Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installation and keep this manual handy for future reference. If you
have any another query, please contact our dealer or local vendor from whom you have purchased the
product. They are trained and ready to serve you at the best. The warranty is valid for 2 years from the date
of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal wear and
tear. The company gives no warranty against damage to any surface due to incorrect removal and installa-
tion of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24
Hours a day would void the warranty. This product is warranted for manufacturing defects only.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
LED STEP LIGHT
3 IN 1 CCT
INSTRUCTION MANUAL
MODEL
SKU
POWER
INPUT VOLTAGE
USEFUL LUMENS
BEAM ANGLE
LIFE SPAN
ON/OFF CYCLE
CRI
COLOR TEMPERATURE
CUT OUT SIZE
BODY TYPE
DIMENSION
VT-10184
24010
3W
AC:220-240V,50Hz
170 lm [@Sphere 360° ]
55° / 65°
20,000 Hours
>15,000 Times
>80
3000/4200/6400K
75mm
Aluminium + PC
Ø81.5 X 48.5mm
TECHNICAL DATA
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: [email protected]
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
OPTIONAL 4 BEZELS (INCLUDED)
WHITE
Beam Angle:65°
[Already mounted]
BLACK
Beam Angle:65°
WHITE
Beam Angle:55°
BLACK
Beam Angle:55°
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. The light source of this luminaire is not replaceable; when the light source reaches its
end of life the whole luminaire shall be replaced.
4. Must be connected to waterproof terminal box
5. Proper grounding should be ensured throughout installation.
WARNING
PRODUCT STRUCTURE AND SIZE
lamp body
Control board
Silicone rubber
Protective ring
Silicone rubber
Back cover
4*screw European pre embedded box
glass
4*magnet drive
Light board
RC face-plate RB face-plate
INSTALLATION INSTRUCTIONS
INSTALLATION DIAGRAM
OFF
OFF
Method A
WIRING DIAGRAM
WIRING DIAGRAM
Three level color
adjustment switch
N
L
Three level color
adjustment switch
N
L
ON
ON
Method B
1. Turn o the power before starting the installation.
2. For Method A: Connect the power supply and set the desired color temperature.
Insert the lamp into the ceiling opening and secure it using the provided screws.
3. For Method B: First, install the pre-embedded mounting box. Then, connect the
power supply, adjust the color temperature, and screw the lighting fixture onto the
mounting box.
4. Attach the magnetic cover onto the lamp body and verify the installation.
5. Turn on the power and test the lamp.
