MODELS:
KM-ICD-26SD, KM-ICD-49SD, KM-ICD-71SD
TABLE OF CONTENT
:
1. Warnings and Safety
3. Troubleshooting
4. Dimensions
5. Warranty
Stay informed with the latest information
for your KoolMore Appliance.
If you need any assistance or have questions, our customer
support team is here to help.
WARNINGS
Transportation and Set Up
• Do not transport the unit on an incline of more than 45 degrees.
•
•
circulation
•
• Install the freezer in a dry area, do not use under direct sunlight, keep away from any corrosive
materials.
•
Fahrenheit you may place food inside and adjust the controller to normal temperature.
1. Never store flammable, explosive or corrosive products in the freezer, and keep the freezer away
from such materials.
2. If power is cut off, wait at least 5 minutes before turning on again to avoid damage to the
compressor.
3. The temperature control may need to be adjusted based on the amount of food in the freezer and
the ambient room temperature. More food or a higher room temperature may require a lower
temperature setting (higher number).
4. Never put hot food directly in to the freezer. Food should be cold or frozen before placing it inside.
5. The cabinet is intended exclusively for the storage and/or display of packaged food. For proper
safety non-packaged foods should be packed in plastic bags or containers.
6. Do no overload the freezer, leave room between products to allow for proper air circulation.
1
DANGER: Risk of fire or explosion. Flammable refrigerant R290 used. To be
repaired only by trained service personnel. Do not use mechanical devices to
defrost refrigerator. Do not puncture refrigerant tubing.
SAFETY
2
Defrosting the Freezer
For optimal performance defrost the freezer when the ice buildup around the freezer walls reaches 1⁄4”.
1. To adjust the temperature turn the knob clockwise. The higher the number the lower the
temperature. Generally, position ‘4’ is suitable to maintain frozen products.
2. “Max’ position will be operating not continually as compressor won’t stop (no cycle).
Turn the temperature control to the “4” or “5” when temperature inside is stable for ice cream
and similar products.
• The freezer should be cleaned regularly.
When cleaning, turn off the power, remove the product
and clean the inside using water or a little neutral detergent.
• Do not use boiling water, acid, chemical diluents, petrol and oil, or dirt-removing powder.
• Dry it after cleaning.
• Use light soap water when cleaning the door seal, apply a little of talcum powder on it after
natural drying to extend its service life.
• Use soft cloth with water or a little detergent to clean the out surface. Note, keep the power
supply away from water
Maintenance
8.
There is a water conduit at the bottom of the freezer, when defrosting, extract the rubber cover,
the defrosted water will drip into the hole and flow out.
9. Plug the freezer in
10. Wait until unit reaches proper temperature before returning product to the freezer
N
OTES: PLEASE KEEP THE RUBBER COVER SAFE DURING THE DEFROSTING AND PUT IT BACK
A
FTER THE DEFROSTING IS COMPLETE.
Temperature Control
This freezer's temperature control is tamper-proof, preventing accidental adjustment and ensuring
that the quality of your frozen treats won't be compromised. The temperature control can be adjusted
easily with a screwdriver when necessary.
1. Lower the freezer temperature to the lowest number on the controller for 6 hours.
2. Remove all product from the freezer.
3. Power the freezer off
4. Remove Ice buildup from the freezer walls.
5. Do not use sharp metal tools such as steel brush to clean the ice buildup so as to avoid damage.
6. Dry the freezer walls with a clean cloth
7. When defrosting has finished drain the water in the bottom of the freezer by removing the cap, as
illustrated below.
SETUP/MAINTENANCE
3
• The sound of water flowing during operation is normal; this is the refrigerant.
• When the humidity is high, dew may form on the surface of the freezer
• When the freezer is running, the condenser and compressor will be hot
The following are not issues but are to be expected as normal operation of your freezer:
Iss ue Ca s e So lutio n
The indicator is not on. The compressor does
not start.
The plug became loose and is not properly
connected.
Adjust the plug
No power Restore power
The indicator is on, but the compressor does
not run and makes a buzzing noise.
The power voltage is <98V.
Put a power-regulator more than 1000W
together.
The compressor stops very shortly after
starting, and restarts after a few minutes,
repeatedly.
The power voltage is >132V.
The compressor works normally, but the
cabinet takes too long to cool.
The door is opened too frequently. Reduce open times.
The
freezer is overloaded or food is placed too
close together.
Adjust the placement of the product to
leave space for proper ventilation.
The frost film is too thick. Defrost the unit.
The surface of the condenser is dirty. Clean the condenser.
The door seals badly. Adjust the door seal.
The freezer is on an unstable service. Move to a stable surface.
The fixing of the freezer is loose. Tighten the fixing.
There's contact between pipes. Separate the pipes.
The noise is too loud The freezer is on an unstable service. . Move to a stable surface.
The fixing of the freezer is loose. Tighten the fixing.
There's contact between pipes Separate the pipes.
TROUBLESHOOTING
Koolmore Supply, Inc. extends a limited warranty to the original purchaser, guaranteeing that this
Koolmore
product is free from manufacturing defects in material or workmanship for one year from the date of
purchase.
Should you discover any such defect within the warranty period, Koolmore Supply, Inc., reserves the
right to
repair or replace the product without charge, or to cover the cost of replacement parts and repair labor
needed
to correct defects present at the time of purchase or resulting from regular usage, when the appliance
has been
installed, operated, and maintained as per the instructions provided.
At its sole discretion, Koolmore Supply Inc. may decide to replace the product. In such an event, your
replacement
appliance will carry the warranty for the remaining term of the original unit's warranty period.
This warranty is valid exclusively to the original purchaser of the product and only applicable within the
United
States. The warranty commences from the date of original consumer purchase. Proof of the original
purchase
date will be required to obtain service under this warranty.
Under this limited warranty, your sole and exclusive remedy will be product repair, as outlined above. All
services must be provided by a Koolmore-designated service company.
To claim warranty or request repair service:
Email support@koolmore.com. Please include your name, address, phone number, warranty repair
request,
and a copy of your proof of purchase receipt. Alternatively, visit koolmore.com and use the contact us
page. A
Koolmore customer service representative will promptly arrange service for your appliance.
We thank you for choosing Koolmore.
This limited warranty will not cover:
1. Failure of the product to perform during power failures or interruptions,
or due to inadequate electrical service.
2. Damage incurred during transportation or handling.
3. Damage caused by accidents, vermin, lightning, winds, re, oods, or acts of God.
4. Damage resulting from accidents, alterations, misuse, abuse, improper installation, repair, or mainte
nance.
This includes using any external device that alters or converts the voltage or frequency of
electricity.
5. Unauthorized product modications, repairs by unauthorized centers, or use of non-approved
replacement parts.
6. Abnormal cleaning and maintenance not aligned with the user's manual.
7. Use of incompatible accessories or components.
8. Any costs associated with repairs or replacements under these excluded circumstances shall be the
responsibility of the consumer.
