VAX Pace
Cordless Vacuum
CLSV-VPKS CLSV-VPKA CLSV-VPKD
User Guide
2
Safety information
This machine is intended for household use only, not for commercial or industrial use.
Please keep instructions for future use and only as instructed in this guide.
Don’ts
• Don’t leave the charger plugged in when unattended.
• Don’t use the machine if it is faulty or has been dropped, damaged or left outdoors.
• Don’t use the machine to pick up any flammable or combustible materials (lighter
fluid, petrol, kerosene etc.) or use the machine in an area with explosive vapours
or liquid.
• Don’t use the machine to pick up hot coals, cigarette butts, matches or smoking hot
burning items or use in an area where there may be harmful fluids (chlorine, bleach
and ammonia drain cleaner).
• Don’t handle the charger, battery or use the machine with wet hands.
• Don’t unplug the charger by pulling on the power cord. The power cord cannot be
replaced. If the cord is damaged the charger should be scrapped.
• Don’t attempt to remove blockages with sharp objects as this may cause damage to
the machine.
• Don’t use the machine with the incorrect battery or charger as this may result in
damage or injury to the user. The correct battery charger information is listed on
the battery pack ratings label.
• Don’t charge the battery outdoors, or leave the charger connected to the mains
when not in use.
• Don’t use the machine with a damaged battery. If the battery is damaged contact us
on: 08000 927737.
• Don’t use on a surface that is damaged, uneven or incorrectly fitted.
• The brushbar in the powered floorhead constantly rotates when activated.
Never use on one spot for any prolonged period of time as this may damage the
floor surface.
Do’s
• Always check suitability with the manufacturer of your flooring prior to using the
machine.
• Only VAX ONEPWR batteries (BVXXXXX) and chargers (BV05XXX) should be used
with this machine.
• Always stand the charger on a stable, level surface, uncovered and away from any
heat source.
• Always protect the charger power cord from heated surfaces and open flames.
• Only VAX ONEPWR recommended tools and accessories should be used with
this machine.
• Always remove the battery from the machine before carrying out any maintenance
or if storing unused for a long period of time.
3
• Keep all openings clear, free from debris and don’t overfill the dirt container as this
may affect the airflow/suction.
• Turn off all controls on the machine before disconnecting or connecting the battery.
• Only use the machine indoors on dry surfaces and keep the area you’re cleaning
well lit.
• This appliance can be used by children from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
• Keep fingers, hair and loose clothing away from moving parts and openings whilst
using the machine.
• Store the machine in a cool, dry area. Keep the machine away from rain and moisture.
• Use only CE/UKCA approved 13amp extension cords, non-approved extension
cords may overheat. Care should be taken to arrange the extension cord as it can
be a trip hazard.
• Take extra care when using the machine on the stairs.
• Always test on an inconspicuous area of the flooring first.
• Always make sure the separator and filter are fitted correctly before using your
machine and only use the machine with the filter and separator in place.
• Always check the powered floorhead and accessories are free from damage, dirt
and debris before using.
• This machine doesn’t stay upright without constant support. Between uses, lie flat
on the floor in a suitable location so that it doesn’t become a trip hazard or can be
stepped on.
Battery Safety Precautions
• Replace the battery with a VAX ONEPWR battery only. Use of another battery may
present a risk of fire or explosion.
• Do not attempt to disassemble the battery, remove any component projecting from
the battery terminals and do not dispose of in a fire. The battery and charger have
no user serviceable parts. Fire or injury may result.
• Prior to disposal, protect exposed terminals with heavy insulating tape to prevent
shorting. The battery is to be disposed of safely at your local battery recycling centre.
• When the battery pack is not in use, keep it away from other metal objects that can
make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
• In case of battery leakages, avoid any contact with skin and contact us on:
08000 927737.
4
Bought your product directly from vax.co.uk?
Relax - your extended guarantee will be automatically emailed to you.
Contact us if you haven’t received this and we’ll be happy to help.
Bought elsewhere? Registering is
quick and easy.
Scan this QR code or visit vax.co.uk/registration
Register your product to activate your free 2 year extended guarantee
Please see the back cover of this User Guide for more detail.
Welcome to the Vax family!
You're now the proud owner of a VAX ONEPWR Pace.
Here you’ll find everything you need to know about your machine and, most importantly,
instructions on how to get started so that you can get cleaning!
Introduction
Safety information
Introduction
Machine overview
Quick start
Getting started
Using your machine
Cleaning and maintenance
Troubleshooting
Guarantee and technical
Contents
2 - 3
4
5
6
7 - 8
9 - 11
12 - 16
17
18
5
7
8
9
10
1
Carry handle
2
Filter (hidden)
3
Dirt container release button
4
Dirt container
5
Dirt release button (hidden)
6
Handheld crevice tool (hidden)
7
Power ON/OFF
8
Brushbar ON/OFF
9
Boost ON/OFF
10
Battery level indicator light
11
Reach wand
12
Reach wand crevice tool (hidden)
13
Powered floorhead
14
Brushbar
15
Battery dock
16
ONEPWR battery
17
ONEPWR slide charger
18
2-in-1 tool
19
Mini motorised pet tool*
20
Wall mount, screws and wall plugs
15
Weight 2.6kg (without battery pack). Dirt bin capacity 0.6L.
Runtime and charge time dependent on battery pack and mode used.
*Mini motorised pet tool included with model CLSV-VPKA only.
Subject to technical change without notice. Images are illustrative only.
1
3
4
2
5
6
13
11
14
16 17
19
*
18
Machine overview
SCAN HERE TO GET TO
KNOW YOUR MACHINE
visit www.vax.co.uk
for help and support with
setting up your machine
12
20
6
Safety information
Assembly
Attach the
handheld to
the wand and
then attach
the floorhead.
They will click
into place
when fitted.
Operation
Switch on the machine
and select a mode.
BRUSHBAR
Switch ON for
carpets and OFF
for hard floors.
BOOST
Increases
suction.
Charging the battery
SCAN HERE TO WATCH OUR HOW-TO VIDEOS
or visit support.vax.co.uk for help and support
with using your machine
Quick start
21
3 4
Press the battery
symbol to check
the battery status.
Fully charge the
battery before
first use.
6
Attaching the battery
Slide the battery into the machine
until it clicks into place.
7
Safety information
Registration and support
7
Quick Start
Getting started
Attaching the wall mount
Without the handheld attached to the
reach wand and powered floorhead,
push the wall mount onto the top and
back of the reach wand.
Choose a location for the machine to be
stored. Stand the powered floorhead
and wand against the wall, ensuring the
powered floorhead is flat on the floor.
Holding the wall mount securely against
the wall, make a small mark for each
screw. Secure the wall mount to the
wall using the wall plugs and screws.
The 2-in-1 tool can be fitted onto the
wall mount.
Fully assemble the machine and firmly
press the machine into the wall mount
to secure. Always ensure the machine is
securely locked into place.
Assembly
Attach the handheld to the reach wand
until it clicks into place. Attach the reach
wand to the powered floorhead until it
clicks into place.
SCAN HERE TO WATCH
OUR HOW-TO VIDEOS
visit www.vax.co.uk
for help and support with
setting up your machine
8
Getting started
Charging the battery
Plug the charger into the mains.
When fully charged, press and hold the
side buttons and slide the charger off
the battery to remove.
Slide the battery on to the charger.
Charging light indicators
ERROR
Charge/battery fault.
CHARGING DELAY
Battery pack is too hot or too cold.
The battery lights will flash white to
indicate the battery is charging. The
battery lights will illuminate in turn until
all four lights are illuminated and the
battery is charged. When fully charged
the lights will go out.
To check the battery charge
level press the battery symbol.
THIS MACHINE IS ONLY TO BE USED WITH VAX ONEPWR BATTERIES AND CHARGER.
PLEASE READ THE SAFETY GUIDE BEFORE USE.
NOTE: Before first use, ensure the battery is fully charged. Failure to fully charge the battery
before first use may result in poor battery performance. The life expectancy of the battery will vary
depending on the usage of the machine.
SCAN HERE TO WATCH
OUR HOW-TO VIDEOS
visit www.vax.co.uk
for help and support with
setting up your machine
9
Safety information
Operation
Place your foot on the powered floorhead.
Pull the handle backwards to recline.
To remove the battery press both the
buttons to release.
Slide the battery into the machine until it
clicks into place.
WARNING: The brushbar in the powered floorhead constantly rotates when activated. Never use
the powered floorhead on one spot for an extended period of time as the brushbar may damage
the surface. Always turn the brushbar off when cleaning hard floors. To prevent any damage being
sustained, test on an inconspicuous area of the flooring/surface first.
Press the brushbar on/off button to
switch the brushbar in the powered
floorhead on.
Press the boost button to increase the
suction for particularly dirty areas.
Press the on/off button to switch the
machine on.
NOTE: The powered floorhead brushbar should be ON for carpets and OFF for hard floors.
Constant use of the boost mode and brushbar will reduce the battery runtime.
Using your machine
10
Safety information
Operation
CAUTION: If the brushbar in the powered floorhead has been obstructed, the brushbar motor
protection sensor may activate, the brushbar will stop and the machine may switch off. To reset
remove the powered floorhead from the reach wand/handheld and clear any obstruction. Wait 1
minute before refitting the powered floorhead tool, switch the machine on and press the brushbar
ON/OFF button.
When less than 20% charge is remaining
the low battery indicator will flash red
indicating the battery is running low and
charging is required.
During use, press the battery symbol
on the battery. The lights will illuminate
indicating how much charge is
remaining.
All of the accessories, including the powered floorhead can be
attached directly onto the handheld or the reach wand.
Press the button on the tools or powered floorhead to remove.
Using the tools
Using your machine
SCAN HERE TO WATCH
OUR HOW-TO VIDEOS
visit www.vax.co.uk
for help and support with
setting up your machine
11
Safety information
2-in-1 dusting brush and crevice tool
1. Soft bristled dusting brush for delicate surfaces and skirting boards.
2a. For edge cleaning press the button and push the dusting brush down.
2b. For tight and hard to reach areas press the button and pull the dusting brush up to remove it.
Handheld and reach wand crevice tool
For hard to reach areas and can be used at different heights for above floor cleaning.
1
2a
2b
Using the tools
Using your machine
Mini motorised pet tool*
While in use, the mini motorised base
plate can be rotated so it can be used flat
or horizontally for all angle cleaning.
*Mini motorised pet tool included with model CLSV-VPKA only.
Press the brushbar ON/OFF button
to switch the mini motorised pet
tool brushbar ON/OFF. For delicate
surfaces turn the brushbar OFF.
12
Safety informationCleaning and maintenance
Removing and refitting the dirt container
Emptying the dirt container
WARNING: Always remove the battery before carrying out any maintenance or troubleshooting.
CAUTION: Don’t over fill the dirt container to avoid blocking the air flow through the machine.
For best cleaning results, empty the dirt container after every use.
Press the dirt container release
button and pull the dirt container
handle to remove.
To refit the dirt bin, slot the tab on the machine into the indent on the base of the dirt
container and push back until it clicks onto place.
Hold the dirt container over a bin and
press the dirt release button to allow dirt
and debris to fall out.
To close, push the dirt release door until
it clicks into place.
Press the dirt container release
button and pull the dirt container
handle to remove.
13
Safety informationCleaning and maintenance
Cleaning the filter and separator
Push the tab on the lid of the dirt container and lift the cover to access the filter.
Refit the separator making sure that the
tab on the separator fits into the groove
on the dirt container.
Lift the filter and separator from the
dirt container.
Tap the separator over a bin to remove
dirt and debris and wipe over the metal
shroud with a dry cloth.
Pull the tab on the filter to remove from
the separator.
Tap the filter against the bin to remove
any dirt and debris.
Wash the filter under running water
(40°C max). Leave for at least 24hrs or
until fully dry before replacing.
24hr
40°C
MAX
IMPORTANT: Filters should be tapped over a bin every 4-6 uses to remove dirt and debris and
washed every 3 months. Filters should be replaced every 6-9 months depending on the level of use.
SCAN HERE TO WATCH
OUR HOW-TO VIDEOS
visit www.vax.co.uk
for help and support with
setting up your machine
14
Safety information
Removing and cleaning the brushbar
Pull the brushbar out from the
brushbar housing.
To remove any threads or hair, slide the
blade of a pair of scissors into the groove
on the brushbar and cut along the groove.
Clear any dirt/debris from the end
caps and inside the housing of the
powered floorhead.
Using a coin, push and turn the brushbar lock anticlockwise to release the brushbar.Press the powered floorhead release
button to remove the powered floorhead
from the wand.
Refit the brushbar into the powered
floorhead. Align the arrow on the
brushbar cover so it points north, firmly
push and twist clockwise to lock.
NOTE: If the brushbar has been obstructed, the brushbar motor protection sensor may activate. The
brushbar will stop and the machine may switch off. To reset remove the tool from the reach wand/
handheld and clear any obstruction. Wait 1 min before refitting. Once refitted switch the machine on
and select a floor selector button to reactivate the brushbar.
Cleaning and maintenance
15
Safety information
Pull the brushbar out from the
brushbar housing.
Using a coin, turn the brushbar lock
anticlockwise to release the brushbar.
To remove any threads or hair slide
the blade of a pair of scissors into the
groove on the brushbar and cut along
the groove. Clear any dirt/debris inside
the housing of the floorhead.
CAUTION: If the brushbar in the mini motorised pet tool has been obstructed, the brushbar motor
protection sensor may activate. The brushbar will stop and the machine may switch off. To reset
remove the tool from the reach wand/handheld and clear any obstruction. Wait 1 minute before
refitting the tool, switch the machine on and press the brushbar ON/OFF button.
Check the inlet for any blockages and use
a blunt object to remove the blockage.
Refit the brushbar and turn the brushbar lock clockwise to lock.
Cleaning and maintenance
Removing and cleaning the mini motorised pet tool brushbar
SCAN HERE TO WATCH
OUR HOW-TO VIDEOS
visit www.vax.co.uk
for help and support with
setting up your machine
16
Safety information
Checking for blockages
Remove the dirt container and reach
wand. Check and clear any dirt and
debris from the dirt container and
handheld inlet.
Press the dirt container release button
and remove the dirt container. Check
and clear any dirt and debris from
behind the dirt container flap.
Check the powered floorhead for any
blockages and use a blunt object to
remove the blockage.
To test for a blockage in the reach wand,
drop a small ball of paper into the wand.
The paper will drop through if the wand
is clear. Use a broom handle or similar
blunt object to remove any blockage.
Cleaning and maintenance
SCAN HERE TO WATCH
OUR HOW-TO VIDEOS
visit www.vax.co.uk
for help and support with
setting up your machine
17
Troubleshooting
There is an accessory missing
• Check the contents on the box to make sure the part is definitely included with your machine.
Why does the machine have no power?
• The battery is not fitted correctly. See Operation page 9.
• The battery has no charge. See Charging the battery page 8.
• The motor thermostat may have tripped. Empty the dirt container and check for blockages. Clean the filters and allow the
machine to cool for approximately 1 hour. If you have washed the filters, wait 24 hours to fully dry before placing back on
the machine. See Cleaning the filter and separator page 13.
• The brushbar motor sensor in the powered floorhead or mini motorised pet tool has been activated. To reset remove the
powered floorhead/tool from the reach wand/handheld and clear any obstruction. Wait 1 minute before refitting the powered
floorhead, switch the machine on and press the brushbar ON/OFF button to reactivate the brushbar. See Operation page 10.
Why won’t the machine pick up?
• The dirt container may not be fitted correctly. See Removing and refitting the dirt container page 12.
• The dirt container may be full or blocked. Check the dirt container and handheld inlet for blockages.
See Emptying the dirt container page 12 and Checking for blockages page 16.
• The filters may be clogged or need replacing. See Cleaning the filter and separator page 13.
• There may be a blockage. See Checking for blockages page 16.
• The brushbar on the powered floorhead has not been activated. See Operation page 9.
• The powered floorhead may be blocked. See Removing and cleaning the brushbar page 14.
• The machine, powered floorhead and reach wand may not be correctly fitted. See Assembly page 7.
Why is there a red light?
• Battery charge is running low (<20%). See Charging the battery page 8.
Why won’t the brushbar in the powered floorhead or pet tool turn?
• The brushbar in the powered floorhead or mini motorised pet tool has not been activated. See Operation page 9.
• The tool/brushbar may be obstructed. See Removing and cleaning the brushbar page 14 and Removing and cleaning the mini
motorised pet tool brushbar page 15.
• The machine, powered floorhead, reach wand and mini motorised pet tool may not be correctly fitted. See Assembly page 7.
WARNING: Always switch off and unplug the machine before performing any checks or maintenance.
Guarantee and technical
Technical
Statement of Compliance: Manufacturer/EU importer: Vax Limited, hereby on
our own responsibility, declare that the VAX ONEPWR Pace is manufactured in
compliance with the following Legislation:
Safety: 2014/35/EU Low Voltage Directives/Electrical Equipment (Safety)
Regulations 2016. EMC: 2014/30/EU Electromagnetic Compatibility Directive/
Electromagnetic Compatibility Regulations 2016.
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice.
VAX is a trade mark of Techtronic Cordless GP.
© 2023 Techtronic Cordless GP. All rights reserved.
Vax Ltd, Artillery House, Heritage Way, Droitwich, WR9 8YB, UK.
Guarantee
If a Vax machine is used in the way it is intended and it breaks down within the
guarantee period, it’s our responsibility to repair or replace it.
Here’s what isn’t covered:
• Normal wear and tear of consumable items, for example: belts, filters,
brushbars, fuses etc.
• Batteries which have become faulty as a result of improper handling.
• Batteries which have a reduced service life as a result of normal wear.
• Accidental damage
- Damage as a result of use not in accordance with the product user guide.
- Damage caused by not carrying out regular maintenance.
- Damage to the charger cable.
- Blockages caused by misuse.
• Faults caused by:
- Negligent use, misuse, neglect or careless operation of the machine.
- Use of the machine cleaner which is not in accordance with the user guide.
- Use of a Vax machine for anything other than normal domestic household
purposes in the country in which it was purchased.
- Use of parts, accessories and consumables, which are not genuine VAX
components.
- Faulty installation or repairs – unless carried out by a qualified electrician or
engineer.
Making a claim?
If you wish to make a claim under your standard 1 year guarantee or extended
guarantee, please contact us on the details set out in our Vax Terms and Conditions.
19
V1.1
Your guarantee is with Vax Limited. Please note that your statutory rights in relation to any Vax products will remain unaffected by these guarantees.
*All Vax products bought in the UK come with a standard 1 year guarantee from the date of purchase. Most Vax products are eligible for a free extended
guarantee (“Extended Guarantee”) by registering with Vax. Registration within 3 months from date of purchase is required to claim the free Extended
Guarantee and is subject to our terms and conditions (www.vax.co.uk/registration/guarantee-information)
If you need help registering, please visit www.vax.co.uk/contact.
1
What you’ll need
Grab your machine and
proof of purchase and
keep them handy.
Register
To get started scan
the QR code, or visit
vax.co.uk/registration
2
3
Bought your product direct from vax.co.uk?
Sit back and relax - your free 2 year extended guarantee
was automatically applied at the checkout.
Check your email for details of your extended guarantee
*
.
Please contact us if you haven't received this and we'll be happy to help.
Bought elsewhere?
To claim your 2 year extended guarantee*,
registering is
quick and easy, just follow the steps below:
REGISTER YOUR PRODUCT TO ACTIVATE YOUR
FREE 2 YEAR
EXTENDED GUARANTEE
*
Congratulations!
You’ve now secured your free 2 year
extended guarantee! (Keep an eye out for
your confirmation email - you'll need to
keep this safe).
