ) to green/yellow.
INSTALLATION INSTRUCTIONS
(N) to blue, and green/yellow ( ) to green/yellow.
1 2 3
4 5 6
7 8 9
10 11
5. Attach the fixture to the mounting bracket.
6. Install the correct light bulb.
7. Turn on the power and test the light.
