EX200
SERIES
To view HOW-TO VIDEOS
scan QR Code located on
top of CarpetXpert Tank.
WITH
3sharkclean.co.uk2 sharkclean.co.uk
CONTENTS
Important Safety Instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
What’s Included � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
Hose Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Cleaning Solution and Tanks � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
Shark Cleaning Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Filling Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
How to Use CarpetXpert with StainStriker � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
Cleaning with CarpetXpert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning with StainStriker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
How to use the Handtool � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
Cleaning the Dirty Water Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning the Brush-Roll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning the Hand Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Unclogging the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning & Drying Guide � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14
Best Practice Floor Nozzle Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Best Practice Stain Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Best Practice for Faster Dry Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Guarantee � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
TECHNICAL SPECIFICATIONS
Voltage: 220 - 240V
Watts: 960W
TIP: You can find
the model and serial
numbers on the QR
code label located on
the back of your unit.
RECORD THIS INFORMATION
Model Number: ������������������������������
Serial Number: �������������������������������
Date Code: ����������������������������������
Date of Purchase (Keep Receipt): ����������������
Store of Purchase: ����������������������������
This marking indicates that this product should not be disposed with other
household wastes. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material sources. To return your used device, please
use the return and collection systems or contact the retailer where this
product was purchased. They can take this product for environmentally
safe recycling.
REGISTER YOUR PURCHASE
TO BENEFIT FROM YOUR PRODUCT'S EXTENDED
GUARANTEE, SIMPLY REGISTER YOUR PURCHASE
AT:
sharkclean.co.uk/register-guarantee
+44 (0)800 862 0453
Scan QR code using mobile device
THANK YOU
for purchasing the Shark® CarpetXpert with StainStriker
PLEASE READ CAREFULLY
AND KEEP FOR FUTURE REFERENCE�
This instruction manual is designed to help you
get a complete understanding of your new Shark
CarpetXpert with StainStriker.
If you have any questions, please call the customer
service line on +44 (0)800 862 0453.
Benefits of registering your product and creating
an account:
• Get easier, faster product support and access to
guarantee information
• Access troubleshooting and product care instructions
• Be among the first to know about exclusive product
promotions
Please note, products purchased directly from Shark
are automatically registered.
5sharkclean.co.uk4 sharkclean.co.uk
SAVE THESE INSTRUCTIONS
QUICK
START
GUIDE
1. If the power cord plug does not fit fully into
the socket, contact a qualified electrician.
DO NOT force into socket or try to modify
to fit.
2. To reduce the risk of shock and unintended
operation, unplug before servicing.
3. This carpet cleaner consists of a motorised
nozzle, main body, pole, handle, hose, and
hand tools. These components contain
electrical connections, electrical wiring, and
moving parts that potentially present risk to
the user.
4. Before each use, carefully inspect all parts
for any damage. If a part is damaged,
discontinue use.
5. Use only identical Shark® replacement parts.
6. DO NOT use the carpet cleaner for any purpose
other than those described in this booklet.
7. DO NOT immerse or spray water on the
body of the carpet cleaner. To clean the
surface, wipe with a dry cloth.
8. Keep the carpet cleaner’s cord out of reach
of children.
9. DO NOT allow the appliance to be used
by children. DO NOT allow to be used as a
toy. Close supervision is necessary when
used near children. Cleaning and user
maintenance must not be done by children.
10. This appliance can be used by persons
with reduced physical, sensory or mental
capabilities or lack of experience or
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved.
11. DO NOT handle plug or carpet cleaner with
wet hands.
12. DO NOT use without the dirty water tank,
clean solution tank, filter, brushroll, and
brushroll cover in place.
13. Only use Shark® branded filters and
accessories.
14. DO NOT put any objects into nozzle
opening. DO NOT use with any opening
blocked; keep free of dust, lint, hair, and
anything that may reduce airflow.
15. DO NOT use if nozzle airflow is restricted.
If the air paths or the motorised floor
nozzle become blocked, turn the carpet
cleaner o. Remove all obstructions before
you turn on the unit again. Keep nozzle
and all carpet cleaner openings away from
hair, face, fingers, uncovered feet, or loose
clothing.
16. DO NOT use if carpet cleaner is not
working as it should, or has been dropped,
damaged, left outdoors, or dropped into
water.
17. Use extra care when cleaning on stairs.
18. DO NOT leave the carpet cleaner
unattended while plugged in.
19. When using on any surface, always keep
the carpet cleaner moving to avoid
damaging the surface (e.g., carpet fibres).
20. DO NOT place carpet cleaner on unstable
surfaces such as chairs or tables. The
surrounding area may be slippery and
present a risk of injury.
21. DO NOT use to pick up:
a) Large objects.
b) Hard or sharp objects (glass, nails,
screws, or coins).
c) Large quantities of dust (e.g., drywall
dust).
d) Smoking or burning objects (hot coals,
cigarette butts, or matches).
e) Flammable or combustible materials
(lighter fluid, petrol, or kerosene).
f) Toxic materials (chlorine bleach,
ammonia, or drain cleaner).
22. DO NOT use in the following areas:
a) Poorly lit areas.
b) Outdoor areas.
c) Spaces that are enclosed and may
contain explosive or toxic fumes or
vapours (lighter fluid, petrol, kerosene,
paint, paint thinners, mothproofing
substances, or flammable dust).
23. The plug must be removed from the
socket-outlet before any adjustment,
cleaning or maintenance of the appliance.
24. During cleaning or routine maintenance,
DO NOT cut anything other than hair,
fibres, or string wrapped around the
brushroll.
25. DO NOT modify or attempt to repair the
carpet cleaner yourself. DO NOT use the
carpet cleaner if it has been modified or
damaged.
26. Turn o all controls before unplugging.
27. To reduce the risk of fire or electric shock
due to internal component damage, use
only Shark® cleaning solution. See the
Cleaning Fluid section of this Instruction
Booklet.
28. DO NOT pull or carry by cord, use cord as
a handle, close a door on cord, or pull cord
around sharp edges or corners. DO NOT
run appliance over cord. Keep cord away
from heated surfaces.
29. DO NOT unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
30. Use indoors only.
31. DO NOT use carpet cleaner on hard floors
or wool as it may damage your floor. To
avoid damage to flooring and to avoid
potential slip hazard, after use: (a) move
to a hard sealed surface (avoid unsealed,
wood and laminate) and (b) place unit on
absorbent material like a towel to soak up
any liquid.
32. DO NOT fill solution tanks while installed
on the appliance. Remove before filling.
33. DO NOT use vinegar in any tanks.
34. The areas around where you are cleaning
may become wet, use care to avoid
slipping and falling.
35. Use care when removing and reattaching
the hand tool to the crevice tool to avoid
accidental activation of the cleaning
solution. DO NOT spray solution on your
skin or in your eyes.
36. Improper connection of the equipment
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician or service person if you are in
doubt as to whether the socket is properly
grounded. DO NOT modify the plug
provided with the appliance. If the plug
will not fit the socket, have a proper socket
installed by a qualified electrician.
37. This appliance is for use on a nominal V
circuit and has a grounding attachment
plug that looks like the plug illustrated
below. Make sure that the appliance is
connected to a socket having the same
configuration as the plug. No adaptor
should be used with this appliance.
38. DO NOT immerse. To reduce risk of electric
shock, use only on carpet moistened by
cleaning.
39. DO NOT run over edges of area rugs.
40. Stalling the brush roll may result in
premature belt failure.
41. Avoid repeated strokes over the same
area, to help prevent damage to Berber/
Loop Pile carpets.
42. Check manufacturer’s tag prior to cleaning
area rugs for any specific cleaning
guidelines. We DO NOT recommend deep
cleaning delicate rugs (including silk,
antique, or area rugs that DO NOT have a
manufacturer’s tag).
43. DO NOT store unit where temperatures
reach freezing levels to avoid damaging
internal parts.
44. FIRST AID Keep out of reach of children.
Causes skin and serious eye irritation. IF
IN EYES, rinse continuously with water for
minutes. Remove contact lenses if present
and easy to do so. Continue rinsing. IF ON
SKIN, wash with soap and water. If skin
and eye irritation persists, seek medical
attention. Please recycle container. Dispose
of contents/container with a licensed
waste disposal site in accordance with the
requirements of the local waste disposal
authority. DO NOT dispose in drains or
watercourses in concentrate form.
WARNING
REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, INJURY,
OR PROPERTY DAMAGE:
IMPORTANT SAFETY INSTRUCTIONS
FOR HOUSEHOLD USE ONLY • PLEASE READ ALL INSTRUCTIONS
BEFORE USING THIS CARPET EXTRACTOR.
To reduce the risk of shock and unintended operation, turn o power before servicing. If the
supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
7sharkclean.co.uk6 sharkclean.co.uk
WHAT’S INCLUDED ASSE MB LY
J
J
H
B
A
What’s Included: Shark® CarpetXpert, 355ml. Shark Deep Clean Pro Solution, 473ml.
Shark OXY Multiplier, Hose-Cleaning Tool, Hand Tool(s)
A
Mode Button
B
Power Button
C
CarpetXpert Tank
D
StainStriker Tank
E
Dirty Water Tank
F
Brushroll Cover/Door
G
Selector Lever (Hand Tool or Brushroll)
H
Tough Hand Tool
I
Spray Outlet
J
Suction Inlet
K
Reversible Bristles (2 sizes)
L
Crevice Tool
M
Hand Tool Trigger
N
Release Button
O
Hose-Cleaning Tool
P
355ml. Deep Clean Pro Formula
Q
473ml. OXY Multiplier Formula
L
K
M
N
O
P Q
Shark Wide tough stain tool and Shark Pet Stain
Trapping Tool included with select models, and
available for purchase at www.sharkclean.co.uk
J
I
2
1
C
D
E
F
G
1. Insert pole into the top of unit until it clicks into place (fig. 1).
2. Store the hose-cleaning tool by clipping it onto the pole (fig. 2).
3. Attach chosen hand tool to crevice tool (fig. 3).
4. Be sure the rubber seal is seated in place under the dirty water tank (fig. 4).
5. Install the dirty water tank by placing the bottom on the nozzle lip then tilting it
forward until it clicks into place (fig. 5).
fig. 1 fig. 2 fig. 3
fig. 5fig. 4
Tip: Store your hand tool on this mount when not in use.
9sharkclean.co.uk8 sharkclean.co.uk
TIP: Wrap hose tightly,
leaving no slack
HOSE ASSEMBLY SHARK® CLEANING SOLUTIONS AND TANKS
6
Align the grooves in the hand
tool with the grooves in the
holder, then slide the tool
down to attach.
5
Loop hose tightly under the
bottom tab.
4
Press hose into second clip.
1
Insert hose tightly into back
of unit until it clicks twice to
avoid leaks.
2
Loop hose tightly into hose
holder opening.
3
Press hose into first clip.
Use ONLY Shark branded cleaning
solutions. Taking care to use the
CarpetXpert/StainStriker formulas
in the correct tanks. Unit is not
compatible with other solutions
or cleaners.
Filling the CarpetXpert Tank (top clear tank)
1. Lift the CarpetXpert Tank by the handle to detach it,
then remove the cap.
2. Add warm water to the tank up to the WATER fill line.
Do not use water hotter than 60°C (140°F).
3. Add Shark Deep Clean Pro up to the CONCENTRATE
fill line.
4. Reattach cap, then reinstall the CarpetXpert Tank,
hearing a ‘click’ once installed properly.
Filling the StainStriker Tank (smaller, cyan tank)
1. Lift the StainStriker Tank by its sides to detach it,
then remove the cap.
2. Add Shark OXY Multiplier up to the MAX FILL line.
3. Reattach cap, then reinstall the StainStriker tank,
hearing a ‘click’ once installed properly.
To order refills of
Shark® Deep Clean Pro and
Shark® OXY Multiplier
scan the QR code.
2
1
SHARK CLEANING SOLUTIONS
FILLING THE TANKS
Shark Deep Clean Pro
For deep-cleaning carpets
with the brushroll
Shark OXY Multiplier
For stain cleaning with the
hand tool, combines with
Deep Clean Pro to help
eliminate tough stains.
11sharkclean.co.uk10 sharkclean.co.uk
CLEANING WITH CARPETXPERT
DEEP CLEANING with the brushroll:
Uses Deep Clean Pro cleaning solution and water
Important: Vacuum with traditional vacuum cleaner first.
1.
Move the selector lever to UP position to engage the floor nozzle.
2.
Gently step on the base and tilt the handle back.
3.
Press power button; unit will enter ‘Deep Clean’ Mode.
4.
Move unit forward slowly; it will automatically dispense water
and Deep Clean Pro cleaning solution.
5.
On the backpass, the unit will use suction to extract liquid
and aid the drying process.
6.
Repeat steps 4 and 5.
7.
Once deep clean is complete, press the Mode button, to activate Dry Only mode.
Repeat passes over the entire cleaning area multiple times to help to reduce dry time.
STAIN CLEANING with the hand tool:
Uses Deep Clean Pro Cleaning Solution + OXY Multiplier
1.
With the unit in upright position, move the selector lever
DOWN until it clicks into place.
2.
Add the desired tool to the crevice tool.
3.
To clean wet messes with the hand tool, first use suction
only to remove liquid.
4.
Then, spray stained area, scrub using bristles, then use
suction until mess is clean and water is extracted.
5.
If your model comes with the Shark® Pet stain trapping tool, use it to
extract liquid messes until the cup is full, then remove the cup and
discard the mess.
Note: Dry time can be impacted by carpet type, climate and cleaning conditions. Dry
time will vary.
Dry Time Tip: Avoid over-cleaning carpet to ensure faster dry times. See Page 14 for
more information on best practice for quicker dry times.
Tip: You may need to repeat cleaning to remove difficult stains.
HANDTOOL USAGE
PET STAIN TRAPPING TOOL
Tip: Avoid over saturating the area, or continual spraying during cleaning.
Tip: Always ensure to use the correct solution dilution measures when setting up the unit for cleaning.
Tip: Choosing the bristles - The rubber bristles are best suited for more delicate surfaces and
upholstery. The tough bristles are ideal for stubborn agitation on hard wearing surfaces.
For best results on wet and dry stains follow the below steps.
Before beginning, turn the unit on.
Spray the stained area using the trigger
on the underside of the handtool. For
older stains, leave to settle.
SPRAY
For wet messes, scrub the stain area
first and then suction up the excess
liquid.
SUCTION
SUCTION
Tilt the handtool forward and drag
it across the stain to extract. Repeat
steps if needed.
Wet
stains
Dry
stains
Scrub the stain with the bristles,
agitating in multiple directions.
SCRUB
The Shark Pet Stain Trapping Tool is included with select models. This extracts unhygienic messes, preventing
the mess from reaching the hose and the interior of the unit. DO NOT use the tool to remove pet hair. To use,
spray the wet mess, then extract it as advised above. To avoid oversaturating, do not over spray. DO NOT exceed
the MAX FILL line on the Pet Tool Cup.
Keep the tool level, without tipping to prevent the mess from reaching the hose. After use, turn off the power of
the main unit and empty the tool cup where appropriate. Wash the cup, filter, and the rest of the tool thoroughly
with soap and water after each use.
fig. 1
fig. 2
Filter
13sharkclean.co.uk12 sharkclean.co.uk
MAINTENANCE MAINTENANCE
DIRTY WATER TANK
Note: You will hear a change in motor noise/air flow when the dirty water tank is full.
1. Press the release button and remove the tank.
2. Remove the lid - do not try to pour out the contents till this is removed.
3. Discard contents in preferred location e.g. drain and clean the tank with soap (e.g. hand
soap, washing up liquid) and water.
4. Remove the filter. Wash the filter by hand with soap and water, rinsing of all suds, then allow
it to air-dry completely before reinstalling.
BRUSHROLL
1. Pull the latch to remove outer cover.
2. Lift the inner cover from the top to open, labelled ‘PULL’.
3. Remove the brushroll by pulling up on the side tab. If hair is wrapped, cut it away by running
scissors along the groove in the brushroll. Rinse brushroll, cover, and doors and allow them
to air-dry before reinstalling.
4. To reinstall the outer cover, connect the 2 hooks at the bottom, then push forward until it
clicks into place.
HAND TOOLS
Press the release button to detach tool. Pull tab to remove window
and bristle strip. Wash tools with soap and water and allow them to
air-dry before reinstalling.
HOSE
Attach the hose-cleaning tool to the end of the crevice tool and turn
on power. Pull the trigger and the cleaning solution will be sucked
into the hose to clean the interior.
1
2
3
4
1 32 4
1. Unplug unit.
2. Remove dirty water tank.
3. Remove seal (fig. 7).
4. Detach the hose by squeezing the fitment
clips on the hose attachment. (fig. 8).
5. Remove the selector lever by pushing it
all the way forward (fig. 9), then pulling
it out sideways (fig. 10).
6. Remove any debris.
7. Reattach parts.
fig. 7 fig. 8 fig. 9 fig. 10
CHECKING FOR DEBRIS
To check airpath for clogs, hair, or debris:
INDICATOR LIGHTS
MODES
Solid blue on the left
AUTO CLEAN MODE
Solid blue on the right
DRY ONLY MODE
Solid green on both sides
HAND TOOL ACTIVATED
NOTIFICATIONS
Solid red: BRUSHROLL JAM
Fix: Remove obstruction, then reinstall brushroll
Flashing blue: DIRTY TANK FULL
Fix: Empty the tank, then reinstall it
Flashing red: BRUSHROLL COVER OPEN
Fix: Close cover
Flashing green: SELECTOR LEVER ERROR
Fix: Move lever to the correct position
float
filter
Note: When turning o the power, it will take 2 to 3 seconds for the unit to clear the lines and
power down completely.
Tip: Clean unit after every use to avoid odours and mould.
15sharkclean.co.uk14 sharkclean.co.uk
FIVE (5) YEAR LIMITED GUARANTEE
When a consumer buys a product in the UK, they get the benefit of legal rights relating to the quality of the
product (your “legal rights”). You can enforce your legal rights against your retailer, including Shark if you bought
your Shark appliance from sharkclean.co.uk. However, at Shark we are so confident about the quality of our
products that we give the owner an additional, free parts and labour manufacturer’s guarantee of up to 5 years.
A household appliance like a Shark floorcare appliance constitutes a sizeable investment. Your new machine
needs to work properly for as long as possible. The guarantee it comes with is an important consideration - and
reflects how much confidence the manufacturer has in its product and manufacturing quality.
The manufacturer’s guarantee does not aect your legal rights.
How long are new Shark machines guaranteed for?
Our manufacturer’s guarantee lasts for one year from the date of purchase as standard, or for five years if you
register your purchase with us within 28 days. There is information on how to register below.
How do I register my Shark guarantee?
If you have purchased your Shark appliance directly from sharkclean.co.uk your guarantee is registered
automatically. If you bought it from anywhere else, you can register your guarantee online within 28 days
of purchase.
• To register online, please visit www.sharkclean.co.uk/register-guarantee or scan the QR code in your instruction
manual.
• Keep a note of the date you purchased the machine.
IMPORTANT:
• Keep your receipt if you bought your Shark floorcare appliance from anywhere except sharkclean.co.uk.
You will need it to claim under your guarantee.
• The free Shark guarantee only applies to Shark owners living permanently in the UK.
What are the benefits of registering my free Shark guarantee?
When you register your guarantee, you will get an extra four years of cover. We’ll also have your details to hand
if we ever need to get in touch. If you further agree to receive communications from us, you can also receive tips
and advice on how to get the best out of your Shark floorcare appliance and hear the latest news about new
Shark technology and launches.
What is covered by the free Shark guarantee?
Repair or replacement (at Shark’s option) of your Shark machine, including all parts and labour.
What is not covered by the free Shark guarantee?
• Normal wear and tear.
• Accidental damage or faults caused by negligent use or care, misuse, neglect, careless operation, or handling of
the Shark appliance which is not in accordance with the Shark Operating Manual supplied with your machine.
• Damage caused by use of the Shark appliance for anything other than normal domestic household purposes.
• Damage caused by use of parts not assembled or installed in accordance with the operating instructions.
• Damage caused by use of parts and accessories which are not Shark Genuine Components
• Faulty installation (except where installed by Shark).
• Repairs or alterations carried out by parties other than Shark or its agents.
How can I claim under the free Shark guarantee?
Contact our customer service helpline on 0800 862 0453. For service hours please visit our website under
‘Contact Us’. It’s free to call, and you’ll be put straight through to a Shark representative. You’ll also find online
support at https://support.sharkclean.co.uk. The Shark representative will go through some troubleshooting with
you, and if we conclude that the item has failed, we will send you a replacement part or a returns label to send the
defective item back to us free of charge. When you have delivered the defective product to us, we will send you a
replacement.
Please remember that the item will need to be boxed when you return it to us, which can be any suitable box; it
does not have to be the original packaging.
Where can I buy genuine Shark spares and accessories?
Shark spares and accessories are developed by the same engineers who developed your Shark floorcare
appliance. You’ll find a full range of Shark spares, replacement parts and accessories for all Shark machines at
www. sharkclean.co.uk. Please remember that damage caused by the use of non-Shark spares may not be
covered under your guarantee.
BEST PRACTICE FOR DRYING
To speed up dry time, follow the below best practice steps.
When moving the nozzle
follow a uniform pattern,
moving back and forth at a
slow controlled pace.
When extracting the liquid,
pass over the cleaning
area in a uniform pattern,
applying downward pressure
throughout.
Moving forward dispenses
cleaning fluid, moving back
extracts the fluid. Try to do a
back pass, for each forward
one.
Angle the hand tool to
engage the suction vents
parallel to the cleaning
surface for optimum suction.
Once satisfied with the clean,
press the mode button to
enter Dry Only mode – and
go back over the entire area.
In this mode no fluid will be
dispensed.
Continue to pass over the
cleaning area until liquid is
no longer extracting through
the hand tool window.
For more information,
scan QR code to view
HOW TO VIDEOS
FLOOR NOZZLE
HAND TOOL
Note: Drying time will take a few hours (cleaning conditions dependent). It’s recommended once
deep clean is completed, press the mode button to activate ‘Dry only’ mode and continue to
extract excess liquid from carpets. This will help to reduce dry time.
Tip: Avoid over-cleaning the same spot in deep clean mode to prevent saturating the carpet leading
to longer drying time.
EX200UK_IB_MP_230609_MV2
PRINTED IN CHINA
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE�
This Instruction Booklet is designed to help you get a complete understanding of your new
Shark® carpet cleaner.
Illustrations may dier from actual product. We are constantly striving to improve our products;
therefore the specifications contained herein are subject to change without notice.
© 2023 SharkNinja Operating LLC. SHARK is a registered trademark in the United Kingdom of
SharkNinja Operating LLC.
CARPETXPERT is an unregistered trademark in the United Kingdom of SharkNinja Ltd Operating LLC.
STAINSTRIKER is a pending trademark application in the United Kingdom of SharkNinja Operating LLC.
SharkNinja Europe Limited,
3150 Century Way, Thorpe Park,
Leeds, LS15 8ZB, UK
+44 (0)800 862 0453
www�sharkclean�co�uk
SharkNinja Germany GmbH,
Rotfeder-Ring 9,
60327 Frankfurt am Main, Germany
www�sharkclean�eu
