PVC LIQUID TIGHT
CONDUIT INSTRUCTION
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
SPECIFICATION：PLFNCB-1/2，PLFNCB-3/4， PLFNCB-1
(The picture is for reference only, please refer to the actual object)
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
PVC LIQUID TIGHT
CONDUIT
- 2 -
INSTRUCTIONS
1、Drawing
2、List of accessories
Accessory
Qty
1
180°connector
5 PCS
2
PVC Liquid tight
flexible conduit
30.48 M
（100ft）
3
90°connector
5 PCS
180
°
connector
90
°
connector
PVC liquid tight
flexible conduit
- 3 -
3、Technical specification
1
Model
PLFNCB-1/2
PLFNCB-3/4
PLFNCB-1
2
Inch
1/2”
3/4”
1”
I.D.
ID:15.80~16.31
ID:20.83~21.34
ID:26.44~27.08
O.D.
OD:20.83~21.34
OD:26.16~26.67
OD:32.77~33.40
3
Length(m)
30.48
（
100ft
）
4
Certificate
UL1660 (NO.：E473661)
5
IP
IP65
6
Flexibility
Medium
7
Fire
retardant
VW-1
8
Temperature
range
-20
℃
~60
℃
9
Color
Grey
1
0
RoHS
Yes
- 4 -
4、Bill of Material
4.1 180°connector exploded view：
4.2 90°connector exploded view：
Nut Material:
carbon steel
Galvanize surface
Seal ring
Material: rubber
Color: black
Centrebody
Material: PA
Color: grey
Lock nut,
Material: PA
Color: grey
Seal ring
Material: rubber
Color: black
Nut Material:
carbon steel
Galvanize
Centrebody
Material: PA
Color: grey
Lock nut,
Material: PA
Color: grey
- 5 -
4.3 PVC liquid tight flexible conduit profile ：
5、Assembly instruction
5.1 Loose the nut
5.2 Insert the conduit into the bottom of the connector
5.3 Lock the nut
6、Main function
Protect wire and cable, waterproof, moisture-proof, flame retardant,
wear-resistant, pressure resistant, dust resistant, weather resistant, soft
and flexible, oil resistant and so on. Suitable for all kinds of residential
and commercial buildings, industrial and mining plants, machinery wiring
and other places.
7、Notes:
7.1 Avoid use and installation out of temperature range and the fire source
environment.
7.2 Trim the edges inside and outside of the conduit before assembly
7.3 When assembling, try to insert the conduit into the bottom of the
connector and lock the nut.
7.4 Conduit and connectors are only suitable for wire and cable protection,
not for other purposes.
5.1
5.2
5.3
- 6 -
Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu,
shanghai 200000 CN.
Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW
2122 Australia
Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim Place,
Rancho Cucamonga, CA 91730
REP
EC
E-CrossStu GmbH
Mainzer Landstr.69, 60329 Frankfurt am Main.
REP
UK
YH CONSULTING LIMITED.
C/O YH Consulting Limited Office 147, Centurion House,
London Road, Staines-upon-Thames, Surrey, TW18 4AX
- 8 -
Technique Assistance et certificat de garantie électronique
www.vevor.com/support
PVC ÉTANCHE AUX LIQUIDES
INSTRUCTION SUR les CONDUITS
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
SPÉCIFICATION : PLFNCB- 1/2 ,PLFNCB- 3/4 , PLFNCB- 1
(L'image est uniquement à titre de référence, veuillez vous référer à l'objet
réel)
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
PVC LIQUID TIGHT
CONDUIT
- 2 -
INSTRUCTIONS
8、Dessin
9、Liste des accessoires
Accessoire
Quantité
1
Connecteur 180°
5 PIÈCES
2
Conduit flexible
étanche aux liquides
en PVC
30,48 millions
（100 pieds）
3
Connecteur 90°
5 PIÈCES
180
°
connector
90
°
connector
PVC liquid tight
flexible conduit
- 3 -
10、Spécifications techniques
1
Modèle
PLFNCB-1/2
PLFNCB-3/4
PLFNCB-1
2
Pouce
1/2"
3/4"
1"
IDENTIFIAN
T
ID:15h80 ~
16h31
ID:20.83~21.34
ID:26.44~27.08
DO
OD:20,83 ~
21,34
DE:26,16 ~
26,67
DE:32,77 ~
33,40
3
Longueur
(m)
30,48 （100 pieds）
4
Certificat
UL1660 (N° : E473661)
5
IP
IP65
6
La flexibilité
Moyen
7
Retardateur
de flamme
VW-1
8
Écart de
température
-20 ℃ ~ 60 ℃
9
Couleur
Gris
d
ix
RoHS
Oui
- 4 -
11、Nomenclature
4.1 Vue éclatée du connecteur 180°：
4.2 Vue éclatée du connecteur 90°：
Nut Material:
carbon steel
Galvanize surface
Seal ring
Material: rubber
Color: black
Centrebody
Material: PA
Color: grey
Lock nut,
Material: PA
Color: grey
Seal ring
Material: rubber
Color: black
Nut Material:
carbon steel
Galvanize
Centrebody
Material: PA
Color: grey
Lock nut,
Material: PA
Color: grey
- 5 -
4.3 Profil de conduit flexible étanche aux liquides en PVC ：
12、instructions de montage
