CS 750 Cart Washer
Engineers of Condence.
Resource responsible, space saving, and workow
efcient. These dene the Belimed CS 750 cart
washer. It’s the only real choice to meet today’s
demand for fast, effective and efcient cart and
container processing in the CSSD.
Workow Efcient
Our high output dual steam heated dryers, tilting oor and high temperature rinse
ensure that drying time is reduced to an absolute minimum. Carts are cleaned
and dried in approximately 8 minutes so the clean side staff can focus on the
instruments instead of hand drying wet carts. The large, bright status indicator,
easily visible from across the room, lets personnel know that the cycle is complete
and ready to be unloaded, further improving productivity. Let your washer/disinfectors
take care of instruments while the CS 750, optimized for washing and drying as
quickly as possible, handles your carts.
Space Saving
Tinted glass pivot doors, compact wash tank and plumbing design increases chamber
volume while reducing the overall footprint. As a result, valuable oor space is left
available for additional needs of the department.
Resource Responsible
A highly efcient tank wash system, coupled with an on-demand rinse water heater,
reduces water use to about 8 gallons per cycle. This unique combination also
eliminates the need to cool drain discharge water, conserving water and reducing
operating costs.
Accessories
Carts for sterilization containers and lids allow you to get more out of your cart
washer and free up the washer/disinfectors for instrument loads. Improved workow,
more efcient.
Container Cart Series
· Stainless steel casters with non-marking 5” diameter neoprene wheels
· Dimensions of cart: 26”W x 49”L x 67”H
· 5 container levels
· Bottom level for lids, with 6 or 12 dividers
· 20 container capacity (7” tall containers)
· Shelves are easily removable for taller containers
CS 750 Cart Washer
Product Guide
Engineers of Condence.
Belimed, Inc.
1.800.451.4118 | 1.843.216.7424
belimed.com
REV2.4.2022_Q0
Parameter CS 750 S CS 750 M CS 750 L
Usable chamber dimensions
H x W x D, in (mm)
78.7” x 39.4” x 53.1”
(2000 x 1000 x 1350)
78.7” x 39.4” x 90.6”
(2000 x 1000 x 2300)
78.7” x 39.4” x 116.1”
(2000 x 1000 x 2950)
Outer dimensions
H x W x D, in (mm)
114.2” x 120” x 88.6”
(2900 x 3050 x 2250)
114.2” x 120” x 126.0”
(2900 x 3050 x 3200)
114.2” x 120” x 151.6”
(2900 x 3050 x 3850)
Pit depth, in (mm) 4.7” (120) 4.7” (120) 4.7” (120)
Tilting oor enables water runoff and
faster cart drying.
