VonHaus 2514086 1850W Large Black Stove Heater

Instruction manual - Transcript

• Page 1: 1850W 61CM BLACK STOVE HEATER 2514086 Instruction Manual 01 0418
• Page 2 - English - : CONTENTS Safety Instructions 1 Safety Instructions Safety Symbols 2 Specification 3 Information Requirements for Electric Local Space Heatr 4 Foot Assembly Controls 5 Operation Bulb Replacement Cleaning amp Care 6 Troubleshooting 7 Specification 8 Warranty 9
• Page 3 - English - : WARNING PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE INTENDED USE This 1850W 61cm Black Stove Heater designed for light domestic use only It is not intended for heavy duty commercial or industrial use and is not suitable for use outdoors WARNING Do not use this appliance to dry clothes This appliance cannot be used by children or persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they have not been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved Children shall not play with the appliance Cleaning and user maintenance shall not be made by children without supervision WARNING This product is not suitable to be used on long pile carpets Use this appliance only as described in this manual Any other use is not recommended by the manufacturer and may cause fire electric shock or injury PRIOR TO USE Remove the packaging and make sure that the appliance is intact If in doubt do not use the appliance and contact DOMU Brands Customer Services Do not leave packaging materials such as bags and staples within reach of children Dispose of packaging carefully and with consideration for the environment It is recommended that you retain the appliance box for seasonal storage For your convenience record the date you received the appliance on the Warranty page of these instructions and attach your proof of purchase Retain this information in the event that a warranty service is required SAFETY INFORMATION When using any electricallypowered appliance basic safety precautions should always be followed to reduce the risk of fire electrical shock or injury to persons or property CABLES AND PLUGS Check to ensure your electricity supply matches that shown on the rating label of the appliance The appliance must only be used as rated Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been dropped or damaged in any manner Take to a qualified electrical person for service and repair Do not connect the appliance to the mains voltage until completely assembled and adjusted Unroll the cord before operating Operating with a coiled cord may cause overheating and risk of fire The use of an extension cord with this appliance is not recommended Do not allow the cord to come into contact with the appliance surface during operation Do not run the cord under carpeting mats or rugs etc Arrange the cord away from traffic areas so that it will not be tripped over Do not twist kink or wrap the cord around the appliance as this may cause the insulation to weaken and split Always unplug the appliance when not in use Do not leave unattended Always switch off the appliance before unplugging from the power socket Always hold the plug when removing it from the wall do not pull the cord CAUTION In order to avoid a hazard due to inadvertent resetting of the thermal cutout this appliance must not be supplied through an external switching device such as a timer or connected to
• Page 4 - English - : WARNING PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE a circuit that is regularly switched on and off RISK OF PERSONAL INJURY Use this appliance only as described in this manual Do not use this appliance with any type of external timer Always operate upright on a flat surface only This appliance heats up when in use To avoid burns do not touch the front of the appliance or any of the grilles or vents WARNING DO NOT COVER Do not cover in any manner as the appliance may overheat and become a fire risk Keep all objects at least 1 metre from the front side and rear of the appliance Do not operate the appliance with wet hands Do not immerse in liquid or use the appliance near water as this could create an electrical shock hazard If the appliance accidentally comes into contact with water switch off the power supply and do not touch the appliance Never attempt to remove the cover of the appliance Repairs requiring opening the appliance or access to internal parts must be carried out by a qualified electrician or repair service professional There are no userserviceable parts of this appliance excluding the plug fuse Before moving the appliance switch it off by unplugging it from the wall and allowing it to cool POSITIONING YOUR HEATER This appliance is designed to be placed on a hard level surface When positioning please keep the following points in mind Do not locate in areas of high foot traffic To avoid accidents always ensure that the power cord and appliance are in full view Do not fit the appliance in confined spaces such as cupboards or wardrobes Do not operate the appliance in areas where gasoline paint or other flammable liquids are used or stored Do not operate the appliance in bathrooms laundry areas or similar moist indoor locations Do not use in the immediate surroundings of a bath shower or swimming pool The appliance must not be located immediately below or in front of a socket outlet The socket must always be accessible in order to disconnect the appliance from the electrical supply for maintenance Store the Heater carefully in a dustfree area during the off season It is ideal to store the Heater in the box in which it was supplied Neatly wind the cord of the Heater to prevent damage Please ensure you understand their meanings before operating this product in order to prevent personal injury and avoid damage to the appliance WARNING Pay attention to all safety and guidance Read manual before use WARNING Do not cover SAFETY SYMBOLS
• Page 5: SPECIFICATION 220240V 50Hz V VOLTAGE 1850 G9 W MAX POWER BULB TYPE 1 Door 2 Fire Display 3 Control Panel
• Page 6 - English - : Item Symbol Value Unit Item Unit Heat Output Type of heat input for Electrical Storage Heaters only select one Nominal Heat Output Minimum Heat Output indicative Maximum Continious Heat Output Manual heat charge control with integrated thermostat Manual heat charge control with room andor outdoor temperature feedback Electronic heat charge control with room andor outdoor temperature feedback NA NA NA NA 0012 fan Motor 0012 fan Motor 00 no no no yes no no no no no no no no Auxiliary electricity consumption Fan assisted heat output At nominal heat output At minimum heat output In standy mode Model Type of heat outputroom temperature control select one Single stage heat output and no room temperature control Two or more manual stages no room temperature control With mechanical thermostat room temperature control With electronic room temperature control Electronic room temperature control plus day timer Electronic room temperature control plus week timer Other control options multiple selections possible room temperature control with prescence detection room temperature control with open window detection with distance control option with adaptive start control with working time limitation with black bulb sensor Contact Details P nom P min P max EL max EL min EL SB kW kW kW kW kW kW INFORMATION REQUIREMENTS FOR ELECTRIC LOCAL SPACE HEATER DOMU Brands Ltd 4th amp 5th Floor The Tower Deva City Office Park Salford M3 7BF
• Page 7 - English - : FOOT ASSEMBLY Take the Heater and turn it upside down ensure to lift the Heater carefully do not tip Take the 4 legs and align over the holes in the base of the Heater Screw in each screw and ensure the feet are secured turn the Heater upright onto its legs NOTE Screwdriver not supplied Thermostat Dial Turn the dial till you hear a click this will be the current room temperature Turn the dial past and when the room has reached its desired temperature turn the dial back until it clicks the heater will now maintain this heat Flame Effect Switch Switch on to activate the flame effect Dimmer Dial Press this to active low heating Press this along with the other Switch to active high heating Fan Switch Use alone for cool air CONTROLS
• Page 8 - English - : OPERATION CLEANING amp CARE BULB REPLACEMENT The bulbs fitted to this Heater are 220240V 50Hz 25W G9 halogen bulbs Due to the indeterminate life span and ease of replacement the light bulbs are specifically excluded from the guarantee Unplug from the mains supply and allow to completely cool Open the door and locate the two screws unscrew both and keep safe Pull the Log Bed from both ends to lift up the Log Bed decoration The two bulbs are located underneath Remove the defective bulb by pulling it out of the holder Replace with a new bulb CAUTION Take care not to touch the bulb with bare hands and ensure that the bulb is pushed in correctly To reassemble follow the above instructions in reverse order CAUTION Always disconnect the Heater from the electricity supply and allow it to cool before undertaking maintenance or replacing the bulb CAUTION Switch off the Heater and disconnect the plug from the power socket Wait for the Heater to cool completely before cleaning To remove dust on external surfaces wipe the Heater with a damp not wet lintfree cloth rinsed in hot soapy water only CAUTION Do not use any harsh detergent or abrasive cleaners WARNING Do not spray with any liquids or submerge in liquid or water WARNING Do not attempt to clean the inside of the Heater Do not attempt to open the Heater casing at any time There are no userserviceable parts Insert the plug into mains socket TO ACTIVATE THE HEATING FUNCTION Turn the Thermostat Dial to maximum by turning clockwise and switch on the Fan Switch For Low Heat Activate 1 Heat Switch For High Heat Activate the second Heat Switch 1850W combined Turn down the Thermostat Control Knob to the desired temperature by turning anticlockwise To activate the flame effect turn on the Flame Effect Switch Control the intensity of the flame effect by turning the Dimmer Dial clockwise to intensify and anticlockwise to reduce the effect Close the door once you have finished adjusting the settings CAUTION Do not knock the Stove Heater over when in use as this could cause damage to the filiments of the bulbs
• Page 9 - English - : TROUBLESHOOTING PROBLEM SOLUTION Possibly a bulb failure Remove the faulty bulb as detailed in the Bulb Replacement section NO LIGHT FROM THE FLAME EFFECT LIGHT BUT NO HEAT Check that the Heat Switches are set to on position Ensure the Heater is switched on and connected to mains power Activate the Power Selector Switches and Heat Switches Check the fuse by replacement Check that the Heater is plugged in and switched on at the mains outlet Make sure that the Heater has not gone into overheat protection mode The Vents may require need cleaning Discontinue use and contact DOMU Brands Customer Services THE HEATER WILL NOT POWER ON THE HEATER IS NOT HEATING UP THE HEATER BECOMES DAMAGED
• Page 11 - English - : DISPOSAL INFORMATION COPYRIGHT WARRANTY CUSTOMER SERVICE Please recycle where facilities exist Check with your local authority for recycling advice All material in this instruction manual are copyrighted by DOMU Brands Any unauthorised use may violate worldwide copyright trademark and other laws To register your product and find out if you qualify for a free extended warranty please go to wwwVonhauscomwarranty Please retain a proof of purchase receipt or statement as proof of the purchase date The warranty only applies if the product is used solely in the manner indicated in the Warnings page of this manual and all other instructions have been followed accurately Any abuse of the product or the manner in which it is used will invalidate the warranty Returned goods will not be accepted unless re packaged in its original packaging and accompanied by a relevant and completed returns form This does not affect your statutory rights No rights are given under this warranty to a person acquiring the appliance secondhand or for commercial or communal use If you are having difficulty using this product and require support please contact hellodomucouk
• Page 12 - English - : VonHaus is a registered trademark of DOMU Brands Ltd Made in China for DOMU Brands Ltd M24 2RW Thank you for purchasing the 1850W 61cm Black Stove Heater
