EDV60******
EDV70******
EN
User Manual
2Tumble Dryer
2 ENGLISH
CUSTOMER CARE AND SERVICE
Get usage advice, brochures, troubleshooter, service information, buy
accessories & spare parts, online product registration :
www.electrolux.com
Welcome to Electrolux! Thank you for choosing our appliance.
We recommend the use of original spare parts. When contacting Service, ensure
that you have the following data available. The information can be found on the
rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Subject to change without notice.
CONTENT
1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4. USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5. HINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6. TROUBLESHOOTING & ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7. TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
ENGLISH 3
1. SAFETY INFORMATION
Read the instructions.
Failure to follow these safety instructions could damage
the dryer or your clothes.
You may then not be covered by warranty for this
damage.
Only plug this appliance directly into an AC power
supply, which is properly earthed and has the correct
voltage.
1.1 Dryer Safety
The Model Name, Serial Number, Product Number Code
(PNC) and other key information about your appliance
is printed on the Rating plate, which can be found by
opening the appliance door and looking at the top of
the door opening.
CAUTION! If this appliance is supplied from a
cord extension set or electrical portable outlet device,
the cord extension set or electrical portable outlet
device must be positioned such that it is not subject to
splashing or ingress of moisture.
For Safety reasons we strongly advise against the use
of double adaptors, extension cords or power boards.
4 ENGLISH
• This appliance is not intended for use by persons
(including children) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• The children should be supervised to ensure that they
do not play with the appliance.
CAUTION!
• If the electrical cord of this appliance is damaged,
it must be replaced by the Manufacturer, Authorized
Service Agent or similarly qualified person in order to
avoid a hazard.
• These dryers are for drying clothes, towels, and linen
at home. Do not use them for any other purpose.
• Lint must not be allowed to accumulate around the
tumble dryer.
• Do not dry unwashed items in the tumble dryer.
• Pre-treatment sprays and stain remover can damage
plastic components on your machine. If you use pre-
treatment sprays or stain removers, apply them to the
clothing well away from your machine.
1.2 Child Safety
1.3 General Safety
WARNING!
Never stop a tumble dryer before the end of the drying
cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
ENGLISH 5
• Items that have been spotted or soaked with
vegetable oil, cooking oil, suntan oil, linseed oil,
salad oil, lubrication oil or grease. Oil affected items
can ignite spontaneously, especially when exposed
to heat sources such as in a tumble dryer. The items
can become warm which is caused by oxidation
reaction in the oil. Oxidation creates heat. If heat
cannot escape, the items can become hot enough
to ignite. Piling, stacking or storing oil-affected items
can prevent heat from escaping and create a fire
hazard. If it is unavoidable that fabrics that contain
vegetable or cooking oil, or have been contaminated
by hair care products be placed in a tumble dryer,
they should first be washed in hot water with extra
detergent-this will reduce, but not eliminate the
hazard. The final part of tumble dryer cycle occurs
without heat (Cooling cycle) to ensure that the items
are left at the temperature that ensures that the items
will not be damage.
• Items that have previously been cleaned in, washed
in or spotted with petrol/gasoline, industrial chemicals
used only for cleaning, dry-cleaning solvents, or
other flammable or explosive substances are highly
flammable. Highly flammable or explosives commonly
found around the house include acetone (nail
polish remover), denatured alcohol, petrol/gasoline,
kerosene, some spot removers, turpentine, waxes, and
wax removers should not be put in the dryer.
1.4 Fire Hazards
WARNING!
Some fabrics are not suitable for tumble drying. The
following MUST NOT be placed in your dryer due to
the risk of a fire or an explosion.
6 ENGLISH
• Items containing foam rubber (also known as latex
foam), similarly textured rubber, or materials e.g.
shower caps, waterproof textiles, rubber-backed
articles, and clothes or pillows fitted with foam rubber
pads should not be dried in the machine on a heat
setting. Foam rubber materials can produce fire by
spontaneous combustion when heated.
• Rubber-backed articles, clothes fitted with foam
rubber pads, pillows, rubber boots, and rubber-
coated sports shoes.
• Fabric softeners, or similar products, should be used
as specified by the fabric softener instructions.
• Remove all objects from pockets such as lighters and
matches.
For your safety, and to reduce the risk of fire or an
explosion, DO NOT store or use petrol or other
flammable vapours and liquids near your dryer.
ENGLISH 7
A
B
C
D
E
F
G
H
A
Control Panel
B
Drum lifter
C
Lint filter
D
Appliance door
E
Exhaust grille
F
Air inlet duct
G
Back cover
H Outlet cover
2. PRODUCT DESCRIPTION
2.1 Accessories
Wall Mounting Kit
to invert the dryer on a wall upside down.
Control Panel Invert Sticker
8 ENGLISH
WARNING!
Before proceeding with installation,
read the safety information, and
dimension preferred.
Positioning
You can choose to install the dryer on :
1. a stable and levelled floor
2. upside down
3. on a wall
3. INSTALLATION
600 mm
max. 625 mm
max. 850 mm
1040 mm
940 mm
160°
90°
ENGLISH 9
WARNING!
The tumble dryer cannot be placed on
top of a washing machine. For more
information, please contact authorized
dealer.
The exhaust grille has a range of
positions, which allows you to select the
optimum exhaust air angle. Simply hold
the grille and rotate it until it hits the
built-in stop.
Do not install your dryer in a cupboard
or small un-vented laundry unless you
are using a venting kit.
There are 2 venting options;
1. Front
2. Rear-using a venting kit
Venting Kit (Optional Extra)
DVK005K - Through the wall
DVK006 - Universal flexible hose
The exhaust duct must not exceed 2
meters in length at 100 millimetres in
diameter.
If connecting the dryer to a common
ducting system, safety advice should be
requested from the manufacturer.
If you choose to use included kit, the
exhaust grille at the front of the dryer will
need to be replaced with the outlet cover
from the back of the dryer. Gently prise
open the grille, using a thin-bladed tool.
Next, remove the cover from the back
and clip it into the grille space at the
front. The exhaust grille is not required
when using a vent kit.
You can position the vent kit at the back
of the dryer to remove air sideways and
upwards.
wall
Your dryer can be inverted and mounted on the
wall above a washer or tub.
On the floor, Should be installed a minimum
of 30 mm clearance from the wall.
Min. 50 mm clearance
Min. 50 mm clearance
1570 mm
1530 mm
If you want to be purchased the
optional extra, please contact your
local retailer or service centre.
Removable
Exhaust Grille
10 ENGLISH
Important
Your dryer must stand firm and levelled
on the floor to ensure correct
operation. The appliance must not be
installed behind cupboard doors which
restricting the full opening of the dryer
door.
Use a spirit level tool on the top and side
of the dryer to check the levels.
If you have no access to a spirit level
tool, use door frame,
cupboard or bench as a guide to check
that the dryer is
levelled.
Inlet and outlet points need clear airflow
to prevent overheating, so ensure there is
adequate ventilation. (i.e. open window
or external door.)
If a venting kit is used and the exhaust is
discharged out of the room, there must
be adequate ventilation to avoid the
back flow of gases into the room from
appliances burning other fuels, including
open fires, when operating the tumble
dryer. This is not applicable where a
venting hose is directed to an open
window.
The exhaust air must not be discharged
into a flue pipe which is used for
exhausting fumes from appliances
burning gas or other fuels.
Airflow
Airflow
Never place cardboard, wood or
similar materials under the machine to
compensate for any unevenness in the
floor. Install the machine on a flat hard
floor.
Make sure that air circulation around the
machine is not
impeded by carpets, rugs etc.
Check that the machine does not touch
the wall or cupboard units.
ENGLISH 11
Inverted Mounting Mode
If machine is installed up side down
follow instruction below to adjust the
display for correct reading.
1. Machine ON : Press and hold "Dry
Temp" and " Start/Pause" touch key
for 3 seconds to go into Setup Mode.
Please remove the protective film from
the control panel trim using sticky tape
as shown in the image before
attaching the inverted mounting trim.
1
2
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
Inverted Mode enable
Normal Mode
Display will show " ".
2. Press "Dry Temp" touch key 2 times.
Display will show " ".
3. Press " Start/Pause" to on/off
Normal mode or Inverted mode
Display will show
4. Wait 2 seconds. Display will blink
once and tone KeyAccept is played to
indicate that the new setting is saved.
5. Turn the knob "OFF" to exit Setup.
12 ENGLISH
Enable/ Disable Buzzer Sound
To disable or enable buzzer sound.
1. Press and hold "Dry Temp" and "
Start/Pause" touch key for 3 seconds
to go into Setup Mode.
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Dela
y
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Dela
y
Enable Sound mode
Disable sound mode
High
Low
Airing
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
Display will show " ". Pressing "
Start/Pause" or turning the knob at this
point will exit Setup.
2. Press "Dry Temp" touch key once.
Display will show " ".
3. Press " Start/Pause" touch key to
enable/disable buzzer. Display will
show
4. Wait 2 seconds.
Display will blink once and tone
KeyAccept is played to indicate that
the new settings is saved.
5. Turn the knob "OFF" to exit Setup.
ENGLISH 13
A : Programme Selector Knob
4.1 The Control Panel
Hygiene
Refresh
BeddingEco Cottons
Delicates
30 mins.
60 mins.
90 mins.
Extra
Cupboard
Iron
Extra
Cupboard
Iron
High
Low
Airing
Cottons Dry
Mixed Dry
*Press & hold
Dry
Temp
Lock
5s
2s
Delay
Off
A CB
4. USE
• Turn the Programme Selector knob to
choose a drying programme. The table
"Programme Guide" will help you in
selecting the right programme.
The Programme Selector knob is
not a timer. Once you select a dry
programme, the Programme Selector
knob will stay at that position for the
whole dry cycle.
Programme Load
1)
Properties / Fabric type
Time Dry
30 mins.
1-1.5 kg. For Cotton fabric selected drying time for 30 minutes.
60 mins.
3 kg For Cotton fabric selected drying time for 60 minutes.
90 mins.
4 kg For Cotton fabric selected drying time for 90 minutes.
Delicates
3.5 kg
Delicate fabrics such as viscose, rayon, acrylic, and their
blends.
Hygiene
4 kg
Dries and sanitizes your garments and other items maintaining
the temperature above 60°C over time, removing 99.9% of
bacteria and viruses.
2)
Note: This cycle should only be used for wet items. Not suitable
for delicate items.
Refresh
5 pcs.
For fabrics that have been in storage long time, normal
synthetic that need to be damp after.
Bedding Half Evenly dries up to three bedding items at once.
Eco Cottons
3)
Max Efficient, low energy programme for cottons.
Mixed Dry
Iron
Half
Mixed load consisting of cotton and synthetic. For fabrics that
do need to be ironed.
Cupboard
Half
Mixed load consisting of cotton and synthetic. For fabrics that
do not need to be ironed.
Extra
Half Mixed load consisting of cotton and synthetic. For thick fabrics.
Programme Guide
14 ENGLISH
Anti crease can be stopped at any
time by opening the door and removing
the clothes.
Programme Load
1)
Properties / Fabric type
Cottons Dry
Iron
Max Cotton Towel, Jeans For thick fabrics.
Cupboard
Max
Bath towels, Cotton underwear. For fabric that do not need to
be ironed.
Extra
Max Cotton Polo shirt, Cotton T-Shirt,For fabric that do need ironed
Off This position to reset programme/switching off the machine.
B : Display
Drying Cycle In Progress
Cooling Cycle In Progress
Anti Crease Cycle In Progress
The display shows the following
information
Your dryer will automatically switch off
the heater at the end of every cycle.
This is important as it remove residual
heat from clothes and help prevent
creasing.
The anti crease cycle is designed to help
prevent creases forming in the clothes
after normal drying cycle has ended.
The anti crease progress indicator will
start blinking with clean filter during the
time anti crease phase is running. The
drum will rotate for 5 seconds every
minute and will go for 1 hour Anti crease
phase cannot be disabled.
After selecting a programme, the
duration is displayed in hours and
minutes (for example 1:45 which means 1
hour and 45 minutes).
The duration is calculated automatically
on the basis of the maximum
recommended load for each type of
fabric. After the programme has started,
the time remaining is updated every
minute.
1) Maximum capacity depends on the model.
2) Tested for Candida albicans, MS2 Bacteriophage and Escherichia coli in external
test performed by Swissatest Testmaterialien AG in 2024(Test Report No. 20242021).
3) The programme "Eco cottons" (capacity, option .e.g at full load and with High
Temp) is the programme for energy label tested according to AS/NZS 2442.1 and
labelled according to AS/NZS 2442.2
ENGLISH 15
C : Start/Pause Touch key
Setting Drying Temp
End of Programme and Clean Filter
Reminder
The dryer will not start unless the
door is closed. (If door is not closed
you will show " " on display.)
This touch key allows you to start or
pause the dryer to check the contents or
perhaps add more clothes.
This mode gives you the option of
selecting different drying levels.
Press "Dry Temp" touch key to select the
drying temp. Corresponding light for
each temp is shown on display. Drying
temp can only be selected during initial
set up.
• Low
Recommendation for drying heat
sensitive fabrics such as delicates and
synthetics at lower heat for maximum
care of the fabrics.
• Mid
Recommendation for drying most fabrics.
• High
Recommendation for drying thick fabrics.
• Airing
This setting does not heat.
ONLY circulate the air in the dryer to
shake out dust and refresh clothes
When the drying programme is
completed, the display will show text
" ".
The Clean Filter LED turns on and blinks
at the end of each dry cycle to serve as
a reminder to user to clean lint filter at
the end of each load.
High
Low
Airing
*Press & hold
Dry
Temp
Dela
y
Drying Temp
Option Table
Programme
Dry Temp
High Temp
Medium temp
Low temp
Airring
Delay start
Time Dry
30 mins.
60 mins.
90 mins.
Delicates
Hygiene
Refresh
Bedding
Eco Cottons
Mixed Dry
Iron
Cupboard
Extra
Cottons Dry
Iron
Cupboard
Extra
Off
-
16 ENGLISH
To cancel or change Delay time, Switch
off the machine by turning the selector
knob to OFF position to cancel the Delay
Start and then repeat above procedure
to set a new delay time.
Child Lock
Activating Child Lock
To activate Child Lock press and hold
the "Dry Temp" touch key for 5 seconds.
Display will show " " for 2 seconds
then back to cycle duration.
Deactivating Child lock
To deactivate Child Lock press and hold
the "Dry Temp" touch key for 5 seconds.
Display will show " " for 2 seconds
then back to cycle duration.
High
LowAiring
*Press & hold
Dry
Temp
Lock 5s2s
Delay
High
LowAiring
*Press & hold
Dry
Temp
Lock 5s2s
Delay
4.2 Operating Sequence
Step 1
Load your dryer loosely until it is no more
than TWO THIRDS FULL. Clothes must
tumble freely in a dryer. Don’t cram them
in. Wet clothes fluff up when dry.
Overloading will
Reduce efficiency.
Increase drying time.
Increase the risk of creasing.
Do not load clothes or other articles
which are dripping wet or have sand
and grit on them into your dryer.
Delay Start
Clock symbol will start blinking after
Delay Start option is activated.
Delay Start can be set from 30 minutes to
20 hours.
To set Delay Start option.
1. Select a drying programme.
2. Press and hold "Dry Temp" touch key
for 2 seconds until a sound is heard
then release the touch key, display will
show number 30 and clock symbol.
High
LowAiring
*Press & hold
Dry
Temp
Lock 5s2s
Delay
High
LowAiring
Dry
Temp
*Pr
ess & hold
3. Press "Dry Temp" to increment the time
until desired level is reached.
4. Once a desired time is reached press
" Start/Pause" touch key to activate
delay start option.
ENGLISH 17
Step 2
Switch On The dryer will not operate
unless the door is fully pressed in.
Step 3
Turn the Programme Selector knob to
choose drying programme you want.
WARNING!
Never stop a tumble dryer before the
end of the drying cycle unless all items
are quickly removed and spread out so
that the heat is dissipated.
The drum is designed to rotate in both
direction, clockwise and anti-clockwise.
This reduces tangling and movie even
drying in a shorter time.
Step 4
Turn the Programme Selector knob to
"OFF" When you have finished using the
dryer to turn off the power, then switch
off at the power point. It is recommended
to power off the appliance when not in
use.
Step 5
Clean Lint Filter
LINT BUILD-UP IS A FIRE HAZARD
A clean lint filter reduces drying times,
saves energy and avoids overheating.
Overheating may also damage your
clothes.
tripled
doubled
normal
Number of usages with an unclean lint
filter (based on laboratory tests using a
load of new towels)
Drying Time
It is important to clean the lint filter
after every load.
The lint filter is
located at the front
of your dryer at the
button of the door
opening.
Lint Filter
To remove the lint
filter, open the door
and press the two
pads together.
Pull the lint filter out
of the pocket.
Ensure that you hear a "Click" when
putting back the lint filter.
• Never operate your dryer without the
lint filter.
• Do not allow lint to build around your
dryer.
• A torn or damaged lint filter must be
replaced immediately.
• Overloading can increase lint build-up
because the airflow is reduced.
18 ENGLISH
To check the dryness or add clothes
during the cycle, simply open the
door. The dryer will beep several times
indicating the door is open. If further
drying is required, close the door and
then press the "Start/Pause" touch key to
continue.
For the best drying performance, only
add or remove clothes at the beginning
of the drying cycle.
Next time you turn your dryer on it will
be ready to go as it remembers the last
programme, Temperature and Option
setting used. You can change the setting
if you wish.
After every load clean the lint
filter to reduce drying time and avoid
overheating.
Checking the Load
To avoid potential fire hazards, we
recommend that you pay a authorized
service centre. To periodically clean
your dryer, You must do this also when
you change mounting from upright to
inverted, or vice versa.
ENGLISH 19
5. HINTS
• Never tumble dry the following:
Delicate items such as net curtains,
woollen, silk, fabric with metal trim,
nylon tights, bulky materials such as
anoraks, blankets, eiderdown, sleeping
bags, feather quilts and any item
containing rubber foam or materials
similar to foam rubber.
• Do not place in your dryer
undergarments such as bras
and corsets that contain metal
reinforcements. Your dryer may be
damaged if metal parts were to
come loose from the garment. Place
such items in a bag designed for this
purpose.
• Check and empty pockets. Clips, pens,
nails and pins can damage both the
dryer and your clothes. Other items
such as matches or cigarette lighters
will cause a fire.
• Close all press studs, hooks, eyes and
zips that may catch on something
else. Tie all belts and apron strings to
prevent tangling.
• Drying time will depend on fabric
type and construction, load size
and wetness, Save time and money
and always spin the load as dry as
possible in your washing machine.
• Drying time will also be affected by
voltage fluctuations, room temperature
and humidity. Clothes will dry more
slowly on a cool or humid day.
• For best results, sort the load
according to fabric types. Such as
heavy items which may take longer to
dry, eg towels, flannelette sheets etc,
than ones which dry quickly, eg poly/
cotton shirts and sheets.
• Avoid drying dark clothes with light
coloured items such as towels as lint
will show on the dark clothes.
Note: Some fabrics will collect lint
from other clothes and items.
Separate the lint "givers" and the lint
"collectors" to minimise this problem.
Clothes that give lint include towels,
nappies, chenille.
Clothes that collect lint include
corduroy, synthetics and permanent
press garments.
• If individual items are still damp after
drying, please add appropriate Time
Drying programme. This may be
necessary particularly for multilayered
items (e.g. jeans, items with collars or
pocket) or very small loads
• Always clean the lint filter-this will
reduce drying time and save you
money.
• The laundry must be thoroughly spun
before tumble drying.
• Easy-care items eg shirts, should
be briefly pre-spun before drying
(depending on the crease resistance
approximately 30 seconds)
• To avoid static charge when drying is
completed, use either a fabric softener
when you are washing the laundry or
a fabric conditioner specifically for
tumble dryers.
• Remove the laundry when the dryer
has finished drying.
• Do not over-dry laundry, this avoids
creasing and saves energy.
• Clothes or towels containing sand or
grit should be washed first.
• Due to variations in dryer load fabric
texture and thickness it is possible
that not all items will be dried evenly.
It you experience uneven dryness on
Cupboard programme please use
either Extra Dry or Timer Programme
but be mindful of the type of fabric
being dried to avoid overdrying
certain types of fabric. Always follow
drying instructions attached to the
items intended to be dried in a clothes
dryer. To help you, here is a list of the
averageweights of some common
laundry items.
20 ENGLISH
Sheet 700g - 1000g
Tablecloth 400g - 500g
Kitchen towel 70g - 120g
Table napkin 50g - 100g
Towelling hand towel 150g - 250g
Bathrobe 1000g - 1500g
Men’s shirt 200g - 300g
Pillowcase 100g - 200g
Men’s pyjamas 400g - 500g
Ladies nightdress 200g 250g
Bath towel 300g - 400g
Drying Guide
Always check your labels for the drying
symbol which this international Care
Labelling Code now uses.
Fabric label Description
Laundry is suitable for
tumble drying.
Laundry is suitable
for tumble drying at
higher temperatures.
Laundry is suitable for
tumble drying at low
temperatures only.
Laundry is not suitable
for tumble drying.
• Permanent press and synhetics
- take out as soon as the dryer stops
to reduce wrinkles.
• Woollen articles
- not recommended. Pull them to their
original shape, then dry them flat.
• Woven and loop knit materials
- may shrink, by varying amount,
depending on their quality. Do not
use the " Extra Dry" setting for
these fabrics, Always stretch them out
immediately after drying.
• Fibre or leather materials
- always check the manufacturer’s
instructions.
• Baby clothes and night gowns
- acrylic clothing or sleepwear use
only on the " Iron Dry" setting.
• Rubber and plastics
- Do not dry any items made from or
containing rubber or plastics, such
as aprons, bibs, babies’ water proof
napkins, curtains, tablecloths, shower
caps, clothes fitted with foam rubber
pads, pillows, galoshes, or rubber
coated tennis shoes.
• Fibreglass
- not recommended, glass particles
left in the dryer could be picked up by
your clothes the next time you use the
dryer and irritate your skin.
• Fabric softeners or similar products
should not be used in a tumble
dryer to eliminate the effects of
static electricity unless this practise
is specifically recommended by the
manufacturer of the fabric softener or
product.
We strongly advise against the use
of fabric conditioners of the sheet type
that are added to the clothes in the
drum. These products may lead to rapid
blockage of the lint filter and inefficient
operation of your dryer.
ENGLISH 21
Malfunction
Alarm
Code
Possible cause Solution
• Machine does
not start
• The appliance door is open or
not closed correctly.
• Close the door firmly.
• The mains supply is unstable. • Wait until the main supply is
stable then press start.
• Internal fail. No communication
between electronic elements of
the appliance.
• Switch off and switch on again.
6.1 Troubleshooting
Problem Possible causes
The dryer will not start:
• Plug is not firmly in socket, or power not turned on.
• You have blown a fuse. Check the power point with another appliance.
• You have not closed the dryer door or pushed in the door safety switch
touch key.
Your clothes are still
wet/not fully dried
• Load is too small for autosensing programme or load consists of some
multilayered items. Use Time Dry programme to complete drying, refer
Hints in section 4.
• The selected drying time was insufficient. Select a longer time setting.
• Longer time may be needed when the room temperature is 10 ºC or less.
• Check that the lint filter is not blocked.
• Check to see that you have read all the instructions carefully.
• Contact the Service Center if you are still having problems. Write down
the model and serial numbers and the date of purchase before you ring.
The Service Center will need this information.
6. TROUBLESHOOTING & ACCESSORIES
Check the points listed here before you call for help, and make sure that you have
followed the Important safety Instructions on pages 3, 4, 5 and 6.
WARNING!
Deactivate the appliance before you do the checks.
22 ENGLISH
6.2 Accessories
Important
You can buy venting kits (as mentioned
on page 9) from your local appliance
shop or Electrolux Home Products Pty.
Ltd. Parts Distributor.
To operate efficiently the clothes dryer
must have an unrestricted air supply and
exhoust ventilation.
Should you require further instructions in
the use and care of your clothes dryer
please contact the CUSTOMER CENTER
on the phone number listed below:
Australia...1300 363 640 8am to 7pm
EST & 8pm EDST Monday to Friday
NewZealand...(09) 573 2384 8am to 5pm
Monday to Friday
THE COST OF THIS TYPE OF CALL WILL
BE CHARGED TO THE CUSTOMER
Service calls resulting from installation
where ventilation is restricted are not
covered by warranty.
ENGLISH 23
Model Name EDV605H3WC
Dimension (Height x Width x Depth) 795 x 600 x 560 mm
Power Supply (Voltage / Frequency) 220-240 V / 50 Hz
Heater Power (Watt) 2100 W
Maximum Capacity 6 kg
Model Name EDV705H3WC
Dimension (Height x Width x Depth) 795 x 600 x 600 mm
Power Supply (Voltage / Frequency) 220-240 V / 50 Hz
Heater Power (Watt) 2100 W
Maximum Capacity 7 kg
7. TECHNICAL DATA
electrolux.com
G0043809-001-A28646412
