Dryer
User Manual
C YD A81 WWGL UK
EN
2960314190_EN/020824.1605
Please read these instructions first
before using your appliance
Thank you for choosing an INDESIT appliance.
Please take some time to read this user manual
before using your appliance, to ensure you
know how to safely operate the controls and
functions.
Carefully follow all unpacking and installation
instructions to ensure the appliance is correctly
connected and fitted prior to use.
Please write your product model and serial
number on the last page of this user manual,
and store in a safe location close to the
appliance for easy future reference.
This user manual may also be applicable for
several other models. Differences between
models will be listed.
If you have any questions or concerns,
please call our contact centre or find help and
information online at www.indesit.com/register
Explanation of symbols used
throughout this User Manual
• Read the instructions.
B
DANGER!
• Warning against electric shock.
DANGER!
• Warning against fire hazard.
A
WARNING!
• Warning for hazardous situations with regard
to life and property.
WARNING!
• Warning against hot surfaces.
WARNING!
• Warning against scalding hazard.
C
NOTE
• Important information or useful hints about
usage.
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging wastes with
the domestic waste or other wastes, discard
them to the dedicated collection points
designated by the local authorities.
This product was manufactured using the latest technology in environmentally friendly conditions.
3
Dryer / User Manual
This symbol reminds you to
read this instruction manual.
Before using the appliance, read
these safety instructions. Keep them
nearby for future reference. These
instructions and the appliance itself
provide important safety warnings,
to be observed at all times. The
manufacturer declines any liability
for failure to observe these safety
instructions, for inappropriate use of
the appliance or incorrect setting of
controls.
AVery young children (0-3
years) should be kept away from the
appliance. Young children (3-8 years)
should be kept away from the
appliance unless continuously
supervised. Children from 8 years
old and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience
and knowledge can use this
appliance only if they are supervised
or have been given instructions
on safe use and understand the
hazards involved. Children must not
play with the appliance. Cleaning
and user maintenance must not
be carried out by children without
supervision.
AWARNING: Never stop a
tumble dryer before the end of the
drying cycle unless all items are
quickly removed and spread out so
that the heat is dissipated.
AItems that have been soiled
with substances such as cooking oil,
acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes
and wax removers and items
such as foam rubber (latex foam),
shower caps, waterproof textiles,
rubber-backed articles and clothes
or pillows fi tted with foam rubber
pads should not be dried in the
tumble dryer. Remove all objects
from pockets, such as lighters and
matches. Do not use the tumble
dryer if industrial chemicals have
been used to clean it.
AOil-soaked items should not
be dried in the tumble dryer due to
their high fl ammability.
ANever open the door forcibly
or use it as a step.
PERMITTED USE
CAUTION: The appliance is not
intended to be operated by means
of an external switching device,
such as a timer, or separate remote
controlled system.
AThis appliance is intended to
be used in household and similar
applications such as: staff kitchen
areas in shops, offices and other
working environments; farm houses;
by clients in hotels, motels, bed
& breakfast and other residential
environments.
4
Dryer / User Manual
AThis appliance is not for
professional use. Do not use the
appliance outdoors.
ADo not store explosive or fl
ammable substances (e.g. gasoline
or aerosol cans) inside or near the
appliance - risk of fire.
ADo not load the machine
above the maximum capacity
(kg of dry cloth) indicated in the
programme table.
ADo not dry unwashed items in
the tumble dryer.
ATake care that no lint or dust
has accumulated around the dryer.
AFabric softeners, or similar
products, should be used as specifi
ed by the fabric softener instructions
ADo not overdry the laundry.
INSTALLATION
AThe appliance must be
handled and installed by two or
more persons - risk of injury. Use
protective gloves to unpack and
install - risk of cuts.
AInstallation, including water
supply (if any), electrical connections
and repairs must be carried out by
a qualifi ed technician. Do not repair
or replace any part of the appliance
unless specifi cally stated in the user
manual. Keep children away from
the installation site. After unpacking
the appliance, make sure that it has
not been damaged during transport.
In the event of problems, contact
the dealer or your nearest After-sales
Service. Once installed, packaging
waste (plastic, styrofoam parts
etc.) must be stored out of reach
of children - risk of suffocation. The
appliance must be disconnected
from the power supply before any
installation operation - risk of electric
shock. During installation, make sure
the appliance does not damage the
power cable - risk of fi re or electric
shock. Only activate the appliance
when the installation has been
completed.
AInstall the dryer in rooms with
adequate ventilation (open door,
ventilation grid or slot larger than
500 cm2) in order to avoid the
backfl ow of gases into the room
from appliances burning other fuels,
including open fi res. If the dryer is
installed under a worktop, provide
a distance of 10 mm between
the upper panel of the dryer and
any objects above it, and 15 mm
between the sides of the appliance
and the walls or furniture units
adjacent to it.
5
Dryer / User Manual
AIf the dryer is installed near to
a gas or coal stove, provide a heat
insulating plate (85 cm x 57 cm)
in between, as the side facing the
stove is covered with aluminium foil.
AExhaust air must not be
discharged into a fl ue which is
used for discharging fumes from
appliances burning gas or other
fuels.
AThe appliance must not be
installed behind a lockable door, a
sliding door or a door with a hinge
on the opposite side to that of the
tumble dryer, in such a way that a
full opening of the tumble dryer door
is restricted.
AThe appliance shall be placed
against the wall to limit access to its
rear side.
ATake care not to use a carpet
which obstructs ventilation openings
in the base of the dryer.
AIf you want to stack the
dryer on a washing machine, first
contact our After-Sales Service or
your specialist dealer to verify the
complete list of suitable models.
The stacking is only possible
if the dryer is attached to the
washing machine by means of the
appropriate stacking kit available
through our After-Sales Service or
your specialist dealer. Instructions
for the correct assembly are
supplied with the stacking kit.
ELECTRICAL WARNINGS
AIt must be possible to
disconnect the appliance from the
power supply by unplugging it if
plug is accessible, or by a multi-pole
switch installed upstream of the
socket in accordance with the wiring
rules and the appliance must be
earthed in conformity with national
electrical safety standards.
ADo not use extension leads,
multiple sockets or adapters. The
electrical components must not
be accessible to the user after
installation. Do not use the appliance
when you are wet or barefoot. Do
not operate this appliance if it has
a damaged power cable or plug, if
it is not working properly, or if it has
been damaged or dropped.
AIf the supply cord is damaged,
it must be replaced with an identical
one by the manufacturer, its service
agent or similarly qualifi ed persons
in order to avoid a hazard - risk of
electric shock.
6
Dryer / User Manual
CLEANING AND MAINTENANCE
AWARNING: Ensure that the
appliance is switched off and
disconnected from the power supply
before performing any maintenance
operation. To avoid risk of personal
injury use protective gloves (risk of
laceration) and safety shoes (risk of
contusion); be sure to handle by two
persons (reduce load); never use
steam cleaning equipment (risk of
electric shock).
Non-professional repairs not
authorized by the manufacturer
could result in a risk to health and
safety, for which the manufacturer
cannot be held liable. Any defect
or damage caused from non-
professional repairs or maintenance
will not be covered by the
guarantee, the terms of which are
outlined in the document delivered
with the unit.
AMake sure that all lint traps
are cleaned before starting any
drying cycle.
DISPOSAL OF PACKAGING
MATERIALS
The packaging material is 100%
recyclable and is marked with the
recycle symbol.
The various parts of the packaging
must therefore be disposed of
responsibly and in full compliance
with local authority regulations
governing waste disposal.
DISPOSAL OF HOUSEHOLD
APPLIANCES
This appliance is manufactured with
recyclable or reusable materials.
Dispose of it in accordance with
local waste disposal regulations. For
further information on the treatment,
recovery and recycling of household
electrical appliances, contact your
local authority, the collection service
for household waste or the store
where you purchased the appliance.
This appliance is marked in
compliance with European Directive
2012/19/EU, Waste Electrical
and Electronic Equipment (WEEE)
and with the Waste Electrical and
Electronic Equipment regulations
2013 (as amended). By ensuring
this product is disposed of correctly,
you will help prevent negative
consequences for the environment
and human health.
The symbol on the product
or on the accompanying
documentation indicates
that it should not be
treated as domestic waste
but must be taken to an appropriate
collection center for the recycling of
electrical and electronic equipment.
7
Dryer / User Manual
Technical Specifications
* Min. height: Height with adjustable feet are
closed.
Max. height: Height with adjustable feet are
opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading
door.
• Technical specifications of the dryer are
subject to specification without notice to
improve the quality of the product.
• Figures in this manual are schematic and
may not match the product exactly.
• Values stated on markers on the dryer
or in the other published documentation
accompanying with the dryer are
obtained in laboratory in accordance with
the relevant standards. Depending on
operational and environmental conditions
of the dryer, these values may vary.
Standard conformity and test
information EU declaration of
conformity / UK declaration of
conformity
The development, manufacturing
and sales phases of this product is
conducted in conformity with the
safety rules specified in all related
.instructions of the European Union
The development, manufacturing
and sales phases of this product is
conducted in conformity with the
safety rules specified in all related
.instructions of the Great Britian
EN
Height (Min. / Max.) 85,6 cm / 86,6 cm*
Width 59,7 cm
Depth 58,4 cm
Capacity (max.) 8 kg**
Net weight (± %10) 32 kg
Voltage
See type label***Rated power input
Model code
Policies, standard
documentation,
ording of spare
parts and additional
product information
can be foundy by:
Visiting our vebsite
doscs.indesit.eu and
parts-selfservice.
europeanappliances.
com
Using QR Code
Alternatively,contact
our After-sales
Service (See phone
number in the
warranty booklet).
When contacting our
After-sales Service,
please state the codes
provided on your
product’s identification
plate.
xxxxxxxxxxxx
8
Dryer / User Manual
2 Your Dryer
7
1
2
3
4
5
6
1. Top panel
2. Control panel
3. Loading door
4. Adjustable legs
5. Type label
6. Lint filter
7. Power cord
2.1 Overview
2.2 Package Contents
1. Water
drain
hose *
6. Water
Filling
Container*
2. Filter
drawer
spare
sponge*
7. Pure
Water*
3. User
Manual
8.
Fragrance
Capsules
Group*
4. Drying
basket*
9. Brush*
5. Drying
basket
user
manual*
10. Filter
cloth*
*Optional - may not be included, depends on
model.
9
Dryer / User Manual
3 Installation
Before the calling the nearest Authorized
Service for the installation of the dryer, ensure
that electrical installation and water drain is
appropriate referring to the user’s manual.
If they are not suitable, contact a qualified
electrician and technician to make necessary
arrangements.
C
NOTE
• Preparation of location and electrical
installation for the product is under
customer’s responsibility.
B
DANGER!
• Installation and electrical connections
must be carried out by a qualified person.
A
WARNING!
• Prior to installation, visually check if the
product has any defects on it. If so, do
not have it installed. Damaged products
will cause risks for your safety.
3.1 Appropriate installation location
• Install the product in an environment
which has no risk of freezing and is in a
stable and level position.
• Operate your product in a well ventilated,
dust-free environment.
• Do not block the air ducts in front of and
under the product with materials such as
long pile rugs and wooden bands.
• Do not place your product on a long pile
rug or on similar surfaces.
• Do not install the product behind a door
with a lock, sliding door or a hinged door
which can strike the product.
• Once the product is installed, it should
stay at the same place where its
connections have been made. When
installing the product, make sure that the
rear wall of it does not touch anywhere
(tap, socket, etc.) and also pay attention
to install the product at a place where it
will stay permanently.
B
DANGER!
• Do not place the product on top of the
power cable.
• Keep at least 1.5 cm distance to walls or
other furniture.
• The rear surface of the tumble dryer shall
be placed against a wall
• This dryer is not able to be wall-mounted
as it would be too too heavy for the walls.
3.2 Ventilation hose and connection
(for products equipped with an outlet
vent)
Ventilation hose allows exhaust air from inside
the machine
Vented dryer has 1 air outlet.
Stainless sheet metal or aluminum pipes can
be used instead of a hose. The pipe diameter
should be minimum 10 cm.
Maximum hose and pipe lengths are given in
the table below.
Hose Pipe
Maximum length 4 m 5 m
1 elbow 45° -1.0 m -0.3 m
1 elbow 90° -1.8 m -0.6 m
1 elbow 90° short -2.7 m
1 wall passage -2.0 m -2.0 m
C
NOTE
• Each elbow and other passages should
be subtracted from the maximum length
stated above.
To connect a ventilation hose;
1. Connect the air outlet hose to the
hose spacer piece by turning it
counterclockwise.
2. Make the hose passages as shown
below.
10
Dryer / User Manual
C
NOTE
• Exhaust of humid air from the dryer into
the room should be considered. It may
damage the walls and furniture in the
room.
• The ventilation hose can be routed
outdoors via a window or it can be
connected to the air outlet in the
bathroom.
• Air outlet hose must be routed directly
to the outdoors. There must be a limited
number of elbows as not to hinder
ventilation.
• To prevent water accumulation in the
hose, make sure that it is not folded on
the floor.
B
DANGER!
• The ventilation hose should not be
connected to the chimney of a stove or a
fireplace.
• Do not operate your product at the same
time with heaters such as a coal or gas
stove. Airflow may cause the chimney to
flare up.
3.3 Adjusting feet
In order to ensure that your product operates
more silently and vibration-free, it must stand
level and balanced on its feet. Front feet of your
product can be adjusted. Balance the machine
by adjusting the feet.
1. Loosen the feet by hand.
2. Adjust the feet until the product stands level
and firmly on the floor.
C
NOTE
• Do not use any tools to loosen the
adjustable feet, otherwise, they can be
damaged.
• Never remove the adjustable feet from
their housings.
• You may consider using 2 plastic
pieces from an Authorized Service
with 2951620100 part number. These
parts prevent your machine from
slipping when the machine is located
on wet and slippery surfaces. You may
assemble mentioned parts to the front
adjustable feet by fitting and pressing
them to snap into ground of feet.
3.4 Transportation of the machine
1. Unplug the machine from the mains.
2. Remove the water drain (if any) and
chimney connections.
3. Drain water remaining in the machine
completely before transportation.
3.5 Changing the illumination lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.The lamp(s) used in this
appliance is not suitable for household room
illumination. The intended purpose of this
lamp is to assist the user to place laundry in
the tumble dryer in a comfortable way. The
lamps used in this appliance have to withstand
extreme physical conditions such as vibrations
and temperatures above 50 °C
11
Dryer / User Manual
4 Preparation
• For models with a condenser unit: clean
the condenser once in a month or after
every 30 operations regularly. .
• Clean the filter periodically.Read the
Maintenance and cleaning of filters for
detalied information.
• For models with flue unit: comply with the
flue connection instructions and clean the
flue.
• During the drying process, air the room
well where your tumble dryer is operating.
4.5 Correct load capacity
Follow the instructions
in the “Programme
selection and
consumption table”.
Do not load more than
the capacity values
stated in the table.
Following weights are given as examples.
Laundry
Approximate
weights (g)*
Laundry
Approximate
weights (g)*
Cotton
quilt covers
(double)
1500 Blouses 150
Cotton quilt
covers (single)
1000 Cotton shirts 300
Bed sheets
(double)
500 Shirts 250
Bed sheets
(single)
350
Cotton
dresses
500
Large
tablecloths
700 Dresses 350
Small
tablecloths
250 Jeans 700
Tea napkins 100
Handkerchiefs
(10 pieces)
100
Bath towels 700 T-Shirts 125
Hand towels 350
*Dry laundry weight before washing.
4.1 Laundry suitable for drying in the
dryer
Always obey the instructions given on the
garment tags. Dry only the laundry having a
label stating that they are suitable for drying in
a dryer.
4.2 Laundry not suitable for drying in
the dryer
Items with this symbol
Do not dry
with dryer
should not be
dried in the dryer.
C
NOTE
• Delicate embroidered fabrics, woollen,
silk garments, delicate and valuable
fabrics, airtight items and tulle curtains
are not suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other
after washing. Separate the laundry items
before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for energy
saving
• Spin your laundry at the highest speed
possible when washing them. Thus,
the drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type of
laundry together. For example thin kitchen
towels and tableclothes dries earlier than
thick bathroom towels.
• Follow the instructions in the user manual
for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.
• Do not add wet laundry while the dryer is
in operation
12
Dryer / User Manual
5 Operating the product
5.1 Control Panel
1. On/Off/Programme selection button
2. Start/Pause button
3. Time Delay button
4. Audio warning level button
On/O Start / Pause
Filter
cleaning
Tank
full
Child-proof
lock
Mute
Anti-
creasing
End Time Delay Iron Dry Cupboard
Dry
Drying
Filter
drawer /
Heat exchanger
cleaning
Low
Temperature
Buzzer
5.2 Symbols
5.3 Preparation of drying machine
• Plug the drying machine.
• Open the loading door.
• Place the laundry to the drying machine
without jamming them.
• Push and close the loading door.
A
WARNING!
Ensure that no laundry
is jammed to the
loading door.
Select the desired programme using the On/
Off/Programme selection knob, the machine
will turn on.
C
NOTE
• Selecting a programme using the On/Off/
Programme selection button does not
mean that the programme started. Press
the Start / Stand-by button to start the
programme.
1
2
3
4
13
Dryer / User Manual
5.4 Programme selection and consumption table
EN
Programmes Programme Description
Capacity (kg)
Spin speed in washing
machine (rpm)
Drying Time (minutes)
Cottons Iron Dry
You may dry your cotton laundry to be ironed in
this program to have them slightly damp for ease
of ironing. (Shirt, T-shirt, tablecloth, etc.)
8 1000 115
Cottons Eco
It dries single layer, casual cotton textiles in the
most economical way.
8 1000 155
Cottons Cupboard Dry
You may use this program for extra dryness in
thick laundry such as pants, tracksuit. You can
put your dry laundry that doesn’t require ironing
directly in the wardrobe.
8 1000 160
Cottons Extra Dry
You may dry your thick cotton laundry in this
program such as towels, bathrobe, etc.
8 1000 165
Iron Dry Synthetics
You may dry your synthetic laundry to be ironed
in this program to have them slightly damp for
ease of ironing. (Shirt, T-shirt, tablecloth, etc.)
4 800 40
Cupboard Dry Synthetics
You may dry all your synthetic laundry in this
program. (Shirt, T-shirt, underwear, tablecloth,
etc.) You can put your dry laundry that doesn’t
require ironing directly in the wardrobe.
4 800 50
Jeans
You may dry denim pants, skirts, shirts or jackets
in this program.
4 1200 90
Refresh
Ventilates for 10 minutes without blowing hot air.
You can ventilate the cotton and linen clothes
that have been enclosed for a long time with this
program to remove their odour. You can use this
program to ventilate and soften wool laundry that
can be washed in a washing machine. Do not
use for full drying.
- - 10
XPress 10’
XPress 30’
You may select from time programmes between
10 and 30 minutes to achieve the desired drying
level at low temperature. In this programme,
tumble drier’s operation lasts for the set time
independently from the dryness of laundry.
- - -
Sport
Use it to dry your clothes made of synthetics,
cotton or mixed fabrics or waterproof products
such as functional jacket, raincoat etc. Turn them
inside out prior to drying.
2 1000 50
Mixed
You can dry both cotton and synthetic laundry
with this programme.Sports and fitness clothes
may be dried with this program.
4 1000 85
Baby
It is a longer program that you can use for the
clothes (baby clothes, towels, underwear, etc.
cotton) you require hygeine. Hygiene is provided
with high temperature. It is especially suitable for
durable fabrics. (This program is identified and
approved by England’s “The British Foundation”
(Allergy UK).
5 800 170
14
Dryer / User Manual
* : Energy Label standard programme (EN 61121)
All the values on the chart are identified according to EN 61121 standard. Consumption values
may vary from the values in the chart depending on laundry type, wringing speed, ambient
conditions and voltage levels.
Delicates
It dries the shirts in a more sensitive manner, and
causes less creasing and easier ironing.
2 1200 28
Iron Dry Mini
You can use this program to dry your cotton
laundry that you have spun at high speeds in
your washing machine.
0,5 1200 35
Energy consumption values
Programmes Capacity (kg)
Spin speed in washing
machine (rpm)
Approximate amount of
remaining humidity
Energy consumption
value kWh
Cottons Eco* 8 1000 60% 4,84
Cottons Iron dry 8 1000 60% 3,75
Synthetics Cupboard Dry 4 800 40% 1,99
"Cottons Eco programme" used at full and partial load is the standard drying programme
to which the information in the label and the fiche relates, that this programme is suitable for
drying normal wet Cottons laundry and that it is the most efficient programme in terms of
energy consumption for Cottons.
15
Dryer / User Manual
5.5 Auxiliary functions
Audible warning
Drying machine makes an audible warning
when the programme is completed. If you don’t
want it to make an audible warning, press the
“Buzzer” button. When you press the Buzzer
button, a light will illuminate and no audible
warning will be made when the programme
ends.
C
NOTE
• You can select this function before or
after the programme starts.
Time Delay
If you wish to dry your clothes at a later time,
thanks to the time delay function, you can
delay the program start up to 3 hours, 6 hours
or 9 hours.
Open the loading door and put the laundry in.
Select the drying program. Press the time delay
button to set the desired delay time. When the
time delay button is pressed once, a 3-hour
delay is selected and the relevant indicator
lights up. When the same button is pressed
again, 6 hours; and if pressed once more, 9
hours delay will be selected.
If you press the time delay button again,
delayed start will be cancelled. After selecting
the delayed start, press the “Start/Pause”
button to start the delayed start for the selected
program.
C
NOTE
• Additional laundry may be loaded/taken
out during the delayed start time. At
the end of the time delay countdown,
the warning symbol disappears and the
drying process starts.
Changing the delay time
If you want to change the time during
countdown, turn the on/off/program selection
knob to cancel the program. Select the desired
program and repeat the delayed start process.
Cancelling the delayed start function
If you wish to cancel the delayed start
countdown and start the program right away,
rotate the on/off/program selection knob
to cancel the program. Select the desired
program and press “Start/Pause”.
5.6 Warning indicators
C
NOTE
• Warning indicators may vary depending
on the model of your dryer.
Filter cleaning
When the programme is completed, the
warning indicator for filter cleaning turns on.
Water tank
If the water tank fills up while the programme
continues, the warning indicator starts flashing
and the machine goes into stand-by. In this
case, empty the water tank and start the
programme by pressing the Start / Stand-
by button. Warning indicator turns off and
programme resumes.
Filter drawer /Heat exchanger cleaning
When the programme is finished, the cleaning
symbol of the heat exchanger or filter drawer
may light up.
5.7 Starting the programme
Press the Start/Stand-by button to start the
programme.
Drying indicator will light up, indicating that the
programme has started.
5.8 Child Lock
The drying machine has a child lock which
prevents the programme flow from being
interrupted when the buttons are pressed
during a programme. When the child lock
is activated, all buttons on the panel except
the On/Off/Programme selection knob are
deactivated.
Press the End Time and Buzzer buttons
simultaneously for 3 seconds to activate the
child lock
The child lock has to be deactivated to be able
to start a new programme after the current
programme is finished or to be able to interfere
with the programme. To deactivate the child
lock, keep the same buttons pressed for 3
seconds.
C
NOTE
• When the child lock is activated, the child
lock warning indicator on the screen
turns on.
• Child lock deactivates when the drying
machine is turned off and on by the On/
Off/Cancel knob.
16
Dryer / User Manual
When the child lock is active:
When the drying machine runs, or in stand-
by state, the indicator symbols won’t change
upon changing the position of the programme
selection knob.
C
NOTE
• When the drying machine runs and the
child lock is active, it beeps twice when
the programme selection knob is turned.
If the child lock is deactivated without
returning the programme selection knob
to its previous position, programme
will terminate due to the change in the
programme selection knob position.
5.9 Changing the programme after it
is started
You can change the programme you selected
to dry your laundry with a different programme
after the drying machine starts running
• For instance, select Extra Dry programme
by turning the On/Off/Programme
selection knob to select Extra Dry instead
of Iron Dry.
• Press the Start/Stand-by button to start
the programme.
Adding and removing clothes during
stand-by
If you want to add or remove clothes to/from
the drying machine after the drying programme
starts:
• Press the Start/Stand-by button to put
the drying machine in Stand-by state. The
drying operation stops.
• Open the loading door while in Stand-
by state, and close the door after you
remove or add laundry.
• Press the Start/Stand-by button to start
the programme.
C
NOTE
• Adding laundry after the drying operation
starts may cause the dried laundry inside the
machine to mix with wet laundry and leave
the laundry damp at the end of operation.
• Adding or removing laundry during drying
may be repeated as many times as you
wish. But this operation continuously
interrupts the drying operation, and thus
increases programme duration and energy
consumption. So, it is recommended to add
laundry before the programme starts.
• If a new programme is selected by turning
the programme selection knob while the
drying machine is in stand-by, the running
programme terminates.
WARNING!
• Do not touch the inner surface of the
drum while adding or removing clothes
during a continuing programme. The
drum surface is hot.
5.10 Cancelling the programme
If you want to cancel the programme and
terminate the drying operation for any reason after
the drying machine starts running, turn the On/Off/
Cancel knob, the programme will be cancelled.
A
WARNING!
• The inside of the drying machine shall
be extremely hot when you cancel the
programme during machine operation, so
run the refresh programme to allow it to cool
down.
5.11 End of programme
When the program ends, the Last/Anti-Wrinkle
and Fibre Filter Cleaning Warning LEDs on
the program follow up indicator will illuminate.
Loading door may be opened and the dryer
machine becomes ready for another run.
Bring the On/Off/Programme selection knob to
On/Off position to turn the drying machine off.
C
NOTE
• If the laundry is not removed after the
programme is completed, the wrinkle
prevention function activates for 2 hours
to prevent the laundry inside the machine
to get wrinkled. The programme tumbles
the laundry with 10-minute intervals to
prevent them from wrinkling.
17
Dryer / User Manual
6 Maintenance and cleaning
Lint filter
Lint and fibres released from the laundry to the
air during the drying cycle are collected in the
“Lint Filter”.
C
NOTE
• Such fibre and lint are generally formed
during wearing and washing.
• Always clean the filter after each drying
process.
• You can clean the filter and filter area by
vacuum cleaner.
Figure 1
Figure 2
To clean the filter:
1.Take out the cover.
2.a) If the product’s lint filter can be opened
as shown in Figure 1, remove the filter by
pulling it up and open the filter.
2.b) If the product’s lint filter is as shown in
Figure 2, remove the filter by pulling it up.
3. Clean lint, fibre, and cotton raveling on the
filter and in the filter housing by hand or
with a soft piece of cloth.
4. Close the filter and place it back into its
seat.
C
NOTE
• Clogging may arise on the filter surface
after using your machine for some time; if
this occurs, wash the filter with water and
dry it before using again.
Sensor (models with a sensor)
There are humidity sensors in your dryer that
detect whether the laundry is dry or not.
To clean the sensor:
1. Open the loading door of the dryer.
2. Allow the machine to cool down if drying
has been carried out.
3. Wipe the metal sensors with a soft cloth,
dampened with vinegar and dry them.
C
NOTE
• Clean metal sensors 4 times a year.
A
WARNING!
• Never use solvents, cleaning agents
or similar substances when cleaning
since these materials can cause fire and
explosion!
18
Dryer / User Manual
7 Troubleshooting
Drying operation takes too long.
Fibre filter pores might be clogged. >>> Wash the filter with warm
water.
Filter drawer might be clogged. >>> Clean the sponge and filter
cloth (if any) in the filter drawer. (for the products with a heat pump)
The condenser might be blocked. >>> Wash the condenser.(for
the products with a condenser )
The ventilation grills in front of the machine may be closed. >>>
Remove any objects in front of the ventilation grills that blocks air.
Ventilation may be inadequate because the area the machine is
installed in is too small. >>> Open the door or windows to prevent
the room temperature from rising very high.
A lime layer may have accumulated on the humidity or temperature
sensors. >>> Clean the humidity or temperature sensors.
Excessive amount of laundry might be loaded. >>> Do not load
the drying machine excessively.
Laundry might not have been wrung adequately. >>> Perform a
higher speed wringing on the washing machine.
Clothes come out damp after drying.
A program not suitable for the laundry type may have been
used.>>> Check the maintenance labels on the clothes and select
a program suitable for the clothes’ type or use time programs as
extra.
Fibre filter pores might be clogged. >>> Wash the filter with warm
water.
The condenser might be blocked. >>> Wash the condenser. (for
the products with a condenser)
Filter drawer might be clogged. >>> Clean the sponge and filter
cloth (if any) in the filter drawer.(For the products with a heat pump)
Excessive amount of laundry might be loaded. >>> Do not load
the drying machine excessively.
Laundry might not have been spun adequately. >>> Perform a
higher spin speed setting on the washing machine.
Drying machine does not turn on or program cannot be started.
Drying machine does not run after it is configured.
Power plug might be unplugged. >>> Make sure the power cord
is plugged in.
Loading door might be open. >>> Ensure that the loading door is
properly closed.
A program might not be set or Start/Stand-by button might not be
pressed. >>> Check that the program is set and it is not in Stand-
by position.
Child lock may be activated. >>> Turn off the child lock.
Program terminated prematurely for no reason.
Loading door might not be closed completely. >>> Ensure that the
loading door is properly closed.
There might be a power outage. >>> Press the Start/Stand-by
button to start the program.
Water tank may be full. >>> Empty the water tank.
Clothes have shrunk, hardened or spoiled.
A program not suitable with the laundry type might have been
used. >>> Check the maintenance labels on the clothes and
select a program suitable for the clothes.
The lighting inside the drying machine does not turn on. (For
models with a lamp)
Drying machine might not be turned on with the On/Off button or
program might not be selected for machines without an On/Off
button. >>> Make sure that the drying machine is turned on.
Lamp might be malfunctioning. >>> Contact Authorized Service to
replace the lamp.
Filter cleaning warning symbol/LED is on/flashing.
Fibre filter might not be cleaned. >>> Clean the filter.
The filter slot might be clogged with lints. >>> Clean the filter slot.
A layer of fluff might have accumulated clogging up the lint filter
pores. >>> Wash the filter with warm water.
The condenser might be blocked. >>> Wash the condenser.
Water drips from the loading door.
Fibres might have gathered on the inner sides of the loading door
and the loading door gasket. >>> Clean the inner surfaces of the
loading door and the loading door gasket surfaces.
Loading door opens by itself.
Loading door might not be closed completely. >>> Push the
loading door until the closing sound is heard.
Water tank warning symbol / led is on/flashing.
Water tank may be full. >>> Empty the water tank.
Water discharge hose might have collapsed. >>> If the product is
connected directly to the water drain check the water discharge
hose.
Steam symbol is flashing.(For the products with a steam function)
Steam tank may be empty => Fill the steam tank with distilled or
condensed water.
Steam programs do not start (For the products with a steam
function)
Steam tank may be empty, steam tank warning icon may light up
on the screen => Fill the steam tank until the steam icon goes off.
Wrinkles are not removed with wrinkle removing program. (For the
products with a steam function)
Excess amount of laundry may have been placed => Place
specified amount of laundry.
Steam application time may be selected in low level => Choose a
program with high amount of steam.
After completion of the program, the laundry may have stayed in
the machine for a long time => Take the laundry out as soon as the
program finishes, and hang it out.
Laundry odour not lessened with the odour removal program.(For
the products with an odour removal program)
Excess amount of laundry may have been placed => Place
specified amount of laundry.
Steam application time may be selected in low level => Choose a
program with high amount of steam.
A
WARNING!
• If the problem persists after following the
instructions in this section, contact your vendor
or an Authorized Service. Never try to repair your
product yourself.
C
NOTE
• In an event that you encounter an issue on
any part on your appliance, you can ask for a
replacement by contacting the authorized service
with the appliance model number.
• Operating the appliance with non-authentic parts
may lead the appliance to malfunction.
• Manufacturer and distributor are not liable for
malfunctions resulting from using non-authentic
parts.
19
Dryer / User Manual
8 Electrical Connection
Make sure that you have an earthed power
outlet socket rated at 13 amps (minimum).
8.1 Attention!
When installed, the socket must be reachable
after installation, or a separate switch (which
can disconnect the two poles) must be used
in the installation. Check for suitability.For a
permanent connection, a master switch with at
least 3mm contact clearance and minimum 13
A rating must be used.
8.2 Electrical requirements
Before you insert the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating label corresponds to your
electricity supply.
We recommend that this appliance be
connected to the mains supply via a suitable
switched and fused socket in a readily
accessible position. Should the mains lead
of the appliance become damaged or need
replacing at any time, it must be replaced by a
special purpose made mains lead which can
only be obtained from a Authorised Service
Agent.
A
WARNING!
This appliance must be earthed
If the fitted moulded plug is not suitable for
your socket, then the plug should be cut off
and an appropriate plug fitted.
The moulded plug on this appliance
incorporates a 13A fuse. Should the fuse need
to be replaced an ASTA approved BS1362
fuse of the same rating must be used. Do not
forget to refit the fuse cover. In the event of
losing the fuse cover, the plug must not be
used until a replacement fuse cover has been
fitted. Colour of the replacement fuse cover
must be the same colour as that visible on the
pin face of the plug. Fuse covers are available
from any good electrical store.
In order to avoid hazards, damaged supply
cord should be replaced by the manufacturer,
its service agent or similarly qualified people.
Built-under installation
This appliance can be installed under a
worktop.
A
WARNING!
Do not operate without the top cover fitted.
Risk of injury.
A
IMPORTANT!
8.3 Fitting a different plug
As the colours of the wires in the mains lead
of this appliance may not correspond with the
coloured markings identifying the terminals on
your plug, proceed as follows:
1 Connect the green - yellow or green (earth)
wire to the terminal in the plug marked ‘E’ or
with the symbol or coloured green and yellow
or green.
2 Connect the blue (neutral) wire to the terminal
in the plug marked ‘N’ or coloured black.
3 Connect the brown (live) wire to the terminal
in the plug marked ‘L’ or coloured red.
With the alternative plugs a 13A fuse must
be fitted either in the plug or adaptor or in the
main fuse box. If in doubt contact a qualified
electrician.
Green and yellow
or green
N
Blue or black
L
Brown or red
8.4 Washer/dryer combination
Do not stack washing machine on top of
the tumble dryer. This would damage both
appliances and guarantees would become
void. It is also unsafe to stack an appliance
on top of another without using a suitable
and approved stacking kit obtained from the
manufacturer of the appliances.
• A special stacking kit is required as an
optional extra please contact customer service.
(4) Weighted average value — L
WA
expressed in dB(A) re 1 pW
(1) Scale from A+++ (most efficient) to D (least efficient)
(2) Energy consumption based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of
the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.
(3) "Cotton cupboard dry programme" used at full and partial load is the standard drying programme to which the information in the
label and the fiche relates, that this programme is suitable for drying normal wet cotton laundry and that it is the most efficient
programme in terms of energy consumption for cotton
: Yes - : No
Supplier name or trademark
Model name
Rated capacity (kg)
Type of Tumble Dryer
Condenser
Air Vented
Energy efficiency class
(1)
Annual Energy Consumption (kWh)
(2)
Type of Control
Energy consumption of the standard cotton programme at full load (kWh)
Energy consumption of the standard cotton programme at partial load (kWh)
Power consumption of the off-mode for the standart cotton programme at full load, P
O
(W)
0,50
Power consumption of the left-on mode for the standart cotton programme at full load, P
L
(W)
1,00
The duration of the left on mode (min)
Standard cotton programme
(3)
Programme time of the standard cotton programme at full load, T
dry
(min)
Programme time of the standard cotton programme at partial load, T
dry1/2
(min)
Weighted programme time of the standard cotton programme at full and partial load (T
t
)
115
Sound power level for the standard cotton programme at full load
(4)
Built-in
PRODUCT FICHE
Complying Commission Delegated Regulation (EU) No 392/2012
8.0
Non-automatic
Automatic
-
-
577,1
2,64
85
67
-
4,84
30
C
155
INDESIT
CYDA81WWGLUK
7185901670
