1. SAFETY
NOTE! This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack
of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. The Sealey Hand Pressure
Sprayer Model No SCSG09 is safe and only becomes a safety issue when used with toxic fluids. The following safety instructions are
bulletin points and cannot cover every aspect of user safety.
WARNING! Be aware of the safety requirements (C.O.S.H.H.) for the fluids contained in the vessel.
WARNING! Wear safety equipment as advised in (C.O.S.H.H.) statements.
9 Do read and follow all the fluid manufacturers instructions for application and safe use.
9 Store the vessel inside an outbuilding away from foodstuffs and out of reach of children.
WARNING! Label vessel with chemical used, even if water. It is highly recommended that individual vessels should be used for individual
chemicals. Cross contamination can give unexpected results. Also possible spillages are avoided in transferring liquids.
8 DO NOT spray at people, animals, protected insect species, in high winds, at naked flames or sources of heat.
8 DO NOT use the pressure sprayer for any purpose other than for which it is designed.
8 DO NOT use whilst eating, drinking, smoking; under the influence of drugs, alcohol, intoxicating medication, or if fatigued.
8 DO NOT use to spray flammable liquids, solvents etc..
2. INTRODUCTIONi
Robust composite construction with ergonomic pump and handle for the generation of dry and long lasting foam. Quality pump made
from highly resistant materials. Ideal for use in detailing and cleaning. Large 55mm opening for easy relling and reduced spillage.
Translucent tank with level indicators. Safety Valve with depressurization option. Supplied with one foam and one adjustable water
mixer.
3. SPECIFICATION
4. OPERATIONp
4.1. Choose the nozzle (foam or water) required for the job. Screw the nozzle to the
end of the vessel (don’t overtighten).
4.2. Grip the handle and rotate the vessel to separate or grip the handle and rotate
the vessel.
4.3. Avoiding spillages fill to, 2L maximum or required volume.
4.4. Re-attach vessel keeping vertical, rotate until hand tight against neck seal.
Pressurise unit by operating pump plunger until resistance is felt.
4.5. Attach a label with contents indicated.
4.6. Operate the trigger to spray and rotate the nozzle to obtain desired spray mode.
4.7. After use, operate pressure relief valve to depressurise vessel.
5. MAINTENANCE
5.1. Flush externally with water to clean off residuals and store in a dry childproof
area.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
SCSG09 Issue 1 - 17/01/25Original Language Version
© Jack Sealey Limited
Refer to instruction
manual
Wear eye
protection
Wear protective
gloves
Wear a mask
SNOW FOAMING/DETAILING MAINTENANCE
PRESSURE SPRAY 2L
To ll, grip handle & turn vessel
Tighten
Undo
Pressurise
140mm stroke
Operating
Trigger
depressurization relief button
Bespoke
contents
label
CW jet-mist-
o.
ACW on-
mist-jet
Pump plunger
Model No: SCSG09
Model No: SCSG09
Nett Weight: 0.475kg
Total Capacity: 2L
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is unlimited from purchase date, proof of which is required for any claim.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
