USER’S MANUAL
TIPS:
Your suggestions and comments for Costway are really important to us!
We sincerely solicit you to go back to our shop and leave a good rating in just a
simple click.It would be quite encouraging if you could kindly do so like below:
Great product so far. Fast delivery, easy setup, and working without any issues.
Great products so far
With your inspiring rating, Costway will be more consistent to offer you
EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE!
UNITED STATES
JAPAN
RUSSIA
AUSTRALIA
US office:Fontana
UK office:Ipswich
EP23936
FRANCE
GERMANY
UNITED KINGDOM
CANADA
ITALY
SPAIN
February 24, 2018
Fully Automatic Washing Machine
L/16L M/23L H/30L
Dimensions
W429mm D433mm H747mm
Rated voltage and frequency
Model
Water level/water
volume（about）
Inlet pressure
120V~ 60Hz
0.03MPa~0.85MPa
Specifications
17
EP23936
Rated input power
Wash：240W spin：210W
10LBS (dry laundries weight)
Rated capacity of
wash and spin
1
2
4
5
6
7
8
9
10
12
13
14
16
17
Before using
Parts name............................
Cautions...............................
Installation and adjustment.....
How to use drainpipe..............
Water inlet installation............
Operation
Preparation before operation..
Load laundries......................
Use of detergent...................
Control panel instruction........
Operation steps....................
Maintenance........................
Troubleshooting...................
Other functions.....................
Specifications......................
Contents
Display
Explanation
Settlement
16
Other functions
1
1. Give an alarm
(1) If do not press START/PAUSE in 10 minutes after pressing POWER, power supply will be cut
off automatically.
(2) Washing finished, power supply will be cut off automatically.
vibration testing system will supervise the running. Once vibration is beyond certain
3. Power supply is cut off automatically
violent vibration. This machine has imbalance adjustment function, and the
During spinning, if the laundries are not placed equally in the tub, it would cause
2. Imbalance adjustment
level, the adjustment system will start automatically to adjust the imbalance.
Parts name
Accessories
Symbol definition
Warning symbols
Pay special attention to the warning symbols. There may be
serous risks to personal body safety or damages to the washing
machine if not follow.
Please stop doing the contents with this symbol, otherwise
it will damage the appliance or injure your personal body.
Tapping screw
ST4X14 (8pcs)
Bottom cover
(1pc)
Water inlet hose (1pc)
water inlet hose connector (1pc)
Forbidden symbols
The end connecting to
the appliance
The end connecting to
water inlet hose connector
Feed valve
Power cord
Fixing foot (3pcs)
Back cover
Handle
Top lid
Top frame
Lint filter
Control panel
Inner tub
Pulsator
Body
Base
Adjustable foot
water level+wash+spin light flash
water level+spin+underwear light flash
water level+spin light flash
water level light flash
water level+wash light flash
After draining 5 minutes,
it still does not reach to
water level
Open top lid, according to before
troubleshooting and settlement to
settle it, then close the top lid and
clear up the alarm.
The top lid is open when
spinning
Spin does not balance
Open the top lid, make the laundries
place equally, then close it and clear
up the alarm
After inlet 50 minutes still
not reach to setting water
level
Open top lid, according to before
troubleshooting and settlement to settle
it. Then close the tip lid and clear up the
alarm
Water level sensor is
wrong
Cut the power supply and call the
technicians
Close the top lid and clear up the alarm
Drain the water until the water level reach
the highest water level.
The water level is more than
overflowing water level.
water level+underwear light flash
After the washing machine is connected to power supply, press the “power” button. If the upper
cover is opened in the initial state or during operation, the barrel will automatically open and the
barrel light will automatically shut down for 5 minutes.
4. Barrel lamp function
15
Insert the plug tightly
Check the socket or change to another socket
Press power switch
Check power supply
Install the inlet hose again
Tighten the connector of the machine
Restart when water supply is resumed
Open the tap
Clean the filter according to before“clean inlet gate”
The machine is adjusting automatically
Close the top lid
Close the top lid
Normal
Normal
Notes: If there is still a fault after the above checks, please pull out the plug and
contact the seller right away. It is dangerous to repair this product by yourself.
Straighten or clean the drainpipe
Settlement
2
Cautions
Do not install the washing machine in bathroom or damp
places. Do not wash the machine with water, do not put
wet clothes on the control panel film.
。
Do not use water hotter than 122 F.
If the machine is situated on a carpeted floor, please adjust
the feet in order to allow air to circulate freely.
Do not wash raincoat, bike cover, feather dress and such
waterproof laundries, which will make the washing machine
abnormal vibrations during spinning.
Do not share the same socket with other electric appliances.
Do not use the damaged plug or loose socket.
Please insert the plug into the power socket with rated voltage
120V A/C.
Always unplug the appliance and turn off the water when
the power is cut, moving or cleaning theor it is not in use,
washing machine. Do not insert or pull off the plug with wet hand.
Do not make the electric cable bended, stretched, twisted, strapped or changed,
pressed or nipped. If the electric cable or plug is damaged or the socket becomes
loose, they must be repaired or changed by our appointed repair stations or the
professionals of our post-sale service department to avoid danger. The pin of the
plug must remain clean. Please clean it carefully with dry cloth if it is dirty.
Ventilation holes
at the bottom
Soft item
Earth
wire
The height of the drainpipe should be less than 3.9ft
14
Troubleshooting
It does not drain
It does not inlet
Spin stops and begins to inlet
during spin program
Press the program button to
select SPIN, but it does not spin
The spin is intermittent when spin
starts
First time to use, some water flows
from the drain hose
No water supply
Tap is not open
Inlet hose gets blocked
Laundries is too much or too little or the
Machine is not place stably
Before contacting the technicians, please make the following checks:
Control panel has no any display
Plug is not inserted tightly
No electricity in the socket
Power switch is not turned on
Power supply is cut off
Inlet hose leaks
Inlet hose connector (connecting with the tap) is not fixed tightly
Inlet hose and washing machine connector is loose
Drainpipe is bended or get blocked
The remaining water when the factory make test
Do not close the top lid when drain is finished
Open up the top lid when start drain
Balance the laundries to reach to the best spin effect
Phenomena
Possible reason
3
Any objects such as coins, safety pins, nails,
screws, stones or any other hard, sharp material
can cause extensive damage and must not be
placed into to the machine.
Before washing, please ensure the tap is open
and the inlet hose is installed properly.
It is suggested to use low foam washing powder.
Do not put hands into the working machine.
It is dangerous even if the speed is very slow.
Take special care of the children, and forbid
them to climb on the washing machine.
It is dangerous to alter the specifications or
attempt to modify this product in any way.
Do not overload the appliance or put any hot
goods (such as the kettle with hot water) on the
washing machine.
Garments which have been in contact with
volatile petroleum products should not be
machine washed.
Keep the appliance away from direct
sunlight and heat sources like the heater.
To prevent the lint from blocking cascade outlet
during washing, please keep the lint filter in good
condition, install it to proper position and clean it
in time.
Cautions
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
汽油
汽油
酒精
苯
Close
Open
Water outlet of drainpipe is higer than 3.9ft
Press it and pull out the lint filter
The baffleplate
(the black rubber block)
Close
Open
Close
Open
Maintenance
13
1.Once you have using the machine, you are advised to turn off the water taps. (if necessary,
pull out the inlet hose)
2. Do not keep water in tub for a long time. When washing is finished, drain it right away.
3. Once you have finished using the machine, you are advised to unplug it.
4. Put the electric cable and the drain hose in order.
5. Wipe the water on the surface and in tub with soft cloth and keep the top lid opening for a
while. It helps to prevent mould and stagnant smells forming inside the appliance.
The machine stops automatically, and music
buzzer will remind you to take out the laundries
or start again.
Once you have finished using the machine,
you are advised to unplug it and turn off the
water taps to avoid unexpected leak or fire.
After the end of the programme
Clean the exterior cabinet of the appliance with
soft cloth. Do not use cleanser, volatile chemical
materials to clean the machine, which will
damage plastic parts and the surface.
External cleaning
Clean inlet gate
It is possible that the inlet filter net can be blocked
by the dust, please clean it according to the follow
steps:
1. Close the tap and turn on the power switch.
2. Start the washing machine for 5 seconds(make
the water in the inlet hose flows to the tub), and
cut off the powersupply.
3. Pull off the inlet hose, remove and clean the
inlet valve and the inlet net, and install again.
Maintenance methods
If the water in the inner tub has possibility to freeze, please do like below:
1. In winter, if remaining water freeze can cause the washing machine trouble,
please take off the water inlet hose and drain out the water in the hose and inner tub.
2. If the water freeze, please don't operate the washing machine. Put 104℉ hot water
in the tub, the hot water should submerge the pulsator, after a few minutes, rotate
the pulsator by hand gently, then you can operate the washing machine.
4
Illustration1 Illustration2
It is necessary to use lint filter during washing.
After washing, please clean the lint filter in time.
Clean the lint filter
Clean the lint filter according to the
following steps:
1. Pull out the lint filter. (see Illustration 1)
2. Open the lint filter and wash it. (see
Illustration 2)
3. Close the lint filter and install it to
proper position.
Loosen
Fasten
Adjustable
nut
Adjustable
foot
High Low
Please install and adjust the machine according to the requirements of the manual.
Open the top lid of washing machine and take out all of the accessories.
You are advised to keep all the packaging for reuse in case the machine is to be
The distance between the washing machine and the wall should be more than 50mm, and the
. The slanting or rough ground
may cause operating stopped or unstable, please adjust it with the following methods:
1
It is very important to your safety and correct operation.
Unpacking
Unpack the carton and take out the bottom panel.
Remove all wrappers, including the polystyrene base.
transported again.
Installing the bottom cover
Positioning
。
maximum allowed angle of the shank base of the machine is 1
Make it horizontal
Use a tied thread with plumb to check
if it is horizontal.
Adjust the adjustable foot
1、Lift up the adjustable foot gently, loose the adjustable nut
and twist the adjustable foot.
2、Fasten the nut after adjustment.
Installation and
adjustment
As the right photo, put down the machine from side,
put down the machine on some soft thing, please let
the remarkable face outside, the arrow direction is
machine front side.
Align the screw hole between bottom and bottom
cover, use the appendix screw to fasten the bottom
cover.
Bottom panel
Soft item
Base
Side
Front
Back
Side
2. Press “program”button to begin selection.program
12
Operation steps
1. Press power switch, put through power, the machine is in state of beginning:
3. Select appropriate water level according to your laundries quantity.
5
4. Close the top lid, press Start/Pause, the washing machine is working.
5. When the washing is finished, buzzer alarm, power supply cut off automatically.
How to use drainpipe
height is not more than 4ft to avoid leakage or stop,
Less than 4ft
1. The drainpipe must be hanged during use, the
To control the washing machine is
in working state or waiting state.
After select process and
water level, press this button to start.
Press this button to pause during
working, press again will rework.
11
6
Water inlet installation
1. Swing the inlet hose gently to confirm if it is
fastened.
2. After installation, open the tap and check if
it leaks.
3. Do not bend the inlet hose with overstrain.
4. Before each usage, check the connection
between inlet hose connector and the tap.
Make sure they are firmly fitted to prevent
dropping from improper installation position.
Inlet valve connector
Inlet hose nut
Water absorption cushion
Connect the inlet hose with the washing machine
Check the connection between inlet
hose connector and the tap
1. Do not take off the water absorption cushion. Please
check if the cushion is dropped or damaged before
each usage. If it is, contact the seller immediately.
2. Put the inlet hose nut on the inlet valve connector.
3. Fasten the inlet hose nut and swing it gently to make
sure if it is suitable.
START
POWER
PAUSE
0.4in
0
.
4i
n
PROGRAM
WATER
LEVEL
[Normal] Commonly used procedures in the main routine
general washing clothes. [Standard] The standard procedure,
required by the general washing dirty clothes often changed.
[Fast] Fast is not too dirty for washing clothes, washing shorter
time. [Underwear] For personal clothing washing underwear,
clothing to be gentle when wasing. [Wash] The program run only
wash washing process. [Spin] The program run only dehyration
process.
Automatically add water: during SOAK, WASH and RINSE
process, if the washing machine check the water level is
lower than setting water level, the washing machine will
pause and add water to setting water level automatically.
During wash (including rinse), if need to add water, press
WATER LEVEL button to add water, un-press will stop adding.
Or PAUSE the washing machine and press WATER LEVEL to
select higher water level, then press START/PAUSE button,
the washing machine will add the water to setting level
automatically and continue working. If your resetting water level
is lower than present water level, the lower water level will valid
in next water inlet.
At the beginning of start, press WATER LEVEL to select water
level, you can select appropriate water level. According to your
laundries quantity. 'L' is low water level, 'M' is middle water level,
'H' is high water level.
10
Control panel instruction
7
Preparation before
operation
Before washing the laundries, please pay attention to the followings:
Make sure if there is
special requirements
for the laundries
Before washing, empty
all pockets of small
objects which may
have been left inside
(coins, keys, screws etc.)
As these could damage
the drain pump.
Knot the long band,
fasten the buttons
and close the zippers.
Do not overload the
machine. Load the
laundry loosely
alternating large
items with small ones.
Sort the laundry
according to the type
of fabric, color-fastness
and how dirty it is. Put
thin laundries, woolens
and such prone to wear
and tear laundries into
washing bag.
A. Make sure the laundries are washable.
B. It is essential to wash new colored items separately when washing for the first time. White items
should not be washed with colored items.
C. Please immerge the non-absorbable laundries by hand.
D. Some stains such as fruit, wine, grass, rust etc. are difficult to remove and should be treated
before washing with specific products, which can be found in most household shops. In some
cases it may help to soak the stain before washing with a special pre-soak product or biological
detergent.
E. Overturn the nap fabric and long floss laundries before putting them into the machine.
F. Do not put the laundries polluted by chemicals into the machine directly.
G. Very small item (handkerchiefs, ribbons, socks etc) should be washed in a washing bag or a pillow case.
on: indicate the selected mode
flashing: indicate the program is running
Mode and meaning of the indicator light
H
M
L
Wash
Light
Flash
Spin
Fast
Normal
Standard
Underwear
Preparation before washing
1. Connect the inlet hose and open the tap.
2. This appliance must be earthed. Confirm
the socket is earthed reliably and insert the
power plug. The earth terminal should not
link to gas pipeline, tap pipeline etc.
3. Put up the drainpipe.
Warning: the temperature of the water should less than 122 ！ F
。
9
Load laundries
The capacity of washing and spinning of the machine refer
to the largest weight of the standard laundries under dry
condition. Washing quantity shall be lower than the rated
capacity.
Different thickness, size and type of the laundries will
influence the actual washing capacity. It is suitable that
the laundries can be turned round normally during washing.
Don t select high water level when laundries are less than '
2.2LBS to avoid water splashing.
8
Use of detergent
For the quantity of the concentrated washing powder, please refer to its manual。
Remarks: avoid splashing of water and waste of washing powder, water level should not be too
high if laundries are too small.
How to use the washing powder
Dissolve in the machine directly
1. Low water level.
2. Add the washing powder, and run for 30 seconds to dissolve it completely.
3. Put laundries in, select suitable water level.
The instant dissolving of the washing powder
1. Prepare warm water of 86 in a container.
2. Pour the powder while stirring to fully dissolve it.
The washing powder is more prone to pollute the laundries than the detergent,
therefore, please use it with proper quantity.
Washing powder with poor quality or not used for a long period may get blocked,
please clean the detergent box in time.
℉
How to use bleach
Fill water to the selected level, dilute the bleach in the container,
and pour it slowly into the washing tub.
Do not use bleach for colored or figured laundries as they are prone
to lose colors.
Do not put bleach to laundries directly.
Refer to the manual for the usage and quantity of the bleach.
Please dissolve powder bleach before use.
Blending coat
(about 1.76LBS)
Working suit (up, down)
(cotton, about 2.46LBS)
Blanket
(cotton, about 1.98LBS)
Pajamas
(cotton, about
0.44LBS)
shirt
(cotton about
0.66LBS)
undershirt
(cotton about 0.4LBS)
underpants
(cotton about 0.15LBS)
socking
(blending, about 0.11LBS)
Single bed sheet
(cotton, about 1.32LBS)
Jacket
(cotton about
1.76LBS)
Jeans(about 1.76LBS)
Reference weight of the laundries
Put the detergent powder into the
tub as the right figure.
Then close the wash lid.
We suggest use low sudsing
detergent powder
