en Table of contents
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
1 Safety ............................................ 3
1.1 General information .................... 3
1.2 Intended use ................................ 3
1.3 Restriction on user group .......... 3
1.4 Safe transport .............................. 3
1.5 Safe installation ........................... 4
1.6 Safe use ........................................ 5
1.7 Damaged appliance ................... 6
2 Preventing material damage ...... 7
3 Environmental protection and
saving energy .............................. 7
3.1 Disposing of packaging ............. 7
3.2 Saving energy .............................. 8
4 Installation and connection ........ 8
4.1 Scope of delivery ........................ 8
4.2 Criteria for the installation loc-
ation ............................................... 8
4.3 Installing the appliance .............. 9
4.4 Preparing the appliance for
the first time ................................. 9
4.5 Connecting the appliance to
the electricity supply ................... 9
5 Familiarising yourself with
your appliance ........................... 10
5.1 Appliance .................................... 10
5.2 Control panel ............................. 11
6 Features ..................................... 11
6.1 Shelf ............................................. 11
6.2 Fruit and vegetable contain-
er .................................................. 11
6.3 Door tray ..................................... 12
6.4 Accessories ............................... 12
7 Basic operation ......................... 12
7.1 Switching on the appliance ..... 12
7.2 Operating tips ............................ 12
7.3 Switching off the appliance ..... 12
7.4 Setting the temperature ........... 12
8 Additional functions ................. 12
8.1 Super cooling ........................... 12
9 Refrigerator compartment ........ 13
9.1 Tips for storing food in the re-
frigerator compartment ............ 13
9.2 Chill zones in the refrigerator
compartment .............................. 13
9.3 "OK" sticker ................................ 13
10 Defrosting ................................ 13
10.1 Defrosting in the refrigerator
compartment ........................... 13
11 Cleaning and servicing ........... 14
11.1 Preparing the appliance for
cleaning .................................... 14
11.2 Cleaning the appliance .......... 14
11.3 Cleaning the condensation
channel and drainage hole ... 15
11.4 Removing the fittings ............. 15
12 Troubleshooting ...................... 16
13 Storage and disposal .............. 17
13.1 Taking the appliance out of
operation .................................. 17
13.2 Disposing of old appliance ... 17
14 Customer Service ................... 18
14.1 Product number (E-Nr.) and
production number (FD) ........ 18
15 Technical data ......................... 18
2
Safety en
Safety 1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Do not connect the appliance if it has been damaged in transit.
1.2 Intended use
Only use this appliance:
¡ For chilling food.
¡ in private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of 2000 m above sea level.
1.3 Restriction on user group
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Do not let children play with the appliance.
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
Children above the age of three years old and younger than eight
years old may load and unload the the fridge-freezer.
1.4 Safe transport
WARNING‒Risk of injury!
The heavy weight of the appliance may result in injury when lifted.
Do not lift the appliance on your own.
3
en Safety
1.5 Safe installation
WARNING‒Risk of electric shock!
Incorrect installation is dangerous.
Connect and operate the appliance only in accordance with the
specifications on the rating plate.
Connect the appliance to a power supply with alternating cur-
rent only via a properly installed socket with earthing.
The protective conductor system of the domestic electrical in-
stallation must be properly installed.
Never equip the appliance with an external switching device,
e.g. a timer or remote control.
When the appliance is installed, the mains plug of the power
cord must be freely accessible. If free access is not possible, an
isolating switch must be integrated into the permanent electrical
installation according to the installation regulations.
When installing the appliance, check that the power cable is not
trapped or damaged.
If the insulation of the power cord is damaged, this is dangerous.
Never let the power cord come into contact with heat sources.
WARNING‒Risk of explosion!
If the appliance's ventilation openings are closed off, a leak in the
refrigeration circuit may result in a flammable mixture of gas and
air.
Keep ventilation openings in the appliance casing or in the in-
tegrated casing clear of obstruction.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-approved
adapters.
Do not use extension cables or multiple socket strips.
Only use adapters and power cords approved by the manufac-
turer.
If the power cord is too short and a longer one is not available,
please contact an electrician to have the domestic installation
adapted.
4
Safety en
Portable multiple socket strips or portable power supply units may
overheat and cause a fire.
Do not place portable multiple socket strips or power supply
units on the back of the appliance.
1.6 Safe use
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
Only use the appliance in enclosed spaces.
Never expose the appliance to intense heat or humidity.
Do not use steam- or high-pressure cleaners to clean the appli-
ance.
WARNING‒Risk of suffocation!
Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
Keep packaging material away from children.
Do not let children play with packaging material.
Children may breathe in or swallow small parts, causing them to
suffocate.
Keep small parts away from children.
Do not let children play with small parts.
WARNING‒Risk of explosion!
If the cooling circuit is damaged, flammable refrigerant may es-
cape and explode.
To accelerate the defrosting process, do not use any other
mechanical devices or means other than those recommended
by the manufacturer.
If food is stuck to the freezer compartment, loosen it with a blunt
object such as the handle of a wooden spoon.
Products which contain flammable propellants and explosive sub-
stances may explode, e.g. spray cans.
Do not store products which contain flammable propellants (e.g.
spray cans) or explosive substances in the appliance.
WARNING‒Risk of fire!
Electrical devices within the appliance may cause a fire, e.g. heat-
ers or electric ice makers.
Do not operate electrical devices within the appliance.
5
en Safety
WARNING‒Danger: Magnetism!
The exchangeable coloured fronts are secured with magnets. The
magnets may affect electronic implants, e.g. pacemakers, defibril-
lators or insulin pumps.
Persons with electronic implants must stand at least 15cm
away from the magnets.
WARNING‒Risk of injury!
Injury to the eyes caused by escaping flammable refrigerant and
hazardous gases.
Do not damage the tubes of the refrigerant circuit or the insula-
tion.
CAUTION‒Risk of harm to health!
To prevent food from being contaminated, you must observe the
following instructions.
If the door is open for an extended period of time, this may lead
to a considerable temperature increase in the compartments of
the appliance.
Regularly clean the surfaces that may come into contact with
food and accessible drain systems.
Store raw meat and fish in suitable containers in the refrigerator
so that they do not touch or drip on other food.
If the fridge/freezer is empty for an extended period of time,
switch off the appliance, defrost it, clean it and leave the door
open to prevent the formation of mould.
Metal or metal-style parts in the appliance may contain aluminium.
If acidic food comes into contact with aluminium in the appliance,
aluminium foil ions may pass into the food.
Do not consume soiled food.
1.7 Damaged appliance
WARNING‒Risk of electric shock!
If the appliance or the power cord is damaged, this is dangerous.
Never operate a damaged appliance.
Never pull on the power cord to unplug the appliance. Always
unplug the appliance at the mains.
If the appliance or the power cord is damaged, immediately un-
plug the power cord or switch off the fuse in the fuse box.
6
Preventing material damage en
Call customer service.
Page18
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained
specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord of this appliance is damaged, it must be re-
placed by the manufacturer, the manufacturer's Customer Ser-
vice or a similarly qualified person in order to prevent any risk.
WARNING‒Risk of fire!
If the tubes are damaged, flammable refrigerant and harmful
gases may escape and ignite.
Keep naked flames and ignition sources away from the appli-
ance.
Ventilate the room.
Switch off the appliance.
Page12
Unplug the mains plug from the mains or switch off the circuit
breaker in the fuse box.
Call customer service.
Page18
Preventing material damage2 Preventing material
damage
ATTENTION
Using the base, runners or appliance
doors as a seat surface or climbing
surface may damage the appliance.
Do not stand or support yourself
on the base, runners or doors.
Contamination with oil or fat may
cause plastic parts and door seals to
become porous.
Keep plastic parts and door seals
free of oil and grease.
Metal or metal-style parts in the appli-
ance may contain aluminium. When
aluminium comes into contact with
acidic foods, it corrodes and discol-
ours.
Only store packaged food in the
appliance.
If you clean fittings and accessories
in the dishwasher, this may cause
them to become deformed or discol-
our.
Never clean fittings and accessory
in the dishwasher.
Environmental protection and saving energy3 Environmental protec-
tion and saving energy
3.1 Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
7
en Installation and connection
Sort the individual components by
type and dispose of them separ-
ately.
3.2 Saving energy
If you follow these instructions, your
appliance will use less power.
Selecting the installation location
Keep the appliance out of direct
sunlight.
Install the appliance as far away as
possible from heating elements,
cookers and other heat sources:
– Maintain a 30mm clearance to
electric or gas cookers.
– Maintain a 300mm clearance to
oil or solid-fuel cookers.
Never cover or block the exterior
ventilation grilles.
Saving energy during use
Note: The arrangement of the fittings
does not affect the energy consump-
tion of the appliance.
Open the appliance only briefly
and then close it carefully.
Never cover or block the interior
ventilation openings or the exterior
ventilation grilles.
Transport purchased food in a
cool bag and place in the appli-
ance quickly.
Allow warm food and drinks to
cool down before storing them.
Thaw frozen food in the refrigerator
compartment to utilise the low tem-
perature of the food.
Always leave some space between
the food and to the back panel.
Installation and connection4 Installation and con-
nection
4.1 Scope of delivery
After unpacking all parts, check for
any transport damage and for com-
pleteness of delivery.
If you have any complaints, contact
your dealer or our after-sales service
Page18
.
The delivery consists of the following:
Equipment and accessories
1
Installation instructions
User manual
Customer service directory
Warranty enclosure
2
Energy label
Information on energy consump-
tion and noises
4.2 Criteria for the installation
location
WARNING
Risk of explosion!
If the appliance is in a space that is
too small, a leak in the refrigeration
circuit may result in a flammable mix-
ture of gas and air.
Only install the appliance in a
space with a volume of at least
1m
3
per 8g refrigerant. The
volume of refrigerant is indicated
on the rating plate.
"Appliance", Fig.
1
/
Page10
The weight of the appliance ex works
may be up to 35kg depending on
the model.
1
Depending on the appliance specifications
2
Not in all countries
8
Installation and connection en
The subfloor must be sufficiently
stable to bear the weight of the appli-
ance.
This refrigerator is intended for use at
ambient temperatures of 10°C to
43°C.
The appliance is fully functional within
the permitted room temperature.
If the appliance is operated at colder
room temperatures, the appliance will
not be damaged up to a room tem-
perature of 5°C.
4.3 Installing the appliance
Install the appliance in accordance
with the enclosed installation in-
structions.
4.4 Preparing the appliance for
the first time
1.
Remove the informative material.
2.
Remove the protective foil and
transit bolts, e.g. remove the ad-
hesive strips and carton.
3.
Clean the appliance for the first
time.
Page14
4.5 Connecting the appliance
to the electricity supply
1.
Insert the mains plug of the appli-
ance's power cable in a socket
nearby.
The connection data of the appli-
ance can be found on the rating
plate.
"Appliance", Fig.
1
/
Page10
2.
Check the mains plug is inserted
properly.
The appliance is now ready for
use.
9
en Familiarising yourself with your appliance
Familiarising yourself with your appliance5 Familiarising yourself with your appliance
5.1 Appliance
You can find an overview of the parts of your appliance here.
3
1
2
4
5
1
Deviations between your appliance and the diagrams may differ with regard to their fea-
tures and size.
Control panel
Page11
Fruit and vegetable container
Page11
Rating plate
Page18
10
Features en
Screw foot
Door tray for large bottles
Page12
5.2 Control panel
You can use the control panel to configure all functions of your appliance and
to obtain information about the operating status.
1 2 3
2
Displays the set temperature for
the refrigerator compartment
in°C.
lights up when Super cooling
is switched on.
3sec. sets the temperature of
the refrigerator compartment.
Features6 Features
The features of your appliance de-
pend on the model.
6.1 Shelf
To vary the shelf as required, you
can remove the shelf and re-insert it
elsewhere.
"Removing the shelf", Page15
6.2 Fruit and vegetable con-
tainer
Store fresh fruit and vegetables in
their packaging in the fruit and veget-
able container.
Cover any chopped fruit and veget-
ables, or store in air-tight packaging.
Condensation may form in the fruit
and vegetable container depending
on the food and quantity stored.
Remove the condensation with a dry
cloth.
To ensure that the quality and aroma
are retained, store fruit and veget-
ables that are sensitive to cold out-
side of the appliance at temperatures
of approx. 8°C to 12°C, e.g. pine-
apple, bananas, citrus fruits, cucum-
bers, courgettes, peppers, tomatoes
and potatoes.
11
en Basic operation
6.3 Door tray
To adjust the door tray as required,
you can remove the door tray and re-
insert elsewhere.
"Removing door tray", Page15
Tip: If moving it when it is fully
loaded, lift the door tray slightly.
6.4 Accessories
Use original accessories. These have
been made especially for your appli-
ance.
The accessories for your appliance
depend on the model.
Egg tray
Store eggs safely on the egg tray.
Basic operation7 Basic operation
7.1 Switching on the appliance
1.
Electrically connect the appliance.
Page9
The appliance begins to cool.
2.
Set the required temperature.
Page12
7.2 Operating tips
Once you have switched on the
appliance, the set temperature is
only reached after several hours.
Do not put any food in the appli-
ance until the set temperature has
been reached.
When closing the door, make sure
that the door is not blocked by
stored items.
When you close the door, a va-
cuum may be created. The door is
then difficult to open again. Wait a
moment until the vacuum is offset.
The temperature in the appliance
varies due to the following condi-
tions:
– How often the appliance is
opened
– Load capacity
– Temperature of newly stored
food
– Ambient temperature
– Direct sunlight
7.3 Switching off the appliance
Disconnect the appliance from the
power supply. Unplug the appli-
ance from the mains or switch off
the circuit breaker in the fuse box.
7.4 Setting the temperature
Setting the refrigerator compart-
ment temperature
Press 3sec. repeatedly until the
temperature display shows the re-
quired temperature setting.
The recommended temperature in
the refrigerator compartment is
4°C.
""OK" sticker", Page13
Additional functions8 Additional functions
Find out which additional functions
can be used for your appliance.
8.1 Super cooling
With Super cooling, the refrigerator
compartment cools as cold as pos-
sible.
Switch on Super cooling before pla-
cing large quantities of food in the re-
frigerator compartment.
Note: When Super cooling is
switched on, increased noise may
occur.
Switching on Super cooling
Press 3sec. repeatedly until
lights up.
12
Refrigerator compartment en
Note: After approx. 6hours, the ap-
pliance switches to normal operation.
Switching off Super cooling
Press 3sec..
Refrigerator compartment9 Refrigerator compart-
ment
You can keep meat, sausage, fish,
dairy products, eggs, prepared meals
and pastries in the refrigerator com-
partment.
The temperature can be set from
2°C to 8°C.
The refrigerator compartment can
also be used to store highly perish-
able foods in the short to medium
term. The lower the selected temper-
ature, the longer the food remains
fresh.
9.1 Tips for storing food in the
refrigerator compartment
Only store food when fresh and
undamaged.
Store food covered or in air-tight
packaging.
To avoid impeding the circulation
of air and to prevent food from
freezing, do not place food so that
it has direct contact with the back
wall.
Allow hot food and drinks to cool
down first before placing in the ap-
pliance.
Observe the best-before date or
use-by date specified by the manu-
facturer.
9.2 Chill zones in the refriger-
ator compartment
The air circulation in the refrigerator
compartment creates different chill
zones.
Coldest zone
The coldest zone is between the
shelf above the vegetable container
and the shelf above that.
Tip: Store highly perishable food
such as fish, sausages and meat in
the coldest zone.
Warmest zone
The warmest zone is at the very top
of the door.
Tip: Store food that does not spoil
easily in the warmest zone, e.g. hard
cheese and butter. Cheese can then
continue to release its aroma and the
butter will still be easy to spread.
9.3 "OK" sticker
The "OK" sticker lets you check
whether the refrigerator compartment
reaches the safe temperature ranges
of +4°C or colder recommended for
food.
The "OK" sticker is not included with
all models.
If the sticker does not indicate "OK",
gradually reduce the temperature.
"Setting the refrigerator compart-
ment temperature", Page12
Once the appliance is switched on, it
may take up to 12hours until the set
temperature is reached.
Correct setting
Defrosting10 Defrosting
10.1 Defrosting in the refriger-
ator compartment
When the appliance is operating,
condensation droplets or frost form
on the rear panel of the refrigerator
13
en Cleaning and servicing
compartment due to functional reas-
ons. The back panel in the refriger-
ator compartment defrosts automatic-
ally.
Condensation runs through the con-
densation channel into the drainage
hole to the evaporation pan and does
not have to be wiped away.
To ensure that the condensation can
drain and odours do not form, ob-
serve the following information:
Cleaning the condensation channel
and drainage hole
Page15
.
Cleaning and servicing11 Cleaning and servi-
cing
To keep your appliance working effi-
ciently for a long time, it is important
to clean and maintain it carefully.
Customer Service must clean inac-
cessible points. Cleaning by cus-
tomer service can give rise to costs.
11.1 Preparing the appliance
for cleaning
1.
Disconnect the appliance from the
power supply.
Unplug the appliance from the
mains or switch off the circuit
breaker in the fuse box.
2.
Take out all of the food and store it
in a cool place.
Place ice packs (if available) onto
the food.
3.
Remove all fittings and accessor-
ies from the appliance.
Page15
11.2 Cleaning the appliance
WARNING
Risk of electric shock!
An ingress of moisture can cause an
electric shock.
Do not use steam- or high-pres-
sure cleaners to clean the appli-
ance.
Liquid in the lighting or in the con-
trols can be dangerous.
The rinsing water must not drip
into the lighting or controls.
ATTENTION
Unsuitable cleaning products may
damage the surfaces of the appli-
ance.
Do not use hard scouring pads or
cleaning sponges.
Do not use harsh or abrasive de-
tergents.
Do not use cleaning products with
a high alcohol content.
Do not use stainless-steel cleaning
agents on the outside of the appli-
ance.
If liquid gets into the drainage hole,
the evaporation pan may overflow.
The rinsing water must not get into
the drainage hole.
Sharp or pointed objects damage the
door tray rail.
Never clean the door tray rail with
sharp or pointed objects, e.g. a
knife.
If you clean fittings and accessories
in the dishwasher, this may cause
them to become deformed or discol-
our.
Never clean fittings and accessory
in the dishwasher.
1.
Prepare the appliance for cleaning.
Page14
2.
Clean the appliance, the fittings,
the accessories and the door seals
with a dish cloth, lukewarm water
14
Cleaning and servicing en
and a little pH-neutral washing-up
liquid.
3.
Dry thoroughly with a soft, dry
cloth.
4.
Insert the fittings.
5.
Electrically connect the appliance.
Page9
6.
Putting the food into the appliance.
11.3 Cleaning the condensa-
tion channel and drainage
hole
Regularly clean the condensation
channel and drainage hole to ensure
that the condensation can drain.
Carefully clean the condensation
channel and the drainage hole,
e.g. using a cotton bud.
11.4 Removing the fittings
If you want to clean the fittings thor-
oughly, remove these from your ap-
pliance.
Removing the shelf
Pull out and remove the shelf.
Removing door tray
Lift the door tray and remove it.
Removing the fruit and vegetable
container
1.
Pull out the fruit and vegetable
container as far as it will go.
2.
Lift the fruit and vegetable con-
tainer at the front and remove it
.
15
en Troubleshooting
Troubleshooting12 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshoot-
ing information before contacting after-sales service. This will avoid unneces-
sary costs.
WARNING
Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist
staff.
Only use genuine spare parts when repairing the appliance.
If the power cord of this appliance is damaged, it must be replaced by the
manufacturer, the manufacturer's Customer Service or a similarly qualified
person in order to prevent any risk.
Fault Cause and troubleshooting
The LED lighting does
not work.
Different causes are possible.
Call customer service.
The customer service number can be found in the
enclosed customer service directory.
The refrigeration unit
is switching on more
frequently and for
longer.
The appliance has been opened frequently.
Do not open appliance door unnecessarily.
The exterior ventilation grilles are blocked.
Remove any obstructions from in front of the exterior
ventilation grilles.
Not a fault. Modern refrigeration machines switch on
more frequently and have different power levels to cool
more efficiently.
Remove any obstructions from in front of the exterior
ventilation grilles.
Install the appliance as far away as possible from
heating elements, cookers and other heat sources.
Avoid prolonged exposure of the appliance to direct
sunlight.
Only open the appliance door as briefly as neces-
sary.
Allow hot food and drinks to cool down first before
storing in the appliance.
16
Storage and disposal en
Fault Cause and troubleshooting
The temperature dif-
fers greatly from the
setting.
Different causes are possible.
1.
Switch off the appliance.
Page12
2.
Switch the appliance back on after fiveminutes.
Page12
If the temperature is too warm, check the temper-
ature again after a couple of hours.
If the temperature is too cold, check the temperat-
ure again on the following day.
The base of the refri-
gerator compartment
is wet.
The condensation channel or drainage hole are
blocked.
Clean the condensation channel and the drainage
hole.
Page15
The appliance hums,
bubbles, buzzes,
gargles or clicks.
Not a fault. A motor is running, e.g. refrigerating unit,
fan. Refrigerant flows through the pipes. The motor,
switches or solenoid valves are switching on or off.
No action required.
The appliance makes
noises.
Fittings wobble or stick.
Check the removable fittings and, if required, re-
place these.
Bottles or containers are touching.
Move the bottles or containers away from each
other.
Storage and disposal13 Storage and disposal
13.1 Taking the appliance out
of operation
1.
Disconnect the appliance from the
power supply.
Unplug the appliance from the
mains or switch off the circuit
breaker in the fuse box.
2.
Remove all of the food.
3.
Clean the appliance.
Page14
4.
To guarantee the ventilation inside
the appliance, leave the appliance
open.
13.2 Disposing of old appli-
ance
Valuable raw materials can be re-
used by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the
appliance, thereby putting their lives
at risk.
Leave shelves and containers in-
side the appliance to prevent chil-
dren from climbing in.
Keep children away from the re-
dundant appliance.
17
en Customer Service
WARNING
Risk of fire!
If the tubes are damaged, flammable
refrigerant and harmful gases may
escape and ignite.
Do not damage the tubes of the re-
frigerant circuit or the insulation.
1.
Unplug the appliance from the
mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an en-
vironmentally friendly manner.
Information about current disposal
methods are available from your
specialist dealer or local authority.
This appliance is labelled
in accordance with
European Directive
2012/19/EU concerning
used electrical and elec-
tronic appliances (waste
electrical and electronic
equipment - WEEE).
The guideline determines
the framework for the re-
turn and recycling of
used appliances as ap-
plicable throughout the
EU.
Customer Service14 Customer Service
Function-relevant genuine spare parts
according to the corresponding Eco-
design Order can be obtained from
Customer Service for a period of at
least 10 years from the date on
which your appliance was placed on
the market within the European Eco-
nomic Area.
Note: Under the terms of the manu-
facturer's warranty applicable to the
location, the use of Customer Service
is free of charge. The minimum dura-
tion of the warranty (manufacturer's
warranty for private consumers) in
the European Economic Area is 2
years according to the terms of war-
ranty applicable to the location. The
terms of warranty do not affect other
rights or claims held by yourself un-
der local legislation.
Detailed information about the war-
ranty period and the warranty condi-
tions in your country is available via
the QR code on the enclosed docu-
ment on service contacts and war-
ranty conditions, from our customer
service or on our website.
If you contact Customer Service, you
will require the product number (E-
Nr.) and the production number (FD)
of your appliance.
You can find the contact details for
our customer service via the QR
code on the enclosed document on
service contacts and warranty condi-
tions or on our website.
14.1 Product number (E-Nr.)
and production number
(FD)
You can find the product number (E-
Nr.) and the production number (FD)
on the appliance's rating plate.
"Appliance", Fig.
1
/ Page10
Make a note of your appliance's de-
tails and the Customer Service tele-
phone number to find them again
quickly.
Technical data15 Technical data
Refrigerant, cubic capacity and fur-
ther technical specifications can be
found on the rating plate.
"Appliance", Fig.
1
/ Page10
You can find more information about
your model online at
https://
18
Technical data en
eprel.ec.europa.eu/
1
. This web ad-
dress is linked to the official EU
EPREL product database. Please
then follow the instructions on
searching for the model. The model
identifier is made up of the charac-
ters before the slash in the product
number (E-Nr.) on the rating plate. Al-
ternatively, you can also find the
model identifier in the first line of the
EU energy label.
1
Only applies to countries in the European Economic Area
19
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service
directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
*9001845870*
9001845870 (050523)
en
