Operating and installation
instructions
Freezer
To avoid the risk of accidents or damage to the appliance it is
essential to read these instructions before it is installed and used for
the first time.
en-GB M.-Nr. 12 794 250
Contents
2
Warnings and safety notes ......................................................................................... 5
Sustainability and environmental protection.......................................................... 14
Caring for the environment ...........................................................................................
14
How to save energy.......................................................................................................
15
Familiarisation................................................................................................................ 16
Guide to the appliance ..................................................................................................
16
Start display............................................................................................................... 17
Settings mode ...........................................................................................................
18
Lock function /.................................................................................................. 18
Switching the refrigeration appliance off .......................................................... 18
Sabbath mode....................................................................................................... 18
Information on Sabbath mode............................................................................. 18
Time before door alarm is triggered...................................................................
18
Miele@home ....................................................................................................... 18
Keypad tone /................................................................................................... 19
Alarms and buzzers / ...................................................................................... 19
Display brightness ............................................................................................... 19
Temperature unit °C/°F............................................................................................ 19
Demo mode............................................................................................................ 19
Factory defaults .................................................................................................. 19
Information on the refrigeration appliance ........................................................ 20
Safety ...............................................................................................................................
20
Temperature alarm.................................................................................................... 20
Switching the temperature alarm off early............................................................ 20
Door alarm ................................................................................................................. 21
Appliance functions .......................................................................................................
21
SuperFreeze.......................................................................................................... 21
Commissioning.............................................................................................................. 22
Before using for the first time.......................................................................................
22
Connecting the refrigeration appliance ................................................................. 22
Switching the refrigeration appliance on ....................................................................
22
Switching off the refrigeration appliance ....................................................................
22
To note when switching off for longer periods of time........................................ 22
Operation........................................................................................................................ 23
Setting the temperature ................................................................................................
23
Temperature range.................................................................................................... 23
Temperature display ................................................................................................. 23
Switching SuperFreeze on .......................................................................................
23
Switching SuperFreeze off .......................................................................................
24
Contents
3
Freezing and storing food..............................................................................................
24
Maximum freezing capacity .................................................................................... 24
Storing frozen food ................................................................................................... 24
Home freezing........................................................................................................... 24
Cooling drinks quickly....................................................................................................
25
Making ice cubes............................................................................................................
25
Adjusting settings ......................................................................................................... 26
Explanation of the different settings............................................................................
26
Switching the lock function/ on.................................................................... 26
Switching Sabbath mode on ............................................................................... 26
Switching Sabbath mode off............................................................................... 26
Changing the time before the door alarm is triggered ....................................
27
Setting up Miele@home for the first time............................................................ 27
Deactivating the WiFi connection.......................................................................... 27
Activating the WiFi connection............................................................................... 27
Switching off the keypad tone ......................................................................... 28
Switching on the keypad tone.......................................................................... 28
Changing the volume of the alarms and buzzers/ ..................................... 28
Changing the display brightness ....................................................................... 28
Changing the temperature unit °C/°F.................................................................... 28
Switching off demo mode.................................................................................... 28
Resetting the settings to their factory defaults ............................................. 28
Cleaning and care ......................................................................................................... 30
Cleaning agents ..............................................................................................................
30
Preparing the refrigeration appliance for cleaning.....................................................
30
Cleaning the inside of the appliance ...........................................................................
30
Cleaning accessories by hand or in the dishwasher .................................................
31
Removing and dismantling accessories for cleaning ................................................
31
Cleaning the door seal...................................................................................................
31
Cleaning the ventilation gaps .......................................................................................
31
After cleaning ..................................................................................................................
31
Defrosting........................................................................................................................
32
Troubleshooting............................................................................................................. 33
Customer Service Department.................................................................................. 40
Contact in the event of a fault......................................................................................
40
EPREL database .............................................................................................................
40
Warranty ..........................................................................................................................
40
Optional accessories.................................................................................................... 41
Contents
4
Installation...................................................................................................................... 42
Installation site ...............................................................................................................
42
Climate range ............................................................................................................ 43
Ventilation........................................................................................................................
43
Side-by-side installation................................................................................................
44
Changing the door hinging ............................................................................................
44
Furniture door panel.......................................................................................................
44
–Gap.......................................................................................................................... 44
Weight of the furniture door.................................................................................... 45
Limiting the opening angle of the appliance door......................................................
45
Building-in dimensions .................................................................................................
46
Niche/side view ........................................................................................................ 46
Connections .............................................................................................................. 48
Installing the appliance..................................................................................................
49
To install the refrigeration appliance, you will need the following tools: .......... 49
Preparing the refrigeration appliance..................................................................... 49
Positioning the refrigeration appliance.................................................................. 50
Aligning the refrigeration appliance........................................................................ 51
Securing the refrigeration appliance in the niche................................................. 52
Fitting the furniture door ...............................................................................................
53
Electrical connection .....................................................................................................
57
EU Conformity declaration.......................................................................................... 58
UK Conformity declaration ......................................................................................... 59
Copyrights and licences .............................................................................................. 60
Warnings and safety notes
5
This refrigeration appliance complies with current safety
requirements. Inappropriate use can, however, lead to personal
injury and material damage.
Please read the operating and installation instructions carefully
before using the refrigeration appliance for the first time. They
contain important information on safety, installation, use and
maintenance. This is to protect yourself from injury, and from
damaging your refrigeration appliance.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow all information provided
on installing the refrigeration appliance, as well as the safety notes
and warnings.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating and installation instructions in a safe place
and pass them on to any future owner.
Correct application
This refrigeration appliance is intended for use in the home and in
similar environments, for example
– in shops, offices and similar work settings
– by the guests in hotels, motels, bed & breakfasts and other typical
home settings.
This refrigeration appliance is not intended for outdoor use.
The refrigeration appliance is intended for domestic use only for
storing deep-frozen food, freezing fresh food and making ice.
The refrigeration appliance is suitable for integrated under-counter
installation.
Any other usage is not permitted.
Warnings and safety notes
6
This refrigeration appliance is not suitable for storing and keeping
cool medicines, blood plasma, laboratory preparations or similar
substances or products that are subject to the Medical Device
Directive. Incorrect use of the refrigeration appliance for such
purposes may cause deterioration of the items stored. The
refrigeration appliance is also not suitable for use in areas where
there is a risk of explosion.
Miele cannot be held liable for damage caused by improper or
incorrect use or operation of the appliance.
The appliance can only be used by people with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
if they are supervised whilst using it, or have been shown how to use
it in a safe way and recognise and understand the consequences of
incorrect operation.
Safety with children
Children under 8 years of age must be kept away from the
refrigeration appliance unless they are constantly supervised.
Children 8 years and older may only use the appliance
unsupervised if they have been shown how to use it in a safe way and
recognise and understand the consequences of incorrect operation.
Children must not be allowed to clean or maintain the appliance
unsupervised.
Please supervise children in the vicinity of the appliance and do
not let them play with it.
Danger of suffocation! Whilst playing, children could become
entangled in packaging (such as plastic wrapping) or pull it over their
head and suffocate. Keep packaging material away from children.
Technical safety
The coolant circuit has been checked for leaks. The refrigeration
appliance complies with statutory safety requirements and the
appropriate EU directives.
If the cooling circuit is damaged, refrigerant and oil can escape and ignite.
Warnings and safety notes
7
Warning: fire hazard/flammable materials. This symbol is on the
compressor and indicates flammable materials. Do not remove this
sticker.
The refrigerant inside the appliance (details on the data plate) is
environmentally friendly but flammable.
The use of this refrigerant does, however, sometimes lead to a slight
increase in the noise level of the appliance. In addition to the noise of
the compressor, you might be able to hear the refrigerant flowing
around the cooling circuit. Unfortunately, this cannot be avoided, but
it does not affect the performance of the refrigeration appliance.
When transporting and installing the refrigeration appliance, ensure
that no parts of the cooling circuit are damaged. Splashes of
refrigerant can damage the eyes and leaking refrigerant can ignite.
In the event of damage:
- Avoid naked flames or anything which creates a spark.
- Disconnect the refrigeration appliance from the mains electricity
supply.
- Ventilate the room where the refrigeration appliance is located for
several minutes.
- Contact the Miele Customer Service Department.
The more refrigerant there is in a refrigeration appliance, the larger
the room it should be installed in. In the event of a leakage, if the
appliance is in a small room, there is the danger of a combustible
gas/air mixture building up. For every 8g of refrigerant at least 1m
3
of
room space is required. The amount of refrigerant in the refrigeration
appliance is stated on the data plate inside the appliance.
To avoid the risk of damage to the appliance, make sure that the
connection data (fuse rating, frequency and voltage) on the data plate
corresponds to the household supply.
Check that this is the case before connecting the appliance. Consult
a qualified electrician if in any doubt.
The electrical safety of this appliance can only be guaranteed when
correctly earthed. It is essential that this standard safety requirement
is met. If in any doubt please have the electrical installation tested by
a qualified electrician.
Warnings and safety notes
8
Temporary or permanent operation on an autonomous power
supply system or a power supply system that is not synchronised
with the mains power supply (e.g. island networks, back-up systems)
is possible. A prerequisite for operation is that the power supply
system complies with the specifications of EN50160 or an
equivalent standard.
The function and operation of the protective measures provided in
the domestic electrical installation and in this Miele product must
also be maintained in isolated operation or in operation that is not
synchronised with the mains power supply, or these measures must
be replaced by equivalent measures in the installation. As described,
for example, in the current version of BS OHSAS 18001–2 ISO
45001.
If the electrical connection cable supplied is damaged, it must only
be replaced by an original spare part to prevent a hazard for the user.
Miele can only guarantee the safety of the appliance when original
Miele spare parts are used. For safety reasons, such replacement
may only be carried out by a qualified specialist or the Miele
Customer Service Department.
Do not connect the appliance to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and do
not guarantee the required safety of the appliance.
If moisture gets into electrical components or into the mains
connection cable, it could cause a short circuit. Therefore, do not
operate this refrigeration appliance in areas which are exposed to
moisture (e.g in a garage or utility room).
This appliance must not be used in a non-stationary location (e.g.
on a ship).
Do not use a damaged appliance. It could be dangerous. Check the
appliance for visible signs of damage.
For safety reasons, this appliance may only be used after it has
been built in.
The appliance must be isolated from the electricity supply during
installation, maintenance and repair work.
Unauthorised installation, maintenance and repairs can cause
considerable danger for the user.
Installation, maintenance and repairs must only be carried out by a
Miele authorised technician.
Warnings and safety notes
9
While the appliance is under warranty, repairs should only be
undertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.
Faulty components must only be replaced with genuine Miele
original spare parts. Miele can only guarantee the safety standards of
the appliance when Miele replacement parts are used.
This refrigeration appliance is supplied with a special lamp to cope
with particular conditions (e.g. temperature, moisture, chemical
resistance, abrasion resistance and vibration). This lamp must only be
used for the purpose for which it is intended. The lamp is not suitable
for room lighting. Replacement lamps may only be fitted by a Miele
authorised technician or by the Miele Customer Service Department.
This refrigeration appliance contains several light sources with at
least energy efficiency classG.
Proper installation
When installing the refrigeration appliance, it is a mandatory
requirement to follow the installation instructions supplied with it.
Always wear protective gloves when transporting and installing the
refrigeration appliance.
Two people are required to install the refrigeration appliance.
Change the door hinging (if necessary) as described in the
installation instructions supplied with the appliance.
Correct use
This refrigeration appliance is designed for use within specific
ambient temperatures (climate range). Do not use in ambient
temperatures for which it is not designed. The climate range is stated
on the data plate in the interior cabinet of the refrigeration appliance.
A lower ambient temperature will cause the compressor to switch off
for longer periods, meaning that the refrigeration appliance is unable
to maintain the required temperature.
Do not cover or block the air vents as this could impair the
efficiency of the appliance, increase the electricity consumption and
could cause damage to the components.
If storing food which contains a lot of fat or oil in the appliance or
the door, make sure that it does not come into contact with plastic
components as this could cause stress cracks or break the plastic.
Warnings and safety notes
10
Risk of fire and explosion. Do not store explosive materials in the
refrigeration appliance or any products containing propellants (e.g.
spray cans). Electrical components can cause flammable mixes of
gases to ignite.
Danger of explosion. Do not operate any electrical equipment (e.g.
an electric ice-cream maker) inside the refrigeration appliance.
Danger of sparking and explosion.
Danger of injury and damage to the appliance. Do not store cans or
bottles containing carbonated drinks or liquids which could freeze in
the freezer zone. Otherwise they could burst.
Danger of injury and damage to the appliance. When cooling drinks
quickly in the freezer zone, make sure bottles are not left in for more
than one hour. Otherwise they could burst.
Danger of injury. Never handle frozen food or the metal parts of the
appliance with wet hands. Your hands may freeze to the frozen food
or to the metal.
Danger of injury. Do not take ice cubes out with your bare hands
and never place ice cubes or ice lollies in your mouth straight from
the freezer zone. The very low temperature of the frozen food can
cause frost burn to the lips and tongue.
Do not refreeze partially or fully defrosted food. Consume
defrosted food as soon as possible, as it will lose its nutritional value
and spoil if left for too long. Defrosted food may only be re-frozen
after it has been cooked.
Observe the manufacturer's “use-by” dates and storage
instructions given on food to avoid the risk of food poisoning. Storage
times will depend on several factors, including the freshness and
quality of the food, as well as the temperature at which it is stored.
Accessories and spare parts
Only use original Miele accessories. If other parts are used,
warranty, performance and product liability claims will be invalidated.
Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the discontinuation
of your refrigeration appliance.
Cleaning and care
Do not use any oils or grease on the door seals, as these will cause
the seals to deteriorate and become porous with time.
Warnings and safety notes
11
Do not use a steam cleaning appliance to clean or defrost this
appliance.
Steam could reach electrical components and cause a short circuit.
WARNING! DANGER of injury and damage! Do not use any
mechanical or other types of aids which are not recommended by the
manufacturer to accelerate the defrosting process.
Sharp edged or pointed objects will damage the evaporator,
causing irreversible damage to the appliance. Do not use sharp edged
or pointed objects to
- remove frost and ice,
- separate frozen food or remove ice trays.
Do not place electric heaters or candles in the appliance to defrost
it. These can damage the plastic parts.
Do not use defrosting sprays or de-icers, as they could contain
substances which could damage the plastic parts or which might
cause the build-up of gases and pose a danger to health.
Transport
Always transport the appliance in an upright position and in its
original transport packaging to avoid damage in transit.
Danger of injury and damage to the appliance. The refrigeration
appliance is very heavy and must be transported by two people.
Warnings and safety notes
12
Disposal of your old appliance
Children playing could become trapped in the appliance and could
suffocate.
- Remove the appliance doors.
- Remove the drawers.
- Leave the adjustable shelves in the refrigeration appliance so
children cannot climb inside.
- If your old refrigeration appliance has a door lock, destroy it. This
will prevent the risk of children playing accidentally locking
themselves in and endangering their lives.
Risk of electric shock!
- Cut the plug off the mains connection cable.
- Cut the mains connection cable off the old appliance.
Dispose of the plug and mains connection cable separately from the
old appliance.
During and after disposal, make sure that the refrigeration
appliance is not placed near petrol or other flammable gases and
liquids.
Risk of fire due to escaping oil or refrigerant!
The refrigerant and oil inside the appliance are flammable. In high
enough concentrations, escaping refrigerant or oil may ignite if they
come into contact with an external heat source.
During disposal, make sure that the cooling circuit is not damaged in
order to prevent refrigerant and oil escaping in an uncontrolled
manner (see the data plate for details of the refrigerant).
Splashes of coolant can damage the eyes. Be careful not to
damage any part of the pipework whilst awaiting disposal, e.g. by
- puncturing the coolant channels in the condenser,
- bending any pipework, or
- scratching the surface coating.
Symbol on the compressor (depending on model)
This information is only relevant for recycling. There is no risk during normal
operation.
Warnings and safety notes
13
The oil in the compressor can be fatal if swallowed or if it
penetrates the airways.
Sustainability and environmental protection
14
Caring for the environment
Disposing of the packaging material
The packaging material is used for
handling and protects the appliance
from transport damage. The packaging
material used is selected from materials
which are environmentally friendly for
disposal and can generally be recycled.
Recycling the packaging material
reduces the use of raw materials. Use
material-specific collection points for
valuable materials and take advantage
of return options. Your Miele dealer will
take the packaging material away.
Disposing of your old appliance
Electrical and electronic appliances
contain many valuable materials. They
also contain certain materials,
compounds and components which
were essential for their correct
functioning and safety. These could be
hazardous to human health and to the
environment if disposed of with
household waste or if handled
incorrectly. Please do not, therefore,
dispose of your old appliance with
household waste.
Take care not to damage your
refrigeration appliance before or during
disposal in an authorised,
environmentally friendly manner.
This is to ensure that refrigerant in the
cooling circuit and oil in the compressor
is contained, and will not leak into the
environment.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle
electrical and electronic appliances in
your local community, with your dealer
or with Miele, free of charge. By law, you
are solely responsible for deleting any
personal data from the old appliance
prior to disposal. You are legally obliged
to remove any old batteries which are
not securely enclosed by the appliance
and to remove any lamps without
destroying them, where this is possible.
These must be taken to a suitable
collection point where they can be
handed in free of charge. Please ensure
that your old appliance poses no risk to
children while being stored for disposal.
Sustainability and environmental protection
15
How to save energy...
Installation site The refrigeration appliance has to cool more often at higher
ambient temperatures and consumes more energy in the process.
Therefore:
- Install the refrigeration appliance in a well-ventilated room.
- Do not install the refrigeration appliance near to a heat source
(heater element, cooker).
- Protect the refrigeration appliance from direct sunlight.
- Ensure an ideal ambient temperature of 20°C.
- Clean the ventilation openings on a regular basis to remove any
dust.
Temperature
setting
The colder the temperature, the higher the energy consumption.
The following settings are recommended:
- -18°C in the freezer section.
Use Energy consumption is increased by heat input and impeded air
circulation. Therefore, you should:
- Only open the appliance door(s) when necessary and for as
short a time as possible. Arrange the food in such a way that
makes it easy to find in the appliance.
- Always close the appliance door(s) properly after opening
them.
- Allow hot food and drinks to cool down before placing them in
the refrigeration appliance.
- Store food well packaged or covered.
- Do not overfill the compartments to allow air to circulate.
- Keep drawers and shelves arranged as they were when the
appliance was delivered.
- When placing food in the appliance, make sure that the
ventilation slots are not blocked.
Familiarisation
16
Guide to the appliance
a
Display
b
Freezer drawer
c
Soft-close mechanism (SoftClose)
d
Ventilation grille
Familiarisation
17
Start display
The display can be scratched by pointed or sharp objects, e.g. pens.
Only touch the display with your fingertips.
It is possible that the display will not react to finger contact if your fingers are
cold.
-18
°C
1
2
3
4
a
Temperature display for freezer section
b
Settings mode
sensor control for adjusting various settings in Settings mode
c
Display for Miele@home connection status
(only visible when the Miele@home function has been set up)
d
Demo mode display
(only visible when the Demo mode function has been switched on)
Operating the refrigeration appliance via the display
Touch the area/symbol you want on the start display.
Swipe left or right across the display until the value/symbol you want is shown in
the middle.
Tap on the option you want on the display to confirm.
The selected value/symbol will light up orange (except for a few exceptions).
To leave the Settings level, tap on or OK.
Familiarisation
18
Settings mode
Lock function /
When the lock function is switched on,
it protects the refrigeration appliance
from being switched off unintentionally
and being adjusted unintentionally by
unauthorised persons, e.g. children.
If you just want to quickly adjust the
temperature, for example, you can
deactivate the lock function temporarily
(see “Adjusting settings”).
Switching the refrigeration appliance
off
See “Commissioning – Switching off
the refrigeration appliance”.
Sabbath mode
The refrigeration appliance offers a
Sabbath mode for the purposes of
religious observance (see “Adjusting
settings”).
When Sabbath mode is switched on,
the following are deactivated
temporarily:
- Interior lighting when the appliance
door is opened
- All visual and audible signals
- The display
- An active WiFi connection
All other functions switched on
previously remain activated.
When Sabbath mode is switched on,
you cannot make any settings on your
refrigeration appliance.
Information on Sabbath mode
You can call up the Sabbath mode
version here.
Time before door alarm
is triggered
You can set the time before the
appliance door alarm is triggered here
(see “Adjusting settings”).
Miele@home
Your refrigeration appliance is
equipped with an integrated WiFi
module.
Networking is deactivated at the
factory.
Here you can set up the Miele@home
function for the first time, deactivate
and activate the WiFi or reset the
network configuration (see “Adjusting
settings”).
To use this feature, you will need:
- A WiFi network
- The Mieleapp
- A Miele user account. You can create
a user account via the Mieleapp.
The Miele app will guide you as you
connect your refrigeration appliance to
your home WiFi network.
Once the refrigeration appliance is
connected to your WiFi network, you
can use the app to carry out the
following activities, for example:
- Call up information on the operating
status of your refrigeration appliance
- Change the settings on your
refrigeration appliance
Connecting your refrigeration appliance
to your WiFi network will increase
energy consumption, even when the
appliance is switched off.
Familiarisation
19
Make sure that the signal of your
WiFi network is sufficiently strong in
the place where you want to set up
your refrigeration appliance.
Availability of the WiFi connection
The WiFi connection shares a frequency
range with other appliances (including
microwave ovens and remote control
toys). This can give rise to sporadic or
even complete connection failures.
Therefore, the availability of featured
functions cannot be guaranteed.
Miele@home availability
The ability to use the Miele app
depends on the availability of the
Miele@home service in your country.
The Miele@home service is not
available in every country.
For information about availability, please
visit www.miele.com.
Miele App
The Miele App is available to download
free of charge from the Apple App
Store
®
or from the Google Play Store™.
Keypad tone
/
You can switch the keypad tone on or
off here (see “Adjusting settings”).
Alarms and buzzers /
You can change the volume of the
alarms and buzzers (e.g. in the event of
a door alarm or a fault message) here.
Alternatively, you can switch the alarms
and buzzers off completely if you find
them annoying (see “Adjusting
settings”).
Display brightness
You can adjust the display brightness to
the lighting conditions in the room here
(see “Adjusting settings”).
Temperature unit °C/°F
You can set the required temperature
unit (°Celsius or °Fahrenheit) here (see
“Adjusting settings”).
Demo mode
You can switch off demo mode here if it
has been switched on as a default
setting ( will appear in the start
display) (see “Adjusting settings”).
Demo mode allows the refrigeration
appliance to be presented in the
showroom without the cooling system
being switched on. This setting is not
needed for domestic use.
Factory defaults
You can reset the refrigeration
appliance‘s settings to their factory
defaults here (see “Adjusting settings”).
Tip: Reset the refrigeration appliance’s
settings to the default settings when
disposing of your refrigeration
appliance, selling it or putting a used
refrigeration appliance into operation.
This will reset the network configuration
so that your personal data is deleted
from the refrigeration appliance. This
will also ensure that a previous owner is
no longer able to access the
refrigeration appliance.
Familiarisation
20
Information on the refrigeration
appliance
You can call up the model identifier and
serial number of your refrigeration
appliance here.
Keep this appliance data to hand:
- For integrating the refrigeration
appliance into your WiFi network (see
“Adjusting settings – Setting up
Miele@home for the first time”)
- When reporting an appliance fault to
the Miele Customer Service
Department (see “Customer Service
Department”)
- When retrieving information from the
EPREL database (see “Customer
Service Department”)
Safety
Temperature alarm
The refrigeration appliance has been
fitted with a temperature alarm so that
the temperature in the freezer zone
cannot rise unnoticed.
If the temperature becomes too
warm,
will light up red in the
temperature display.
An alarm will also sound until the cause
of the alarm is rectified or the alarm is
switched off.
The set temperature determines when
the appliance recognises a temperature
as being too warm.
The audible and visual signals may be
activated in the following situations:
- You switch on the refrigeration
appliance and the temperature
differs greatly from the set
temperature.
- Too much warm ambient air enters
the freezer when you are
rearranging or taking out frozen
food.
- You are freezing large amounts of
food at once.
- You are freezing warm food.
- There was a power cut.
- The refrigeration appliance has a
fault.
Health risk caused by
decomposing food.
If the temperature in the freezer
remains above -18°C for a long time,
the frozen food can start to defrost.
This will reduce the storage life of the
food.
Check whether the frozen food has
started to defrost. If it has, check that
the food is safe to use and if it is,
then use it as soon as possible or
cook it before freezing it again.
Switching the temperature alarm off
early
Before you switch the temperature
alarm off, you must determine the
cause and rectify it.
If the alarm disturbs you, it can be
turned off early.
Tap
.
The alarm message is confirmed:
goes out and the alarm stops.
Familiarisation
21
The start screen appears in the display:
the warmest temperature recorded in
the freezer section will flash for about
1minute in the display. Then the
temperature display will change to the
current temperature in the freezer
section.
Door alarm
The refrigeration appliance is fitted
with a door alarm to avoid increased
energy consumption and food
becoming warm if the door is left
open.
If the appliance door is left open for an
extended period,
will light up yellow
in the temperature display. An alarm will
also sound and the interior lighting will
flash.
The amount of time until the door alarm
is triggered can be changed (see
“Adjusting settings – Changing the time
before the door alarm is triggered”).
The door alarm’s buzzer can also be
switched off (see “Adjusting settings –
Changing the volume of the alarms and
buzzers”).
The alarm will stop and
will go out
on the display as soon as the appliance
door is closed.
Switching the door alarm off early
Tap
.
The alarm will stop,
will go out and
the interior lighting will light up again
constantly.
If the appliance door is not closed, the
door alarm will sound again after a
short time.
Appliance functions
SuperFreeze
When switched on, the SuperFreeze
function can be used to rapidly
reduce the temperature in the freezer
zone to its lowest setting (depending on
the ambient temperature). The
refrigeration appliance will work at full
power and lower the temperature.
Select this function before freezing fresh
food. This helps food to freeze quickly
and retain its nutrients, vitamins,
flavours and appearance.
The SuperFreeze function must be
switched on approx.6hours before
the food to be frozen is placed in the
freezer (see “Operation” section,
“Switching on SuperFreeze”). When
you are freezing the maximum amount
of food, the SuperFreeze function
should be switched on 24hours
beforehand.
The SuperFreeze function will
switch itself off automatically after a
maximum of 72hours. The quantity of
fresh food placed in the freezer will
determine the duration before it
switches off.
Commissioning
22
Before using for the first time
Remove all packaging material and
protective film.
Clean the inside of the appliance and
the accessories (see “Cleaning and
care”).
Connecting the refrigeration appliance
Connect the refrigeration appliance to
the electricity supply as described in
“Electrical connection”.
Miele will then appear on the appliance
display, followed by .
Switching the refrigeration
appliance on
Open the appliance door.
Tap on the display.
The refrigeration appliance will start to
cool and the interior lighting will come
on.
When the set temperature is reached,
the
symbol disappears, the
temperature display lights up constantly
and the alarm tone stops.
If the alarm annoys you, tap
.
The alarm will stop.
The refrigeration appliance will gradually
reach the pre-set temperatures.
Do not place food in the freezer zone
until it has reached the preset
temperature (min. -18°C).
Switching off the refrigeration
appliance
Touch the temperature display on the
display.
Swipe right until is shown in the
middle.
Tap.
The cooling and interior lighting are
switched off.
will appear in the display.
Please note: The refrigeration
appliance is not disconnected from
the power supply when it is switched
off.
To note when switching off for longer
periods of time
If, during a long absence, the
refrigeration appliance is switched off
but not cleaned and the door is left
shut, there is a danger of mould
building up inside the appliance.
It is essential to clean the
refrigeration appliance before a long
period of absence.
If the refrigeration appliance is not going
to be used for a longer period of time,
observe the following:
Switch the refrigeration appliance off.
Switch off at the wall and disconnect
the plug from the socket, or
disconnect the fuse.
Clean the refrigeration appliance and
leave the door ajar to air the appliance
and avoid odours building up inside.
Operation
23
Setting the temperature
Health risk caused by
decomposing food.
To freeze fresh food, a temperature of
-18°C is required. Please note that, if
the temperature is any warmer, the
food will have a shorter shelf life.
When freezing food and storing it
over the long term, set a minimum
temperature of 0°F (-18°C).
Touch the temperature display.
Swipe left or right until the
temperature you want is shown in the
middle.
Tap the temperature you want to
confirm.
The temperature display will then
change back to the current temperature
in the freezer zone.
By keeping the freezer zone at a
constant temperature of -18°C and
taking appropriate hygiene measures
you can maximise the storage life of
your food and avoid food waste.
The temperature in the freezer zone
increases:
- The more often the appliance door is
opened and the longer it is kept open
- The more food is stored in it
- The warmer the food is which is being
put into it
- The higher the ambient temperature
surrounding the refrigeration
appliance This refrigeration appliance
is designed for use within specific
ambient temperatures (climate range).
Do not use in ambient temperatures
for which it is not designed.
Temperature range
The temperature in the freezer zone can
be adjusted from -15°C to -28°C.
Temperature display
In normal operation, the temperature
display shows the current maximum
freezer section temperature in the
refrigeration appliance.
Depending on the ambient temperature
and the temperature setting, it can take
the appliance a few hours to reach the
temperature required and for this
temperature to then be shown as a
constant temperature in the display.
Switching SuperFreeze on
The SuperFreeze function should be
switched on around6hours before
placing food in the freezer. If you are
freezing the maximum amount of
food, the SuperFreeze function
should be switched on 24hours
beforehand.
You do not need to switch on the
SuperFreeze function:
- If you are placing food that is
already frozen in the freezer
- If you only freeze up to 2kg of fresh
food daily
Touch the temperature display for the
freezer zone.
Tap.
will light up orange.
Tap on the temperature display to
leave the Settings level.
Operation
24
Switching SuperFreeze off
The SuperFreeze function will
switch itself off automatically after a
maximum of 72hours.
To save energy, you can switch off the
SuperFreeze function early yourself
once food and drinks are sufficiently
chilled.
Touch the temperature display for the
freezer zone.
Tap.
no longer lights up orange.
Tap on the temperature display to
leave the Settings level.
Freezing and storing food
Maximum freezing capacity
To ensure that fresh food placed in the
freezer freezes through to the core as
quickly as possible, the maximum
freezing capacity must not be exceeded.
The maximum freezing capacity for
freezing within a 24-hour period is given
on the data plate: “Freezing
capacity...kg/24hrs”.
Storing frozen food
When buying frozen food to store in
your freezer, check:
- That the packaging is not damaged
- The use-by date
- That the temperature at which the
frozen food is being stored in the shop
is -18°C or colder
Where possible, transport frozen food
in an insulated bag and then store it
quickly in the refrigeration appliance.
Home freezing
Not suitable for freezing
Please note that some food is not
suitable for freezing. This includes, for
example, vegetables that are usually
eaten raw, such as lettuce or radishes.
To note before placing food in the
freezer
When freezing more than 2kg of fresh
food, switch on the SuperFreeze
function for 6hours before placing
the food in the freezer.
When freezing even larger amounts of
food, switch on the SuperFreeze
function for 24hours before
placing the food in the freezer.
This helps the frozen food which is
already stored in the freezer to stay
frozen.
Only freeze fresh food which is in
good condition.
Tip: To retain colour, taste, aroma and
vitamin C, vegetables should be
blanched before they are frozen. To do
so, place vegetables portion by portion
into boiling water for 2–3minutes. Then
remove and plunge the vegetables into
ice-cold water to cool quickly. Leave the
vegetables to drain.
Packaging food for freezing
Freeze food in portions.
Tip: Use suitable packaging to avoid
freezer burn (such as freezer
containers).
Expel as much air as possible from
the packaging and close it tightly.
Make a note of the contents and the
date of freezing on the packaging.
Operation
25
Placing food in the freezer
Risk of damage caused by
loading too much food.
Loading food which is too heavy can
cause damage to the freezer drawers.
Do not exceed the relevant maximum
load size:
Bottom freezer drawer = 10kg
All other freezer drawers = 15kg.
Unfrozen food should not touch
frozen food as this will cause the
frozen food to begin to thaw.
To prevent food sticking together
when frozen, make sure that the
packaging and containers are dry.
To ensure that food freezes through to
the core quickly, do not exceed the
following packaging and container
sizes:
- Fruit and vegetables: max. 1kg
- Meat: max. 2.5kg
–Freezing small amounts of food
Place the food flat in the top freezer
drawer so that it freezes through to
the core as quickly as possible.
Place the food so that it is touching
the back of the drawer if possible.
–VarioRoom: freezing large amounts
of food
Tip: You can expand the space available
in the freezer zone. If you wish to freeze
large items such as a turkey or game,
the top freezer drawers can be removed.
Do not exceed the maximum
permitted amount of food for freezing
(see the specifications on the data
plate).
If the ventilation slots are blocked,
the cooling performance will
decrease and energy consumption
will increase.
When placing food in the freezer,
make sure that the ventilation slots
are not blocked.
Distribute the food across all the
freezer drawers, ideally the top
freezer drawers.
Place the food so that it is touching
the back of the drawer to help it
freeze through to the core as quickly
as possible.
After freezing
Switch the SuperFreeze function
off.
Place the frozen food in the freezer
drawers and push them back in.
Cooling drinks quickly
When cooling drinks quickly in the
freezer zone, make sure bottles are
not left in for more than 1hour.
Otherwise they could burst.
Making ice cubes
Fill the ice cube tray 3/4 full with
water and place it on the bottom of
one of the freezer drawers.
Once frozen, use a blunt instrument,
for example a spoon handle, to
remove the ice cube tray from the
freezer if it is stuck.
Tip: Ice cubes can be removed easily
from the tray by twisting the tray gently
or by holding it under cold running water
for a short time.
Adjusting settings
26
Explanation of the different
settings
The door alarm and other warnings are
automatically disabled when the
appliance is in Settings mode.
Switching the lock function/ on
Tap.
Swipe left or right until is shown in
the middle.
Tap.
When the lock function is switched on,
will light up orange.
To leave this Settings level, tap.
Close the appliance door. Only then
will the lock function be active.
Deactivating the lock function/
temporarily
If you want to adjust the temperature,
for example, you can deactivate the lock
function temporarily:
Touch the temperature display.
Touch for approx. 6seconds.
The display switches to the temperature
controls.
Now select the required settings.
Closing the appliance door will
reactivate the lock function.
Switching the lock function/ off
completely
Tap .
Touch for approx. 6seconds.
Swipe left or right until is shown in
the middle.
Tap .
When the lock function is switched off,
will light up white.
To leave this Settings level, tap .
Switching Sabbath mode on
When Sabbath mode is switched on,
you cannot change any settings.
Tap.
Swipe left or right until is shown in
the middle.
Tap.
will light up orange.
To leave this Settings level, tap.
If Sabbath mode is switched on, this
is indicated on the display for approx.
3s.
The display then switches off.
Ensure that the appliance door is
properly closed, as visual and audible
alarms are switched off.
Switching Sabbath mode off
The Sabbath mode function will
switch off automatically after approx.
80hours.
However, you can switch the Sabbath
mode function off early.
Tap the black display.
will appear in the display.
Tap.
will light up orange.
Tap the symbol again.
When Sabbath mode is switched off,
will light up white.
To leave this Settings level, tap.
Adjusting settings
27
Changing the time before the door
alarm
is triggered
Tap .
Swipe left or right until
is shown
in the middle.
Tap
.
Swipe left or right until the time you
want between 30seconds and
3minutes 30seconds is shown in the
middle.
Tap to confirm the setting.
To leave this Settings level, tap .
Setting up Miele@home for the first
time
Tap .
Swipe left or right until is shown in
the middle.
Tap .
Tap the connection method you wish
to use (app or WPS).
After you have successfully logged in,
will appear in the display.
If a connection could not be created,
will appear.
In this case, start the process again.
To leave this Settings level, tap .
Deactivating the WiFi connection
Tap .
Swipe left or right until is shown in
the middle.
Tap .
Tap to deactivate the WiFi
connection.
will appear in the display.
To leave this Settings level, tap .
Activating the WiFi connection
Tap .
Swipe left or right until is shown in
the middle.
Tap .
Tap to activate the WiFi
connection.
will appear in the display.
To leave this Settings level, tap .
When the WiFi connection is active,
will light up on the display.
Resetting the network configuration
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Swipe right until is shown in the
middle.
Tap.
Tap.
To leave this Settings level, tap.
All entered settings and values for
Miele@home are reset to the default
settings.
The WiFi connection has been
deactivated. will go out on the start
display.
Reset the network configuration if
you are disposing of or selling your
refrigeration appliance, or if you are
putting a used refrigeration appliance
into operation. All personal data is
removed from the refrigeration
appliance. This will also ensure that a
previous owner is no longer able to
access the refrigeration appliance.
Adjusting settings
28
Switching off the keypad tone
Tap .
Swipe left or right until
is shown
in the middle.
Tap
.
If the keypad tone is switched off,
will light up white.
To leave this Settings level, tap .
Switching on the keypad tone
Tap .
Swipe left or right until
is shown
in the middle.
Tap
.
If the keypad tone is switched on,
will light up orange.
To leave this Settings level, tap .
Changing the volume of the alarms
and buzzers/
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Select the volume you want by
swiping the segment bar to the left or
right (level 1–7).
If you want to switch the alarms and
buzzers off completely, swipe to the
left until the segment bar goes out
completely.
Confirm the setting you want by
tapping the segment bar.
When the alarms and buzzers are
switched off, will light up white.
When the alarms and buzzers are
switched on, will light up orange.
To leave this Settings level, tap.
Changing the display brightness
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Select the brightness you want by
swiping the segment bar to the left or
right (level 1–7).
Confirm the setting you want by
tapping the segment bar.
To leave this Settings level, tap.
Changing the temperature unit °C/°F
Tap.
Swipe left or right until °C or °F is
shown in the middle.
Tap °C or °F to change the
temperature unit.
°C or °F will appear on the display.
To leave this Settings level, tap.
Switching off demo mode
Tap.
Tap.
Swipe left or right until is shown in
the middle.
Tap.
After demo mode has been switched
off, the refrigeration appliance shuts
down and must be switched on again.
Resetting the settings to their factory
defaults
Tap.
Swipe left or right until is shown in
the middle.
Tap.
will appear in the display.
Adjusting settings
29
Tap .
The refrigeration appliance shuts down
and must be switched on again.
Cleaning and care
30
The data plate located inside the
interior cabinet of the refrigeration
appliance must not be removed. It
contains information which is required
in the event of a fault.
Do not let water get into the
electronic unit or the lighting.
Risk of damage due to moisture
ingress.
The steam from a steam cleaner can
damage plastic and electrical
components.
Do not use a steam cleaner to clean
the refrigeration appliance.
Cleaning agents
Cleaning and conditioning agents
used in the interior cabinet of the
refrigeration appliance must be food
safe.
To avoid damaging the surfaces of the
appliance, do not use the following:
- Cleaning agents containing soda,
ammonia, acids or chlorides
- Cleaning agents containing descaling
agents
- Abrasive cleaning agents (e.g.
scouring powder, scouring liquid or
pumice stones)
- Cleaning agents containing solvents
- Stainless steel cleaners
- Dishwasher cleaner
- Oven sprays
- Glass cleaning agents
- Hard, abrasive sponges and brushes
(e.g. pot scourers)
- Eraser stain remover blocks
- Sharp metal scrapers
We recommend using a clean sponge
and lukewarm water with a little
washing-up liquid to clean the surfaces
of the appliance.
Preparing the refrigeration
appliance for cleaning
Switch the refrigeration appliance off.
Take any food out of the refrigeration
appliance and store it in a cool place.
Take out all other removable parts for
cleaning.
Cleaning the inside of the
appliance
The refrigeration appliance should be
cleaned regularly (at least once a
month).
If soiling is left on for any length of
time, it may become impossible to
remove under certain circumstances.
Surfaces may suffer discolouration or
damage.
It is therefore best to remove any
soiling immediately.
Clean the interior with a clean
sponge, lukewarm water and a little
washing-up liquid.
After cleaning, wipe with clean water
and dry with a cloth.
Leave the door open to air the
refrigeration appliance sufficiently for
a short while and to prevent odour
build-up.
Cleaning and care
31
Cleaning accessories by hand
or in the dishwasher
The following components must be
cleaned by hand only:
- All drawers
The following components are
dishwasher-safe:
Risk of damage due to high
dishwasher temperatures.
Parts of the refrigeration appliance
may become unusable, e.g. deform, if
they are washed in the dishwasher at
more than 55°C.
For dishwasher-safe components,
always select dishwasher
programmes with a maximum
temperature of 55°C.
Contact with natural dyes from
carrots, tomatoes and ketchup, etc.,
may discolour the plastic parts in the
dishwasher. This discolouration does
not affect the stability of the parts.
- The ice cube tray
Removing and dismantling
accessories for cleaning
Taking out the freezer drawers
Lift the freezer drawers at the front
and pull them up and out at an angle.
Inserting the freezer drawers
Insert the freezer drawers back in the
freezer zone at an angle.
Cleaning the door seal
Risk of damage as a result of
incorrect cleaning.
If you treat the door seal with oils or
grease, it can become porous.
Do not use any oils or grease on the
door seal.
The door seal should be cleaned
regularly with clean water, and then
wiped dry with a soft cloth.
Cleaning the ventilation gaps
A build-up of dust will increase the
energy consumption of the appliance.
The ventilation gaps should be
cleaned on a regular basis with a
brush or vacuum cleaner (you could
use a Miele vacuum cleaner dusting
brush, for example).
After cleaning
Close the appliance door.
Switch the refrigeration appliance
back on.
Switch on the SuperFreeze function
so that the refrigeration appliance can
cool down quickly.
Once the temperature in the
refrigeration appliance is sufficiently
low, place the frozen food back in the
freezer drawers and put them back in
the refrigeration appliance.
Switch the SuperFreeze function off
again.
Cleaning and care
32
Defrosting
The appliance is equipped with a
“NoFrost” system. The refrigeration
appliance defrosts automatically.
The moisture generated in the appliance
collects on the condenser and is
automatically defrosted and dissipated
from time to time.
This automatic defrosting system
enables the freezer to remain
permanently ice-free. Food stored in the
freezer will not defrost with this system.
Troubleshooting
33
Many malfunctions and faults can be easily remedied. You can save time and
money in many cases, as you do not need to contact Customer Service.
More information to help you remedy faults yourself can be found at
www.miele.co.uk/support/customer-assistance.
To prevent unnecessary loss of temperature it is advisable not to open the door
while waiting for the appliance to be serviced.
Problem Cause and remedy
The compressor is
switching on more fre-
quently and for longer
periods of time. The
temperature in the refri-
geration appliance is too
low.
The ventilation gaps have been covered or become
too dusty.
Do not block the ventilation gaps.
Dust the ventilation gaps regularly.
The appliance door has been opened too frequently, or
a large amount of fresh food has been placed inside or
frozen at the same time.
Only open the appliance door when necessary and
for as short a time as possible.
After a while, the temperature will return to normal by
itself.
The appliance door is not properly closed. A thick layer
of ice may have formed in the freezer section.
Close the appliance door.
After a while, the temperature will return to normal by
itself.
If a thick layer of ice has already formed, this will
affect cooling and increase energy consumption.
Defrost the refrigeration appliance and clean it.
The ambient temperature is too high. The higher the
ambient temperature, the longer the compressor runs.
See the information in “Installation – Installation
site”.
The refrigeration appliance was not properly installed
in the niche.
Troubleshooting
34
Problem Cause and remedy
Install the refrigeration appliance in the niche as
described in the installation instructions supplied
with it.
The temperature setting in the refrigeration appliance
is too low.
Correct the temperature setting.
A large amount of food is being frozen at once.
See “Freezing and storing food”.
The SuperFreeze function is still switched on.
Switch off the SuperFreeze function earlier to
save energy.
Other problems
Problem Cause and remedy
There is no audible alarm
even though the appli-
ance door has been
open for a long time.
This is not a fault. The alarm has been switched off in
Settings mode. If you want to switch the audible alarm
back on again:
Tap.
Swipe left or right until is shown in the middle.
Tap.
Select the volume you want by swiping the segment
bar to the right.
Confirm the setting you want by tapping the
segment bar.
When the alarms and buzzers are switched on,
orange will appear.
The external walls of the
appliance feel warm.
This is not a fault. The heat created by the evaporator
is used to prevent condensation.
Troubleshooting
35
Display warnings
Message Cause and remedy
lights up on the
start display, the
refrigeration ap-
pliance does not
get cold even
though the con-
trols and the in-
terior lighting are
working.
Demo mode has been activated.
Tap.
Tap.
Swipe left or right until is shown in the middle.
Tap.
After Demo mode has been switched off, the
refrigeration appliance shuts down and must be
switched on again.
Nothing is visible in the
display. The display is
completely blank.
Sabbath mode is switched on: the interior lighting is
switched off and the refrigeration appliance is cooling.
Tap the black display.
will appear in the display.
Tap .
will light up orange.
Tap again.
When Sabbath mode is switched off, will light up
white.
is lit up on the display
and the appliance can-
not be used.
The lock function has been activated.
Unlock the refrigeration appliance temporarily or
switch the lock function off completely (see
“Selecting further settings – Deactivating the lock
function/ temporarily/switching off
completely”).
will light up yellow in
the display, an alarm will
also sound and the in-
terior lighting will flash.
The door alarm has been activated.
Tap
.
The alarm will stop,
will go out and the interior
lighting will light up again constantly.
Troubleshooting
36
Message Cause and remedy
is lit up red in the
temperature display and
an alarm is also sound-
ing.
The temperature alarm has been activated; the
temperature in the freezer section has risen higher or
fallen lower than the temperature set.
Possible reasons for this include:
– The appliance door has been opened too
frequently.
– A large quantity of fresh food has been placed in
the freezer without the SuperFreeze function
being switched on.
– A prolonged power cut (mains outage) has
occurred.
– The refrigeration appliance has a fault.
Tap
.
The alarm message is confirmed:
goes out and the
alarm stops.
The warmest temperature recorded in the refrigeration
appliance will flash for about 1minute in the display.
Then the temperature display will change to the
current temperature.
You can exit from the flashing temperature display
early:
Touch the temperature display.
The warmest temperature displayed will disappear.
The display will then revert to showing the current
temperature in the freezer.
Rectify the cause of the alarm.
Depending on the temperature displayed, you
should check whether food in the freezer has started
to thaw or has defrosted. If it has, it should be used
as soon as possible. Defrosted food may only be re-
frozen after it has been cooked.
Troubleshooting
37
Message Cause and remedy
lights up red in the
display and an alarm
also sounds.
Indication of an interruption to the power supply: the
temperature in the refrigeration appliance over the last
few days or hours has risen too high because of a
power cut or interruption to the power supply.
Tap
.
The fault message is confirmed:
goes out and the alarm will stop.
The warmest temperature recorded in the refrigeration
appliance will flash for about 1minute in the display.
Then the temperature display will change to the
current temperature.
You can exit from the flashing temperature display
early:
Touch the temperature display.
The warmest temperature displayed will disappear.
The display will then revert to showing the current
temperature. The refrigeration appliance will go back
to the last temperature setting when the power is
back on.
Rectify the cause of the alarm.
Depending on the temperature displayed, you
should check whether food in the freezer has started
to thaw or has defrosted. If it has, it should be used
as soon as possible. Defrosted food may only be re-
frozen after it has been cooked.
Troubleshooting
38
Message Cause and remedy
lights up red in
the display and a
fault code F with
numbers may ap-
pear. An alarm is
also sounding.
There is a fault.
Tap on the display to switch the alarm off.
Contact the Miele Customer Service Department.
To report the fault, you need the fault code and also
the model identifier and serial number of your
refrigeration appliance. You can access this
information on the display:
To do this, touch on the display.
The appliance data required will be shown on the
display.
Confirm with to exit the information display and the
fault code will be shown again on the display.
The refrigeration appliance can be switched off
directly from the fault message display.
There is an appliance fault: this display always has
priority over any settings which have just been
selected.
An appliance fault has priority over any current door
and/or temperature alarms displayed.
Interior lighting
Problem Cause and remedy
Risk of electric shock due to exposed, live electrical components.
When removing the lighting cover, there is a risk of coming into contact with
live electrical components.
Do not remove the lighting cover. The LED lighting may only be repaired or
replaced by the Miele Customer Service Department.
Risk of injury from LED lighting.
This lighting corresponds to risk group RG2. If the cover is defective, there is a
risk of eye injury.
If the lighting cover is defective, do not look from a close range directly into the
lighting with optical instruments (e.g. magnifying glass or similar).
Troubleshooting
39
Problem Cause and remedy
The interior lighting is
not working.
The refrigeration appliance has not been switched on.
Switch the refrigeration appliance on.
Sabbath mode is switched on: the display is dark
and the refrigeration appliance is cooling.
Tap on the black display.
will appear on the display.
Tap.
lights up orange.
Tap on the symbol in Settings mode.
When Sabbath mode is switched off, the symbol
will light up white.
To avoid overheating, the lighting switches itself off
automatically after approx. 15minutes if the appliance
door is left open. If this is not the case, then there is a
fault.
Call the Miele Customer Service Department.
Customer Service Department
40
Information to help you rectify faults
yourself and about Miele spare parts
can be found at www.miele.com/
service.
Contact in the event of a fault
In the event of a fault which you cannot
remedy yourself, please contact your
Miele dealer or Miele Customer Service.
You can book a Miele Customer
Service call-out online at
www.miele.com/service.
Contact information for Miele
Customer Service can be found at the
end of this document.
Please quote the model identifier and
serial number of your appliance (SN)
when contacting Miele Customer
Service. Both numbers can be found on
the data plate inside the refrigeration
appliance or, depending on the model,
in Settings mode under Information.
EPREL database
Since 1 March 2021, information on
energy labelling and ecodesign
requirements has been available in the
European Product Database (EPREL).
You can find the product database at
the following link https://
eprel.ec.europa.eu/. You will be asked to
enter the model identifier.
The model identifier can be found on the
data plate inside the refrigeration
appliance or, depending on the model,
in Settings mode under Information.
SN-ST
R600a:
XXXXXX
Nr. XX/ XXXXXXXXX.
XXX l
XXg
Warranty
For information on the appliance
warranty specific to your country please
contact Miele. See back cover for
address.
In the UK, your appliance warranty is
valid for 2 years from the date of
purchase. However, you must activate
your cover by calling 0330 160 6640 or
registering online at www.miele.co.uk.
Optional accessories
41
Multi-purpose microfibre cloth
The microfibre cloth is suitable for
removing fingerprints and light soiling
from surfaces such as stainless steel,
glass, plastic and chrome without the
use of chemicals.
MicroCloth Kit
The MicroCloth Kit contains a universal
cloth, a glass cloth and a polishing cloth.
These cloths are extremely resistant to
tearing and very robust. Thanks to very
fine microfibres these cloths achieve an
excellent cleaning performance.
MicroCloth HyClean
The MicroCloth HyClean is a multi-
purpose antibacterial cloth and is
particularly tear resistant and durable. It
can be used wet or dry, with or without
cleaning agent.
Optional accessories can be ordered
from the Miele webshop. They can
also be ordered from the Miele
Customer Service Department (see
end of this booklet for contact details)
or from your Miele dealer.
Installation
42
Installation site
Risk of damage and danger of
injury due to the refrigeration
appliance tipping over.
This refrigeration appliance is very
heavy and can tip forwards when the
appliance door is open.
Keep the appliance door(s) closed
until the refrigeration appliance has
been built in. The refrigeration
appliance must be secured in its
building-in niche in accordance with
the operating and installation
instructions.
Fire risk and risk of damage from
appliances which give off heat.
Appliances which give off heat can
catch fire and set fire to the
refrigeration appliance.
This refrigeration appliance must not
be installed underneath a hob.
Fire risk and danger of damage
from open flames.
Open flames can set fire to the
refrigeration appliance.
Keep open flames (e.g. a candle)
away from the refrigeration
appliance.
Risk of damage caused by
appliances discharging vapours.
Installing appliances that discharge
vapours behind the refrigeration
appliance will put it at risk of damage.
Do not install appliances that
discharge air or vapours behind the
refrigeration appliance. Provide a
separate air guide or install a partition
wall between the appliances.
This appliance should be installed in a
dry, well-ventilated room.
Risk of damage due to high
humidity.
In environments with high humidity,
condensation can build up on
external refrigeration appliance
panels.
This condensate can cause corrosion
on external appliance panels.
Install the refrigeration appliance in a
dry and/or air-conditioned room with
sufficient ventilation.
After installation please make sure
that the appliance door(s) closes
(close) properly and the refrigeration
appliance is installed in accordance
with these installation instructions. It
is essential to comply with the
specified ventilation cutout
requirements.
When deciding on the installation site,
please bear in mind that your
refrigeration appliance will use more
energy if installed near to a heater, a
cooker or another appliance that gives
off heat. Avoid direct sunlight.
The higher the ambient temperature, the
longer the compressor runs and the
higher the energy consumption is.
When installing the refrigeration
appliance, please note the following:
- The socket must be easily accessible
in an emergency, not concealed
behind the appliance.
- The mains plug and mains connection
cable must not touch the rear of the
refrigeration appliance as they could
be damaged by vibrations from the
appliance.
Installation
43
- Other appliances must also not be
plugged into a socket located directly
behind the refrigeration appliance.
- When installing the refrigeration
appliance, make sure that the mains
connection cable does not get
trapped or damaged.
- Do not position or operate multi-
socket adapters, distributor strips or
other electronic devices (e.g. halogen
transformers) at the rear of the
appliance.
- The floor at the installation site must
be horizontal and level and must be as
high as the surrounding floor.
Climate range
This refrigeration appliance is designed
for use within specific ambient
temperatures (climate range). Do not
use in ambient temperatures for which
it is not designed.
A lower ambient temperature leads to
the compressor switching off for longer
periods. This can cause the internal
temperature in the refrigeration
appliance to rise with the risk of food
deteriorating and going off.
The climate range is stated on the data
plate in the interior cabinet of the
refrigeration appliance.
Climate range Ambient
temperature
SN 10to32°C
N 16to32°C
ST 16to38°C
T 16to43°C
SN-ST 10to38°C
SN-T 10to43°C
A refrigeration appliance from the SN
climate range can operate without any
difficulties in rooms with a cooler
ambient temperature (down to +5°C).
Ventilation
Ventilation takes place through a
ventilation grille in the refrigeration
appliance plinth.
Risk of fire and damage due to
insufficient ventilation.
If the refrigeration appliance is not
ventilated sufficiently, the
compressor will run more frequently
and for longer periods. This will result
in increased energy consumption and
a higher operating temperature for
the compressor. This may, in turn,
cause damage to the compressor.
Please ensure that there is adequate
ventilation around the refrigeration
appliance.
It is essential to observe the required
ventilation gaps.
The ventilation gaps must not be
covered or blocked in any way.
They must also be regularly dusted.
Installation
44
Side-by-side installation
Risk of damage due to
condensation on external appliance
panels.
In environments with high humidity,
condensation can build up on
external appliance panels, which can
cause corrosion.
Do not place different refrigeration
appliance models directly next to or
on top of one other.
However your refrigeration appliance
can be installed “side-by-side” because
it is equipped with built-in heating units
in the side panels.
Please contact your dealer for specific
information about which combinations
will work with your appliance.
Changing the door hinging
Danger of injury and damage to
the appliance due to heavy door.
There is an increased risk of injury
and damage if the door hinging is
installed by a single person.
Always change the door hinging with
the help of a second person.
Risk of crushing at the hinge.
Fingers can get trapped in or around
the hinge.
Do not reach into the hinge when
opening and closing the door.
The refrigeration appliance is supplied
with right-hand hinging. If left-hand
hinging is required, the hinges must be
changed (see accompanying installation
instructions) before the refrigeration
appliance is installed in the niche.
Tip: Place a suitable cover on the floor
in front of the refrigeration appliance to
protect the appliance door and your
floor from damage during door hinging.
Be careful not to damage the door
seal. If the door seal is damaged, the
appliance door may not close
properly and cooling will be
insufficient.
Furniture door panel
–Gap
Depending on the style of kitchen
furniture, the thickness and edge radius
of the furniture door and the gap that
runs around the door, vertically and
horizontally, are specified.
It is essential to pay attention to the
following:
If the gap between the refrigeration
appliance furniture door panel and the
adjoining housing unit door or wall on
the hinged side is too small, the
appliance door could collide with the
adjoining housing unit door or wall
when opened.
It may be necessary to adjust the size
of this gap to suit the thickness and
edge radius of the appliance furniture
door.
Tip: This must be taken into
consideration when planning your
kitchen and when replacing an old
refrigeration appliance with a new one
to ensure the installation conditions
required are met.
Installation
45
Appliance
furniture
door
thickness
A [mm]
Gap X [mm]
for different
edge radiiB
R0 R1.2 R2 R3
≥16–19 min. 3
20 5 4 4 3.5
21 5.5 5 4.5 4
22 6.5 6 5.5 5
Adjoining kitchen furniture front
A=Furniture front thickness
B=Edge radius
X=Gap
Adjoining side wall
A=Furniture front thickness
B=Edge radius
X=Gap
Tip: Fit a spacer between the housing
unit carcase and the side wall. This way
you will get a sufficiently wide gap.
Weight of the furniture door
If the furniture door panel is too
heavy, this can cause damage.
Fitting a furniture front which is
heavier than the maximum permitted
weight could damage the hinges. This
damage can affect various factors,
such as operation of the appliance.
Before fitting a furniture door, ensure
that the weight of the door does not
exceed the maximum permitted.
The maximum permissible weight of the
furniture door is 10kg.
Limiting the opening angle of
the appliance door
The door hinges are set ex works to
enable the appliance door to be opened
wide.
If the opening angle of the appliance
door needs to be limited to approx. 90°,
the hinge can be adjusted to
accommodate this.
The locking pins for limiting the door
opening must be fitted before the
refrigeration appliance is installed.
Insert the locking pins supplied for
limiting the door opening into the
hinges from above.
The appliance door opening angle is
now limited to approx. 90°.
Installation
*INSTALLATION*
46
Building-in dimensions
Niche/side view
All dimensions are given in mm.
The refrigeration appliance will function correctly if the specified ventilation
openings are kept clear.
FNUS7040
+4
≤10kg
560
≥150cm²
560
≤18
60
55
+54
21
Installation
*INSTALLATION*
47
FNUS7140
≤10kg
+4
560
≥150cm²
560
≤18
860
60
55
+54
21
Installation
*INSTALLATION*
48
Connections
All dimensions are given in mm.
3
+60
≥150cm²
a
View from the front
b
Mains connection cable, length = 2200mm
A longer mains connection cable is available to order from the Miele Customer
Service Department.
c
No connection sockets in this area
Installation
*INSTALLATION*
49
Installing the appliance
To install the refrigeration appliance,
you will need the following tools:
Tip: Store the enclosed metal rod in a
safe place. It is required for adjusting
the rear appliance feet.
Preparing the refrigeration appliance
Position the refrigeration appliance in
front of the niche.
Hold the plinth panel at the side and
pull it forwards and off.
You have a choice of two different
ways of securing your refrigeration
appliance:
1. Secured at the top
This method is suitable for securing
the appliance underneath a plastic
worktop, e.g., laminate. The worktop
must be suitable for screwing a fixing
bracket onto.
With the appliance feet fully
extended the appliance should sit
lightly tensioned between the floor
and the worktop.
2. Secured at the side
This method is suitable for securing
the appliance underneath a solid
worktop, e.g. granite. The furniture
side walls to the right and left of the
refrigeration appliance must be
suitable for screwing fixing brackets
to.
With the feet fully extended the
refrigeration appliance will sit lower
than the worktop.
1.Secured at the top
Fit the bracket in the opening in the
appliance lid.
Bend the bracket at the perforated
position.
Installation
*INSTALLATION*
50
2.Secured at the side
Both ends of the bracket must be
bent.
Fit the bracket in the opening in the
appliance lid.
Bend the bracket at the perforated
position.
Remove the bracket from the opening
and insert the straight end of the
bracket.
Now bend this end of the bracket at
the perforated position.
Positioning the refrigeration appliance
Risk of damaging the mains
connection cable.
When pushing the refrigeration
appliance into its niche, the mains
connection cable can get trapped
and damaged.
Carefully push the refrigeration
appliance into the niche.
Risk of damaging the floor.
Moving the refrigeration appliance
can cause damage to the floor.
Move the refrigeration appliance
carefully on floors that are sensitive
to scratching.
Risk of damaging the appliance
feet.
The appliance feet can break off.
The feet should be almost fully
screwed in when you push the
refrigeration appliance into the niche.
Tip: Before pushing the appliance into
the niche the two rear feet should be
loosened by half a turn. After pushing it
into the niche, the feet will be easier to
adjust from the front (see “Aligning the
refrigeration appliance”).
Position the mains connection cable
so that the refrigeration appliance can
be connected easily once installed.
Tip: To help you push it into position, tie
a piece of string around the plug to
“lengthen” the mains connection cable.
Then pull the mains connection cable by
the end of the string through the
housing unit.
Installation
*INSTALLATION*
51
If the refrigeration appliance is
pushed too far into the niche, the
appliance door may not close
properly once the furniture panel has
been fitted. This can cause ice to
build up, condensate to accumulate
and lead to faults in the appliance.
These can all lead to increased
energy consumption.
Push the refrigeration appliance into
the niche, making sure a gap of
42mm is maintained all round
between the appliance carcase and
the front of the housing unit side
walls.
Push the refrigeration appliance into
the niche until the front edges of the
hinges at the top and bottom are flush
with the front edge of the housing unit
side wall.
This will create a gap all round of
42mm to the front edges of the
housing unit side walls.
On furniture with door fittings (e.g.
stubs, seals, etc.), the dimension of
these must be taken into account to
ensure there is a gap all round of
42mm.
Pull the refrigeration appliance
forwards by the appropriate
dimension.
Check again to make sure there is a
gap of 42mm to the front edges of
the door fittings.
Tip: If possible, remove the door fittings
and push the refrigeration appliance into
the niche until all fixing brackets at the
top and bottom are touching the front
edge of the housing unit side wall.
Aligning the refrigeration appliance
When securing the refrigeration
appliance in the niche at the top, it
should sit lightly tensioned between
the floor and the worktop.
Adjust the front and rear feet
alternately according to the niche
height and make sure the refrigeration
appliance is correctly aligned.
Proceed as follows:
Adjust both rear feet with appropriate
screws at the front right and left in the
appliance plinth using the rod
supplied and a flat-head screwdriver.
Unscrew the two front levelling feet
alternately with the rear ones. The
maximum adjustment range is 6cm.
Tip: As soon as the feet have been
unscrewed slightly, you can adjust them
with a screwdriver at the bottom of the
foot (see small illustration).
The foam attached to the
ventilation grille ensures the airflow is
separated to prevent malfunctioning
of the appliance.
Installation
*INSTALLATION*
52
Replace the plinth panel with the
ventilation grille, but do not fix it in
place yet.
Without a continuous plinth facing:
Pull the plinth panel forwards until
the ventilation slots are in alignment
with adjacent cabinet plinth panels.
Hold the plinth panel securely and
attach it to the right and left using the
bolts supplied.
With the plinth panel attached, the
rear feet can only be adjusted when
the plinth panel is fully inserted.
Otherwise, the bar is not long enough.
With a continuous plinth facing:
Push the plinth panel with the
ventilation grille right up against
the refrigeration appliance, and attach
it to the right and left using bolts.
If a continuous plinth facing is to be
fitted, a suitable ventilation gap will
need to be made in it for the
ventilation grille of the refrigeration
appliance.
Trim the furniture plinth facing (U) to
the correct height.
Adjust the height (V) along the niche
width (W) underneath the appliance
plinth facing.
Securing the refrigeration appliance in
the niche
1.Secured at the top
Screw the refrigeration appliance in
place underneath the worktop with
two screws in each case.
Installation
*INSTALLATION*
53
2.Secured at the side
Screw the refrigeration appliance into
the niche on the right and left with
one screw in each case.
Fitting the furniture door
If fitted in a run of units make sure that
the top edge of the furniture door is at
the same height as neighbouring unit
doors.
The furniture door must be fitted
correctly and not under tension.
The next section gives instructions on
how to fit a furniture door that is at
least 16–19 mm thick.
Ensure that the plinth panel is refitted
correctly.
The distance between the appliance
door and the fixing bracket is set to
8mm at the factory. Check this
distance and adjust it if necessary.
Push the fitting aids up to the
height of the furniture door: the lower
edge X of the fitting aids must be at
the same height as the upper edge of
the furniture door being fitted (see
in diagram).
Installation
*INSTALLATION*
54
Tip: Push up the fitting aids with the
furniture front until they are the same
height as the doors of adjacent kitchen
units.
Undo the nuts and take the fixing
bracket off together with the fitting
aids .
Using a pencil, lightly mark a line
down the centre of the inside of the
furniture door.
Hang the fixing bracket with the
fitting aids onto the inside of the
furniture door. Align the fixing bracket
centrally.
Attach the fixing bracket securely
using at least 6 short chipboard
screws. (On cassette doors only
use 4 screws on the edges.) Drill
holes into the furniture door if
necessary.
Pull the fitting aids upwards to
remove them .
Turn them around and fit them into
the middle slots on the fixing bracket
for safe keeping.
Installation
*INSTALLATION*
55
Fit the side cover to the fixing bracket
on the opposite side of the hinge.
Turn the furniture door over and
attach the handle (if required).
Open the appliance door.
Hang the furniture door onto the
adjusting bolts.
Loosely attach the nuts on the
adjusting bolts.
Close the door and check the
distance between the door and
neighbouring furniture doors.
Align to match neighbouring doors if
necessary:
Side adjustments X are made by
sliding the furniture door, and height
adjustments Y by turning adjusting
bolts with a screwdriver.
Whilst counterholding adjusting
bolts with a screwdriver, tighten
nuts on the appliance door with
screwdriver.
Attach the appliance door and the
furniture door using screws through
fixing brackets:
- Drill holes in the furniture door (mark
the position of the holes first).
- Screw in the short chipboard
screws (4x14mm).
Align the furniture door along the
depth plane Z: loosen the screws in
the long slots at the top of the
Installation
*INSTALLATION*
56
appliance door as well as under the
appliance door. By moving the
furniture door, create a gap of 2mm
between the furniture door and the
front edge of the niche. Align
according to the adjacent furniture
doors.
Close the door, check it is secured
correctly, and align it with adjacent
furniture doors.
Tighten all the screws again.
Replace the cover and click it into
place.
To make sure the appliance is
correctly fitted:
- The door must close properly.
- The door must not touch the housing
unit.
- The seal at the top edge of the handle
side must fit properly.
To double check place a torch in the
appliance and close the door.
Turn the lights out in the room. If you
can see any light shining out from the
sides double check the installation.
Installation
*INSTALLATION*
57
Electrical connection
The refrigeration appliance must only be
connected to an earthed socket using
the mains connection cable supplied.
The socket must be easily accessible
after the refrigeration appliance has
been installed. If the socket is not easily
accessible, ensure that a suitable
means of disconnection is provided on
the installation side for each pole.
Risk of fire from overheating.
Connecting the refrigeration
appliance to a multi-socket plug
adapter or to an extension lead can
overload the cable.
For safety reasons, do not use an
extension lead or multi-socket
adapter.
The electrical installation must comply
with VDE0100 requirements.
For safety reasons, we recommend
using a type residual current device
(RCD) in the assigned electrical
installation for connecting the
refrigeration appliance.
If the mains connection cable is
damaged, it must only be replaced with
a specific mains connection cable of the
same type (available from the Miele
Customer Service Department). For
safety reasons, such replacement may
only be carried out by a qualified
specialist or the Miele Customer
Service Department.
These operating instructions and the
data plate indicate the nominal power
consumption and the appropriate fuse
rating. Compare this information with
the data of the on-site electrical
connection. If in any doubt, consult a
qualified electrician.
Temporary or permanent operation on
an autonomous power supply system or
a power supply system that is not
synchronised with the mains power
supply (e.g. island networks, back-up
systems) is possible. A prerequisite for
operation is that the power supply
system complies with the specifications
of EN50160 or an equivalent standard.
The function and operation of the
protective measures provided in the
domestic electrical installation and in
this Miele product must also be
maintained in isolated operation or in
operation that is not synchronised with
the mains power supply, or these
measures must be replaced by
equivalent measures in the installation.
As described, for example, in the current
version of VDE-AR-E2510-2.
Connecting the refrigeration appliance
Insert the plug connector into the
socket at the back of the refrigeration
appliance.
Make sure that the plug connector has
clicked into position correctly.
Insert the plug of the refrigeration
appliance into the socket.
The refrigeration appliance is now
connected to the electricity supply.
EU Conformity declaration
58
Miele hereby declares that this freezer
complies with Directive 2014/53/EU.
The complete text of the EU declaration
of conformity is available from one of
the following internet addresses:
- Products, Download from
www.miele.ie
- For service, information, operating
instructions etc: go to https://
miele.co.uk/manuals and enter the
name of the product or the serial
number
Frequency band of
the WiFi module
2.4000GHz –
2.4835GHz
Maximum
transmitting
power of the WiFi
module
<100mW
UK Conformity declaration
59
Miele hereby declares that this freezer complies with UK Radio Equipment
Regulations 2017, as amended.
The complete text of the UK declaration of conformity is available from one of the
following internet addresses:
- Products, Download from www.miele.co.uk
- For service, information, operating instructions etc: go to https://miele.co.uk/
manuals and enter the name of the product or the serial number
Frequency band of the WiFi module 2.4000GHz – 2.4835GHz
Maximum transmitting power of the
WiFi module
<100mW
ThisStatement of Compliance confirms this Miele product fully complies with the
Product Security and Telecommunications Infrastructure (Security Requirements
for Relevant Connectable Products) Regulations 2023.
1) Household Appliance –
2)
Manufactured by: Miele & Cie KG,
Carl Miele Street 29, 33332 Gutersloh Germany
Imported by and contact point: Miele Company Ltd, Fairacres, Marcham Road,
Abingdon, Oxon, OX14 ITW Great Britain
The defined support period at the time of first supply is 10 years
3)
To report vulnerabilities and cybersecurity issues please contact: [email protected]4)
5) Signature
Name: Paul Wright
Company Position: Head of Technical Management
Date of signature: 19th March 2024
Place of signature:
Abingdon, Oxfordshire
Freezer - 120002, 120003, 320001, 320002
Refrigerator - 110001, 110002, 310001, 310002, 310003
Fridge-freezer - 130001, 130002, 130003, 130004,
330001, 330002
Wine unit - 210007, 310004, 330004
Copyrights and licences
60
For the purpose of operating and controlling the communication module, Miele
uses proprietary or third-party software that is not covered by open source
licensing terms. This software/these software components are protected by
copyright. The copyrights held by Miele and third parties must be respected.
Furthermore, the communication module integrated in the appliance contains
software components which are distributed under open source licence conditions.
The open source components contained in the appliance along with the
corresponding copyright notices, copies of the licensing terms valid at the time and
any further information can be accessed locally by IP via a web browser (http[s]://
<IP address>/Licenses). The liability and warranty arrangements for the open
source licences displayed in this location only apply in relation to the respective
rights holders.
United Kingdom
Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW
Tel: 0330 160 6600, Internet: www.miele.co.uk, E-mail: [email protected]
Australia
Miele Australia Pty. Ltd.
ACN 005 635 398
ABN 96 005 635 398
Level 4, 141 Camberwell Road
Hawthorn East, VIC 3123
Tel: 1300 464 353
E-mail: [email protected]
Internet: www.miele.com.au
Miele Electrical Appliances Co. Ltd.
No. 82, Shimenyi Road, JingAn District
Shanghai, China, P.R.C
Post Code: 200040
Phone: +86 21 6157 3500
Fax: +86 21 6157 3511
E-mail: info@miele.cn
Internet: www.miele.cn
China Mainland
Miele (Hong Kong) Ltd.
41/F - 4101, Manhattan Place
23 Wang Tai Road
Kowloon Bay, Hong Kong
Tel: (852) 2610 1025
Fax: (852) 3579 1404
E-mail:
Website: www.miele.hk
Hong Kong, China
Miele India Pvt. Ltd.
1st Floor, Copia Corporate Suites,
Commercial Plot 9, Mathura Road,
Jasola, New Delhi - 110025
E-mail: customercare@miele.in
Website: www.miele.in
India
Miele Ireland Ltd.
2024 Bianconi Avenue
Citywest Business Campus
Dublin 24
Tel: (01) 461 07 10
Fax: (01) 461 07 97
E-mail: [email protected]
Internet: www.miele.ie
Ireland
Malaysia
Miele Sdn Bhd
Suite 12-2, Level 12
Menara Sapura Kencana
Petroleum
Solaris Dutamas No. 1
Jalan Dutamas 1
50480 Kuala Lumpur, Malaysia
Phone: +603-6209-0288
Fax: +603-6205-3768
Miele New Zealand Limited
IRD 98 463 631
8 College Hill
Freemans Bay, Auckland 1011
Tel: 0800 464 353
Internet: www.miele.co.nz
New Zealand
Miele Pte. Ltd.
29 Media Circle
#11-04 ALICE@Mediapolis
Singapore 138565
Tel: +65 6735 1191
Fax: +65 6735 1161
E-mail: [email protected]
Internet: www.miele.sg
Singapore
Miele (Pty) Ltd.
63 Peter Place, Bryanston 2194
Tel: (011) 875 9000
Fax: (011) 875 9035
E-mail: [email protected]
Internet: www.miele.co.za
South Africa
Miele Appliances Ltd.
Showroom 1, Eiffel 1 Building
P.O. Box 114782 - Dubai
Tel. +971 4 3044 999
Fax. +971 4 3418 852
800-MIELE (64353)
E-mail: [email protected]
Website: www.miele.ae
United Arab Emirates
Manufacturer: Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Thailand
Miele Appliances Ltd.
BHIRAJ TOWER at EmQuartier
43rd Floor Unit 4301-4303
689 Sukhumvit Road
North Klongton Sub-District
Vadhana District
Bangkok 10110, Thailand
Sheikh Zayed Road, Umm Al Sheif
E-mail: customercare@miele.co.nz
P.O. Box 69434, Bryanston 2021
M.-Nr. 12 794 250 / 01en-GB
FNUS 7040 ..., FNUS 7140 ...
