Technical Support and E-Warranty Certificate
www.vevor.com/support
DOUBLE-HANDED CARRY CLAMPS
USER MANUAL
MODEL: GM-2/GM-2(H)
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: GM-2/GM-2(H)
(The picture is for reference only, please refer to the actual object)
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
DOUBLE-HANDED
CARRY CLAMPS
- 2 -
SAFETY INSTRUCTION AND PRECAUTIONS
WARNING:
Read this material before using this product. Failure to do so can result in
serious injury.
1. This product is not a toy. Do not allow children to play with this item.
2. Use as intended only.
3. Make sure the handle is not loose before each use.
4. Do not exceed the listed weight capacity.
5. Double Hand Carrying Device should be used on non-porous or rough
flat panel materials.
6. Double Hand Carrying Device can only be operated by hand lifting.
7. When serving, use only identical replacement parts. Use of any other
parts will avoid the warranty.
8. Check for damaged parts. Before using, any part that appears damaged
should be carefully checked to determine that it will operate properly and
perform its intended function and the surface of rubber pads should be
cleaned up without dirt.
9. When not in use, product should be stored in a dry, not high temperature,
without direct sun shining location to inhibit rust and wear out.
Operation Direction：
1.The principle of operation is by lever and hand lifting.
2.Carrying aid made of aluminium,for transporting all materials such as
kitchen counters or dry wall sheets,especially good for glass and stone
carrying.
3. Loaded Surface need to be relatively, and non-porous or rough flat
panel materials both can use.
4.The heavier the load,the stronger the clamping action.
5.The load is held firmly between two non-slip,rubber-lined clamps.
- 3 -
OPERATION AS BELOW
1. Open the Double Hand Carrying
Device carton box and check the
product and accessories are intact.
2.The Double Hand Carrying
Device must be controled by 2
guys per pair.
3. When use,open the mouth of the
device and clamp the materials of
both side till to the botton of mouth.
- 4 -
4.After the transportation process
is completed, put down the
materials and hold, then the mouth
of the device will be open, so that
you can remove the device.
Items
Description
1
Name
Double-handed carry clamps
2
Model
GM-2
3
Parameter
Thickness of clamping：0-50mm
Load-bearing：200kg
Items
Description
1
Name
Double-handed carry clamps
2
Model
GM-2（H）
3
Parameter
Thickness of clamping：0-60mm
Load-bearing：250kg
- 5 -
Manufacturer: Shanghaimuxinmuyeyouxiangongsi
Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu,
shanghai 200000 CN.
Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD
NSW 2122 Australia
Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim
Place, Rancho Cucamonga, CA 91730
REP
EC
E-CrossStu GmbH
Mainzer Landstr.69, 60329 Frankfurt am Main.
REP
UK
YH CONSULTING LIMITED.
C/O YH Consulting Limited Office 147, Centurion
House, London Road, Staines-upon-Thames, Surrey,
TW18 4AX
