Choose your light color
1. Daylight
2. Cool
3. Warm
Set Light Color Dial
HomeGuard LED
Security Floodlight
HGX LED 3RH ALO SWW2 120 PE
1
2
3
1
2
3
Set dial here
for DIM
brightness
Set dial here
for FULL
brightness
Set Brightness Dial
Set Daylight Sensor Dial
Set dial in this position
to allow lights to activate
in daytime.
Set dial in this position
for dusk-to-dawn function
when your surroundings
have any bright lights.
Set dial in this position
for dusk-to-dawn function
lights on at night/when it
is dark outside.
For more detailed
information, reference
HGX Installation Instructions
