The leg design allows you to push on the
driveline or on the U-Joint cross. Works
either way on virtually all cars, light duty
trucks and farm machinery.
U-Joint Puller
10105
1.800.661.4 661
View demonstration videos and a
complete product list at tigertool.com
Technical Support
Have What It Takes
Operating Instructions
1 Remove all bolt retainers from bearing cups.
2 Slip the U-Joint Puller over the yoke of the driveline.
3 Turn the tools forcing screw clockwise with either an air
or hand wrench. (Note: reverse thread)
Preventative Maintenance
Keep forcing screw clean and lubricated at all times.
Lubricate load bearing surface in glove and under cap.
We recommend SAE 30 lube for the threads and
EP molly grease.
Here at Tiger Tool, your satisfaction is our number one
priority. Should you have any questions about this or any
of our products, please call us at 1.800.661.4661.
•
Stay Alert! Watch what you are doing and use common sense when
operating this tool.
•
Inspect product for damage prior to using; do not use if product is
in unsafe condition.
•
Do not operate tool while under the influence of drugs, alcohol
or medication.
•
Always use safety equipment to prevent injuries. Approved face
and eye protection must always be worn by the operator, as well
as others in the work area.
•
Do not overreach. Keep proper footing and balance at all times.
•
Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving parts.
•
Keep your work area clean and well lit.
CAUTION: DO NOT USE OVER
ӚӍ" IMPACT WRENCH. DOING SO WILL VOID WARRANTY.
Safety Warning
Read all instructions and safety warnings prior to operation. Failure to do so could
result in equipment damage, personal injury or even death.
NOTE: HAMMERING THIS TOOL WILL VOID YOUR WARRANTY.
Find out more about this and other great tools
at www.cal-vantools.com
Parts Breakdown
1.800.661.4 661
View demonstration videos and a
complete product list at tigertool.com
Technical Support
Have What It Takes
U-Joint Puller
10105
1
3
2
Item No.
1
2
3
4
5
Part Number
10105-1
10105-2
10105-5
10105-3
10105-6
Qty.
1
1
1
1
1
Description
Fork
Glove
Forcing Screw
Dome Plug
External Snap Ring
5
4
Find out more about this and other great tools
at www.cal-vantools.com
1
5
4
3
2
905-1
905-2
905-3
905-4
Not Serviced
