en Table of contents
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
1 Safety ........................................................................ 2
2 Hob layout ................................................................ 4
3 Basic operation of the appliance ........................... 5
4 Customer Service .................................................... 7
5 Environmental protection ...................................... 8
6 Troubleshooting ..................................................... 8
7 Access additional information about the
device ....................................................................... 9
Safety 1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product
information safe for future reference or for
the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
The appliance can only be used safely if it is
correctly installed according to the safety in-
structions. The installer is responsible for en-
suring that the appliance works perfectly at its
installation location.
CAUTION‒Risk of injury!
This appliance is for cooking purposes only.
It shall not be used for other purposes, for
example room heating.
Only use this appliance:
¡ To prepare meals and drinks.
¡ Under supervision. Never leave the appli-
ance unattended when cooking for short
periods.
¡ In a private household and in a domestic en-
vironment.
¡ Up to an altitude of 2000m above sea level.
Do not use the appliance:
¡ On boats or in vehicles.
¡ as a room heater.
¡ with an external timer or a remote control.
¡ Outdoors.
Call the after-sales service if you want to con-
vert your appliance to a different type of gas.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of explosion!
Escaping gas may cause an explosion.
WHAT TO DO IF YOU SMELL GAS OR IF
THERE ARE FAULTS IN THE GAS INSTALLA-
TION
Immediately shut off the gas supply or close
the gas cylinder valve.
Immediately extinguish all naked flames and
cigarettes.
Do not operate any light switches or appli-
ance switches.
Do not pull any plugs out of any sockets.
Do not use any telephones or mobile
phones within the building.
Open windows and ventilate the room.
Call the after sales service or the gas sup-
plier.
2
Safety en
Escaping gas may cause an explosion.
Small amounts of gas can collect over a
longer period of time and ignite.
Close the safety valve for the gas supply
when the appliance is out of use for pro-
longed periods.
Escaping gas may cause an explosion.
If the liquefied gas bottle is not upright, lique-
fied propane/butane can enter the appliance.
Intense darting flames may therefore escape
from the burners. Components may become
damaged and start to leak over time so that
gas escapes uncontrollably.
Always use liquefied gas bottles in an up-
right position.
WARNING‒Risk of poisoning!
The use of a gas cooking appliance results in
the production of heat, moisture and products
of combustion in the room in which it is in-
stalled. Ensure that the kitchen is well ventil-
ated especially when the appliance is in use.
Prolonged intensive use of the appliance
may require additional ventilation, for ex-
ample the increasing of mechanical ventila-
tion where present, additional ventilation to
safely remove the products of combustion to
outside (external) air whilst also providing
room air changes with additional ventilation.
Consult a professional before installation of
the additional ventilation.
WARNING‒Risk of fire!
Leaving fat or oil cooking on an unattended
hob can be dangerous and may lead to fires.
Never leave hot oil or fat unattended.
Never attempt to extinguish a fire using wa-
ter; instead, switch off the appliance and
then cover with a lid or a fire blanket.
The appliance becomes very hot.
Never place flammable objects on the cook-
top or in its immediate vicinity.
Never store any objects on the cooktop.
The appliance will become hot.
Do not keep combustible objects or aerosol
cans in drawers directly underneath the hob.
Never store or use combustible materials
(e.g. spray cans or cleaning agents) under
the appliance or in its immediate vicinity.
Hob covers can cause accidents, for example
due to overheating, catching fire or materials
shattering.
Do not use hob covers.
When gas burners are in operation without any
cookware placed on them, they can build up a
lot of heat. The extractor hood above it may
become damaged or catch fire.
Only operate the gas burners with cookware
on them.
The appliance becomes very hot, fabrics and
other objects may ignite.
Keep fabrics (e.g. garments or curtains)
away from the flames.
Never reach over the flames.
Do not place combustible objects (e.g. tea
towels or newspapers) on, next to or behind
the appliance.
Escaping gas may ignite.
If the burner does not ignite after
10seconds, turn the control knob to the
"Off" position and open the door or window
in the room. do not attempt to re-ignite the
burner for at least one minute.
In the event of the burner flames being acci-
dentally extinguished, turn off the burner
control and do not attempt to re-ignite the
burner for at least one minute.
Food may catch fire.
The cooking process must be monitored. A
short process must be monitored continu-
ously.
WARNING‒Risk of burns!
The accessible parts can become hot during
operation.
Small children should be kept away from the
appliance.
Hob guards may cause accidents.
Never use hob guards.
Empty cookware becomes extremely hot when
set on gas burners that are operating.
Never heat up empty cookware.
The appliance becomes hot during operation.
Allow the appliance to cool down before
cleaning.
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be car-
ried out by trained specialist staff.
Only use genuine spare parts when repairing
the appliance.
If the power cord of this appliance is dam-
aged, it must be replaced by the manufac-
turer, the manufacturer's Customer Service
or a similarly qualified person in order to pre-
vent any risk.
If the appliance or the power cord is damaged,
this is dangerous.
Never operate a damaged appliance.
3
en Hob layout
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
If the appliance or the power cord is dam-
aged, immediately unplug the power cord or
switch off the fuse in the fuse box and turn
off the gas supply.
Call customer service.
Page7
An ingress of moisture can cause an electric
shock.
Do not use steam- or high-pressure cleaners
to clean the appliance.
The insulation on cables of electrical appli-
ances may melt if it touches hot parts of the
appliance.
Never bring electrical appliance cables into
contact with hot parts of the appliance.
WARNING‒Risk of injury!
Faults or damage to the appliance and repairs
that have not been carried out correctly are
dangerous.
Never switch on the appliance if there is a
fault with it.
If the appliance is faulty, unplug the mains
plug or switch off the fuse in the fuse box.
Shut off the gas supply and call the after
sales service.
Always have repairs carried out to the appli-
ance and damaged gas lines replaced by
trained, specialist personnel.
Cookware that is not the right size, or that is
damaged or incorrectly positioned may cause
serious injuries.
See the notes on cookware.
When switching on the burner, sparks are gen-
erated in the ignition plugs.
Never touch the ignition plugs while the
burner is being lit.
If a control knob is too stiff to turn or it is
loose, it must no longer be used.
Contact our after-sales service immediately
to have the control knob repaired or re-
placed.
WARNING‒Risk of suffocation!
Children may put packaging material over their
heads or wrap themselves up in it and suffoc-
ate.
Keep packaging material away from chil-
dren.
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
Hob layout2 Hob layout
Individual details, such as colour and shape, may differ from the figure.
Component
Pan support -
Control knob -
Economy burner 1.00 / 1.02kW
Standard-output burner 1.75 / 1.80kW
High-output burner 3.00 / 3.10kW
Mini-wok multi-crown burner 3.30 / 3.40kW
4
Basic operation of the appliance en
PGC6B.K9..
CA B
F E
PGH6B.K9..
A
B
D F
D C
PGP6B.K9..
A
B
D
D
E
C
PGM7B.K9..
A
BC
D
D
EF
PGQ7B.K9..
A
BC
D
D
EF
Basic operation of the appliance3 Basic operation of the appliance
3.1 Burner
You can find an overview of the parts of the burner here.
5
en Basic operation of the appliance
2
1
4
3
Burner cover
Burner cup
Thermocouple for the flame monitoring
Ignition plug
3.2 Pan supports
Insert the pan supports correctly.
Place the cookware correctly on the pan supports.
Never place the cookware directly on the burner.
Always carefully remove the pan supports. When mov-
ing a pan support, the pan supports next to it may also
move.
Tip: You can remove the metal residue that remains
when some items of cookware are moved on the pan
support by cleaning it properly.
3.3 Accessories
You can buy accessories from the after-sales service,
from specialist retailers or online. Only use original ac-
cessories, as these have been specifically designed for
your appliance.
Accessories vary from one appliance to another. When
purchasing accessories, always quote the exact product
number (E no.) of your appliance.
Page8
You can find out which accessories are available for
your appliance in our catalogue, in the online shop or
from our after-sales service.
www.bosch-home.com
3.4 Cookware
This information has been provided to help you save en-
ergy and avoid damaging your cookware.
Use cookware that is a suitable size The table shows
the minimum and maximum base diameters (dia.) re-
commended for each burner.
Burner min. dia. max. dia.
Wok multi-crown burner 22cm 30cm
Mini-wok multi-crown burner 22cm 28cm
High output burner 20cm 26cm
Standard output burner 14cm 22cm
Burner min. dia. max. dia.
Economy burner 12cm 20cm
Use an additional espresso maker grid for cookware
with a diameter of 12cm.
"Accessories", Page6
Only use cookware with a concave base on the multi-
crown burner.
The hob must have a multi-crown burner and addi-
tional wok grid.
The additional wok grid must be correctly inserted.
"Accessories", Page6
3.5 Basic operation
Igniting a gas burner
The hob has automatic ignition of the burners.
1.
Press the control knob for the selected burner and
turn it anti-clockwise to the highest level.
Keep the control knob pressed in.
For all of the burners, sparks are generated and the
flame ignites in the selected burner.
2.
Wait a few seconds and release the control knob.
"Safety system", Page6
3.
Turn the control knob to the required position.
4.
If the burner does not ignite, turn the control knob to
the off position and repeat the steps described
above. This time, hold the control knob down for
longer (up to 10 seconds).
Note
Take the following information into account to ensure
that the appliance works correctly:
The burner parts and the must be inserted correctly.
Do not swap the burner caps around.
The burner holes and grooves must be clean to en-
sure a correct flame.
Igniting a gas burner manually
In the event of a power cut, you can light the burners
manually.
1.
Press the control knob for the selected burner and
turn it anti-clockwise to the highest level.
2.
Hold a lighter or a flame (lighter, match, etc.) against
the burner.
Switching off a burner
Turn the control knob clockwise to .
3.6 Safety system
The safety system (thermocouple) prevents the flow of
gas if the flames accidentally go out. To ignite the
burner, you must activate the system that enables the
gas flow.
1.
Ignite the burner without releasing the control knob.
The flame ignites.
2.
Press and hold the control knob for a further four
seconds.
6
Customer Service en
3.7 Additional information about the
appliance functions
You can find additional information and
explanations online.
Scan the QR code on the title page or
visit the sections on your appliance
and Customer Service at
www.bosch-
home.com
.
3.8 Cleaning and servicing
Cleaning recommendations
Clean all parts of the appliance after each use.
Notes
Read the information on the cleaning agents.
"Cleaning product", Page7
The high temperatures of the multi-crown burner can
cause the stainless steel surface to discolour slightly.
This is normal.
Recommended cleaning
method
Please note
Appliance surface
Clean using a sponge and
soapy water.
Use stainless steel cleaner
regularly for stainless steel
surfaces. Stainless steel
cleaner is available from
customer service.
Wipe up spilled liquids
immediately. This pre-
vents food residues from
burning.
Never remove the control
elements when cleaning
the appliance.
Do not use stainless
steel cleaner in the area
around the control ele-
ments. Stainless steel
cleaners may remove
screen-printed displays.
Pan supports
Cleaning by hand:
Scrub with a non-metal-
lic brush or a non-
scratching scouring
sponge and soapy wa-
ter.
Carefully remove the pan
supports.
Carefully clean the area
around the rubber pads.
If the rubber pads come
loose, the pan support
may scratch the hob.
Cleaning in the dishwasher:
Clean at a temperature
of at least 60°C.
Recommended cleaning
method
Please note
Cleaning in the dish-
washer:
Use cleaning agents re-
commended by the
dishwasher manufac-
turer.
Pre-clean the pan sup-
ports if they are particu-
larly dirty.
As soon as the washing
process is finished, re-
move the pan supports
from the dishwasher
and remove any resid-
ual moisture.
Note: The pan supports
may discolour during use
and cleaning. This discol-
ouration does not affect
their usability.
Burner
Scrub with a non-metallic
brush or a non-scratching
scouring sponge and
soapy water.
Do not clean in the dish-
washer!
Do not mix up the burner
covers.
Gently move the burner
cover back and forth un-
til it locks into the projec-
tions on the burner.
Thermocouples/ignition
plugs
Clean using a small non-
metallic brush.
Clean carefully. Thermo-
couples and ignition
plugs are sensitive.
Do not moisten the ther-
mocouple and the igni-
tion plug. If there is ex-
cessive moisture, the
burner may not light.
Cleaning product
You can obtain suitable cleaning products from after-
sales service or the online shop
www.bosch-home.com
.
ATTENTION
Unsuitable cleaning products may damage the surfaces
of the appliance.
Do not use harsh or abrasive detergents.
Do not use steel wool or scouring sponges.
Do not use a knife or sharp objects to remove dried-
on food remnants from the hob.
Do not use knives or sharp objects to clean the con-
nection between the metal and the glass or alu-
minium plate wit.
Do not use steam-cleaning appliances.
Customer Service4 Customer Service
Function-relevant genuine spare parts according to the
corresponding Ecodesign Directive can be obtained
from Customer Service for a period of at least 10years
from the date on which your appliance was placed on
the market within the European Economic Area.
Furthermore, our Customer Service will continue to
provide you with other function-relevant and storable
genuine spare parts for up to 15years from the date on
which your appliance was placed on the market.
For more information, please contact our Customer Ser-
vice team.
Note: Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information about the warranty period and the
warranty conditions in your country is available via the
QR code on the enclosed document on service con-
tacts and warranty conditions, from our customer ser-
vice or on our website.
You can find the contact details for our customer ser-
vice via the QR code on the enclosed document on ser-
vice contacts and warranty conditions or on our website.
7
en Environmental protection
You can find the information required as per Regula-
tions (EU) 66/2014 and (EU) 2023/826 online at
www.bosch-home.com
on the product and service
pages for your appliance, in the area of user manuals
and additional documents.
4.1 Product number (E-Nr.) and production
number (FD)
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD), which you can find on the appliance's rating plate.
The rating plate can be found:
on the appliance certificate.
on the lower section of the hob.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
Environmental protection5 Environmental protection
5.1 Disposing of packaging
The packaging materials are environmentally compatible
and can be recycled.
Sort the individual components by type and dispose
of them separately.
5.2 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Close the main gas tap.
4.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are avail-
able from your specialist dealer or local authority.
This appliance is labelled in accordance
with European Directive 2012/19/EU
concerning used electrical and elec-
tronic appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the framework
for the return and recycling of used ap-
pliances as applicable throughout the
EU.
Troubleshooting6 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-
sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
If the appliance is defective, call Customer Service.
"Customer Service", Page7
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Cus-
tomer Service or a similarly qualified person in order to prevent any risk.
6.1 Malfunctions
Fault Cause and troubleshooting
The general electrical operation is
impaired.
The circuit breaker is faulty.
Check the circuit breaker in the fuse box.
The circuit breaker or one of the residual-current circuit breakers has been
triggered.
In the fuse box, check whether the circuit breaker or one of the residual-current
circuit breakers has been triggered.
The mains plug of the power cord is not plugged in.
Connect the appliance to the power supply.
8
Access additional information about the device en
Fault Cause and troubleshooting
The general electrical operation is
impaired.
There has been a power cut.
Check whether the lighting in your room or other appliances are working.
Automatic ignition is not working. Food remnants or dirt are located between the ignition plug and the burner.
Clean the space between the ignition plugs and burners.
Burner parts are wet.
Carefully dry the burner parts.
The burner parts are positioned incorrectly.
Correctly position the burner parts.
The appliance is not earthed or has not been connected correctly, or the earth
cable is damaged.
Contact an electrician.
The burner flame is not uniform. The burner parts are positioned incorrectly.
Correctly position the burner parts.
Openings on the burner are soiled.
Clean and dry the openings on the burner.
Burner flames are large or un-
stable.
The gas reaches the appliance at excessive pressure.
1.
Switch off the appliance.
2.
Contact an approved installer and have them check the regulator of the gas
cylinder or liquid gas tank.
Tip: To prevent damage due to excessive pressure, you can install an overpres-
sure safety device that limits or cuts off the gas supply if the regulator of the gas
cylinder or liquid gas tank fails.
The gas does not appear to be
flowing normally or there is no
gas being produced at all.
The gas supply has been shut off by the intermediate valves.
Open the intermediate valves.
There is a smell of gas in the kit-
chen.
The control knob is open.
Close the control knob.
The gas pipe to the appliance is leaking.
1.
Close the main gas tap.
2.
Ventilate the room.
3.
Immediately call an authorised installer, who can inspect the gas system and
issue an installation certificate.
4.
Do not use the appliance until you are sure that gas is not leaking from the in-
stallation or the appliance.
The burner switches off as soon
as you release the control knob.
Control knob not pressed down long enough.
1.
Keep the control knob pressed down for a few seconds after ignition.
2.
Press the control knob down firmly.
Openings on the burner are soiled.
Clean and dry the openings on the burner.
6.2 Normal behaviour during operation
This behaviour is normal for the appliance:
Slight hissing noise from the ignited burner.
Release of odours when using the appliance for the
first time. These odours disappear after a short time.
An orange flame is normal. This is due to dust in the
environment, spilled liquids, etc.
Popping noise a few seconds after the burner is
switched off. This is caused by switching on the
safety system.
"Safety system", Page6
Access additional information about the device7 Access additional information about the device
A digital version of the information for use is available
on the web page, with more detailed information on:
Suitable cookware
Recommended settings for cooking
Cleaning and maintenance
Environmental protection and saving energy
You can find additional information and
explanations online.
Scan the QR code on the title page or
visit the sections on your appliance
and Customer Service at
www.bosch-
home.com
.
9
Many thanks for choosing a Bosch home
appliance!
Register your new appliance now on MyBosch and benefit directly from:
• Expert advice and tips to make the most of your appliance
• Options for warranty extension
• Discounts on spare parts and accessories
• Digital information for use and all appliance data to hand
• Easy access to Bosch Home Appliance Service
Simple to register, free of charge – including on mobile devices:
www.bosch-home.com/welcome
Need some help?
You can find it here.
Expert advice on your Bosch home appliances, help with problems or repairs by professionals from
Bosch.
Discover all the different ways Bosch can assist you:
www.bosch-home.com/service
The contact details of all countries are listed in the attached service directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
*8001314297*
8001314297 (051107) REG25
en
