Deluxe Edition
Storage Box
Fold S1 APEX
Screwdriver
H3, H4, H5, H6
SL3, SL4, SL5, SL6
PH0, PH1, PH2, PH3
TR10, TR15, TR20, TR25, TR30
S1 S2
PZ2
- 01 -
Angle A (unfolded)
Angle Adjustment Button
Press the button and pivot the handle
Start/Stop Button
Press the button to start rotation
- 02 -
Angle B Angle C Angle D
24
°
48
°
72
°
- 03 -
RPM Level
Battery Level
Current Torque
Setting
Screw In/Out
Indicator
- 04 -
High/Low RPM Button
Press to switch rotation speed
Screw In/Out Button
Press to switch rotation direction
- 05 -
LED light
Turns on/off automatically
Quick Change Chunk
Self-locking chunk
Torque Setting Knob
Rotate the knob to change torque
- 06 -
USB-C Charging Port
Supports 5V/2A Input
- 07 -
Specifications Attention
Warranty Info
Product Name
Product Model
Screwdriver Dimension
Torque Control
Max. manual torque
Net Weight(with storage case)
Charging Input
Rated Voltage
Battery Capacity
Rotation Speed(unloaded)
Charging Time
Foldable cordless screwdriver
Fold S1 APEX - Deluxe Edition
275*50.5*48.5mm(10.8*2.0*1.9 inches)
0.5-7.0 N·m
8 N·m
1245g(2.74lb)
5V/2A
3.7V
2500mAh
100RPM(Low) and 250RPM(High)
2-3 hours
Avoid moisture, dust, and drop.
Do not store the product in extreme temperature environments.
Stay alert, watch what you are doing and use common sense when operating. Do
not operate while you are tired or under the influence of drugs, alcohol or
medication.
This product is not a toy and should not be used by kids under 10 years old.
This product has built-in battery, do not throw it into fire and should be recycled by
local laws and regulations.
Do not dismantle the machine by yourself. Have your power tool serviced by a
qualified repair person or contact us for advice.
Your Warranty Includes
12-Month Coverage:
Within 12 months of purchase, we will provide timely and effective online
after-sales service. We will repair or replace any defective product(due to manufac-
turing faut).
How to Return Your Fanttik Product
Contact [email protected] with your order number.
If your purchase was fulfilled by Amazon, please use Amazon’s 30-day return
service.
.
.
.
.
.
.
.
.
.
- 08 -
