Model No.: HD986-B7
Item No.: U630201 / U630202
海宫 145x210mm 8P(16K*2张) 单色 2023-8-9 12:46:12
When using heater, basic precautions should always be followed to reduce the risk of fire,
electric shock, injury to persons, and hyperthermia, including the following:
1) Read all instructions before using this heater.
2) This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If
provided, use handles when moving this heater. Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front of the
heater and keep them away from the sides and rear.
3) Extreme caution is necessary when any heater is used by or near children or invalids and
whenever the heater is left operating and unattended.
4) Always unplug heater when not in use.
5) Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has
been dropped or damaged in any manner. Discard heater, or return to authorized service
facility for examination and/or repair.
6) Do not use outdoors.
7) This heater is not intended for use in bathrooms, laundry areas and similar indoor locations.
Never locate heater where it may fall into a bathtub or other water container.
8) Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic area
and where it will not be tripped over.
9) To disconnect heater, turn controls to off, then remove plug from outlet.
10) Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
11) To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on
soft surfaces, like a bed, where openings may become blocked.
12) A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline,
paint, or flammable liquids are used or stored.
13) Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to persons.
14) Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord
or relocatable power tap (outlet/power strip).
15) SAVE THESE INSTRUCTIONS
16) Hyperthermia can result in death. Symptoms of hyperthermia include high body tempera-
ture, headache, nausea, vomiting, tiredness, dizziness, fainting, and rapid pulse. If you begin to
experience symptoms related to hyperthermia, turn off the heater and seek medical attention.
17) To avoid excessive room temperatures which can cause hyperthermia: DO NOT leave
product running unattended in a confined space around infants, or individuals with reduced
physical, sensory, or mental capabilities.
77 F
77 F
77 F
2
10
59
3.Touch and hold on the temperature key for 5 seconds, and the Fahrenheit mode (point + F)
is converted to Celsius mode (point + c). When the machine is in Celsius mode, touch and
hold on to the temperature key for 5 seconds to switch back to Fahrenheit mode.
4. In Celsius mode, the default control temperature is 25℃ and the setting range is
15℃-35℃.
INCREASE / DECREASE:
1.When there is no timing setting or temperature setting, the two corresponding lights are
low light and there is no response by touching this key.
2.When making the timing setting or temperature setting, the two keys are active and
become highlighted.
3.Before setting the control temperature, you must touch the temperature key first.
T
IP
-
OVER
FUNCTION:
1. When the angle between the machine tilting and the horizontal position is less than 40±5
degrees, the display window flashes and prompts "Eo", and all outputs are closed.
2.When the angle between the machine and the horizontal position is more
tha
n 50 ±5 degrees, the working state before tilting will be restarted.
ANTI-FROST FUNCTION:
1.ln the standby state, the mid-range heating is automatically turned on when the NTC
temperature is lower than 41
°
F ( 5 °C ), and when the NTC temperature is higher than 45
°
F
( TC ), the heating is stopped and returned to the standby state.
2.When the frost protection function is turned on, the ON/STANDBY key becomes
highlighted and flashes at a frequency of 2 seconds per time, and the display window
flashes "45
°
F (or TC)" at a frequency of 2 seconds per time.
SUPPLEMEN EXPLANION:
1.lf the display window is flashing prompt "EH" or "EL", it needs to be repaired by a power
outage.
CLEANING AND MAINTENANCE
1. Avoid bruised or scratched heater, so as not to damage the suace coating and rust.
2. Aer a so clean cloth is placed in the box collection when unused for long periods, with
the heater.
Thank you for purchasing this product! If you have any questions about
the product, such as missing pas, damaged products, product
assembling, and operation, please contact us via Amazon Message or
customer service number: 213-4467172 or 661-4358826.
IMPORTANT
Please call our customer service department r any consulting:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
DED PROOF OF PURCHASE IS REQUIRED FOR WARRANTY
SERVICE.
AVIS
uillez appeler le seice a la clientele pour toutes questions au:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
PREUVE D'ACHAT ORIGINALE REQUISE POUR SERVICE DE
GARANTIE.
IMPORNTE
S61o hay que llamar nuestro departamento de servicio
al cliente en caso de tener preguntas o inquietudes:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
SE REQUIERE PRUEBA DE COMPRA CON FECHA PARA
SERVICIO BAJO GARANT[A.
Address: ROWAN ELECTRIC APPLIANCE LLC
28407 Ascent Way, Santa Clarita, CA 91350
Phone: 213-4467172 or 661-4358826
