Alpicool GE40 Car Fridge Freezer User Manual

USERMANUAL

ModelGE30GE40GE50

Pleasereadthisoperatingmanualcarefullybeforestartingthedevice.

Keepitinasafeplaceforfuturereference.



CONTENTS



SAFETYINSTRUCTIONS



PRODUCTFEATURES

PRODUCTSTRUCTURE

FUNCTIONANDOPERATION

CAREANDMAINTENANCE

WARRANTY

TROUBLESHOOTING

TECHNICALINFORMATION



Page1

Page3

Page5

Page6

Page8

Page7

Page8



CONTENTS

REVERSEDOORDIRECTION

Page4



•Donotoperatetheapplianceifitisvisiblydamaged.

•Donotblockthegapsofthefridgewiththingslikepin,wire,etc.

•Donotexposetheappliancetorainorsoakitinwater.

•Donotplacetheappliancenearnakedﬂamesorotherheatsources(heaters,directsunlight,

gasovensetc.)

•Donotstoreanyexplosivesubstanceslikespraycanswithaﬂammablepropellant.

•Ensurethesupplycordisdryandnottrappedordamaged.Donotlocatemultipleportable

socket-outletsorportablepowersuppliesattherearoftheappliance.

•Checkthevoltagespeciﬁcationonthetypeplatecorrespondstothatoftheenergysupply.

Theapplianceisonlytobeusedwiththepowersupplyunitprovidedwiththeappliance.

•Donotuseelectricalappliancesinsidethefoodstoragecompartmentsoftheappliance,

unlesstheyareofthetyperecommendedbythemanufacturer.

•Onceunpackedandbeforeturningon,theappliancemustbeplacedonalevelsurfacefor

morethan6hours.

•Makesurethattheappliancestayshorizontallywhenitisrunning.Thetiltanglemustbeless

than5°forlongtimerunningandbelessthan45°forshorttimerunning.

•Keeptheventilationopeningsintheunitcasingorinthebuilt-instructurefreeofobstacles.

•Keeptheappliancestableonthegroundorinthecar;Donotdrainupsidedown.

•Whenpositioningtheappliance,ensurethesupplycordisnottrappedordamaged.

•Donotlocatemultipleportablesocket-outletsorportablepowersuppliesattherearofthe

appliance.

•Riskofchildentrapment.Beforeyouthrowawayyouroldrefrigeratororfreezer:

*Takeoﬀthedoors.

*Leavetheshelvesinplacesothatchildrenmaynoteasilyclimbinside.

•Donotusemechanicaldevicesorothermeanstoacceleratethedefrostingprocess,other

thanthoserecommendedbythemanufacturer.

•:Riskofﬁre/ﬂammablematerials.

•Repairsmayonlybecarriedoutbyqualiﬁedpersonnel.Incorrectrepairmaycausedanger.

Thelampandsupplycordmustbereplacedbythemanufacturerorqualiﬁedpersons.

•TheinstallationofDCpowerintheboatmustbehandledbyqualiﬁedelectricians.

•Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshallnotbemade

bychildrenwithoutsupervision.

CAUTION!

WARNING!

1.SAFETYINSTRUCTIONS

•Theappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswith

reducedphysical,sensoryormentalcapabilitiesorlackofexperienceandknowledgeif

they'vebeengivensupervisionorinstructionconcerninguseofthedeviceinasafewayand

understandthehazards.

NOTICE!

•Disconnectthepowersupplybeforeeachcleaningandmaintenanceandaftereveryuse.

•Donotusesharptoolstodefrost;Donotdamagetherefrigerantcircuit.

•Riskofchildentrapment.Beforeyouthrowawayyouroldrefrigeratororfreezer:takeoﬀthe

doors:leavetheshelvesinplacesothatchildrenmaynoteasilyclimbinside.

•Checkifthecoolingcapacityoftheapplianceissuitableforstoringthefoodormedicine.

Foodmayonlybestoredinitsoriginalpackagingorinsuitablecontainers.

-Staﬀkitchenareasinshops,oﬃcesandotherworkingenvironments;

-Camping,Farmhousesandbyclientsinhotels,motelsandotherresidentialenvironments;

-Bedandbreakfasttypeenvironments;

-Cateringandsimilarnon-retailapplications.



•Theapplianceisintendedtobeusedinhouseholdandsimilarapplicationssuchas:

•Iftheapplianceisleftemptyforlongperiods,switchoﬀ,defrost,clean,dry,andleavethe

dooropentopreventmoulddevelopingwithintheappliance.

Pleaseaccordingtolocalregulationsregardingdisposaloftheapplianceforitsﬂammable

refrigerantandblowinggas.

•Toavoidcontaminationofdrink,pleaserespectthefollowinginstructions:

Openingthedoorforlongperiodscancauseasigniﬁcantincreaseofthetemperaturein

thecompartmentsoftheappliance.

-Cleanregularlysurfacesthatcancomeincontactwithdrinkandaccessibledrainage

systems.

-Storerawmeatandﬁshinsuitablecontainersintherefrigerator,sothatitisnotincontact

withordripontootherfood;

-Storerawmeatandﬁshinsuitablecontainersintherefrigerator,sothatitisnotincontact

withordripontootherfood.

-Iftherefrigeratingapplianceisleftemptyforlongperiods,switchoﬀ,defrost,clean,dry,

andleavethedooropentopreventmoulddevelopingwithintheappliance.

2.PRODUCTFEATURES

3.PRODUCTSTRUCTURE

•High-eﬃciencyDCcompressorandconversionmodule.

•CFCfreeand greatheatinsulation.

• DC12/24VorAC100~240V(usingdedicatedadapter)powersupply.

• Fastcoolingto-20°C/-4°F(basedon25°C/77°Froomtemperature).

• Threestagebatteryprotectionsystempreventsvehiclerunoutofbattery.

• Speciﬁcparts:LEDdisplay,interiorLEDlight,built-inhandle,cupholder,interiordrain

plug,measuringscale.

Doorlatch

Sealingstrip

Controlpanel

Built-inhandle

Chargingport

Storageroom

Machinecompartment

Measuringscale

Cupholders

4.REVERSEDOORDIRECTION

Thedooropeningdirectioncanbechangedaccordingtoactualneeds,pleasefollowthe

instructionsbelow:

DoorDisassembly:

Openthedoor

ata30°angle

Takeoﬀthedoor

fromoneside

Takeoﬀthedoor

fromtheotherside

DoorInstallation:

Alignthedoorshaftwiththe

holeononesideandinsertit

Fixthedooron

theotherside,

installationﬁnished

Changethedirectionof

thebox，thedoorbodyand

theboxare30degrees

•Battery ProtectionMode：undertherunningstate,longpressfor3secondsuntilscreen

ﬂashes,thenpresstoselectthreebatteryprotectionmodes H(High),(Medium)andL(Low).

(*FactorysettingisH.)

Fromlefttoright:L/M/H.

8 .8.8

TEMPERATURECONTROL

ON/OFF

LEDDISPLAY

SET

•Display ScreenInitialization：connecttoDC12V/24VorAC100~240Vpowersupply,the

buzzerwillmakealongbeep,andthedisplay willlightupfor1secondthenenterthe

standbymode.

•Cooling Mode：under therunningstate,presstoswitchHH(fastcoolingmode)orECO

(energysaving mode).*FactorysettingisHH.

•PowerON/OFF：presstoswitchON/OFF.

•TemperatureSetting：undertherunningstate,pressorfortemperaturesetting.The

settingwillbesavedafterstopoperatingfor3seconds.Range:-20°C~20°C（-4~68°F）.







*Hshouldbesetwhentheproductisconnectedtocarpower,andMorLshouldbesetwhen

itisconnectedtoaportablebatteryorotherback-upbattery.

22.7V

23.7V

CUTIN

DC24V

CUTIN

10.9V

11.4V

12.4V

INPUT

MODE

25.7V

21.3V

22.3V

24.3V

CUTOUT

8.5V

10.1V

11.1V

DC12V

*Thevoltageistheoreticalvalue,theremaybeadeviationindiﬀerentsceneries.

•TemperatureUnitSetting：switchOFFthefridge,longpressfor3secondsuntildisplays

E1,andswitchtoE5bypressingagain,thenpressortoswitchCelsiusorFahrenheit.

(*Factorysettingis°C.)

Voltagereference:

•Reset：switchOFFthefridge,longpressfor3secondsuntildisplaysE1,underE1mode,

longpressatthesametimeforsecondstoresetthesettings.

5.FUNCTIONANDOPERATION

Drinks

5°C/41°F

Fruits

Vegetable

Delicatessen Wine Icecream

Meat

3~10°C/37~50°F

4°C/39°F

10°C/50°F

-10°C/14°F -18°C/0°F

5~8°C/41~46°F

•Recommendedtemperatureforcommonfood:

6.CAREANDMAINTENANCE

•Switchoﬀandunplugthedeviceﬁrsttoavoidelectricshock.

•Removethecoveranddrainfromtheholeatthebottomofthedevice.

•Usewetclothtocleanthedeviceanddryit.

•Donotsoakthefridgeinwateranddonotwashit directly.

•Donotuseabrasivecleaningagentsduringcleaningasthesecandamagethedevice.

■Cleaning:

Ifthedevicewillnotbeinuseforalongtime,pleasefollowtheinstruction:

•Switchoﬀandunplugthedevice.

•Takeoutallthe itemsstoredinthedevice.

•Wipeoﬀexcesswaterwithasoftrag.

•Putthedeviceinacooland dryplace.

•Leavethelidslightlyopen topreventodorsfromforming.

■Storage:

Humiditycanformfrostintheinteriorofthecoolingdeviceor ontheevaporator.

Thisreducesthecoolingcapacity.Defrostthedevicein goodtimetoavoidthis.

•Switchoﬀandunplugthedeviceﬁrsttoavoidelectricshock.

•Takeoutallthe itemsstoredinthedevice.

•Keepthelidopen.

•Wipeoﬀthedefrostedwater.

■Defrosting:

Neverusehardorpointedtoolstoremoveiceortoloosenobjectswhich

havefrozeninplace.

Issues

Cause/Suggestions

Refrigeratordoes

notwork

•Check if the switch is on.

•Check if the plug and socket are connected well.

•Check if the fuse has been burnt.

•Checkifthepowersupplyismalfunctioned.

•Switchon/oﬀthefridgefrequentlymaycausestartdelayofthecompressor.

Refrigerator

compartments

aretoowarm

•Thedoorisopenedfrequently.

•Alargeamountofwarmorhotfoodwasstoredrecently.

•Therefrigeratorhasbeendisconnectedforalongtime.

Foodisfrozen

Thereis"waterﬂow"

noisefrominsidethe

refrigerator

•Thetemperaturewassettoolow.

•It'sanormalphenomenon,causedbytheﬂowofrefrigerant.

Therearewaterdrops

aroundtherefrigerator

casingordoorgap

•It'sanormalphenomenon,themoisturewillcondenseto

waterwhenittouchesacoldsurfaceoftherefrigerator.

Thecompressoris

slightlynoisywhen

starting

•It'sanormalphenomenon,thenoisewillbereduced

afterthecompressorworksstably.

CodeF1displayed

•Possiblecause:lowvoltagetofridge.

AdjustthebatteryprotectionfromHightoMediumorfromMediumtoLow.

CodeF2displayed

•Possiblecause:condenserfanisoverloaded.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

CodeF3displayed

•Possiblecause:thecompressorstartstoofrequently.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

CodeF4displayed

•Possiblecause:compressornotkickingin.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

CodeF5displayed

•Possiblecause:overheatingofthecompressor&electronics.

Disconnectpowertofridgefor30minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

•Possiblecause:temperaturesensorisfaulty.

Contactmanufacturerforservice.

CodeF6displayed

CodeF7orF8displayed

•Possiblecause:noparametercanbedetectedbythecontroller.

Disconnectpowertofridgefor5minutes&re-start.

Ifthecodeshowsagain,contactmanufacturerforservice.

6.TOUBLESHOOTING

-20~20°C（-4~68°F）

614*365*444mm

243/16*14

3/8*177/16inch

12.2kg/27.1lb

•Contriveddamage.

•Damagecausedbyforcemajeuresuchasearthquake,conﬂagration,etc.

•Damagefrominappropriateuseorviolatingthisinstruction.

•Damageormalfunctioncausedbydisassembling.

DC12/24VorAC100~240V(using dedicatedadapter)powersupply

≤45dB

*Duetoproductimprovement,thetechnicalinformationmightbediﬀerentfromactual

information,pleaserefertotheratinglabelontheproduct.

MODEL

RATEDVOLTAGE

RATEDPOWER

CAPACITY

NOISE

TEMPERATURE

SETTINGRANGE

CLIMATECATEGORY

DIMENSIONS

(L*W*H)

NETWEIGHT

T/ST/N

60W

37.1L/1.31Cu.Ft.

Ifthedevicegetsmalfunctional,thecompressorlimitedwarrantywillbeprovidedfor3 year

fromthedateofpurchase,exceptfollowingsituations:

8.WARRANTY

9.TECHNICALINFORMATION

GE40GE30 GE50

28.7L/1.01Cu.Ft.

45.3L/1.6Cu.Ft.

614*365*374mm

243/16*14

3/8*147/8inch

614*365*514mm

243/16*14

3/8*201/8inch

11.3kg/24.9lb 12.8kg/28.2lb

Alpicool GE40 Car Fridge Freezer

Product's Documents

Alpicool GE40 User Manual

Specifications

Alpicool GE40 Questions and Answers
